Assembly Guide
Model: 2GMCC
Fortress 31.5" Mobile Garage Cabinet
With Drawer And Shelves

Do not place the parts directly onto the floor.
Use a cardboard sheet or a mat to place the
parts, during the separation and assembly.
In order to ease the assembly,
you should separate and identify the parts first
Necessary hardware for the assembly
Stuck? Questions? We are here to help.
1-888-230-2225
[email protected]
IMPORTANT
In order to avoid severe or even fatal injuries, follow the instructions carefully.
* Included in the kit * Not included in the kit
Locking nut, no key tightening required.

Hardware list
Fortress 31.5" Mobile Garage Cabinet With Drawer And Shelves
lb
Maximum weight
supported by
shelf and
drawer
WARNING
F1
1000011853
P10
Upper Back
55lb
P7
Bottom
P17
Column
P5
Top
P9
Lower Back
P19
Shelf
P2
Right Side
P3
SideLeft
55lb
55lb
31lb
P15
Drawer Fund
P28
Drawer Front
P27
Left Door
P26
Right Door
P12
Drawer Right Side
P14
Drawer Back
P13
SideDrawer Left
Qty. 38
F2
1000011851
Qty. 38
F7
1000008301
Qty. 4
F15
1000010159
Qty. 1
F13
1000011850
Qty. 1
F10
1000008352
Qty. 2
F11
1000008354
Qty. 2
F17
1000008285
Qty. 1
F18
1000011849
Qty. 19
N º
D ESC R I PT ION GR EY C HA R C OAL M A T T E W HI TE
M A T ER IA L
M A TER I A L
M A T ER I A L
P2 RIGHT SIDE
3000007327 3000011876 3000011962 STEEL UN
P3 LEFT SIDE
3000007341 3000011875 3000011961 STEEL 1 UN
P5 TOP 3000007369 3000011874 3000011960 STEEL 1 UN
P7 B OTTOM 3000008643 3000011848 3000011935 STEEL 1 UN
P9 LOWER BACK 3000007266 3000011842 3000011930 STEEL 1 UN
P10 UPP ER BACK
3000007312 3000011846 3000011933 STEEL 1 UN
P12 DRAWER RIGHT SIDE 3000007360 3000011856 3000011943 STEEL 1 UN
P13 DRAWER LEFT SIDE
3000007337 3000011858 3000011945 STEEL 1 UN
P14 DRAWER B A CK 3000007365 3000011867 3000011953 STEEL 1 UN
P15 DRAWER FUND
3000007334 3000011869 3000011955 STEEL 1 UN
P17 COLUM N 3000007344 3000011873 3000011959 STEEL 1 UN
P19 SHELF
3000007311 3000011847 3000011934 STEEL 1 UN
P26 RIGHT DOOR 3000007351 3000011862 3000011948 STEEL 1 UN
P27 LEFT DOOR
3000007348 3000011864 3000011949 STEEL 1 UN
P28 DRAWER FRONT 3000007355 3000011861 3000011947 STEEL 1 UN
I D EN T I F Y TH E C OL OR OF YOU R C A B I N ET
QU A N T I T Y

1 - Fit part P2 inside part P7
2 - Fit both parts in the frontal side, with F1 and F2.
1 - Fit part P7 inside part P3
2 - Fit both parts in the frontal side, with F1 and F2.
STEP 2
STEP 1
4x
F2
4x
F1
P7
P3
4x
F2
4x
F1
P7
P3
P2
2
1
2
1
WARNING
Do not tighten
the screw
completely.
WARNING
Do not tighten
the screw
completely.

1 - Fit part P5 between part P2 and P3
2 - Check that all 4 tabs have been fitted
3 - Fit part P5 to parts P2 and P3, at the frontal
side, with F1 and F2.
STEP 4
STEP 3
1 - Turn the cabinet with the back side
upwards. 2 - Fit parts P2 and P3 to parts P5 and P7 with
F1 and F2.
4x
F2
4x
F1
8x
F2
8x
F1
P7
P3
P5
P2
P7
P2 P5
P3
180°
180°
P7
P2 P5
P3
1
2
3
WARNING
Check that all parts are
correctly supported to
ensure product alignment.
WARNING
Do not tighten
the screw
completely.
WARNING
Do not tighten
the screw
completely.

1 - Fit part P9 into parts P2, P3 and P7
Check that all fits are supported over the
bolts
2 - After fitting the parts, screw the bolts until
locked
STEP 6
STEP 5
1 - Fit part P10 into parts P2, P3 and P5
Check that all fits are supported over the
bolts.
2 - After fitting the parts, screw the bolts until
locked.
WARNING
Position part P10
on the P5 side for
mounting the
cabinet.
1
2P7
P2 P5
P10
P3
P7
P10
P9
P2
P3
1
2
Do not tighten
the screw
completely.

