Sime MURELLE HE 70 R ErP User manual

INSTALLER INSTRUCTIONS
CONTENTS
1 DESCRIPTION OF THE BOILER.......................................................................................................... pag. 72
2 INSTALLATION................................................................................................................................... pag. 75
3 CHARACTERISTICS............................................................................................................................ pag. 87
4 USE AND MAINTENANCE .................................................................................................................. pag. 95
IMPORTANT
When carrying out commissioning of the boiler, you are highly recommended to perform the following
checks:
–
Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
– Make sure that the electrical connections have been made correctly and that the earth wire is con-
nected to a good earthing system.
– Open the gas tap and check the soundness of the connections, including that of the burner.
– Make sure that the boiler is set for operation for the type of gas supplied.
– Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has
been properly installed.
– Make sure that any shutoff valves are open.
– Make sure that the system is charged with water and is thoroughly vented.
– Check that the circulating pump is not locked.
– Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve
on the gas valve inlet.
–
The installer must provide the user with instruction in operation of the boiler and safety devices and
hand over the instruction booklet to the user.
MURELLE HE 70 R ErP - ENGLISH
CONFORMITY
Our Company declares that MURELLE HE 70 R ErP boilers comply with the essential requirements of the
following directives:
- Boiler Efficiency Directive 92/42/EEC
- Gas Appliances Directive 2009/142/EC
- Electromagnetic Compatibility Directive 2014/30/UE
- Low Voltage Directive 2014/35/UE
- Ecodesign Directive 2009/125/EC
- Regulation (EU) N. 813/2013 - 811/2013

72
1.1 INTRODUCTION
MURELLE HE 70 R ErP are premixed
gas condensation for heating only with
wide range of power modulation (from
20% to 100% of power) designed for sin-
gle installation and in modular systems
with several generators connected in se-
quence/cascade and independent from
each other. For optimum installation and
operation, always follow the instructions
provided in this manual.
1 DESCRIPTION OF THE BOILER
120 161
149
CS CA
450
214
95
130
82
490
145
385
700 113
249
128
178
268
15
721
M
R3
R
S3
G
C
Fig. 1
1.2 DIMENSIONS (fig. 1)
FIXTURES
R C.H. return G 1” (UNI - ISO 228/1)
M C.H. flow G 1” (UNI - ISO 228/1)
G Gas connection G 3/4” (UNI - ISO 228/1)
R3 D.H.W. tank return G 1” (UNI - ISO 228/1)
C Filling system G 1/2” (UNI - ISO 228/1)
S3 Condensation outlet ø 25
CA Inlet ø 80
CS Outlet ø 80

MURELLE HE 70 R ErP
Heat output
Nominal (80-60°C) (Pn max) kW 63.4
Nominal (50-30°C) (Pn max) kW 69.4
Reduced (80-60°C) (Pn min) kW 13.6
Reduced (50-30°C) (Pn min) kW 15.3
Heat input (*)
Nominal (Qn max - Qnw max) kW 65.0
Reduced /Qn min - Qnw min) kW 14.0
Min/max useful yield (80-60°C) % 97.0 / 97.5
Min/max useful yield (50-30°C) % 109.1 / 106.7
Useful yield at 30% of the load (40-30°C) % 108.3
Losses after shutdown to 50°C (EN 15502) W 86
Supply voltage V-Hz 230-50
Adsorbed power consumption (Qn max - Qn min) W 187 - 116
Electrical protection grade IP X4D
Energy efficiency
Seasonal energy efficiency class of the heating system A
Seasonal energy efficiency of the heating system % 92
Sound power of the heating system dB (A) 69
C.H. setting range °C 20/80
Water content boiler l 3.5
Maximum water head (PMS) bar (kPa) 3.5 (343)
Maximum temperature (T max) °C 85
Capacity of the heating expansion vessel l --
Pressure of the heating expansion vessel bar (kPa) --
Exhaust fumes temperature at max flow rate (80-60°C) °C 87
Exhaust fumes temperature at min. flow rate (80-60°C) °C 74
Exhaust fumes temperature at max flow rate (50-30°C) °C 55
Exhaust fumes temperature at min. flow rate (50-30°C) °C 48
Smokes flow min/max g/s 4.4 / 22.2
CO
2 at max/min flow rate (G20) % 9.0 / 9.0
CO
2 at max/min flow rate (G31) % 10.0 / 10.2
NOx measured (EN 15502-1:2015) mg/kWh 26.5
PIN number 1312CS6213
Category II2H3P
Type B23-B53-B23P-53P-C13-C33-C43-C53-C83
NOx emission class (EN 15502-1:2015) 6 (‹ 56 mg/kWh)
Weight when empty kg 39
Main burner nozzle
Quantity nozzles n° --
G20 nozzle diameter ø mm --
G31 nozzle diameter ø mm --
Consumption at maximum/minimum flow rate
Maximum (G20) m
3
/h 6.78
Minimum (G20) m
3
/h 1.43
Maximum (G31) kg/h 2.65
Minimum (G31) kg/h 0.57
Gas supply pressure
(G20) mbar (kPa) 20 (1,96)
(G31) mbar (kPa) 37 (3,63)
(*) Heat input of the heating system measured using lower heating value (LHV)
1.3 TECHNICAL FEATURES
73
ES
PT
ENG

74
8
4
7
5
6
10
11
2
13
14
17
12
1
CR3
G
S3
MR
1.4 FUNCTIONAL DIAGRAM (fig. 2)
Fig. 2
KEY
1 Gas valve
2 Condensate drain tap
4 Fan
5 C.H. flow sensor (SM)
6 Safety thermostat 100°C
7 Sensor fumes (SF)
8 Primary exchanger
10 C.H return sensor (SR)
11 Water pressure transducer
12 Air release vent
13 Pump high efficiency
14 Boiler discharge
17 Safety valve 3.5 bar
CONNECTIONS
R C.H. return
M C.H. flow
G Gas connection
S3 Condensation outlet
C Filling system
R3 D.H.W. tank return
MODEL
SERIAL NUMBER
YEAR OF CONSTRUCTION
WATER CONTENT IN BOILER
HEAT INPUT MAX
HEAT OUTPUT MAX (80-60°C)
HEAT OUTPUT MAX (50-30°C)
MAX OPERATING PRESSURE
CONTENTS D.H.W.
HEAT INPUT MAX D.H.W.
MAX OPERATING PRESSURE D.H.W.
D.H.W. FLOW RATE
POWER SUPPLY
MAX POWER ABSORBED
COUNTRIES OF DESTINATION
CATEGORY
TYPE
CODE
DIRECTIVE OF REFERENCE
PIN NUMBER
HEAT INPUT MIN
HEAT OUTPUT MIN (80-60°C)
HEAT OUTPUT MIN (50-30°C)
MAX OPERATING PRESSURE
HEAT INPUT MIN D.H.W.
MAX OPERATING PRESSURE D.H.W.
ELECTRICAL PROTECTION GRADE
NOx CLASS
CODE GAS COUNCIL NUMBER (UK)
CERTIFICATION WRAS (UK)
TYPE OF GAS
GAS SUPPLY PRESSURE
CLASSIFICATIONS
Fig. 3
1.5 TECHNICAL DATA PLATE (fig. 3)

