Simpli Home AXCART17-RNAB User manual

Model # AXCART17-RNAB
Artisan / Holden / Stratford
Tall TV Media Stand
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customer[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
May require 2 people for ease of assembly.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
5

Care & Maintenance
• Do not use abrasive cleaners
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
This furniture is designed for indoor use.
• Dust with soft dry cloth
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
• Do not use liquid or aerosol products
• For soil build-up, wipe with damp cloth & dry
• Don't over-humidify; that can damage wood by causing it to expand and contract
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
To help protect your wood furniture, take these steps:
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
6

WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip over
onto a child and cause physical injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of fire
and electric shock that is associated with the use of electrical components such as
operation, user-maintenance, loading, storage and as applicable electrical issues
including grounding or double-insulation.
Improper use of furniture to support TVs may result in serious injury or death.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves or
place heavy items on top shelves or drawers.
WARNING
The recommended maximum width of the television intended for use is 60 inch (152.4 cm).
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58
cm). For use with televisions weighing 200 lbs or less. Using larger or heavier televisions may
cause instability or tip over which can lead to serious injury or even death.
MAXIMUM LOAD 25 LBS
MAXIMUM LOAD 200 LBS
7

TOP
QTY 1
LEFT SIDE
QTY 1
RIGHT SIDE
QTY 1
CENTRE SHELF
QTY 1
BOTTOM SHELF
QTY 1
LEFT DIVIDER
QTY 1
RIGHT DIVIDER
QTY 1
DOOR (L&R Same)
QTY 2
SHELF PART
QTY 4
Front
/
Avant
Front / Avant
Front /
Avant
Front /
Avant
Front
/
Avant
Front /
Avant
V16-BRV16-BLV16-A
V16-ELV16-DV16-C
V16-GV16-FV16-ER
8
Part Description
Pre-Assembly Information Model # AXCART17-RNAB

SHELF PART
QTY 1
BACK PANEL
QTY 1
BACK PANEL
QTY 1
LEFT BACK PANEL
QTY 1
DRAWER FRONT
QTY 2
LEFT DRAWER SIDE
QTY 2
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
RIGHT DRAWER SIDE
QTY 2
RIGHT BACK PANEL
QTY 1
Warning Label
BOTTOM SUPPORT LEG
QTY 1
V16-JV16-IV16-H
V16-LV16-KRV16-KL
V16-NV16-MRV16-ML
V16-PV16-O
9
Part Description
Pre-Assembly Information Model # AXCART17-RNAB

1 2 3
4 5 6
7
10
8 9
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
PHILLIPS SCREW
M3 X 12 mm
QTY 12
HANDLE
M4 X 30 mm
QTY 4 SETS
CAM LOCK PIN
CAM LOCK
QTY 20 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 8
MAGNET AND PLATE
QTY 2 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 25
SHELF SUPPORT
QTY 30
Required -
Not Included
Phillips screwdriver
Flathead screwdriver
11
( )1 is extra
a. M4 X 25 - QTY 2
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
PHILLIPS SCREW
M4 X 30 mm
QTY 4
10
Hardware Description
Pre-Assembly Information Model # AXCART17-RNAB

Front
/
Avant
Front /
Avant
Front
/
Avant
Front /
Avant
Front
/ Avant
Front / Avant
V16-A
V16-KR V16-I V16-KLV16-EL V16-ERV16-BL V16-BRV16-H
V16-J
V16-K
V16-N
V16-G V16-DV16-F V16-P V16-C V16-G V16-F
V16-MR
V16-O V16-LV16-ML
11
Components - Key Diagram Model # AXCART17-RNAB

1. Slide Drawer Bottom V16-O firmly into slots on Drawer Sides V16-ML , V16-MR and
Drawer Front V16-L .
B
2
2. Align Cam Lock Pins with guide holes and attach Drawer Sides V16-ML , V16-MR .
3. Insert 2 Cam Locks 2 into guide holes on each Drawer Side V16-ML , V16-MR .
1. Attach 4 Cam Lock Pins 2 to back of Left Drawer Front V16-L .
4. Use flathead screwdriver to secure Cam Locks.
V16-MR
V16-ML
V16-L
V16-MR
V16-ML
V16-L
V16-O
Step 1
Step 2
Assembly Model # AXCART17-RNAB
12