STEP 7
STEP 8
3 - To assembly the cabinet with caster, align
the F10 and F11 to the holes in part P7
and fix them with F1 and F2.
4 - WARNING: Casters with lock (F11) must be
fitted in the frontal side of the cabinet
1- Turn the cupboard so that it will stand in the position of use
2- Fix F7 to parts P2 and P3, as shown here below
4x
F7
2x
F10
2x
F11
16x
F2
16x
F1
P7
P5
P2
P3
P7
P5
P2
P3
WARNING
After tightening the screws, make sure the cabinet does
not appear to be misaligned.
FLAT SURFACE
1 - Put the cabinet a flat surface.
2 - Completely tighten all screws.

STEP 9 1 - Fit the lower part P19 in diagonal position to insert it inside the cupboard
2 - Lean part P19 in part P2, P3 and place it over the F7 detailed in the figure here
below
3 - Lower the other side of part P19, leaning it over the left F7
STEP 10
F7
P7
P5
P2
P3
P19
P7
P7
P5
P2
P3
P17
P19
2x
F2
2x
F1
1
2
1 - Fit the lower part P17 in diagonal position to insert it inside the cupboard.
2 - Fit part P17 in cut-offs of parts P2 and P3, as detailed here below
3 - Fix part P17 in parts P2 and P3, with F1 and F2.

4x
F18
STEP 11 1 - To assembly the doors, fit door P26 lower hinge bolt inside the bushing fixed in part P7.
Then, pull down the pin of door P26 upper hinge; align the door and release the pin to fit the
bushing fixed in part P17.
2 - Repeat the step for part P27.
STEP 12 1 - Fit part P15 in part P28.
2 - Screw the two parts with F18.
1º
2º
P5
P3
P19
P2
P7
P17
P26
P27
P15
P28

6x
F18
9x
F18
1 - Align parts P12 and P13 on
part P15 and slide to part P28.
2 - Screw the two parts with F18.
STEP 13
STEP 14 1 - Insert part P14 over part P15 and
between parts P12 and P13.
2 - Then, fix part P14 to parts
P12, P13 and P15, with F1 .8
P13
P15
P28
P12
P15
P13
P28 P12
P14

1 -Insert product logo
STEP 16
P5P3
P2
STEP 15
3- Procedure for removing the drawer
Left Right
1 - Fit the drawers - already assembled-
between parts P2 and P3, through the
drawer slides.
2 - Check that the drawer slides on both sides
are properly fitted. If they are not properly fitted,
the drawer will not close completely. Slide the
drawer in and out to test it and be sure it is
sliding smoothly.

FORTRESS GARAGE WARRANTS TERMS
This product has the guarantee for a period of twelve (12) months, this limited warranty is effective from the date of
the original consumer purchase. Proof of original purchase date is required to obtain service or replacement under
this limited warranty. Once the defect of manufacture has been verified, the consumer should contact the store where
he purchased the product. In the warranty period, any defective parts will be replaced free of charge by another of
the same line and model. The installation and assembly in the residence of the costumer is not the responsibility of
the factory or the store. The assembly must correctly follow the instructions inside the packaging of each module.
ITEMS EXCLUDED FROM WARRANT S
This limited warranty does not cover:
1. In-home service including, but not limited to, service calls to correct the installation of any Manhattan Comfort
Fortress Garage products or to instruct the consumer on how to use or install them.
2. Damage resulting from improper handling or shipping of products , or products damaged by accident, alteration,
misuse, abuse, fire, flood, improper installation, acts of God, neglect, corrosion, modification or mishandling.
3. All travel, transportation, shipping or freight fee s to deliver replacement products or to return de fective products.
4. Factory specified replacement parts or product replacement when your product is used in other than normal,
single-family household use, such as a commercial environment or handled in a m anner contrary to published user
or operator instructions and/or installation instructions.
5. Aesthetic damages including scratches, dings, dents or cracks that do not affect the structural or functional
capability of the product.
6. Any labor costs during the limited warranty period.
7. Damage resulting from improper loading beyond the specified maximum weight capacity outlined in the assembly
instructions provided with the product including overloading of hooks, baskets, shelves, cabinets, and other
Manhattan Comfort Fortress Garage accessories used with the product.
8. Surfaces damaged due to chemical interaction resulting in corrosion of paint or metal.
9. Replacement keys or locking mechanism.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANT Y
Implied warranties, including any implied warranty of merchantability or implied warrant of fitness for a particular
purpose, are limited to one year or shortest period allo wed by law.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
Your sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Manhattan
Comfort Fortress Garage shall not be liable for incidental or consequential damages.
TAKING GOOD CARE OF YOUR CABINET
Cleaning and caring instructions:
Avoid dragging objects on top of the cabinet. They might scratch the finishing.
Only non-abrasive natural chemical products are recommended to clean your cabinet. Simply wipe the cabinet down
with a wet cloth to remove the cleaning product excess.
Never clean the cabinet with scouring powders, steel scrubber pads or any other product which can scratch its
surface.
Chemical products are not recommended.
Cabinet surfaces should not be covered with colored plastic or paper sheets.
Acid substances must remain properly stored in sealed containers.
Avoid the direct contact of water with other surfaces, as the humidity can affect the durability of the cabinets.
Avoid cabinets exposure to direct Sun light. Drapers suggested.
This guidance should be saved for future reference, if necessary.
