1. Introduction
The EXMICRO2 can extend an HDMI2.0b (18Gbps) high definition video / audio signal and
one-way IR up to 50 meters (164 feet) between transmitter and receiver over a single
Cat5e/6 cable. The EXMICRO2 supports resolutions up to 4K2K@60Hz 4:4:4, up to
18Gbps, and HDCP 2.2/1.4. In addition, the EXMICRO2 extender is equipped with one-
way IR (from display to transmitter device) which allows for source control and one HDMI
loop output.
The EXMICRO2 extender includes two units: transmitter unit and receiver unit. The
transmitter unit is responsible for transmitting the HDMI input signal via one Cat6 cable
and emitting IR control signals sent from the IR RX at the receiver end. The receiver unit
is responsible for receiving the HDMI signal and transmitting IR control signal.

3
2. Features
•HDMI 2.0b, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
•Supports input and output video resolution up to 4k2k@60Hz 4:4:4 up
to 18Gbps
•Supports HDR
•Distance up to 164ft / 50 meters
•Compact size
•IR transmission from Display (RX Device) to TX device at source end
•HDMI loop output
•Single power supply – can be powered from either the RX or TX
•Automatic EDID copy function
3. Package Contents
•1× HDMI 18Gbps transmitter
•1× HDMI 18Gbps receiver
•1× IR Blaster (1.5m length)
•1× 20~60KHz IR Receiver (1.5m length)
•1× 12V/1A Locking Power supply
•4× Mounting Ears
•1× User Manual

4
4. Specifications
Technical
HDMI Compliance
HDMI 2.0b
HDCP Compliance
HDCP 2.2 / HDCP 1.4
Video Bandwidth
18Gbps
Video Resolution
Up to 4K60Hz 4:4:4
Color Space
RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4
Color Depth
8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr
4:2:2/4:2:0)
8-bit (4K60Hz 4:4:4 )
HDMI Audio Formats
LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby
TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS
HD Master, DTS HD-HRA, DTS-X
ESD Protection
Human body model — ±8kV (Air-gap discharge)
&±4kV (Contact discharge)
Connections
Transmitter
Inputs: 1x HDMI Type A [19-pin female]
1x SERVICE [Micro USB, Update port]
Outputs: 1x HDMI Type A [19-pin female]
1x IR OUT [3.5mm Stereo Mini-jack]
1x CAT OUT [RJ45, 8-pin female]
Receiver Inputs: 1x IR IN [3.5mm Stereo Mini-jack]
1x CAT IN [RJ45, 8-pin female]
1x SERVICE [Micro USB, Update port]
Outputs: 1x HDMI Type A [19-pin female]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
Transmitter / Receiver:
61mm [W] x 88mm [D] x 18mm [H]
Weight
Transmitter: 160g, Receiver: 155g
Power Supply
Input: AC 100 - 240V 50/60Hz
Output: DC 12V/1A
Power Consumption
3.84 W
Operating
Temperature
32 - 104°F / 0 - 40°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)
Resolution /
Distance
4K60 - Feet / Meters
4K30 / 1080P - Feet /
Meters
CAT5e
164ft / 50M
164ft / 50M
CAT6/6a/7
197ft / 60M
230ft / 70M
HDMI IN/OUT
10ft / 3M
30ft / 10M

5
5. Operation Controls and Functions
5.1 Transmitter Panel
Numb
er
Name
Function description
1
HDMI OUT
HDMI loop output port, connect to HDMI display device such
as TV or Projector with an HDMI cable.
2 HDMI IN HDMI input port, connect to HDMI source device such as
Media server or other 4K source
3
CAT OUT
Connect to CAT IN port on the receiving end with a CAT6
cable.
4 Power Indicator
Lamp (Green)
The LED will illuminate when the transmitter is powered on.
5
Data signal
Indicator Lamp
(Orange)
The LED will illuminate when the transmitter and the
receiver have signal transmission (link)
6
SERVICE port
For firmware updated use.
7
IR OUT
Connect to wideband IR Blaster (included). The IR signal is
from the IR IN port of the receiver.
8 DC 12V Plug DC 12V/1A power supply into the unit and connect the
adapter to an AC outlet.
(Note: The EXMICRO2 can be powered from either the RX
or the TX by 12V/1A power adapter, only one supply is
needed)

6
5.2 Receiver Panel
Numb
er
Name
Function description
1 HDMI OUT HDMI output port, connect to HDMI display device such as
TV or Projector with an HDMI cable.
2
CAT IN
Connect to CAT OUT port on the transmitter end with a
CAT6 cable.
3 Power Indicator
Lamp (Green)
The LED will illuminate when the receiver is powered on.
4
Data signal
Indicator Lamp
(Orange)
The LED will illuminate when the transmitter and the
receiver have signal transmission (link).
5
SERVICE port
For firmware updated use.
6
IR IN
Connect to wideband IR Receiver. The IR signal will be
transmitted to the IR OUT port of the transmitter.
7 DC 12V Plug DC 12V/1A power supply into the unit and connect
the adapter to an AC outlet.
(Note: The EXMICRO2 can be powered from either the RX
or the TX by 12V/1A power adapter, only one supply is
needed)
5.3 IR Pin Definition

7
IR Use Example;
6. Application Example

8
7. Warranty
Should you feel that this product does not function adequately due to defects in
materials or workmanship, we (referred to as “the warrantor”) will, for the length of
the period indicated below (starting from the original date of the purchase) either a)
repair the product with new or refurbished parts. Or b) Replace the product with new
or refurbished product. All Simplified MFG products are covered by a 3-year PARTS
and LABOR warranty. During this period there will be no charge for unit repair,
replacement of unit components or replacement of the product if deemed necessary.
The decision to repair or replace is made by the warrantor. The purchaser must mail
in the product during the warranty period. This limited warranty only covers the
product purchased as new and is extended to the original purchaser only. It is non-
transferrable to subsequent owners, even during the warranty period. A purchase
receipt or other proof of purchase date is required for the limited warranty service.
8. Contact Information
Sales and Tech Support
P. 833-HDMI-411 (833-436-4411)
E. [email protected]om
Simplified MFG • 550 W Baseline Rd Ste 102-121 • Mesa AZ 85210