1. Align Drawer Back V16-N with Drawer Bottom V16-O and press firmly into slot.
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
3. Use Allen Key 3 to tighten screws. Do not over tighten.
1. Use Phillips screwdriver to attach Handle 7 to Drawer Front V16-L .
Repeat Step 1-4 for the second drawer.
B
1
3
7
V16-MR
V16-ML
V16-L
V16-O
V16-N
V16-L
Step 3
Step 4
Assembly Model # AXCART17-RNAB
13

4. Use flathead screwdriver to secure Cam Locks.
1. Attach 3 Cam Lock Pins 2 to each Divider V16-EL , V16-ER .
3. Insert 6 Cam Locks 2 into guide holes on Center Shelf V16-C .
2. Align Cam Lock Pins with guide holes and attach Center Shelf V16-C .
Front
/ Avant
Front
/
Avant
2
V16-C
V16-EL
V16-ER
Step 5
Assembly Model # AXCART17-RNAB
14

1. Attach Dividers V16-EL , V16-ER to Bottom Shelf V16-D using 6 Allen Key Screws 1
through guide holes.
1
3
Front /
Avant
Front / Avant
Front
/
Avant
V16-D
V16-EL
V16-ER
Step 6
Assembly Model # AXCART17-RNAB
15

Bottom Shelf V16-D .
2. Align Cam Lock Pins with guide holes on Bottom Shelf V16-D and attach
3. Insert 6 Cam Lock 2 into guide holes on Bottom Shelf V16-D .
1. Attach 6 Cam Lock Pins 2 to 2 Sides V16-BL , V16-BR using pre-drilled holes.
4. Use a flathead screwdriver to tighten Cam Locks into Pins.
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/ Avant
Front
/ Avant
Right
Left
22
V16-D
V16-BL
V16-BR
Step 7
Assembly Model # AXCART17-RNAB
16

1. Attach Bottom Support Leg V16-P to Bottom Shelf V16-D using 4 Phillips Screws 10.
2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
Front / Avant
Front
/
Avant
Front
/
Avant
Front
/
Avant
Front
/ Avant
10
V16-P
V16-D
V16-BL
V16-BR
V16-P
Step 8
Assembly Model # AXCART17-RNAB
17

1. Attach Top V16-A to 2 Sides V16-BL , V16-BR and 2 Dividers V16-EL , V16-ER using
Allen Key Screws 1 through guide holes.
2. Use Allen Key 3 to tighten screws. Do not over-tighten.
Front / Avant
Front /
Avant
Front
/
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
1
3
1
3
V16-BR
V16-BL
V16-EL
V16-ER
V16-A
Step 9
Assembly Model # AXCART17-RNAB
18

Front
/ Avant
Front /
Avant
Front
/
Avant
Front / Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
Front
/
Avant
Warning Label
1. Use Phillips screws Round Head 6 to attach Back Panels V16-I , V16-J , V16-KL ,
V16-KR through guild holes.
2. Use Phillips screwdriver to tighten screws.
6
Note:
The back of the tv frame does not have
pre-drilled holes to aach the back panels.
V16-I
V16-J
V16-KR
V16-KL
V16-KR
V16-KL
V16-I
V16-J
Step 10
Assembly Model # AXCART17-RNAB
19

holes on hinges).
1. Attach hinges on Doors V16-F to Sides V16-BL , V16-BR using Phillips Screws 4 into
2. Attach Magnet Plates 8 to bottom corners of Doors V16-F using Phillips Screws 5 into
pre-drill holes on Doors V16-F .
- Adjust the door to ensure they are aligned straight & square with bottom shelf & side.
- Using Phillips screwdriver to attach Screws 4 at middle hole of hinges for both top &
3. Attach Magnets 8 using Phillips Screws 5 into pre-drill holes on Bottom Shelf V16-D .
bottom hinges.
pre-drill holes:
4. Use Phillips screwdriver to attach Handles 7 to Doors V16-F .
- Using Phillips screwdriver to tighten the rest of screws 4 into pre-drill holes ( top & bottom
8
5
5
8
7
First Step Last Step ( after adjust the door )
4
4
4
V16-BL
V16-F
V16-D
V16-F
V16-BR
Step 11
Assembly Model # AXCART17-RNAB
20
