TRENDnet TE100-S50g User manual

The compact 5-Port 10/100Mbps GREENnet Switch (model TE100-S50g)
provides improved bandwidth performance, ease of use and reliability, all while
reducing power consumption by up to 40%*.
GREENnet technology automatically adjusts power voltage as needed, resulting
in substantial energy savings. Embedded GREENnet technology works right out
of the box with no management requirement.
Boost your office efficiency and reduce network congestion with a total switching
capacity of 1Gbps with Full-Duplex Mode. Plug and Play this sturdy metal switch
for reliable high-speed network connectivity.
TE100-S50g (V1.0R)
5-Port 10/100Mbps GREENnet Switch
TE100-S50g
rev: 06.30.2010
• 5 x 10/100Mbps Auto-Negotiation, Auto-MDIX Ethernet ports
• GREENnet technology reduces power consumption when:
a. Ethernet port is not in use
b. Connected device is turned off
c. Connected device is in power-saving mode
d. Based on Ethernet cable length
• Compliant with IEEE 802.3/IEEE 802.3u standards
• 1Gbps switching fabric
• Store-and-Forward switching architecture with non-blocking wire-speed performance
• IEEE 802.3x flow control support
• Provides 1k MAC address entries
• Compliant with Windows, Linux, and Mac Operating Systems
• Sturdy metal housing
• Diagnostic LEDs
• Plug & Play installation
• 3-Year Limited Warranty
FEATURES
switches

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
TE100-S50g (V1.0R)
5-Port 10/100Mbps GREENnet Switch
TE100-S50g
60m
Full Power
60m
Delivers less power
to unused ports
1
100m
100m
on on
less power
20m
Regular
Switch
GREENnet
Switch
20m
Delivers less power
when devices are off
Delivers less power
with shorter
cable lengths
2
3
on on
off less power
*Max power savings compared with standard TRENDnet
switches.
Network Media
Power Adapter
Data Rate
Protocol / Topology
Power Consumption
Switch Fabric
Interface
Data RAM Buffer
Dimensions
Weights
Humidity
Temperature
Certifications
• IEEE 802.3 10Base-T
• Ethernet: UTP/STP Cat. 3, 4, 5 up to 100m
• 1K entries
• 7.5V DC, 1A external power adapter
• Operating: 0° ~ 40° C (32° ~ 104° F)
• CE, FCC
• CSMA/CD, Star
• 2.1W (max.)
• 384Kbits
• 116 x 25 x 70mm (4.57 x 0.98 x 2.76 in.)
• Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)
• Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)
• Operating: 10%~90% (non-condensing)
• 225g (7.8 oz)
• 1Gbps forwarding capacity
• 5 x 10/100Mbps Auto-MDIX RJ-45 ports
• Power, Link/ACT, 100Mbps
Filtering Table
Diagnostic LED
Standards
Hardware
SPECIFICATIONS
• Fast Ethernet: UTP/STP Cat. 5, 5e, 6 up to 100m
• IEEE 802.3u 100Base-TX
• IEEE 802.3x Flow Control
• Storage: -10° ~ 70° C (14° ~ 158° F)
• Storage: 5%~90% (non-condensing)
*Max power savings compared with standard TRENDnet switches.
RELATED PRODUCTS
PACKAGE CONTENTS
TE100-PCBUSR
TEG-S50g
TE100-PCIWN 10/100Mbps PCI Adapter
• Power adapter (7.5V DC, 1A)
10/100Mbps PC Card
• TE100-S50g
5-Port Gigabit GREENnet Switch
• Multi-Language Quick Installation Guide
