Simpli Home brooklyn+max WyndenHall AXCLRY-10-WAL User manual

Lowry / Mitchell / Fulton
Sideboard Buffet
Model # AXCLRY-10-WAL
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH)
in our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to
protect against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly
·Dust with soft dry cloth
·Wipe up spills promptly
·Clean with a dry cloth
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish
·Use soft felt base coasters, placemats to help prevent scratches
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer
·If it can be avoided, do not put furniture near heating vents
·Keep the furniture 3 to 4 inches away from the wall, giving heat and air space to
circulate.
Care & Maintenance
6

.A.B
.E
.G.H
TOP
QTY 1 BOTTOM SHELF
QTY 1 LEFT SIDE
QTY 1
.
L
C
RIGHT SIDE
QTY 1
.
R
C.
L
D.
R
D
LEFT DIVIDER
QTY 1 RIGHT DIVIDER
QTY 1
MIDDLE FRAME
QTY 2
.
L
F.
R
F
LEFT DOOR
QTY 1 RIGHT DOOR QTY 1
SHELF
QTY 2 TOP BACK PANEL QTY 1 BOTTOM BACK PANEL QTY 1
.I
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Warning Label
Part Description
7
Model # AXCLRY-10-WALPre-Assembly Information

RIGHT DRAWER SIDE
QTY 3 DRAWER BACK
QTY 3 DRAWER BOTTOM
QTY 3
.M.N
.O
LEG
QTY 2
DRAWER FRONT
QTY 3 LEFT DRAWER SIDE QTY 3
JOINING STRIP
QTY 1
.
L
L
.
R
L
.K .J
Part Description
8
Model # AXCLRY-10-WALPre-Assembly Information

ALLEN KEY BOLT
M8 x 20 mm
QTY 12
.1.2.3.4
.5.6.7.8
.9.10 .11
ALLEN KEY SCREW
M6 X 30mm
QTY 48
ALLEN KEY
QTY 1
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 28
MAGNET AND PLATE
QTY 2 SETS SHELF SUPPORT
QTY 12
PHILLIPS SCREW
M3 X 15mm
QTY 10
PHILLIPS SCREW
M4 X 15mm
QTY 24
WOOD DOWEL
Ø8 X 30mm
QTY 8
ADJUSTABLE HINGE
Ø35
QTY 4 SETS
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
FURNITURE TIP OVER
RESTRAINT
QTY 1 SET
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
.12
.13
LOCK WASHER
Ø12 / Ø8 x 1.5 mm
QTY 12
WASHER
Ø19 / Ø8 x 1 mm
QTY 12
.14
CAM LOCK PIN
CAM LOCK
QTY 12 SETS
Hardware Description
9
Model # AXCLRY-10-WALPre-Assembly Information

A
H
I
J
O
O
E
C
L
C
R
F R
F L
G
G
D L
D
R
B
K
M
N
L
R
L
L
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
10
Model # AXCLRY-10-WALComponents - Key Diagram

Step 1
P
X
K
K
14
14
1. Attach four Cam Lock Pins 14 to pre-drilled holes at back of Drawer Front K .
2. Use Phillips screwdriver secure Cam Lock Pins.
11
Model # AXCLRY-10-WALAssembly

Step 2
K
L
R
L
L
K
L
R
L L
14
14
1. Align Cam Lock Pins with drilled holes and attach Drawer Sides LL , LR .
2. Insert two Cam Locks 14 into drilled holes on each Drawer Side LL , LR .
3. Use Phillips screwdriver secure Cam Locks.
12
Model # AXCLRY-10-WALAssembly

Step 3
Step 4
K
L R
L
L
N
M
N
K
L
L
L
R
4
5
1. Slide Drawer Bottom N firmly into slots on Drawer Sides LL , LR and
Drawer Front K .
1. Align Drawer Back M with Drawer Bottom N and press firmly into slot .
2. Attach Drawer Back using two Allen Key Screws 4 through drilled holes on
each Side LL , LR .
3. Use Allen Key 5 to tighten screws. Do not over-tighten.
4. Repeat Step 1-4 for the two other drawers.
13
Model # AXCLRY-10-WALAssembly

Step 5
D L D R
D
L
D
R
&
11
11
1. Insert two Dowels 11 into drilled holes on each Left Divider DL and Right Divider DR .
2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/3 length of
Dowels should be exposed.
Front /
Avant
Front /
Avant
Front /
Avant
14
Model # AXCLRY-10-WALAssembly

Step 6
D L
D
R
D
R
E
E
E
E
4
5
4
5
1. Attach Middle Frame E to Right Divider DR and Left Divider DL using twelve Allen
Key Screws 4 ( six Screws / each Divider ).
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
Front / Avant
Front / Avant
Front / Avant
Front / Avant
15
Model # AXCLRY-10-WALAssembly

Step 7
B
TOP VIEW
BOTTOM VIEW
11
11
11
1. Insert four Dowels 11 into drilled holes on Bottom Shelf B .
2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/3 length of
Dowels should be exposed.
Front /
Avant
Front /
Avant
16
Model # AXCLRY-10-WALAssembly

Step 8
B
B
D
L
D R
D
R
D
L
4
5
1. Attach Right Divider DR and Left Divider DL to Bottom Shelf B using six Allen
Key Screws 4 .
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
Front /
Avant
17
Model # AXCLRY-10-WALAssembly

Step 9
1. Attach Bottom Shelf B to Left Side CL using three Allen Key Screws 4 .
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
B
C L
B
C L
4
5
Front / Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front / Avant
18
Model # AXCLRY-10-WALAssembly

Step 10
B
C R
1. Repeat Step 10 for Right Side CR .
B
C
R
4
5
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
19
Model # AXCLRY-10-WALAssembly

Step 11
A
D
R
D
L
C
L
C
R
4
5
4
5
1. Attach Top A to Sides CL , CR using six Allen Key Screws 4
( three Screws / each Side ).
2. Attach Top A to Dividers DL , DR using six Allen Key Screws 4
( three Screws / each Side ).
3. Use Allen Key 5 to tighten screws. Do not over-tighten.
Front / Avant
Front / Avant
Front / Avant
Front / Avant
20
Model # AXCLRY-10-WALAssembly