The boiler must be installed in a fixed
location and only by specialized and
qualified firms in compliance with all
instructions contained in this manual.
Furthermore, the installation must be in
accordance with current standards and
regulations.
2.1 BOILER ROOM
The boilers MURELLE HE 50 R ErP can
be installed in boiler rooms whose size
and requirements meet current regu-
lations.
Furthermore, vents, with surface areas
at least 3.000 sq. cm or 5.000 sq. cm
for gas with density over 0.8, must be
installed in the outer walls for room
ventilation.
2.2 INSTALLATION
2.2.1 Single boiler (fig. 4)
A single function compensator kit is avai-
lable upon request: cod. 8101541.
The kit is for use on an accumulating
boiler with capacity equal to or greater
than 80 litres.
2.2.2 Sequence/cascade boilers
(fig. 4 - fig. 4/a)
For sequence/cascade installations
using polypropylene smoke collectors
with a clapet valve, every single boiler
that makes up the heating system must
have the following installation parame-
ters modified:
2 INSTALLATION
M
R
S3
G
Fig. 4
R C.H. return
M C.H. flow
G Gas connection
S3 Condensation outlet
Single installation
with kit optional code 8101541
Installation in sequence/cascade
WARNING:
- It is mandatory to arrange the thermal
system with the hydraulic separator.
- When replacing one or more boilers in
existing plants, it is advisable to install
a heat exchanger to separate the boiler
circuit from the secondary circuits. See
the pressure curve for the boiler supply
shown in figure 14.
M2
313
268
RM
330 65
700
595
M2
440,5 450
R3
170,5
268
207,5
M C.H. flow
R 2” (UNI-ISO 7/1)
R C.H. return
R 2” (UNI-ISO 7/1)
M2 D.H.W. tank flow
G 1” (UNI-ISO 228/1)
R3 D.H.W. tank return
G 1” (UNI-ISO 228/1)
75
ES
PT
ENG

76
- PAR 1 = 6 (for G20 NATURAL GAS boi-
lers)
- PAR 1 = 14 (for G31 PROPANE boilers)
Refer to section 3.3 to access the
INSTALLER PARAMETERS section.
ATTENTION: In sequence/cascade
installations, it is mandatory to arrange
the thermal system with the hydraulic
separator and safety devices.
The boiler is provided with the board
RS-485 that permits to manage up to 8
boilers in cascade and communication
in MODBUS. The board is placed on the
back of the control panel. Access the
board and chose the desired operating
mode (CASCADE or MODBUS) by selec-
ting the DIP SWITCH of the board as
indicated in figure 4/a.
CASCADE mode (fig. 4/b)
Electrically connect all the boilers that
form the modular cascade thermal
system and set installer parameters PAR
15 on every single boiler as indicated in
fig. 4/b.
MODBUS mode (fig. 4/c)
The RS-485 board can be used for
MODBUS communication of every
MURELLE HE 70 R ErP boiler.
In this case, proceed as follows:
- Set the DIP SWITCH of the RS-485
board and the PAR 16 as indicated in
the figure.
- Choose the communication configu-
ration suited to the MODBUS network
(PAR 17 INST) according to Table PAR
17 INST.
DIP SWITCH
GESTIONE IN CASCATA
123
CASCADE MANAGEMENT
DIP SWITCH
GESTIONE IN MODBUS
MODBUS MANAGEMENT
123
ON
123
ON
x 2
Fig. 4/a

77
ES
PT
ENG
SCHEDA CALDAIA (MASTER)
DIP SWITCH
SCHEDINO RS-485
SCHEDA CALDAIA (SLAVE 1)
DIP SWITCH
SCHEDA CALDAIA (SLAVE ...)
DIP SWITCH
123
CONNETTORE
CABLATO CN10
(cod. 6319165
SCHEDINO RS-485
SCHEDINO RS-485
CONNETTORE
CABLATO CN10
(cod. 6319165)
CONNETTOR
E
CABLATO CN10
(
cod. 6319165
)
123456
123456
123456
X5 X5
WIRED
CONNECTOR CN10
(code 6319165)
RS-485 BOARD
RS-485 BOARD
RS-485 BOARD
WIRED
CONNECTOR CN10
(code 6319165)
WIRED
CONNECTOR CN10
(code 6319165)
BOILER BOARD (SLAVE ...)BOILER BOARD (SLAVE 1)BOILER BOARD (MASTER)
Pmin Pmax
TS
KIT SICUREZZE INAIL
(solo per mercato Italia)
ON
123
ON
123
ON
SONDA ESTERNA (SE) EXTERNAL SENSOR (SE)
SONDA MANDATA CASCATA (SMC) CASCADE SUPPLY PROBE (SMC)
CARATTERISTICHE CAVO:
- 3 fili di sezione almeno AWG24 - Schermato e twistato - Impedenza caratteristica almeno 100 Ω - Schermatura connessa a terra da un solo lato della linea
CHARACTERISTICS
OF ELECTRIC CABLE:
-
3 wires of 24 AWG
- Screened and twisted - Characteristic impedance 100 Ω - Shield connected to ground with only one side of the line
–
+
GND
–
+
GND
–
+
GND
–
+
GND
–
+
GND
–
+
GND
Fig. 4/b
INSTALLER PARAMETER SETTING: PAR 15 CASCADE ADDRESS -- = Not enabled 0 = Master 1...7 = Slave from 1 to 7 (ATTENTION: Avoid assigning the
same number to SLAVE boilers)
NOTE: The external temperature sensor (SE)
must be connected to the MASTER sensor and
the cascade delivery sensor (SMC) to boiler
SLAVE 1. The board sensors and connection cables are
provided in a kit upon request code 8092250.
When the red LED flashes RS-485 board, DIP
SWITCH is not set correctly.

