Simpli Home AXCHOL005-72-NAB User manual

Artisan / Holden / Stratford
72 inch TV Media Stand
Model # AXCHOL005-72-NAB
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customer[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
May require 2 people for ease of assembly.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
5

Care & Maintenance
• For soil build-up, wipe with damp cloth & dry
This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
• Dust with soft dry cloth
• Do not use liquid or aerosol products
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
To help protect your wood furniture, take these steps:
• Don't over-humidify; that can damage wood by causing it to expand and contract
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• Do not use abrasive cleaners
6

WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip over
onto a child and cause physical injury or death.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves or
place heavy items on top shelves or drawers.
Improper use of furniture to support TVs may result in serious injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of fire
and electric shock that is associated with the use of electrical components such as
operation, user-maintenance, loading, storage and as applicable electrical issues
including grounding or double-insulation.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58
cm). For use with televisions weighing 220 lbs or less. Using larger or heavier televisions may
cause instability or tip over which can lead to serious injury or even death.
The recommended maximum width of the television intended for use is 80 inch (203.2 cm).
MAXIMUM LOAD 220 LBS
MAXIMUM LOAD 25 LBS
7

A
TOP
QTY 1
TOP SHELF
QTY 1
BOTTOM SHELF
QTY 1
B C
LEFT BACK PANEL
QTY 1
DL
RIGHT BACK PANEL
QTY 1
DRD1
TOP BACK PANEL
QTY 1
D2
BOTTOM BACK PANEL
QTY 1
LEFT SIDE
QTY 1
EL
RIGHT SIDE
QTY 1
ER
Front
/
Avant
Front
/ Avant
Front / Avant
Front /
Avant
Warning Label
8
Pre-Assembly Information Model # AXCHOL005-72-NAB
Part Description

LEFT DIVIDER
QTY 1
FL
RIGHT DIVIDER
QTY 1
FR
LEFT MIDDLE DIVIDER
QTY 1
GL
RIGHT MIDDLE DIVIDER
QTY 1
GR
TOP DIVIDER
QTY 1
H
CENTER SHELF
QTY 1
I
SHELF
QTY 2
J
LARGE DOOR (L&R Same)
QTY 2
K
SMALL DOOR (L&R Same)
QTY 2
L
Front /
Avant
Front
/ Avant
Front
/
Avant
Front
/
Avant
Front / Avant
9
Pre-Assembly Information Model # AXCHOL005-72-NAB
Part Description

M
BOTTOM SUPPORT LEG
QTY 2
N O
DRAWER FRONT
QTY 1
FLIP DOWN DOOR
QTY 1
PL
LEFT DRAWER SIDE
QTY 1
PRQ
RIGHT DRAWER SIDE
QTY 1
DRAWER BACK
QTY 1
R
DRAWER BOTTOM
QTY 1
10
Pre-Assembly Information Model # AXCHOL005-72-NAB
Part Description

1243
5 6 8
7
9
13
10 12
11
ALLEN KEY SCREW
M6 X 30 mm
QTY 43
PHILLIPS SCREW
ROUND HEAD
M4 X 15 mm
QTY 39
PHILLIPS SCREW
M3 X 12 mm
QTY 24
HANDLE
M4 X 30mm
QTY 6 SETS
PHILLIPS SCREW
M4 X 30 mm
QTY 8
PHILLIPS SCREW
M4 X 15 mm
QTY 6
ALLEN KEY
QTY 1
SHELF SUPPORT
QTY 12
LATCH
QTY 1 SET
CAM LOCK PIN
CAM LOCK
QTY 19 SETS
MAGNET AND PLATE
QTY 4 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 20
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
11
Pre-Assembly Information Model # AXCHOL005-72-NAB
Hardware Description

Front
/ Avant
Front
/
Avant
Front /
Avant
Front
/ Avant
Front /
Avant
Front
/ Avant
Front /
Avant
DL
A
DR
D1
D2
EL
ER
FL
FR
GLGR
PL
PR
H
CJ
K
L
J
L
K
I
N
B
M
M
Q
O
R
12
Components - Key Diagram Model # AXCHOL005-72-NAB

1. Slide Drawer Boom R firmly into slots on Drawer Sides PL , PR and Drawer Front O .
PL
PR
O
2
1. Aach 4 Cam Lock Pins 2 into pre-drilled holes at the back of Drawer Front O .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides PL , PR .
3. Insert 2 Cam Locks 2 into guide holes on each Drawer Side PL , PR.
4. Use flathead screwdriver to secure Cam Locks.
O
PR
PL
R
PR
PL
O
2
Step 1
Step 2
Assembly Model # AXCHOL005-72-NAB
13

