Simpli Home AXCHOL005 User manual

ARTISAN / HOLDEN / STRATFORD
TALL TV MEDIA STAND
MODEL # AXCHOL005
1/19

DO NOT RETURN
FOR REPLACEMENT PARTS OR OTHER INQUIRIES
PLEASE CONTACT US AT:
simpli home.com/customer-support-
PLEASE ENSURE TO HAVE THE MODEL #
FROM THE PACKAGING OR
INSTRUCTION BOOKLET
2/19

IMPORTANT : Please read this manual carefully before beginning
.assembly of this product Keep this manual for future reference.
SAFETY INFORMATION
CARE and MAINTENANCE
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by children
and pets. Keep children and pets away during assembly. To avoid danger of
suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. We do not recommend the use of power tools for assembly as this
could damage the unit. Only use manual tools.
May require 2 people for ease of assembly.
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure proper
performance and safety of your item.
3/19

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 5 pm EST)
PRE ASSEMBLY INFORMATION-
MODEL # AXCHOL005
A
PARTS DESCRIPTION
CBD
E
I
M
GFH
KJL
ON
TOP
QTY 1
SIDE
QTY 1 PAIR
CENTRE SHELF
QTY 1
BOTTOM SHELF
QTY 1
DIVIDER
QTY 1 PAIR
Back
Side
Front
Side
DOOR
QTY 1 PAIR
SHELF PART
QTY 4
SHELF PART
QTY 1
BACK PANEL
QTY 1
BACK PANEL
QTY 1
BACK PANEL
QTY 1 PAIR
DRAWER FRONT
QTY 2
DRAWER SIDE
QTY 2 PAIRS
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
Back
Side
Front
Side
Front Side
4/19

1
PRE ASSEMBLY INFORMATION-
HARDWARE DESCRIPTION
23
4 5
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 5 pm EST)
6
7
10
8 9
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
PHILLIPS SCREW
M3 X 12 mm
QTY 12
HANDLE
M4 X 25 mm
QTY 4 SETS
CAM LOCK PIN
CAM LOCK
QTY 20 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 8
MAGNET AND PLATE
QTY 2 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 25
SHELF SUPPORT
QTY 30
M4 X 25 - QTY 1
a.
b.
c.
M4 X 15 - QTY 1
M4 X 25 - QTY 1
TIPPING RESTRAINT
QTY 1 SET
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
5/19
MODEL # AXCHOL005

COMPONENTS – KEY DIAGRAM
A
B
B
K
IK
J
E
E
H
C
G
G
N
M
OL
M
F
F
6/19
MODEL # AXCHOL005

ASSEMBLY
STEP 1
STEP 2
B
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front L .
2. Insert 2 Cam Locks 2 into pre-drilled holes on each Drawer Side M .
3. Align Cam Lock Pins with Cam Lock and attach Drawer Side M .
4. Use flathead screwdriver secure Cam Locks.
1. Slide Drawer Bottom O firmly into slots on Drawer Sides M and Drawer Front L .
7/19
MODEL # AXCHOL005

ASSEMBLY
STEP 3
STEP 4
B
1. Align Drawer Back N with Drawer Bottom O and press firmly into slot.
2. Attach back using 2 Allen Key Screws 1 through pre-drilled holes on each side.
3. Use Allen Key 3 to tighten. Do not over tighten.
1. Use Phillips screwdriver to attach Handle 7 to Drawer Front L .
Repeat Step 1-4 for the second drawer .
8/19
MODEL # AXCHOL005

ASSEMBLY
STEP 5
1. Attach 3 Cam Lock Pins 2 to each Divider E .
2. Align Cam Lock Pins with pre-drilled holes and attach Center Shelf C .
3. Insert 6 Cam Locks 2 into pre-drilled holes on Center Shelf C .
4. Use flathead screwdriver secure Cam Locks.
9/19
MODEL # AXCHOL005

ASSEMBLY
STEP 6
B
1. Attach Dividers E to Bottom Shelf D using 6 Allen Key Screws 1 through
pre-drilled holes.
10/19
MODEL # AXCHOL005

ASSEMBLY
STEP 7
1. Attach 6 Cam Lock Pins 2 to 2 Sides B using guide holes.
2. Align Cam Lock Pins with pre-drilled holes on Bottom Shelf D and attach Bottom
Shelf D .
3. Insert 6 Cam Lock 2 into pre-drilled holes on Bottom Shelf D .
4. Using a flathead screwdriver tighten Cam Locks into Pins.
11/19
MODEL # AXCHOL005

ASSEMBLY
STEP 8
B
1. Attach Top A to 2 Sides B and 2 Divider E using Allen Key Screws 1 through pre-
drilled holes.
2. Use Allen Key 3 to tighten screws. Do not over tighten.
12/19
MODEL # AXCHOL005

ASSEMBLY
STEP 9
1. Using Phillips Round Head Screw 6 attach Back Panel I , J , K to back of TV Stand.
13/19
MODEL # AXCHOL005

ASSEMBLY
STEP 10
1. Attach Hinges on Doors F to Sides B using Phillips Screws 4 into guide holes.
2. Attach Magnet Plates 8 to bottom corner of Door F using Phillips Screws 5 into guide
holes on Doors F .
3. Attach Magnet 8 using Phillips Screws 5 into guide holes on Bottom Shelf D .
4. Use a Phillips screwdriver to attach Handles 7 to Doors F .
14/19
MODEL # AXCHOL005

ASSEMBLY
STEP 11
A
B
NOTE: Injuries and damage can occur from furniture tip-over. It is important to use the
safety bracket included. If the tipping restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the furniture.
1. Use Shelf Supports 9 for each Shelf H or G in desired location .
2. 2 Shelf Supports 9 may be used on back top of each Shelf H or G as a tipping
restraint.
B
STEP 12
15/19
MODEL # AXCHOL005

ASSEMBLY
16/19
MODEL # AXCHOL005
STEP 13
1. To attach Tipping Restraint 10 , follow instructions on Tipping Restraint package.
When you determined the location for your unit, install the Furniture Tipping
restraint. Carefully follow the instructions contained on the package.

WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality standards
and are guaranteed for domestic use against manufacturing faults for a period of
12 months from the date of purchase. This warranty does not affect your
statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.) please
contact us at our toll free service line at 1-866-518-0120 ext. 262 from 9 am to 5
pm, Monday to Friday, Eastern Standard Time or by email at
simpli-home.com/customer-support.
We reserve the right to repair or replace the defective product, at its discretion.
This product is guaranteed for 12 months if used for normal purposes. Any
warranty is invalid if the product has been overloaded or subject to neglect,
improper use or an attempted repair by other than an authorized agent. Heavy-
duty or daily professional/commercial usage are not guaranteed.
Due to continuous product improvement, we reserve the right to change the
product specifications without prior notice.
PLEASE NOTE: This item is hand-crafted and hand-finished with utmost care.
As such, variations and imperfections should be expected and should be
welcomed as the natural beauty of the wood.