78
SCHEDA CALDAIA
DIP SWITCH
SCHEDINO RS-485
123
C
ONNETTORE
CABLATO CN10
(
cod. 6319165
)
123456
WIRED CONNECTOR
CN10
(code 6319165)
COMUNICAZIONE MODBUS
MODBUS COMMUNICATION
RS-485 BOARD
/ BOILER BOARD
ON
–
+
GND
–
+
GND
11200 8No 1
21200 8No 2
31200 8Pari / 1
41200 82
51200 8Dispari / 1
61200 82
72400 8No 1
82400 8No 2
92400 81
10 2400 82
11 2400 81
12 2400 82
13 4800 8No 1
14 4800 8No 2
15 4800 81
16 4800 82
17 4800 81
18 4800 82
19 9600 8No 1
20 9600 8No 2
21 9600 81
22 9600 82
23 9600 81
24 9600 82
25 19200 8No 1
26 19200 8No 2
27 19200 81
28 19200 82
29 19200 81
30 19200 82
PAR 17 INST Baud Rate N° Bit Dati Parità Bit di Stop
Par 17 INST Baud Rate No. Data Bit Parity Stop Bit
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Pari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Dispari /
Even
Even
Even
Even
Even
Even
Even
Even
Even
Even
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
Odd
TABELLA PAR 17 INST/ Tab. PAR 17 INST
Fig. 4/c
INSTALLER PARAMETER SETTING:
PAR 16 MODBUS ADDRESS
-- = Not enabled
1...31 = Slave from 1 to 31
(ATTENTION: Avoid calling the
boiler with the same number
assigned to either appliances)
PAR 17 MODBUS CONFIGURATION
-- = Not enabled
1...30 =
Default value: 25
(See Table PAR 17 INST)
ATTENTION: Upon setting the parameters, we
recommend turning the boiler off and then back
on again.

79
ES
PT
ENG
Modbus address
Variable description
Type
Read /Write
U.M.
Min
value
Max
value
Function
Di
g
ital variables
(
COILS
)
1 Boiler CH Enable/Re
q
uest D R/W - 0 1 Richiesta riscaldamento zona 1
2 Boiler DHW Enable D R/W - 0 1 Abilitazione preparazione ACS
3 Boiler Water Fillin
g
Function D R/W - 0 1 Non usato
32 Boiler CH Mode D R - 0 1 Stato riscaldamento zona 1
33 Boiler DHW Mode D R - 0 1 Stato
p
re
p
arazione ACS
34 Boiler Flame Status D R - 0 1 Stato
p
resenza fiamma
35 Boiler Alarm Status D R - 0 1 Stato
p
resenza allarme
Analog/integer variables
(REGISTERS Word 16 bit)
1 Boiler CH Primary Setpoint A R/W 0,1°C 20,0 80,0 Setpoint riscaldamento zona 1.
Se viene ricevuto un valore fuori range
equivale a nessun valore ricevuto e viene
mantenuta la termoregolazione di caldaia
a punto fisso o a curva climatica.
2 Boiler DHW Primary Setpoint A R/W 0,1°C 20,0 80,0
Setpoint circuito primario durante
la preparazione ACS
(al posto di PAR 66 caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzato
il valore di regolazione presente in caldaia.
3 Boiler DHW Setpoint A R/W 0,1°C 10,0 80,0
Setpoint acqua calda sanitaria.
Se viene ricevuto un valore fuori range
equivale a nessun valore ricevuto
e viene utilizzato il valore
di regolazione presente in caldaia.
4 Outside Temperature MB A R/W 0,1°C -55,0 95,0
Valore di temperatura esterna comunicato via ModBus.
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto. Nel caso di conflitto
la caldaia dà la priorità al valore della sonda
ad essa collegata.
5 Boiler CH Curve Slope A R/W 0,1 3,0 40,0
Pendenza della curva climatica della zona 1
(utilizzato al posto della curva impostata in caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzata
la curva climatica presente in caldaia.
6 Boiler CH Curve Displacement A R/W 0,1 -5,0 5,0
Valore di shift del set ambiente della zona 1
(utilizzato al posto dello shift impostato in caldaia).
Se viene ricevuto un valore fuori range equivale
a nessun valore ricevuto e viene utilizzato
lo shift presente in caldaia.
64 Boiler DHW Water Tem
p
erature A R 0,1°C 0,0 100,0 Temperatura Sonda Acqua calda sanitaria
65 Boiler Primar
y
Water Tem
p
erature A R 0,1°C 0,0 100,0 Temperatura Sonda Circuito Primario (Mandata)
66 Boiler Return Water Tem
p
erature A R 0,1°C 0,0 100,0 Temp. Sonda Ritorno Circuito Primario (NO cascata)
67 Boiler Flue Gas Tem
p
erature A R 0,1°C 0,0 200,0 Temperatura Sonda Fumi (NO cascata)
68 Boiler Relative Modulation Level A R 0,1% 0,0 100,0 Livello Modulazione (0%=Minima Potenza -
100%=Massima Potenza)
69 Boiler Primar
y
Water Pressure A R 0,1 bar 0,0 6,0 Valore Pressione Acqua Circuito Primario
70 Boiler Outside Temperature A R 0,1°C -100,0 100,0 Valore di temperatura esterna letto
dalla caldaia tramite la sonda ad essa collegata.
129 Boiler Current Minute I R/W - 0 59 Non usato
130 Boiler Current Hour I R/W - 0 23 Non usato
131 Boiler Current Da
y
of the Week I R/W - 1 = Lun 7 = Dom Non usato
132 Boiler Current Da
y
of the Month I R/W - 1 31 Non usato
133 Boiler Current Month I R/W - 1 12 Non usato
134 Boiler Current Year I R/W - 2000 2200 Non usato
192 Boiler Alarm Code I R - 0 100 Codice numerico visualizzato durante
anomalia caldaia (Master se in cascata).
193 Boiler Slave 1 Alarm Code I R - 0 100
194 Boiler Slave 2 Alarm Code I R - 0 100 Codice numerico visualizzato durante
anomalia caldaia slave 2 (Solo cascata)
195 Boiler Slave 3 Alarm Code I R - 0 100
196 Boiler Slave 4 Alarm Code I R - 0 100
Boiler Slave 5 Alarm Code I R - 0 100
199 Boiler Slave 7 Alarm Code I R - 0 100 Codice numerico visualizzato durante
anomalia caldaia slave 7 (Solo cascata)
200 Boiler Combustion Parameter
(
Par1
)
I R - 0 199 Valore del PAR 1 in caldaia (Master se in cascata)
201 Boiler H
y
draulic Parameter
(
Par2
)
I R - 0 199 Valore del PAR 2 in caldaia (Master se in cascata)
Codice numerico visualizzato durante
anomalia caldaia slave 4 (Solo cascata)
Codice numerico visualizzato durante
anomalia caldaia slave 5 (Solo cascata)
Codice numerico visualizzato durante
anomalia caldaia slave 6 (Solo cascata)
Request CH zone 1
Enable DHW preparation
Not used
State CH zone 1
Descrizione /
State preparation DHW
State presence flame
State presence alarm
Setpoint CH zone 1.
If you receive a value out of range
so the value isn’t received and
the boiler temperature control is
maintained of fixed point or a
temperature curve.
Setpoint CH during ACS preparation
(for PAR 66 installer parameters)
If you receive a value out of range
the value isn’t received and it is used
the boiler value regulation .
Setpoint ACS.
If you receive a value out of range
the value isn’t received and it is used
the boiler value regulation.
External value of temperature by MobBus.
If you receive a value out of range
the value isn’t received. In case of
conflict the boiler will give priority to the value
of the probe connected to it.
Slope of heating curve of zone 1
(it is used instead of the curve set in the boiler).
If you receive a value out of range
the value isn’t received and it is used
the boiler heating curve.
If you receive a value out of range
the value isn’t received and it is used
the boiler heating curve.
Shift value of room zone 1 set
(it is used instead of the shift set in the boiler).
DHW temperature sensor
CH temperature sensor (Delivery)
CH temperature sensor (Return) (No cascade)
Smoke temperature sensor (No cascade)
Modulation level: (0%= minimum power
100%= maximum power)
Pressure value water CH
Outside temperature read from the boiler
through the probe connected to it
Not used
Not used
Not used
Not used
Not used
Not used
Numeric code shown during boiler error
(If Master is in cascade)
Numeric code shown during slave 02 error
(Only cascade)
Numeric code shown during slave 07 error
(Only cascade)
PAR 1 value (If Master is in cascade)
PAR 2 value (If Master is in cascade)
TABELLA DELLE VARIABILI MODBUS /
MODBUS BOILER VARIABLES LIST
Codice numerico visualizzato durante
anomalia caldaia slave 3 (Solo cascata)
Numeric code shown during slave 03 error
(Only cascade)
Numeric code shown during slave 04 error
(Only cascade)
Numeric code shown during slave 05 error
(Only cascade)
Numeric code shown during slave 06 error
(Only cascade)
7 Boiler Delta-T CH A R/W 0,1 10,0 40,0 Valore di setpoint Delta-T (Mandata - Ritorno)
Value setpoint Delta-T (Delivery - Return)
Numeric code shown during slave 01 error
(Only cascade)
Codice numerico visualizzato durante
anomalia caldaia slave 1 (Solo cascata)
Code
01 READ COIL STATUS
03
WRITE MULTIPLE COILS
05
(p
artiall
y
su
pp
orted
)
WRITE SINGLE COIL
04
(p
artiall
y
su
pp
orted
)
READ INPUT REGISTER
06
(p
artiall
y
su
pp
orted
)
WRITE SINGLE REGISTER
Name
COMANDI MODBUS SUPPORTATI /
MODBUS COMMANDS SUPPORTED
15
16
READ HOLDING REGISTERS
WRITE MULTIPLE REGISTERS
197
198 Boiler Slave 6 Alarm Code I R - 0 100

