Stryker Tru-Fit 3150 Manual

2015/08 B.0 3150-009-001 REV B www.stryker.com
Tru-Fit®Overbed Table
3150
Operations/Maintenance Manual

www.stryker.com 3150-009-001 REV B 3
Return To Table of Contents
Table of Contents
Introduction .............................................................................4
Intended Use .........................................................................4
Specifications ........................................................................4
Warning / Caution / Note Definition.........................................................5
Symbols ................................................................................5
Summary of Safety Precautions ..............................................................6
Operations ..............................................................................7
Single-top With or Without Optional Vanity Operation ...........................................7
Split-top With Optional Vanity Operation .....................................................8
Clip Operation ........................................................................9
Bin Operation .......................................................................10
Preventative Maintenance ..................................................................11
Checklist ...........................................................................11
Cleaning...............................................................................11
Troubleshooting Guide ....................................................................12
Service Information.......................................................................13
Optional Storage Compartment Replacement ................................................13
Primary Top Replacement (Single-top and Single-top With Vanity Only) .............................13
Primary Top Replacement (Split-top With Vanity Only)..........................................14
Secondary Top Replacement (Split-top Only) ................................................14
Upper Column Replacement.............................................................15
Gas Spring Replacement ...............................................................15
Caster Assembly Replacement...........................................................16
Caster Replacement ..................................................................16
Base Cover Replacement...............................................................17
Vanity Tray Replacement (Single-top Only) ..................................................18
Vanity Tray Replacement (Split-top Only) ...................................................18
Vanity Tray Mirror Replacement ..........................................................19
Single-top Overbed Table Assembly, Without Vanity...............................................20
Single-top Overbed Table Assembly, With Vanity .................................................23
Split-top Overbed Table Assembly, Without Storage ...............................................26
Single-top Overbed Table Assembly, With Storage................................................30
Single-top Overbed Table Assembly, With Vanity, With Storage ......................................34
Split-top Overbed Table Assembly, With Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Gas Spring.............................................................................44
Warranty ..............................................................................45
One Year Warranty ...................................................................45
To Obtain Parts and Service ............................................................45
Return Authorization...................................................................45
Damaged Merchandise ................................................................45
International Warranty Clause............................................................45
Service Contract Coverage .............................................................46
Service Contract Programs .............................................................46

4 3150-009-001 REV B www.stryker.com
Return To Table of Contents
4 3150-009-001 REV B www.stryker.com
Introduction
INTENDED USE
This manual is designed to assist you with the maintenance of Stryker Overbed Table, Model 3150. Carefully read
this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of this
equipment, it is recommended that methods and procedures be established for educating and training staff on the safe
operation of this product.
SPECIFICATIONS
OVERBED TABLE WITHOUT OPTIONAL STORAGE COMPARTMENT
Single-top Without Vanity Single-top With Vanity Split-top With Vanity
Base Length 32” 32” 32”
Overall Table Top Length/Width 31” / 17.5” 31” / 17.5” 31” / 17.5”
Minimum/Maximum Table Top Height 27” / 43.75” 27” / 43.75” 29” / 45.5”
Weight of Table 43 pounds 50 pounds 61 pounds
Weight Capacity of Table * 75 pounds 75 pounds 75 pounds
* Safe Working Load 25 lbs
Stryker reserves the right to change specifications without notice.
OVERBED TABLE WITH OPTIONAL STORAGE COMPARTMENT
Single-top Without Vanity Single-top With Vanity Split-top With Vanity
Base Length 32” 32” 32”
Overall Table Top Length/Width 42.75” / 17.5” 42.75” / 17.5” 42.75” / 17.5”
Minimum/Maximum Table Top Height 27” / 43.75” 27” / 43.75” 29” / 45.5”
Weight of Table 68 pounds 75 pounds 86 pounds
Weight Capacity of Table * 75 pounds 75 pounds 75 pounds
SAFE OPERATING LOADS OF OPTIONAL STORAGE COMPARTMENT
Top Shelf 20 pounds
Bottom Shelf 20 pounds

www.stryker.com 3150-009-001 REV B 5
Return To Table of Contents
www.stryker.com 3150-009-001 REV B 5www.stryker.com 3150-009-001 REV B 5
Introduction
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serous adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to the
user or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.
Safe Working Load Symbol
Warning, consult accompanying documentation
Symbols

