Sauder Shoal Creek 409714 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 397443 10/31/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
4-Drawer Chest
Shoal Creek Collection | Model 409714
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4
5-22
23-25
26-28
29-30
31
409714 www.sauder.com/servicesPae 2
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A2 RIGHT END (1)
B2 LEFT END (1)
C2 TOP (1)
D BOTTOM (2)
D10 RIGHT DRAWER SIDE (1)
D11 LEFT DRAWER SIDE (1)
D132 LARGE RIGHT DRAWER SIDE (3)
D138 LARGE LEFT DRAWER SIDE (3)
D174 DRAWER BACK (1)
D175 LARGE DRAWER BACK (3)
D983 DRAWER BOTTOM (4)
E BACK (1)
G RIGHT FRONT LEG (1)
H LEFT FRONT LEG (1)
I REAR LEG (2)
J2 DRAWER FRONT (1)
M65 DRAWER BRACE (4)
M72 END MOLDING (2)
O2 LARGE DRAWER FRONT (3)
VV LARGE BACK (1)

Part Identification
409714www.sauder.com/services Pae 3
M65
D10
D983
D11
D132
D983
D138
D175
D174
M65
A2
B2
C2
D
E
G
H
I
D
I
VV
M72
M72
J2
O2

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
409714 www.sauder.com/servicesPae 4
40DA UNIVERSAL CABINET RAIL - 840DC DRAWER RIGHT - 4 40DD DRAWER LEFT - 4
SAFETY
STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M SAFETY DRYWALL
ANCHOR - 1
61M
WASHER - 1
13M
BLACK 1-1/8" MACHINE SCREW - 3
21S
METAL
BRACKET - 4
2G
SILVER 3/4" MACHINE SCREW - 12
20S
BLACK 9/16" LARGE HEAD SCREW - 15
1S
BLACK 2-1/4" FLAT HEAD SCREW - 6
26S
7F TWIST-LOCK®
FASTENER - 8
3S GOLD 5/16" FLAT HEAD SCREW - 32
METAL PIN - 4
1R
PULL - 6
7K
10A SLIDE
CAM - 8
BLACK 9/16" FLAT HEAD SCREW - 4
32S
CAM SCREW - 10
8F KNOB - 3 24K
NAIL - 16
1N
HIDDEN
CAM - 10
1F
30S BLACK 1-9/16" FLAT HEAD SCREW - 20
11L WARNING LABEL - 1
(Refer to Step 17 for proper location and application)
WARNING AVERTISSEMENT ADVERTENCIA
Serious or fatal crushing injuries can
occur from furniture tipover.
To help prevent tipover:
• Install tipover restraint provided.
• Place heaviest items in the lower drawers.
• Unless specifically desined to
accommodate, do not set TVs or other
heavy objects on top of this product.
• Never allow children to climb or han on
drawers, doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer
interlock system.
Use of tipover restraints may only reduce,
but not eliminate, the risk of tipover.
This is a permanent label. Do not remove.
Des blessures graves ou fatales par écrasement
peuvent survenir si le mobilier bascule. Pour
prévenir le basculement:
• Installer le dispositif anti-basculement fourni.
• Placer les articles plus lourds dans les tiroirs inférieurs.
• Sauf si le meuble a été conçu spécialement à
cette fin, ne pas mettre de téléviseur ou d’autre
objets lourds sur le dessus de ce meuble.
• Ne jamais laisser d’enfants rimper sur les
tiroirs, les portes ou les étaères ou s’y aripper.
• Ne jamais ouvrir plus d’un tiroir à la fois.
(OU)
• Ne pas démanteler ou enlever le système de
verrouillae pour tiroir.
L’utilisation de dispositifs anti-basculement peut
réduire le risque de basculement, mais pas l’éliminer.
Cette étiquette est permanente. Ne pas l’enlever.
Lesiones graves o fatales por aplastamiento, pueden
ocurrir por el volcar de los muebles. Para ayudar a
prevenir que se volqué:
• Instalar la contención brindada para evitar que se volqué.
• Coloque los artículos más pesados en los cajones
inferiores.
• A menos que sea específicamente diseñado para
acomodar, no establezca televisores u otros objetos
pesados en la parte superior de este producto.
• Nunca permita que los niños se suban o se cueluen
de cajones, puertas o estantes.
• Nunca abra más de un cajón a la vez.
(O)
• No anule o elimine el sistema de bloqueo de los cajones.
El uso de la contención puede solamente reducir, pero
no eliminar, el riesgo de volcar.
Esta es una etiqueta permanente. No remover.
10/16 395783

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
409714www.sauder.com/services Pae 5
Do not tihten the TWIST-LOCK® FASTENERS in this step.
(8 used)
7F
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the lare holes in the ENDS (A2
and B2). Repeat this step for the BOTTOMS (D).
A2
B2
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1620
to watch a video on how to assemble your unit.

Step 2
409714 www.sauder.com/servicesPae 6
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the ede of the board.
Hole
å Push ten HIDDEN CAMS (1F) into the ENDS (A2 and B2)
and DRAWER BRACES (M65).
Arrow
1F
(10 used)
1F
Arrow
A2
B2
M65
M65
M65
M65
Some assembly
(and snacks) required.