80
CASCADE+MODBUS mode (fig. 4/d)
This mode allows for MODBUS commu-
nication of at least two boilers in cascade
and is performed by requesting another
RS-485 board provided in the kit code
8092244.
ATTENTION: Communication will occur
only with the MASTER boiler, (boiler
with PAR 15 = 0), interpreting the casca-
de as a single heat capacity generator:
P CASCADE = P BOILER x No. BOILERS.
To install the second board, proceed as
follows:
- Remove the cover and electrical-
ly connect the second RS-485 board
equipped with lid to the RS-485 board
already installed in the MASTER boiler
(boiler with PAR 15 = 0) with the wired
connector provided in the kit.
CAUTION: Insert the wired connector
with caution.
- Set the DIP SWITCH of the new board
in MODBUS mode.
- Close the lid of the second board.
- Choose the communication configu-
ration suited to the MODBUS network
(PAR 17 INST) according to Table PAR
17 INST.
RS-485 connection to the INSOL/ZONA
MIX (fig. 4/e)
The RS-485 board can be connected
to optional INSOL kit code 8092254 or
ZONA MIX code 8092252. Both require
the board housing kite code 8092236.
Carry out the electrical connections as
indicated in the figure.
CAUTION: For electrically connecting
the INSOL/ZONA MIX board to the boiler
board, refer to the instruction leaflet
provided in the kit.
CN10
CN10
COMUNICAZIONE
MODBUS
MODBUS
COMMUNICATION
12345
6
Schedino
INSOL/ZONA MIX e kit
alloggiamento scheda
Schedino
INSOL/ZONA MIX e kit
alloggiamento scheda
Cavo kit INSOL/ZONA MIX
Kit INSOL/MIX ZONE cable
Cod.6323801
Fig. 4/e
Fig. 4/d
CN10
COMUNICAZIONE
MODBUS
MODBUS
COMMUNICATION
CONNETTORE CABLATO
(cod. 6319173)
WIRED CONNECTOR
(cod 6319173)
12345
6
123
DIP SWITCH
GESTIONE IN MODBUS
MODBUS MANAGEMENT
123
ON
INSTALLER PARAMETER SETTING:
PAR 16 MODBUS ADDRESS
-- = Not enabled
1...31 = Slave from 1 to 31
(ATTENTION: Avoid calling the
boiler with the same number
assigned to other appliances)
PAR 17 MODBUS CONFIGURATION
-- = Not enabled
1...30 =
Default value: 25
(See Table PAR 17 INST)
Module with 1 RS-485 board Module with 2 RS-485 board
INSOL / ZONA MIX
board and kit board
housing
INSOL / ZONA MIX
board and kit board
housing