6 3150-009-001 REV B www.stryker.com
Return To Table of Contents
WARNINGS
• Do not lean on table. Leaning on table may cause the table to tip which may result in injury to the individual or
damage to the unit.
• To avoid personal injury or damage to the table, support the table top before removing the screws or nuts securing
it to the top support.
• To avoid personal injury or damage to the table, while turning the table top over, securely hold the top on the sides
to prevent the primary and secondary tops from separating.
CAUTIONS
• Use discretion in the placement of personal items located near or by biohazardous/unsanitary materials.
• Do not apply lubricant of any kind to the gas spring. Lubricant will damage the gas spring.
• Make sure that nothing is on top of the unit and that you have the unit fully supported so not to cause damage to
the overbed table nor to cause injury to yourself.
Summary of Safety Precautions

www.stryker.com 3150-009-001 REV B 7
Return To Table of Contents
To operate the table:
1. Pull up on the table top to raise it.
2. To unlock and lower the table top, squeeze handle (A) while guiding the table top down.
3. Pull out the optional vanity (B) with the flip up mirror in either direction (if equipped).
WARNING
Do not lean on table. Leaning on table may cause the table to tip which may result in injury to the individual or damage
to the unit.
A
B
SINGLE-TOP WITH OR WITHOUT OPTIONAL VANITY OPERATION
Operations

8 3150-009-001 REV B www.stryker.com
Return To Table of Contents
Operations
To operate the table:
1. Pull up on the table top to raise it.
2. To unlock and lower the table top, squeeze handle (A) while guiding the table top down.
3. Grasp and pull any of the four handles (B) to slide out the secondary top in either direction.
4. Pull out the vanity (C) with the flip up mirror in either direction.
WARNING
Do not lean on table. Leaning on table may cause the table to tip which may result in injury to the individual or damage
to the unit.
A
C
B
B
B
B
(behind mirror)
SPLIT-TOP WITH OPTIONAL VANITY OPERATION

www.stryker.com 3150-009-001 REV B 9
Return To Table of Contents
Operations
To connect a bag to the bag clip:
1. Push the clip back.
2. Insert the waste bag.
3. Release the clip.
WARNING
Do not lean on table. Leaning on table may cause the table to tip which may result in injury to the individual or damage
to the unit.
CLIP OPERATION

10 3150-009-001 REV B www.stryker.com
Return To Table of Contents
To operate the bin:
1. Pull bin out to access storage.
2. Push bin in to close.
WARNING
Do not lean on table. Leaning on table may cause the table to tip which may result in injury to the individual or damage
to the unit.
BIN OPERATION
Operations

www.stryker.com 3150-009-001 REV B 11
Return To Table of Contents
CHECKLIST
_____ All fasteners secure.
_____ Top and laminate intact - not damaged.
_____ Top edge mold intact - not damaged.
_____ Release handle locking and releasing properly.
_____ All casters secure and swiveling properly.
_____ No debris in casters.
_____ Base cover intact - not damaged.
_____ Optional pull-out vanity and mirror intact and secure.
_____ Optional Storage Compartment intact - not damaged.
CAUTION
Do not apply lubricant of any kind to the gas spring. Lubricant will damage the gas spring.
Overbed Table Serial Number:
Completed by: _______________________________________ Date: ___________________
Cleaning
The Center for Disease Control recommends a 1:4 mixture of bleach and water for disinfection. Thoroughly rinse the
solution from the product surface. If other hospital-grade cleaning agents are used, follow the instructions provided by
the cleaning solution’s manufacturer. Wipe the surface with a soft, dry cloth to remove any moisture.
As part of routine maintenance, follow steps 1-5 of the upper column replacement procedure on page 15 to remove
the top assembly from the base assembly. Use a soft cloth to remove dust and debris from the top weldment tube and
the inside of the base column. Spray the top weldment tube with pure silicone spray before reassembly. DO NOT use
WD-40 or any other lubricant or damage to the table could occur.
Preventative Maintenance