Step 3
409714www.sauder.com/services Pae 7
8F
å Turn ten CAM SCREWS (8F) into the FRONT LEGS (G
and H) and DRAWER FRONTS (J2 and O2).
G
H
O2
O2
O2
J2
(10 used)

Step 4
409714 www.sauder.com/servicesPae 8
A2
B2
H
G
å Fasten the ENDS (A2 and B2) to the FRONT LEGS (G and H).
Tihten six HIDDEN CAMS.
1
2
LEFT END ASSEMBLY
RIGHT END ASSEMBLY
Surface with
HIDDEN CAMS
Ede with
TWIST-LOCK®
FASTENERS
These surfaces
should be even.
The FRONT LEG will
overhan this ede.
Surface with
HIDDEN CAMS
These surfaces
should be even.
Ede with
TWIST-LOCK®
FASTENERS
The FRONT LEG will
overhan this ede.

Step 5
409714www.sauder.com/services Pae 9
A2
B2
M72
M72
å Lay the ENDS (A2 and B2) flat on the floor exactly as shown.
å Turn four BLACK 9/16" FLAT HEAD SCREWS (32S) into the
ENDS (A2 and B2) until the shoulders of the SCREWS rest on
the surfaces of the ENDS.
å NOTE: Do not overtihten the SCREWS.
å Slide the END MOLDINGS (M72) onto the ENDS (A2 and B2).
Line up the rooves in the MOLDINGS over the heads of the
SCREWS in the ENDS.
å NOTE: If the MOLDING comes up o of the SCREWS, remove it and
slide it on aain.
LEFT END ASSEMBLY
RIGHT END ASSEMBLY
These edes
should be even.
These edes
should be even.
Shoulder
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
Shoulder
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
32S
32S

Step 6
409714 www.sauder.com/servicesPae 10
å Stand the ENDS (A2and B2) upriht as shown and fasten
the REAR LEGS (I) to the ENDS (A2 and B2). Use six
BLACK 2-1/4" FLAT HEAD SCREWS (26S) .
LEFT END ASSEMBLY
RIGHT END ASSEMBLY
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
These surfaces
should be even.
Ede with
TWIST-LOCK®
FASTENERS
Ede with
TWIST-LOCK®
FASTENERS
These surfaces
should be even.
The BACK LEG will
overhan this ede.
The BACK LEG will
overhan this ede.
BLACK 2-1/4" FLAT HEAD SCREW
(6 used in this step)
26S
I
I
26S
A2
B2

Step 7
409714www.sauder.com/services Pae 11
å Fasten the UNIVERSAL CABINET RAILS* (40DA) to the
ENDS (A2 and B2). Use sixteen GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #4.
å *patent pendin lide system
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
3
2
1
1
2
3
4
4
Glide end
Glide end
A2
B2
H
G
1
2
3
41
2
3
4
1
2
3
4
3
2
1
4
3
2
1
4
3
2
1
4
Surface
with
TWIST
-
LOCK®
FASTENERS
Surface
with
TWIST
-
LOCK®
FASTENERS
VIEW THE DRAWER GLIDE VIDEO

Step 8
409714 www.sauder.com/servicesPae 12
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
å Fasten the LEFT END (B2) to the TOP (C2). Tihten
two TWIST-LOCK® FASTENERS.
Dowel end
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
B2
C2
Finished ede
Surface
with holes
H
This hole
must be here.
Surface with
TWIST-LOCK®
FASTENERS

å Fasten four METAL BRACKETS (2G) to the BACK (E). Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the METAL BRACKETS are even with the ede of the BACK.
å Fasten the BACK (E) to the LEFT END (B2). Use two BLACK 9/16" LARGE HEAD SCREWS (1S) throuh the METAL
BRACKETS on the BACK and into the LEFT END.
Step 9
409714www.sauder.com/services Pae 13
B2
E
E
2G
2G
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
Surface with
METAL BRACKETS
The six holes on the
other surface should
be closer to this ede.

Step 10
409714 www.sauder.com/servicesPae 14
å Insert a METAL PIN (1R) into the hole in each short ede
of the BOTTOMS (D).
å Fasten the BOTTOMS (D) to the LEFT END (B2). Tihten
two TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert
into the holes in the LEFT END.
Don't worry. It isn't
Rome. This can be built
in a day.
D
D
1R
1R
Surface without
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Finished ede
Finished ede
B2

Step 11
409714www.sauder.com/services Pae 15
å Fasten the RIGHT END (A2) to the TOP (C2) and BOTTOMS (D). Tihten four
TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert into the holes
in the RIGHT END.
å Fasten the RIGHT END (A2) to the BACK (E). Use two BLACK 9/16" LARGE HEAD
SCREWS (1S) throuh the METAL BRACKETS on the BACK and into the RIGHT END.
D
D
C2
A2
E
Surface without
TWIST-LOCK®
FASTENERS
G
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
1S