81
ES
PT
ENG
2.3 CONNECTING UP SYSTEM
To protect the heat system from dama-
ging corrosion, incrustation or depo-
sits, before installation it is extremely
important to clean the system using
suitable products such as, for example,
Sentinel X300 (new system), X400 and
X800 (old system) or Fernox Cleaner F3.
Complete instructions are provided with
the products but, for further informa-
tion, you may directly contact SENTINEL
PERFORMANCE SOLUTIONS LTD or
FERNOX COOKSON ELECTRONICS.
For long-term protection agains cor-
rosion and deposits, the use of inhibi-
tors such as Sentinel X100 or Fernox
Protector F1 is recommended after cle-
aning the system. It is important to check
the concentration of the inhibitor after
each system modification and during
maintenance following the manufactu-
rer’s instructions (specific tests are avai-
lable at your dealer).
The safety valve drain must be con-
nected to a collection funnel to collect
any discharge during interventions. If the
heating system is on a higher floor than
the boiler, install the on/off taps supplied
in kit optional on the heating system deli-
very/return pipes.
WARNING: Failure to clean the heat
system or add an adequate inhibitor
invalidates the device’s warranty.
Gas connections must be made in
accordance with current standards and
regulations. When dimensioning gas
pipes from the meter to the module,
both capacity volume (consumption) in
m3/h and gas density must be taken
into account. The sections of the piping
making up the system must be such as
to guarantee a supply of gas sufficient
to cover the maximum demand, limiting
pressure loss between the gas meter
and any apparatus being used to not
greater than:
– 1.0 mbar for family II gases (natural
gas);
– 2.0 mbar for family III gases (butane or
propane).
An adhesive data plate is sticked insi-
de the front panel; it contains all the
technical data identifying the boiler and
the type of gas for which the boiler is
arranged.
2.3.1 Connection of condensation
water trap
The drip board and its water trap must
be connected to a civil drain through a
pipe with a slope of at least 5 mm per
metre to ensure drainage of condensa-
tion water.
The plastic pipes normally used for civil
drains are the only type of pipe which is
appropriate for conveying condensation
to the building’s sewer pipes.
2.3.2 Filter on the gas pipe
The gas valve is supplied ex factory with
an inlet filter, which, however, is not
adequate to entrap all the impurities in
the gas or in gas main pipes.
To prevent malfunctioning of the valve,
or in certain cases even to cut out the
safety device with which the valve is
equipped, install an adequate filter on
the gas pipe.
2.4 INITIAL PHASE
SYSTEM FILLING
The charge pressure, at cold start, must
be 1 bar. The filling is to be done slowly
to allow air bubbles to escape through
the air vents.
2.4.1 System draining (fig. 5)
To drain the system, turn off the boiler
and use the discharge valve (1 fig. 5).
3
1
2
Fig. 5
KEY
1 Boiler discharge
2 Pump high efficiency
3 Safety valve 3.5 bar

82
2.5 EXHAUST
The boiler is supplied with a 80 mm
gasket, which must be fitted over the
exhaust terminal prior to the flue being
installed
(11 fig. 6 - fig. 7 - fig. 8).
2.5.1 Type B (fig. 6)
If the inlet is not connected, the boiler
should be regarded a Type B device. When
installing the boiler in locations where it
needs to be protected from water, replace
the intake terminal inserted in the flange
with terminal code 8089510.
For information on how to configure the
boiler in this mode see figure
6.
The maximum overall length of ø 80
exhaust flues is determined by the load
losses of the single accessories installed
and should not exceed 16 mmH
2 O .
The exhaust pipe can be connected to
existing chimneys.
When the boiler works at low temperatu-
re is possible to use normal chimneys at
the following conditions:
– The chimney must not be used by
other boilers.
– The inside of the chimney must be
protected from direct contact with the
boiler condensation. Combustion pro-
ducts must be conveyed with a flexible
piping or rigid plastic pipes with a
diameter of about 100-150 mm provi-
ding so to the condensation siphoned
drainage at the end of the pipe. The
useful height of the siphon must be at
least 150 mm.
2.5.2 Type C (fig. 7 - fig. 8)
The boiler becomes a Type C device
when the intake terminal is removed
from the flange and the intake is con-
nected to separate exhaust ducts (fig. 7)
or with coaxial exhaust (fig. 8).
2.5.3 Maximum usable length
for separate ø 80 flues
The maximum overall length of ø 80
suction and exhaust flues is determined
by the load losses of the single acces-
sories installed and should not exceed
16 mmH2O.
When the segment of piping is between
11-16 mm H2O it is necessary to check
and, if needed, correct the maximum
and minimum pressure adjustment of
the gas valve as specified in point 4.2.2.
2.5.4 Maximum usable
length for coaxial ø 80/125 flues
In installations with ø 80/125 coaxial
exhaust, the maximum horizontal
length including the 90° curve, should
not exceed 5 m.
For roof exits it should not exceed 8 m
along vertical.
When the segment of pipe is between 2-5
m horizontal / 4-8 m vertical, it is neces-
sary to check and, if needed, correct
the maximum and minimum pressure
adjustment of the gas valve as specified
in point 4.2.2.
WARNING:
Before installing accessories, lubricate the internal part
of gaskets with silicon-based products. Avoid using oils
and greases.
KEY
1 90° MF polypropylene curve (6 pcs.) code 8077450
2 a Polypropylene extension L. 1000 (6 pcs.) code 8077351
2 b Polypropylene extension L. 500 (6 pcs.) code. 8077350
3 Hinged tile code 8091300
4 Roof terminal kit L. 1381 code 8091204
5 Polypropylene extension L. 250 with socket code 6296513
6 45° MF polypropylene curve (6 pcs.) code 8077451
7 Exhaust terminal code 8089501
8 Internal-external ring nut kit code 8091500
11 Rubber gasket ø 80 (supplied as standard)
Type B
Fig. 6
ø 80 ACCESSORY LOAD LOSS TABLE
Accessory ø 80 Load loss
(mm H
2
O)
90° MF polypropylene curve 0,80
45° MF polypropylene curve 0,40
Polypropylene extension L. 1000 0,40
Polypropylene extension L. 500 0,20
Roof exit terminal L. 1381 1,30
Exhaust terminal 1,50
Polypropylene extension L. 250 with socket 0,10

83
ES
PT
ENG
WARNING:
- Installations with roof exit terminal (4a) and coa-
xial exhaust (13) require the use of a condensation
recovery (12) that has to be connected to the water
drain siphon (waste water).
- The installation of the roof exit terminal (4a) requi-
res the removal of the two ø 60 and ø 100 reducers.
- Before installing accessories, lubricate the internal
part of gaskets with silicon-based products. Avoid
using oils and greases.
Fig. 7
KEY
1 90° MF polypropylene curve (6 pcs.) code 8077450
2 a Polypropylene extension L. 1000 (6 pcs.) code 8077351
2 b Polypropylene extension L. 500 (6 pcs.) code. 8077350
3 Hinged tile code 8091300
4 Roof terminal kit L. 1381 code 8091204
4 a Coaxial roof exit terminal code 8091205
5 Polypropylene extension L. 250 with socket code 6296513
6 45° MF polypropylene curve (6 pcs.) code 8077451
7 Exhaust terminal code 8089501
8 Internal-external ring nut kit code 8091500
9 Air inlet terminal (supplied with unit)
10 Inlet/exhaust fitting code 8091401
11 Rubber gasket ø 80 (supplied as standard)
12 Condensation recovery L. 135 code 8092800
13 Coaxial exhaust ø 80/125 L. 885 code 8091210
Type C (separate ø 80 flues and
coaxial exhaust terminal)
Type C (separate ø 80 flues)
TABLE OF LOAD LOSSES OF ACCESSORIES
Load loss
(mm H
2
O)
Inlet Exhaust
90° MF polypropylene curve 0,80 0,80
45° MF polypropylene curve 0,45 0,45
Polypropylene extension L. 1000 0,35 0,45
Polypropylene extension L. 500 0,15 0,20
Coaxial roof exit terminal + Fitting (pos. 10) - 4,00
Roof exit terminal L. 1381 - 1,30
Exhaust terminal - 1,50
Air inlet terminal 0,20 -
Polypropylene extension L. 250 with socket - 0,10
Coaxial exhaust L. 885 + Fitting (pos. 10) - 5,00
Condensation recovery L. 135 1,80 -