12 3150-009-001 REV B www.stryker.com
Return To Table of Contents
Problem / Failure Recommended Action
Table drifts up.
Make sure original table top and storage compartment
(if applicable) remain attached to the base. If so, then
replace the gas spring (see page 15).
Table drifts down without weight on table top. If the table is difficult to raise and drops back down
when released, replace the gas spring (see page 15).
Table has a spongy feeling. This is normal as long as long as it does not drift down.
Table drifts down with weight on table top. Adjust the gas spring lock pin for more clearance so
there is a little play in the handle.
Table randomly drifts down with
light weight load applied. Replace gas spring (see page 15).
Squeaky noise in between base and column. Add 1/4” washers under the four main base bolts.
NOTE: Remove and reinstall bolts one at a time.
Identify the problem from the table below and follow the instructions for resolution. If assistance is needed at any time
during troubleshooting, please contact a service technician at 1-800-327-0770 option 2.
Troubleshooting Guide

www.stryker.com 3150-009-001 REV B 13
Return To Table of Contents
OPTIONAL STORAGE COMPARTMENT REPLACEMENT
Tools Required:
• T25 Torx Driver
• T27 Torx Driver
• Regular Screwdriver
Procedure:
1. Raise the table to its full height.
2. Remove the upper column cover by pulling
outward slightly on both sides and pulling out
and down.
3. Using a regular screwdriver, unlock the lock tabs
and remove the upper column clamp.
4. Using a T25 Torx driver, remove the T25 Torx
screw from the top front of the upper column.
5. Using a T27 Torx driver, remove the two screws
that hold the storage weldment to the upper
weldment.
6. Remove the storage compartment.
7. Reverse this procedure to reinstall the storage compartment.
PRIMARY TOP REPLACEMENT (SINGLE-TOP AND SINGLE-TOP WITH VANITY ONLY)
Tools Required:
• #2 Phillips Screwdriver
WARNING
To avoid personal injury or damage to the table, support the table top before removing the screws securing it to the top
support.
Procedure:
1. If your unit has a storage compartment, follow the procedures above for Storage Compartment Replacement, then
proceed to step 2.
2. Lift the table to its highest height.
3. Using a Phillips screwdriver, remove the four #2 Phillips screws under the table top that hold the top to the support
weldment.
4. Lift off the table top.
5. If your unit has a vanity tray installed, follow steps 5a through 5c. If not, proceed to step 6.
a. Turn the table top over.
b. Using a Phillips screwdriver, remove the ten #10 Phillips screws that hold the vanity tracks to the bottom
of the table top.
c. Remove the vanity tray from the table top.
6. Reverse procedures to install the new top.
Service Information
Upper Column
Cover
Upper Column
Clamp

14 3150-009-001 REV B www.stryker.com
Return To Table of Contents
Service Information
PRIMARY TOP REPLACEMENT (SPLIT-TOP WITH VANITY ONLY)
Tools Required:
• #2 Phillips Screwdriver
• 3/8” Nut Driver
WARNING
To avoid personal injury or damage to the table, support the table top before removing the screws securing it to the top
support.
Procedure:
1. If your unit has a storage compartment, follow the procedures on page 13 for Storage Compartment Replacement,
then proceed to step 2.
2. Lift the table to its highest height.
3. Using a 3/8” nut driver, remove the 3/8” acorn nuts from the bottom of the table at each of the four corners.
4. Lift off the table top.
WARNING
To avoid personal injury or damage to the table, while turning the table top over, securely hold the top on the sides to
prevent the primary and secondary tops from separating.
5. Turn the table top upside down and separate the primary and secondary tops.
6. Using a Phillips screwdriver, remove the six #10 Phillips screws that hold the two slides on the primary table top
and set them aside.
7. Reverse procedures to install the new top.
SECONDARY TOP REPLACEMENT (SPLIT-TOP ONLY)
Tools Required:
• 3/8” Nut Driver
WARNING
To avoid personal injury or damage to the table:
• Support the table top before removing the screws securing it to the top support.
• While turning the table top over, securely hold the top on the sides to prevent the primary and secondary tops
from separating.
Procedure:
1. If your unit has a storage compartment, follow the procedures on page 13 for Storage Compartment Replacement,
then proceed to step 2.
2. Using a 3/8” nut driver, remove the 3/8” acorn nuts from the bottom of the table at each of the four corners.
3. Lift off the table top.
4. Turn the table top upside down and separate the primary and secondary tops.
5. Turn over the secondary top, turn the vanity tray approximately 45 degrees and remove it from the table top.
6. Reverse procedures to install the new top.

