SIMONSWERK SIKU RB Type 5 User manual

Telescope jig SIKU RB Type 5
01.08.2021 © SIMONSWERK GMBH
While every due care has been taken, we cannot be held responsible for errors, omissions or defects. www.simonswerk.com
Telescope jig SIKU RB
Type 5
for drilling of SIKU RB
Note
Fitting instructions
1. Adjust the end stops with regard to the upper hinge position.
The jig can now be used for both right and left hand mounting.
2. Place door into frame and use spacer blocks to create
clearance as per profile manufacturer's instructions.
3. Place telescopic serial drilling jig on the door leaf and adjust
the outer drilling jigs so that the stops rest against the door at
top and at the bottom (the middle drilling jig is centred
automatically).
4. Clamp telescopic serial drilling jig in place and drill holes with
Ø 5,0 mm drill bit.
Scope of supply
1 x telescopic serial drilling jig
2 x end stops
1 x drill bit Ø 5,0 mm
1 x torx wrench T30
1 x fitting instruction
Note
Also available as drilling jig SIKU RB simultaneous fitting.
Item
Finish(es) without (000)
VPE pack of 1
DIN DIN right and left hand
Item No. 5 260508 0 00001
EAN 4015471108397