84
Type C (ø 80/125 coaxial exhaust)
NOTES:
- Installation requires the use of a condensation recovery (12) that must be
connected to a water drain siphon (waste water).
- The installation of the coaxial roof exit terminal (4a) requires the removal
of the two ø 60 and ø 100 reducers.
- Before installing accessories, lubricate the internal part of gaskets with
silicon-based products. Avoid using oils and greases.
- Inserting each supplementary 90° elbow reduces the available segment
by 2 metres and Inserting each supplementary 45° elbow reduces the
available segment by 1 metre.
KEY
2 a Extension ø 80/125 L. 1000 code 8096171
2 b Extension ø 80/125 L. 500 code 8096170
3 Hinged tile code 8091300
4 a Coaxial roof exit terminal code 8091205
10 Inlet/exhaust fitting with test outlet code 8091401
11 Rubber gasket ø 80 (supplied as standard)
12 Condensation recovery ø 80 L. 135 code 8092800
13 Coaxial exhaust ø 80/125 L. 885 code 8091210
14 a 90° curve ø 80/125 code 8095870
14 b 45° curve ø 80/125 code 8095970
Fig. 8
Model H (m) L (m)
Murelle HE 70 R ErP 8 5
HORIZONTAL EXHAUST
To ensure correct operation of the appliance, do
as follows:
- set the installer parameter PAR 9 as indicated in
table (see point 3.3 to access the installer para-
meters).
- proceed with calibrating CO2at the maximum
and minimum capacity as specified in point 4.2.2.
Maximum length PAR 9
exhaust (m) (long chimneys)
0 - 1,0 2
1,0 - 2,0 3
2,0 - 3,0 4
3,0 - 4,0 5
4,0 - 5,0 6

85
ES
PT
ENG
2.6 ELECTRICAL
CONNECTION
The boiler is supplied with an electric
cable. Should this require replacement,
it must be purchased exclusively from
SIME.
The electric power supply to the boiler
must be 230V - 50Hz single-phase throu-
gh a fused main switch, with at least 3
mm spacing between contacts.
Respect the L and N polarities and the
earth connection.
NOTE: SIME declines all responsibili-
ty for injury or damage to persons,
animals or things, resulting from the
failure to provide for proper earthing of
the appliance.
2.6.1 Chronothermostat connection
Connect the chronothermostat as indica-
ted in the boiler electrical diagram (see
fig. 11) after having removed the existing
bridge.
The chronothermostat to be used must
be of a class conforming to the standard
EN 607301 (clean electrical contact).
2.6.2 Remote control SIME HOME
connection (optional)
The boiler is designed for connection to
a remote control unit SIME HOME, sup-
plied on request (code 8092280/81).
The remote control unit SIME HOME
allows for complete remote control of
the boiler,.
The boiler display will show the following
message:
For installation and use of the remote
control, follow the instructions in the
package.
NOTE: Ensure PAR 10 set to 1 (PAR 10
= 1).
2.6.3 External sensor connection
The boiler is designed for connection to
an external temperature sensor, sup-
plied on request (code 8094101), which
can automatically regulate the tempera-
ture value of the boiler output according
to the external temperature.
For installation, follow the instruction
in the package. It is possible to make
corrections to the values read by the drill
acting on the PAR 11.

86
2.7 BOILER ELECTRICAL (fig. 11)
OP
(24 VAC)
TA2 (24 VRAC)
TA1 (24 VRAC)
SE (5 VDC)
TS (24 VDC)
SB/SA
(5 VDC)
SM (5 VDC)
SF (5 VDC)
SR (5 VDC)
RS-485
(24 VAC)
cd. 6301480
Fig. 11
KEY
F1-2 Fuse (4 AT)
TRA Ignition transformer
PI Pump high efficiency
V Fan
EA Ignition electrode
ER Detection electrode
EV1-2 Gas valve coil
TS Safety thermostat
SF Sensor fumes
TFU Thermal fuse
SM C.H. flow sensor
SR C.H. return sensor
TPA Pressure transducer
JP1 Selection TA2 or 0-10 VDC
TA1 Zone 1 environment thermostat
TA2 Zone 2 environment thermostat
SB/SA D.H.W. sensor L. 2000 (optional)
CR Remote control
SIME HOME (optional)
SE External sensor (optional)
OP Programming clock (optional)
AR Remote alarm
VZ Zone valve
AUX Auxiliary connection
RS-485 CASCADE/MODBUS board
NOTE: Connect TA1 to the clamps 7-8
after having removed the bridge.
CONNECTOR SPARE PART CODES:
CN1 code 6319162
CN2 code 6319160
CN3 code 6319164
CN4 code 6316203
CN5 code 6316200
CN6 code 6316202
CN7 code 6316204
CN9 code 6316201
CN10 code 6319165
CN12 code 6299991
CN13 code 6319161
CN14 code 6319163
CN18 code 6319147
For the range 0 ... 10VDC:
- Remove the jumper JP1
- Connect the positive signal at terminal 10 of CN6
- Connect the negative signal at terminal 4 of the CN4.