Step 12
409714 www.sauder.com/servicesPae 16
E
Printed
information
must be
facin up.
NAIL
(16 used in this step)
1N
VV
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
The perforation
should be here.
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
å Carefully turn your unit over onto its front edes. Lay the LARGE
BACK (VV) over your unit.
å Turn six BLACK 9/16" LARGE HEAD SCREWS (1S) into the bottom
ede of the LARGE BACK (VV) and into the BACK (E). Do not completely
tihten the SCREWS at this time.
å Then, makin sure that the top ede of the LARGE BACK (VV) sits
slihtly below the top ede of your unit, fasten the top and side edes
of the LARGE BACK to your unit usin the NAILS (1N).
å Now, completely tihten the SCREWS in the bottom ede of the
LARGE BACK (VV).
å NOTE: A perforation has been provided for access throuh the LARGE BACK.

Step 13
409714www.sauder.com/services Pae 17
å Insert the LARGE DRAWER SIDES (D132 and D138)
at an angle into the slot at each end of the LARGE
DRAWER FRONT (O2).
å Slide the DRAWER BOTTOM (D983) into the grooves
in the LARGE DRAWER SIDES (D132 and D138) and
LARGE DRAWER FRONT (O2).
å Fasten the DRAWER BRACE (M65) to the LARGE
DRAWER FRONT (O2). Tighten one HIDDEN CAM.
å Fasten the LARGE DRAWER BACK (D175) to the LARGE
DRAWER SIDES (D132 and D138) and DRAWER
BRACE (M65). Use five BLACK 1-9/16" FLAT HEAD
SCREWS (30S). Repeat this step for the other large drawers.
The smaller drawer will use DRAWER FRONT (J2), DRAWER
SIDES (D10 and D11), and DRAWER BACK (D174).
The tabs should insert freely into the
slots. Gently tilt the DRAWER SIDES side
to side until the tabs slip into the slots.
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
O2
M65
VIEW THE T-LOCK BOX VIDEO
D138
D132
D138
D983
D132
D132
D138
D175
Unfinished
surface
O2
O2
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(20 used in this step)
30S
M65
1
2
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
Surface with
HIDDEN CAM

Step 14
409714 www.sauder.com/servicesPae 18
å Insert a SLIDE CAM (10A) into the LARGE DRAWER SIDES (D132 and D138).
å Fasten a DRAWER RIGHT (40DC) to the LARGE RIGHT DRAWER SIDE (D132) and a DRAWER LEFT (40DD) to the LARGE
LEFT DRAWER SIDE (D138). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #2.
å NOTE: The screw head in the CAM must be visible throuh the slotted hole in the SLIDE.
å NOTE: The lides are not intended to rotate.
å Repeat this step for the other drawers.
1
2
1
2
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
(4 screws per drawer)
Glide end
Glide end
D138
D132
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
VIEW THE DRAWER GLIDE VIDEO

Step 15
409714www.sauder.com/services Pae 19
å Fasten three KNOBS (24K) to the DRAWER FRONT (J2). Use
three BLACK 1-1/8" MACHINE SCREWS (21S).
å Fasten two PULLS (7K) to the LARGE DRAWER FRONT (O2).
Use four SILVER 3/4" MACHINE SCREWS (20S).
å Repeat this step for the other lare drawers.
7K
24K
BLACK 1-1/8" MACHINE SCREW
(3 used for the KNOBS)
21S
SILVER 3/4" MACHINE SCREW
(12 used for the PULLS)
20S
O2
J2
Want options? Customize
your item with add-on
hardware kits available
on sauder.com.

Step 16
409714 www.sauder.com/servicesPae 20
60M
61M
BLACK 9/16" LARGE HEAD SCREW
(1 used in this step)
1S
13M
å Carefully stand your unit upriht.
å Position your unit in its final location. We recommend usin the SAFETY STRAP (60M) for added stability.
å NOTE: Do not turn the SAFETY DRYWALL ANCHOR (61M) into a wall stud. If you prefer to fasten the SAFETY
STRAP (60M) to a wall stud, o to your local hardware store for proper hardware.
å INSTALLATION INSTRUCTIONS: (Also available at www.yl-anchors.com)
1. Insert the SAFETY DRYWALL ANCHOR (61M) throuh the WASHER (13M) and one end of the SAFETY STRAP (60M).
2. Usin a Phillips screwdriver or a hand drill, press the screw slihtly onto the drywall.
3. Apply pressure; turn the screw until a pilot hole is made and the nylon sheath slips throuh.
4. Turn the screw until it is flush aainst the wall and you feel a firm resistance.
5. Continue to turn until the screw starts spinnin freely.
å Carefully cut out the perforated hole in the LARGE BACK (VV). Insert the other end of the SAFETY STRAP (60M) throuh
this hole, then use a BLACK 9/16" LARGE HEAD SCREW (1S) throuh the SAFETY STRAP and into the pre-drilled hole in
the underside of the TOP.
å NOTE: Before movin your unit to a dierent location, unscrew the SAFETY DRYWALL ANCHOR (61M) from your wall.
The nylon sheath will remain behind your wall.
VV