1. Align Drawer Back Q with Drawer Boom R and press firmly into slot .
2. Aach back using 2 Allen Key Screws 1 through guide holes on each Side PL , PR.
3. Use Allen Key 3 to ghten screws. Do not over-ghten.
1. Use Phillips screwdriver to aach Handle 4 to Drawer Front O .
Step 4
NOTE: The screwdriver is not
included in the hardware pack.
PL
PR
Q
O
R
1
3
O
4
Step 3
Assembly Model # AXCHOL005-72-NAB
14

1. Aach Centre Shelf I to each Middle Divider GL , GR using 3 Allen Key Screws 1 .
2. Use Allen Key 3 to ghten screws. Do not over-ghten.
Front
/ Avant
Front /
Avant
Front /
Avant
I
GL
GR
1
3
Step 5
Assembly Model # AXCHOL005-72-NAB
15

1. Aach 6 Cam Lock Pins 2 into pre-drilled holes at the boom of Top Shelf C .
2. Align Cam Lock Pins with guide holes on Middle Divider GL , GR.
3. Insert 3 Cam Lock 2 into guide holes on each Middle Divider GL , GR.
4. Use flathead screwdriver to secure Cam Lock .
5. Aach Top Divider H to Top Shelf C using 3 Allen Key Screws 1 .
NOTE: The screwdriver is not
included in the hardware pack.
Front
/
Avant
Front / Avant
Front
/
Avant
I
GL
GR
C
H
2
2
2
2
1
2
2
1
3
Step 6
Assembly Model # AXCHOL005-72-NAB
16

1. Aach Top Shelf C to each Divider FL , FR using 3 Allen Key Screws 1 .
2. Use Allen Key 3 to ghten screws. Do not over-ghten.
Front /
Avant
Front /
Avant
Front
/ Avant
Front
/
Avant
Front / Avant
Front
/ Avant
Step 8
1. Aach Boom Shelf B to Dividers FL , FR & GL , GR using 12 Allen Key Screws 1
(3 Allen Key Screws / each Divider ).
2. Use Allen Key 3 to ghten screws. Do not over-ghten.
1
1
1
3
1
1
1
11
1
3
FL
FR
C
FL
FR
GL
Front
/
Avant
Front
/ Avant
Front / Avant
Front /
Avant
Front / Avant
1
GR
B
Step 7
Assembly Model # AXCHOL005-72-NAB
17

Step 9
NOTE: The screwdriver is not
included in the hardware pack.
B
EL
ER
M
M
8
3. Insert 6 Cam Locks 2 into guide holes on Boom Shelf B .
2. Align Cam Lock Pins with guide holes and aach Boom Shelf B .
Use to ghten 8 Screws 8 . Phillips screwdriver Phillips
4. Use flathead screwdriver secure Cam Locks.
5. Aach 2 Boom Support Legs M align with pre-drilled holes at back of Boom Shelf B .
1. Aach 3 Cam Lock Pins 2 into pre-drilled holes on each Side EL , ER.
Front /
Avant
Front
/ Avant
2
2
2
Assembly Model # AXCHOL005-72-NAB
18

Front
/
Avant
Front
/ Avant
A
EL
ER
FR
FL
H
ER
EL
A
FR
H
3. Insert 3 Cam Locks 2 into guide holes on Top Divider H .
5. Aach the Boom of Top A to 2 Sides EL , ER and 2 Dividers FL , FR using 12 Allen Key
2. Align Cam Lock Pins with guide holes on Top Divider H .
4. Use flathead screwdriver to secure Cam Locks.
1. Aach 3 Cam Lock Pins 2 into pre-drilled holes at the boom of Top A ( at center ).
Screws 1 ( 3 Allen Key Screws / each part )
1
3
3
1
1
2
2
2
Front
/
Avant
Front
/ Avant
FL
Step 10
Assembly Model # AXCHOL005-72-NAB
19

Step 11
NOTE: The screwdriver is not
included in the hardware pack.
guild holes from Back Panels to the back of Cabinet.
1. Use Phillips screws Round Head 5 to aach Back Panels DL , DR , D1 , D2 through
2. Use Phillips screwdriver to ghten screws.
Front / Avant
A
D1
D2
DL
DR
5
Warning Label
The back of the tv frame does not have
pre-drilled holes to aach the back panels.
Note:
Assembly Model # AXCHOL005-72-NAB
20
