Simplicity 1694919 Setup guide

Attachment
Illustrated
Parts List
Rev. 04/2007
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2007 TP 400-4569-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1694919 42" Snow Blade
1734853
Part No.:

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
42" Snow Blade Group ......................................................................................................................................... 4

42" Snow Blade Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1694919
The above parts group applies to the following Mfg. Nos.:
4
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694919 - 42" Snow Blade
TP 400-4569-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
42" Snow Blade Group
Footnotes
ROD, 1/2 Diameter, 10.95 LG Angle w/Flat1 1731380SM 1
PIN, Quick2 1918196SM 9
NUT, Hex Flange, 5/16-18 ESNA3 1960686SM 7
CAPSCREW, Hex Head, 5/16-18 x 14 1921333SM 7
ROD, 1/2 Diameter Angle w/Flat Top 49.2LG5 1732871SM 1
JOINT, Ball6 1702779SM 3
NUT, Hex Jam, 1/2-207 1919262SM 3
ROD, 1/2 Diameter 5.85 LG, Latch 1/2-20 x 1-1/28 1732149SM 1
NUT, Hex Lock ESNA Light 3/8-16NC3B9 1919439SM 1
WASHER, 3/810 1924356SM 1
SPACER11 1663752SM 1
LEVER, Latch 7GA 42" Snow Blade12 1732147ASM 1
CAPSCREW, Hex Head, 3/8-16 x 7/813 1921966SM 2
NUT, Hex Flange 3/8-16 Whiz Lock Small14 1931211SM 17
BRACKET, Cross, 42" Snow Blade, 10GA15 1732594ASM 1
ROD & BRACE ASSEMBLY, Lift, 42" Blade16 1732144ASM 1
CLIP, Hair Pin17 1960033SM 1
WASHER, 5/818 1924366SM 1
PIVOT, Lift19 1732358SM 1
LOCKWASHER, Spring20 1916965SM 1
EYEBOLT, 1/4-2021 2172162SM 1
NUT, Hex Lock ESNA Light 1/4-2022 1920397SM 1
SUPPORT/BRACE ASSEMBLY, Rod 42"23 1732176ASM 1
ROD, 5/8 10.8 LG, Bellcrank24 1730080SM 1
NUT, Push for 1/2 Diameter Stud Capped25 1960519SM 1
ROD, 1"Diameter, 12.50 LG, Frame Latch26 1732420SM 1
REACH, 42" Snow 12GA27 1730076ASM 1
ROD, 1/2" Diameter 7.62LG28 1713578SM 1
ROD, Latch29 1731414SM 2
HITCH, Lift 12GA30 1730077ASM 1
CAPSCREW, Hex Head 3/8-16 x 1-1/4 G531 1920415SM 1
SPACER32 1666697SM 3
CAPSCREW, Hex Head 1/2-13 x 1.3533 1921176SM 1
BRACKET/BRACE ASSEMBLY, 42" Blade34 1732454ASM 1
CARRIAGE BOLT, 3/9-16 x 3/435 1931348SM 4
SPACER36 1719683SM 1
SPACER37 1667812SM 1
PLATE, Wear38 1732764SM 1
RIVET, Pop39 1928707SM 4
LATCH, Blade40 1732756ASM 1
SPACER41 1703900SM 1
WASHER, 3-5/1642 1919381SM 1
COTTER PIN43 1918447SM 2
LINK44 1732355SM 1
The above parts group applies to the following Mfg. Nos.:
5
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694919 - 42" Snow Blade
TP 400-4569-00-AT-SMA

42" Snow Blade Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1694919
The above parts group applies to the following Mfg. Nos.:
6
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694919 - 42" Snow Blade
TP 400-4569-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
42" Snow Blade Group
Footnotes
WASHER, 1/248 1918431SM 3
HITCH, Pivot49 1730078ASM 1
SPACER50 1709235SM 2
CARRIAGE BOLT, 3/8-16 x 151 1931350SM 12
CAPSCREW, Hex Head, 1/2-13 x 1.3552 1921176SM 2
PLATE, Backer53 1730079ASM 1
SHOE, Skid54 1731352ASM 2
BAR, Scraper55 1731351ASM 1
BLADE, Snow56 1730075ASM 1
NUT, Hex 5/16-1857 1917372SM 2
EYEBOLT, 5/16-1858 1675198SM 1
SPRING59 2101126SM 1
ROD, 5/8" Diameter60 1731354SM 1
The above parts group applies to the following Mfg. Nos.:
7
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694919 - 42" Snow Blade
TP 400-4569-00-AT-SMA

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36
20 2.3 31 3.5 43 4.9
10-24
27 3.1 43 4.9 60 6.8
10-32
31 3.5 49 5.5 68 7.7
1/4-20
66 7.6 810.9 12 16.3
1/4-28
76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
0
1/4 3/4
1/2
1
1/4 3/4
1/2
2
1/4 3/4
1/2
3
1/4 3/4
1/2
4
