Simpli Home brooklyn + max WyndenHall AXCAMH39-HIC User manual

Amherst / Halifax / Washington
Wide 3 Door Storage Cabinet
Model # AXCAMH39-HIC
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more slowly
than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
·Don't over-humidify; that can damage wood by causing it to expand and contract
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
·If you can avoid it, don't put furniture near heating vents; if you can’t, keep the
item 3 to 4 inches away from the wall, giving the heat and air space to circulate
·Dust with soft dry cloth
·Do not use liquid or aerosol products
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry
·Do not use abrasive cleaners
Care & Maintenance
6

.A
Part Description
Model # AXCAMH39-HICPre-Assembly Information
7
.BL .BR
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
LEFT BACK PANEL
QTY 1
CENTER BACK PANEL
QTY 1
RIGHT BACK PANEL
QTY 1
Warning Label
.C.D.E
.FL .FR .G .GL
.GR .G
Front /
Avant
Front /
Avant
Front /
Avant
SHELF
QTY 3
LEFT DOOR
QTY 2
BOTTOM SHELF
QTY 1
DIVIDER
QTY 2
RIGHT DOOR
QTY 1
BOTTOM SUPPORT LEG
QTY 1
.H
Front /
Avant
Front /
Avant

.1
Hardware Description
Model # AXCAMH39-HICPre-Assembly Information
8
HANDLE
M4 X 25 mm
QTY 3 SET
ALLEN KEY SCREW
M6 X 30mm
QTY 18
ALLEN KEY
QTY 1
MAGNET AND PLATE
QTY 3 SETS
SHELF SUPPORT
QTY 18
PHILLIPS SCREW
M3 X 15mm
QTY 12
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
CAM LOCK PIN
CAM LOCK
QTY 6 SETS
.2.3.4
.5.6.7.8
.9.10 .11
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 34
PHILLIPS SCREW
M4 X 15mm
QTY 36
ADJUSTABLE HINGE
QTY 6
.13
.12
WOOD DOWEL
Ø8 X 30mm
QTY 4
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
PHILLIPS SCREW
M4 X 25mm
QTY 4

Model # AXCAMH39-HICComponents - Key Diagram
9
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front/
Avant
A
CC
BL
BR
GR
GGL
E
E
E
FL
FL
FR
D
H

10
Model # AXCAMH39-HICAssembly
Step 1
P
X
1. Attach three Cam Lock Pins 2 into pre-drilled holes on each part BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 3 into guide holes on Bottom Shelf D .
4. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
Front / Avant
Front /
Avant
BL
BR
22
2
3
3
3
Front / Avant
D

Step 2
11
Model # AXCAMH39-HICAssembly
Front / Avant
Front / Avant
C
Front / Avant
Front /
Avant
1. Use thee Allen Key Screws 1
to attach each part C through guide holes
from part D to pre-drilled holes of parts C .
2. Use Allen Key 4 to tighten Screws. Do not over-tighten.
C
Front / Avant
D
1
1
14
Front / Avant
Front /
Avant
C
C
Front / Avant
D

Step 3
12
Model # AXCAMH39-HICAssembly
BL
BR
Front / Avant
Front / Avant
1. Align Cam Lock Pin and Wood Dowels with guide holes
and attach parts BL , BR to part D .
2. Insert six Cam Locks 2 into guide holes on part D .
3. Use Phillips screwdriver to secure Cam Locks. Do not over-tighten.
Front / Avant
C
Front / Avant
C
Front /
Avant
D
BL
Front /
Avant
BR
Front / Avant
Front / Avant
C
Front / Avant
C
2
2
2
Front / Avant
D

Step 4
13
Model # AXCAMH39-HICAssembly
1
4
1
1
4
1
Front / Avant
Front / Avant
Front / Avant
1. Use three Allen Key Screws 1 to attach each part BL , BR , C through guide
holes each part BL , BR , C to pre-drilled holes of Top A .
2. Use Allen Key 4 to tighten Screws. Do not over-tighten.
C
Front / Avant
C
Front / Avant
BR
Front / Avant
BL
Front / Avant
Front / Avant
Front / Avant
A

Step 5
14
Model # AXCAMH39-HICAssembly
A
BL
BR
1. Align Bottom Support Leg H with pre-drilled holes on back of Bottom Shelf D .
Use Phillips Screwdriver to tighten four Phillips Screws 11 .
Front /
Avant
A
BL
BR
Front /
Avant
11
HD

Step 6
15
Model # AXCAMH39-HICAssembly
1. Attach the Back Panels GL , GR , G to back frame using Phillips Screws
Round Head 10 through guide holes from Back Panels.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
Note:
The back of the cabinet frame does not have pre-drilled holes to attach the back panels.
Warning Label
Front / Avant
Front /
Avant
10
GR
GL
G
GR
GL
G

Step 7
16
Model # AXCAMH39-HICAssembly
FL FR
9
8
1. Attach Adjustable Hinges 8 to Doors FL , FR
using Phillips Screws 9 into pre-drilled holes on Doors FL , FR .
2. Attach Adjustable Hinges 8 on Doors FL , FR to parts BL , BR , C
using Phillips Screws 9 into pre-drilled holes on parts BL , BR , C .
3. Use Phillips screwdriver to snugly tighten screws. Do not over-tighten.
8
9
FL
FL
FR
BL
BR
C
C

Step 8
17
Model # AXCAMH39-HICAssembly
Tighten the Screw marked II to fasten hinge. The door may need to
be adjusted so that all the spaces between the door and the unit sides are equal.
To adjust, follow instructions:
1. Side adjustment 4 mm
To move the door towards the side panel, loosen screw I and tighten screw II .
To move the door away from the side panel, loosen screw II and tighten screw I .
2. Depth adjustment 4 mm
Loosen screw II ( just one turn ), adjust door to desired position, re-tighten screw.
3. Height adjustment
Loosen screw 9 , adjust door to desired position, re-tighten screw.
9
II I
IMPORTANT NOTE:

Step 9
18
Model # AXCAMH39-HICAssembly
NOTE: The screwdriver is not
included in the hardware pack.
FL
5
1. Attach Magnet Plates 6 to bottom corner of Doors FL , FR using Phillips Screws 7
into pre-drilled holes on Doors FL , FR .
2. Attach Magnets 6 using Phillips Screws 7 into pre-drilled holes Divider C .
3. Use Phillips screwdriver to snugly tighten screw. Do not over-tighten.
4. Use Phillips screwdriver to attach Handles 5 to Doors FL , FR .
FR
7
6
7
6
7
6
C
C
FL

Step 10
19
Model # AXCAMH39-HICAssembly
1. Use four Shelf Supports 12 for each Cabinet Shelf E in desired location.
2. Two Shelf Supports 12 may be used on back top of each Cabinet Shelf E
as a tipping restraint.
shelf level 3
shelf level 2
shelf level 1
shelf support
anti - tipping 12
E
E
E
12

NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
Furniture Tip Over Restraint Assembly
20
Step 11
13
13