87
ES
PT
ENG
3 CHARACTERISTICS
3.1 CONTROL PANEL (fig. 12)
5
3
1
2
4
2 - DESCRIPTION OF CONTROLS
ON/OFF KEYS
ON = Electricity supply to boiler is on
OFF = Electricity supply to boiler is on but nor ready
for functioning. However, the protection fun-
ctions are active.
SUMMER MODE KEY
When this key is pressed, the boiler functions only
when D.H.W. is requested (function not available)
WINTER MODE KEY
When this key is pressed, the boiler provides hea-
ting and D.H.W.
D.H.W. TEMP KEY
When this key is pressed, the temperature of the
D.H.W. is shown on the display (function not available)
HEATING TEMP KEY
The first time the key is pressed, the temperature of
heating circuit 1 is shown.
The second time the key is pressed, the temperatu-
re of heating circuit 2 is shown.
The third time the key is pressed, the temperature
of heating circuit 3 is shown (Three zones).
RE-SET KEY
This allows for restoring functioning after a functio-
ning anomaly.
INCREASE AND DECREASE KEY
By pressing this key the set value increases or
decreases.
4 - LUMINOUS BAR
Blue = Functioning
Red = Functioning anomaly
5 - PROGRAMMING CLOCK (optional)
Mechanical clock (code 8092228) or digital clock
(code 8092229) to program heating and water supply. Fig. 12
3 - KEYS RESERVED FOR THE INSTALLER
(access to INST and OEM parameters)
PC CONNECTION
To be used only with the SIME programming kit and only
by authorised personnel. Do not connect other electronic
devices (cameras, telephones, mp3 players, etc.) Use a
tool to remove the cap and reinsert after use.
ATTENTION: Communication port
sensitive to electrostatic charges.
Before use, it is advisable to touch an
earthed metallic surface to discharge static electricity.
INFORMATION KEY
This key can be pressed several times to view the
parameters.
CHIMNEY SWEEP KEY
This key can be pressed several times to view the
parameters.
DECREASE KEY
This key changes the default settings.
INCREASE KEY
This key changes the default settings.
DESCRIPTION OF DISPLAY ICONS
SUMMER MODE ICON
WINTER MODE ICON
D.H.W. MODE ICON
HEATING MODE ICON
GRADED POWER SCALE
The segments of the bar light up in proportion to boiler
power output .
BURNER FUNCTIONING AND BLOCK ICON
DESCRIPTION OF DISPLAY ICONS
CHIMNEY SWEEP ICON
SECONDARY DIGITS
The boiler visualises the value of the pressure of
the system (correct value is between 1 and 1.5 bar)
MAIN DIGITS
The boiler visualises the values set, the state
of anomaly and the external temperature
INTEGRATIVE SOURCES ICON

88
3.2 ACCESS TO INSTALLER’S INFORMATION
For access to information for the installer, press the key (3 fig. 14). Every time the key is pressed, the display moves to the next
item of information. If the key
is not pressed, the system automatically quits the function. If there is no expansion board (ZONA MIX
or INSOL) the relative info shall not be displayed. List of information:
1. Visualizzazione temperatura esterna
solo con sonda esterna collegata
2. Visualizzazione temperatura sonda
mandata riscaldamento (SM)
3. Visualizzazione temperatura sonda
sanitario (SS) solo per caldaie istantanee
4. Visualizzazione temperatura sonda
ausiliaria o sonda bollitore (SB)
6. Visualizzazione temperatura
riscaldamento riferita al primo circuito
7. Visualizzazione temperatura
riscaldamento riferita al secondo circuito
9. Visualizzazione numero giri ventilatore in rpm x 100 (es. 4.800 e 1.850 rpm)
10. Visualizzazione ore di funzionamento del bruciatore in h x 100 (es. 14.000 e 10)
11. Visualizzazione numero di accensioni del bruciatore x 1.000 (es. 97.000 e 500)
5. Visualizzazione temperatura sonda
fumi (SF)
8. Visualizzazione corrente
di ionizzazione in μA
17. Visualizzazione portata sanitaria flussimetro (es. 18 l/min
e 0,3 l/min) o stato flussostato (rispettivamente ON e OFF)
12. Visualizzazione numero totale
delle anomalie
13. Contatore accessi parametri
installatore (es. 140 accessi)
14. Contatore accessi parametri
OEM (es. 48 accessi) 15. Contatore accessi parametri
CASCATA OEM (es. 05 accessi)
2. Visualisation of C.H. flow sensor (SM)
3. Visualisation of D.H.W. temperature sen-
sor (SS) only for instantaneous boilers
4. Visualisation of auxiliary temperature
sensor or D.H.W. sensor (SB)
6. Visualisation of heating temperature of
first circuit
7. Visualisation of heating temperature of
second circuit
8. Visualisation of ionisation current in μA
10. Visualisation of hours of functioning of the burner in h x 100 (e.g. 14000 and 10)
11. Visualisation of number of times the burner has ignited x 1000 (e.g. 97000 and 500)
12. Visualisation of total number
of anomalies
5. Visualisation of smoke temperature sen-
sor (SF) 13. Parameter access counter–
Installer (i.e. 140 accesses)
14. Parameter access counter–OEM
(i.e. 48 accesses)
1. Visualisation of external temperature,
only with external sensor connected
9. Visualisation fan speed in rpm x 100 (e.g. 4.800 and 1850 rpm)
15. Parameter access counter–
CASCADE OEM (i.e. 05 accesses)
17. Visualisation of D.H.W. flowmeter load (i.e. 18 l/min and 0.3 l/min) or flow switch
(respectively ON and OFF)

89
ES
PT
ENG
20. Visualizzazione valore sonda mandata impianto miscelato
con schedino ZONA MIX 1 (ingresso
S2)
21. Visualizzazione termostato sicurezza ZONA MIX (ingresso S1)
rispettivamente ON e OFF
22. Visualizzazione pompa con schedino ZONA MIX 1
(rispettivamente ON e OFF)
23. Visualizzazione comando apertura valvola con
schedino ZONA MIX 1 (rispettivamente ON e OFF)
24. Visualizzazione comando chiusura valvola
con schedino ZONA MIX 1 (rispettivamente ON e OFF)
25. Visualizzazione valore della sonda mandata impianto miscelato
con schedino ZONA MIX 2
26. Visualizzazione termostato sicurezza con schedino
ZONA MIX 2 (ingresso S1) rispettivamente ON e OFF
27. Visualizzazione pompa con schedino ZONA MIX 2
(rispettivamente ON e OFF)
28. Visualizzazione comando apertura valvola con schedino
ZONA MIX 2 (rispettivamente ON e OFF)
29. Visualizzazione comando chiusura valvola con schedino
ZONA MIX 2 (rispettivamente ON e OFF)
30. Visualizzazione valore temperatura sonda solare S1
con schedino solare INSOL
31. Visualizzazione valore temperatura sonda solare S2
con schedino solare INSOL
32. Visualizzazione valore temperatura sonda solare S3
con schedino solare INSOL
33. Visualizzazione relè solare R1 con schedino solare INSOL
(rispettivamente ON e OFF)
34. Visualizzazione relè solare R2 con schedino solare INSOL
(rispettivamente ON e OFF)
35. Visualizzazione relè solare R3 con schedino solare INSOL
(rispettivamente ON e OFF)
18. Visualizzazione valore sonda ritorno riscaldamento (SR)
19. Visualizzazione valore sonda collettore cascata
40. Visualizzazione valore %
comando pompa PWM
36. Visualizzazione stato flussostato solare
(rispettivamente ON e OFF)
60. Visualizzazione codice
errore ultima anomalia 61. Visualizzazione codice
errore penultima anomalia 70. Codice di warning
90. Versione software presente
su RS-485 (es. versione 01)
91. Versione software presente su
schedino EXP (config. ZONA MIX)
92. Versione software presente su 2°
schedino EXP (config. ZONA MIX)
45. Visualizzazione temperatura
riscaldamento riferita al terzo circuito
20. Visualisation delivery probe value mixed with board
ZONA MIX 1 (input S2)
21. Visualisation safety thermostat ZONA MIX (input S1)
respectively ON and OFF
22. Visualisation pump with board ZONA MIX 1 (respecti-
vely ON and OFF)
23. Visualisation valve opening control with board ZONA
MIX 1 (respectively ON and OFF)
24. Visualisation valve closing control with board ZONA
MIX 1 (respectively ON and OFF)
25. Visualisation of the plant delivery probe mixed with
board ZONA MIX 2
26. Visualisation safety thermostat with board ZONA MIX
2 (input S1) respectively ON and OFF
27. Visualisation pump with board ZONA MIX 2 (respecti-
vely ON and OFF)
28. Visualisation valve opening control with board
ZONA MIX 2 (respectively ON and OFF)
29. Visualisation valve closing opening control with board ZONA MIX
2 (respectively ON and OFF)
30. Visualisation solar probe temperature value S1 with
solar board INSOL
31. Visualisation solar probe temperature value S2 with
solar board INSOL
32. Visualisation solar probe temperature value S3 with
solar board INSOL
33. Visualisation solar relay R1 with solar board INSOL
(respectively ON and OFF)
34. Visualisation solar relay R2 with solar board INSOL
(respectively ON and OFF)
35. Visualisation solar relay R3 with solar card INSOL
(respectively ON and OFF)
18. Visualisation C.H. return sensor value (SR)
19. Visualisation collector probe value
36. Visualisation solar flow meter state (respectively ON
and OFF)
40. Visualisation % value
pump control PWM
60. Visualisation of error
code of last anomaly
61. Visualisation of error code
of penultimate anomaly
70. Code warning
90. Software version on
RS-485 (e.g. version 01)
91. Software version on EXP
(configuration ZONA MIX)
92. Software version on second
EXP (configuration ZONA MIX)
45. Visualisation of heating temperature
of third circuit