www.stryker.com 3150-009-001 REV B 15
Return To Table of Contents
Service Information
UPPER COLUMN REPLACEMENT
Tools Required:
• #2 Phillips Screwdriver
• T25 Torx Driver
• T27 Torx Driver
Procedure:
1. If your unit has a storage compartment, follow the procedures on page 13 for Storage Compartment Replacement,
then proceed to step 2.
2. Using a T25 Torx driver, remove the three T25 Torx screws from the top of the upper column and lower the column
down to the base.
3. Using a T27 Torx driver, remove the two opposing T27 Torx screws that connect the upper bushing to the lower
column.
4. Lift the top assembly straight up and out of the lower column and set it aside.
5. Reverse procedures to reassemble.
GAS SPRING REPLACEMENT
Tools Required:
• T25 Torx Driver
• T27 Torx Driver
• Pliers
Procedure:
1. If your unit has a storage compartment, follow the procedures on page 13 for Storage Compartment Replacement,
then proceed to step 2.
2. Using a T25 Torx driver, remove the three T25 Torx screws from the top of the upper column.
3. Lower the column down to the base.
4. Using a T27 Torx driver, remove the two opposing T27 Torx screws that connect the upper bushing to the lower
column.
5. Using pliers, remove the gas spring release lever (as shown)
from the gas cylinder. Gently push down on the lever and pull
it out while moving it slightly from side to side.
6. Lift the top assembly out of the lower column and set it aside.
7. Remove the rue clip from the clevis pin that holds the gas
spring assembly to the top weldment and remove the clevis
pin.
8. Reverse to install the new gas spring.
NOTES:
When reinstalling the gas cylinder, align the threaded stud
with the hole in the bottom of the lower column before
placing the top assembly above the lower column.
When reinstalling the upper bushing, compress the gas
spring slightly before tightening the two T27 Torx screws
that connect the upper bushing to the lower column.
Gas Spring
Release Lever
Gas Spring Release Lever Removal

16 3150-009-001 REV B www.stryker.com
Return To Table of Contents
CASTER ASSEMBLY REPLACEMENT
Tools Required:
• Cordless Drill, 3/16” Drill Bit
• Pop Rivet Gun with 3/16” Tip
Procedure:
1. Fully raise the table top.
2. While maintaining a secure grip on the table, carefully flip it forward or turn it on its side to allow access to the
damaged caster.
3. Using a cordless drill and 3/16” drill bit, drill out the two rivets and remove the damaged caster.
4. Using a pop rivet gun with a 3/16” tip, install the new caster using two new pop rivets.
Service Information
CASTER REPLACEMENT
Tools Required:
• Wheel removal tool (3150-001-202)
• T27 Torx driver (if needed)
Procedure:
1. Fully raise the table top.
2. While maintaining a secure grip on the table, carefully tip it forward or
turn it on its side to allow access to the damaged caster.
3. For model 3150 overbed tables only, if equipped with leg ballasts,
using a T27 Torx driver, remove the truss head screw to remove the
leg ballast that blocks the removal of the caster wheel. Save all parts.
4. Using the supplied wheel removal tool (3150-001-202), remove the
caster wheel.
NOTE: Make sure that the wheel is facing the wheel removal tool with
the stem facing away from the wheel removal tool.
5. Press to install the new caster wheel (3150-001-201).
6. If equipped, reinstall the leg ballast that was removed in step 3. Using
a T27 torx driver, hand-tighten the truss head screws to secure the leg
ballasts in place.
NOTE: Do not overtighten the screws to avoid stripping them out.
7. Verify proper operation of the product before returning it to service.

