Simpli Home Wynden Hall Brooklyn+Max END TABLE AXCBXT-03 User manual

1/13
END TABLE
MODEL # AXCBXT - 03
BRAXTON / ELLERY / HOLT

2/13
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship
your replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
or go to
www.simpli-home.com/parts request
If you wish to return the product, please contact the retailer where the
product was purchased.
In order to assist you in a timely manner, please have the following information ready:
Model # ____________________Part Number or Letter______________________
Purchased at _________________Date of Purchase _________________________

3/13
IMPORTANT : for Please read this manual carefully before beginning
assembly of this product. keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you have
checked that you have all of the parts and hardware required. hardware package
may have spare parts.
WARNING: This item contains small parts which can be swallowed by children
and pets. keep children and pets away during assembly. to avoid danger of
suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid scratches.
If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

4/13
CARE and MAINTENANCE
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH) in
our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing and
roughness. Wood absorbs water as relative humidity rises and falls, and in doing so it
swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and keeps it
looking good for years to come. The wood is sealed and lacquered to protect against
humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly.
·Dust with soft dry cloth.
·Wipe up spills promptly. Clean with a dry cloth.
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish.
·Use soft felt base coasters, placemats to help prevent scratches.
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer.
·If it can be avoided, do not put furniture near heating vents. Keep the furniture
3 to 4 inches away from the wall, giving heat and air space to circulate.

5/13
NEED HELP? for help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm est)
PARTS DESCRIPTION
HARDWARE DESCRIPTION
TOP
QTY 1
A B
C
PRE-ASSEMBLY INFORMATION MODEL # AXCBXT - 03
PRE-ASSEMBLY INFORMATION MODEL # AXCBXT - 03
RIGHT LEG
QTY 1
BOTTOM
QTY 1
D
LEFT LEG
QTY 1
12
34
ALLEN KEY
QTY 1
WASHER
Ø 16 / Ø 6.5 X 1.5 mm
QTY 18
LOCK WASHER
Ø 12 / Ø 6.5 X 1.5 mm
QTY 18
ALLEN KEY BOLT
M6 X 15 mm
QTY 18

6/13
COMPONENTS - KEY DIAGRAM MODEL # AXCBXT - 03
A
B
C
D
P1
P2
P3
P4

7/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 1
1. Align Left Leg D to Top A by matching the letters P1 to P1 .
2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 2
to attach Top A and Left Leg D .
3. Use Allen Key 4 to tighten Bolts. Do not over-tighten.
A
D
P1
2
1
4
A
D
3

8/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 2
B
C
1. Align Leg C to Bottom Shelf B by matching the letters P3 to P3 .
2. Use four Allen Key Bolts 1 , four Lock Washers 3 and four Washers 2
to attach Bottom Shelf B and Leg C (front and back of Leg).
3. Use two Allen Key Bolts 1 , two Washers 2 and two Lock Washers 3
to secure Bottom Shelf B and Leg C (middle of Leg).
4. Use Allen Key 4 to tighten Bolts. Do not over-tighten.
P3
2
1
4
2
3
1
B
A
C
A
3

9/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 3
1. Align Right Leg C to Top A and Bottom Shelf B by
matching the letters P2 to P2 and P4 to P4 .
A
B
C
C
P4
P2

10/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 4
1. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 2
to attach Top A and Right Leg C .
2. Use Allen Key 4 to tighten Bolts. Do not over-tighten.
C
D
B
A
2
1
4
3

11/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 5
1. Use four Allen Key Bolts 1 , four Lock Washers 3 and four Washers 2
to attach Bottom Shelf B and Right Leg C (front and back of Leg).
2. Use two Allen Key Bolts 1 , two Washers 2 and two Lock Washers 3
to secure Bottom Shelf B and Right Leg C (middle of Leg).
3. Use Allen Key 4 to tighten Bolts. Do not over-tighten.
2
14
231
A
B
D
C
3

12/13
ASSEMBLY MODEL # AXCBXT - 03
STEP 6
Note: Levelers on bottom of legs can be adjusted if floor is uneven.

13/13
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing faults
for a period of 12 months from the date of purchase. This warranty does not
affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.) please
contact us at our toll free service line at 1-866-518-0120 ext. 262 from 9 am
to 4 pm, Monday to Friday, Eastern Standard Time or by email at
simpli-home.com/customer-support.
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change the
product specifications without prior notice.
WARRANTY