90
3.3 ACCESS TO
INSTALLER’S
PARAMETERS
For access to the installer’s parameters,
press simultaneously the keys and
or 2 seconds (3 fig. 12).
For example, the parameter PAR 23 is
visualised on the display of the control
panel in the following way:
The parameters scroll forwards and
backwards with the key and and
the default parameters can be changed
with the keys and .
The standard visualisation returns auto-
matically after 60 seconds, or by pres-
sing one of the control keys (2 fig. 12)
excluded the key RESET.
3.3.1 Replacing the board or
RESETTING parameters
If the electronic board is replaced or
reset, it is necessary to configure PAR 1
and PAR 2 by associating the following
values to each type of boiler to be able to
restart the boiler:
PARAMETERS INSTALLER
FAST CONFIGURATION
PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT
MEASUREMENT UNIT SETTING
1 Combustion configuration -- = ND = = “- -”
1 ... 46
2 Hydraulic configuration -- = ND = = “- -”
1 ... 14
3 Timetable 2 programmer 1 =
DHW + Recirc. pump = = 1
2 = DHW
3 = Recirculation pump
4 Pressure transducer disabler 0 = Disabled = = 1
1 = Enabled 0-4 BAR
2 = Enabled 0-6 BAR
3 = Enabled 0-4 BAR (NO ALL 09)
4 = Enabled 0-6 BAR (NO ALL 09)
5 Assignment of auxiliary relay AUX 1 = Remote supply = = 1
2 = Recirculation pump
3 = Automatic load.
4 = Remote alarm NC
5 = Heat pump
6 = Zone 2 valve
6 Luminous bar indicating presence 0 = Disabled = = 1
of voltage 1 = Enabled
7 Allocation of SIME HOME channels 0 = Not assigned = = 1
1 = Circuit 1
2 = Three-zone circuit
8 Fan rpm Step ignition 0,0 ... 81
rpmx100 0,1 from 0,1 to 19,9 0,0
1 from 20 to 81
9 Long chimneys 0 ... 20 % 1 0
10 Remote control option setting 1 = SIME HOME = = 1
2 = CR 53
3 = RVS 43.143
4 = RVS 46.530
5 = RVS 61.843
11 Correction values external sensor -5 ... +5 °C 1 0
12 Backlighting duration -- = Always sec. x 10 1 3
0 = Never
1 ... 199
13 Modulating pump speed -- = None % 10 Au
Au = Automatic mod.
30...100 = % Settable
modulation
14 Setting second input TA -- = Contact TA -- -- --
5...160 = Input 0...10VDC
15 Cascade address -- = Not enabled -- 1 --
0 = Master
1...7 = Slaves
16 ModBus address -- = Not enabled -- 1 --
1...31 = Slaves
17 ModBus communication configuration 1 ... 30 -- 1 25
19 Type circuit 0 = Two zones -- -- 0
1 = Three zones
D.H.W. - HEATING
PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT
MEASUREMENT UNIT SETTING
20 Minimum heating temperature Zone 1 PAR 64 OEM ... PAR 21 °C 1 20
21 Maximum heating temperature Zone 1 PAR 20 ... PAR 65 OEM °C 1 80
22 Heating curve slope Zone 1 3 ... 40 -- 1 20
23 Minimum heating temperature Zone 2 PAR 64 OEM ... PAR 24 °C 1 20
24 Maximum heating temperature Zone 2 PAR 23 ... PAR 65 OEM °C 1 80
25 Heating curve slope Zone 2 3 ... 40 -- 1 20
26 Minimum heating temperature Zone 3 PAR 64 OEM ... PAR 27 °C 1 20
27 Maximum heating temperature Zone 3 PAR 26 ... PAR 65 OEM °C 1 80
28 Heating curve slope Zone 3 3 ... 40 -- 1 20
29 Δt heating circuit 10 ... 40 °C 1 20
30 Post-circulation heating time 0 ... 199 Sec. 10 30
31 Maximum heating capacity 30 ... 100 % 1 100
32 Zone 1 pump activation delay 0 ... 199 10 sec. 1 1
33 Start-up delay 0 ... 10 Min. 1 3
34 Additional source activation threshold -- , -10 ... 40 °C 1 “- -”
35 Boiler antifreeze 0 ... +20 °C 1 3
36 External sensor antifreeze -5 ... +5 °C 1 -2
37 Band saturation -- =
Disabled % 1 100
flowmeter modulation 0 ... 100
38 D.H.W. post-circulation time 0 ... 199 Sec. 1 0
39 Anti-legionella 0 =
Disabled -- -- 0
(only D.H.W tank)) 1 =
Enabled
GAS MODEL PAR 1
Single (70 R ErP) 58
METHANE
(G 20)
Sequence/cascade 6
Single (70 R ErP) 59
PROPANE
(G 31)
Sequence/cascade 14