www.stryker.com 3150-009-001 REV B 17
Return To Table of Contents
BASE COVER REPLACEMENT
Tools Required:
• #2 Phillips Screwdriver
• T25 Torx Driver
• T27 Torx Driver
• 3/8” Ratchet
• 3/8” Nut Driver
• 7/16” Socket
WARNING
To avoid personal injury or damage to the table, support the table top before removing the screws securing it to the top
support.
Procedure:
1. If your unit has a storage compartment, follow the procedures on page 13 for Storage Compartment Replacement,
then proceed to step 2.
2. While holding the upper column, use a T25 Torx driver and remove the three T25 Torx screws from the top of the
upper column then lower the column down to the base.
3. Using the T27 Torx driver, remove the two opposing T27 Torx screws that conenct the upper bushing to the lower
column.
4. Lift the top assembly straight up and out of the lower column and set it aside.
5. Lift the upper column off the lower column and remove it from the base.
NOTE: It is easier to perform the next step while sitting on a chair.
6. Flip the base and lower column over and rest the lower column on the top of your thigh.
7. Using the T27 Torx driver, remove the four T27 Torx screws from the bottom of the base that hold the column
assembly and remove the lower column.
8. Turn the base and cover over. Using the Phillips screwdriver, remove the six #8 Phillips screws that hold the cover
to the base.
9. Turn the base back over and remove the cover.
10. Reverse procedures to install the new cover.
Service Information

18 3150-009-001 REV B www.stryker.com
Return To Table of Contents
Service Information
VANITY TRAY REPLACEMENT (SINGLE-TOP ONLY)
Tools Required:
• #2 Phillips Screwdriver
WARNING
To avoid personal injury or damage to the table, support the table top before removing the screws securing it to the top
support.
Procedure:
1. Raise the table top to its highest height.
2. Using a Phillips screwdriver, remove the four #10 Phillips screws under the table top that hold the top to the support
weldment.
3. Lift off the table top.
4. Turn over the table top.
5. Using a Phillips screwdriver, remove the five #10 Phillips screws that hold one of the vanity tracks to the bottom
of the table top.
6. Remove the vanity from the table top.
7. Reverse procedures to install the new vanity tray.
VANITY TRAY REPLACEMENT (SPLIT-TOP ONLY)
Tools Required:
• 3/8” Nut Driver
WARNING
To avoid personal injury or damage to the table, support the table top before removing the nuts securing it to the top
support.
Procedure:
1. Raise the table top to its highest height.
2. Using a 3/8” nut driver, remove the 3/8” acorn nuts from the bottom of the table at each of the four corners.
3. Lift off the table top.
WARNING
To avoid personal injury or damage to the table, while turning the table top over, securely hold the top on the sides to
prevent the primary and secondary tops from separating.
4. Turn over the table top, turn the vanity tray approximately 450and remove it from the table top.
5. Reverse procedures to install the new vanity tray.

www.stryker.com 3150-009-001 REV B 19
Return To Table of Contents
Service Information
VANITY TRAY MIRROR REPLACEMENT
Tools Required:
• None
Procedure:
1. Open the side of the vanity tray with the broken mirror and flip up the mirror.
2. While holding the top of the broken mirror with one hand, use your other hand to flex the bottom of the mirror in
the middle and remove it from the vanity.
3. Reverse procedures to install the new mirror.

20 3150-009-001 REV B www.stryker.com
Return To Table of Contents
Single-top Overbed Table Assembly, Without Vanity
For Reference Only: Part Number 3150-000-100
Item Part No. Part Name Qty.
A (see page 21) Single-top, Without Vanity 1
B (see table above) Upper Column Cover 1
D 0001-163-000 Flat Countersunk Head Screw 2
E 0004-136-000 Pan Head Machine Screw 3
F 0026-296-000 Gas Spring Clevis 1
G 0027-019-000 Rue Clip 1
H 3150-002-205 Lift Handle 1
J 3150-002-310 Gas Spring Assembly (see page 43) 1
K 3150-002-405 Lower Bushing 1
L 3150-002-410 Upper Bushing 1
M 3150-009-100 Label 1
N 3150-010-115 Top Support Weldment 1
Y 0023-256-000 Phillips Pan Head Screw 6
Y
M
D
E
J
F
G
H
A
B
K
L
N
Upper Column Cover Color Part Number
Pewter 3150-002-290
Coffee 3150-002-291
Graphite 3150-002-292
Light Chocolate 3150-002-293
B
