Simrad IS40 User manual

IS40 Display & OP10 Autopilot Controller
Quick Reference Guide
AUTO
10 10
11
MODE STBY
IS40 Display Keys
Menu / Enter / Lighting: Used to enter the main menu, select sub menus and
confirm selection. Note: Press and hold the Enter key for 3 seconds takes you directly
to the display setup lighting level screen. If the lighting level is set below 5 it will
automatically increase to 5. Use the up and down keys to set the desired level and
press Enter to confirm.
Page: Scrolls through the eight default display pages and navigates back a step in
menus. Note: the eight default display pages including the autopilot page can be
customized to display the required data.
Directional keys: Scrolls up and down through selected menus / set values.
OP10 Autopilot Controller Keys
MODE
Changes the autopilot mode. When in Auto mode, pressing the MODE key:
1) when the boat type is set to Sail: changes to Wind mode.
2) when set to any other boat type: enters into NoDrift mode.
3) for all boat types: (long key press) enters into Navigation mode; which will require
confirmation via the display before it is engaged.
STBY (or OFF): Disengages the autopilot. Places the autopilot into Standby mode.
1
Left 1º: Adjust the set course or wind angle 1 degree / steer to Port in Non Follow Up
(NFU) mode. When pressed in Standby mode this will enter the autopilot into NFU
mode.
1
Right 1º: Adjust the set course or wind angle 1 degree / steer to Starboard in NFU
mode. When pressed in Standby mode this will enter the autopilot into NFU mode.
10
Left 10º: Adjust the set course or wind angle 10 degrees / steer to Port in NFU mode.
When pressed in Standby mode this will enter the autopilot into NFU mode.
10
Right 10º: Adjust the set course or wind angle 10 degree / steer to Starboard in NFU
mode. When pressed in Standby mode this will enter the autopilot into NFU mode.
AUTO
Engage the autopilot / Acknowledge tack/gybe or navigation course change.
Changing the Autopilot mode
3 SEC Boat Type:
• Displacement
• Outboard
• Planing
Boat Type:
• Sail
Mode Symbol Function / Mode
SStandby
AAuto (Compass)
WWind
NNavigation
ND NoDrift
NFU Non Follow Up (Power steer)
Tack & Gybe in Wind mode
To tack or gybe in Wind mode press both 1º course keys on the OP10 Autopilot controller.
1
1
EN
Part No.988-10364-002 - Section 1 of 5

Page navigation
Menu navigation
Back lighting
Night mode
3 SEC
Replacing a data page
Creating custom pages
Disable / Enable a data page
Start / Stop timer
Reset trip log
