Simrad OP10 User manual

Dimensions - Single unit Dimensions - Multiple instruments
English
OP10/Triton Pilot
Controller
Installation Guide
www.bandg.com | www.simrad-yachting.com
Technical specications
*988-10223-002*
88 mm (3.5")
18 mm (0.7")
15 mm (0.6")
60 mm (2.4")
115 mm (4.5")
120 mm (5.5")
65 mm (2.5")
Suncover
outline
Min
65 mm
(2.5")
Min 120 mm (5.5")
Power
Power Supply 12V DC nominal (via network)
Power Consumption Backlight off: 45mA @ 13.5V DC
Backlight max: 145mA @13.5V DC
Technical/Environmental
Housing ABS moulding
Waterproofing standard IPx7
Operating temperature -10° C to +55° C (+14° F to + 131° F)
Storage temperature -30° C to +70° C (-22° F to 158° F)
Maximum Humidity 100%
Connectors 1x male Micro-C
Weight excluding bracket 155 grams (0.34 lb)
Retention Bracket weight 25 grams (0.06 lb)
System Installation manual
System Operator manual
www.simrad-yachting.com
www.bandg.com
MODE STBY
11
10
AUTO
10
N2584

Installation - Mounting clip (2)
Wiring
Installation - Mounting clip (1)
Installation - Bracket
CLICK!
A0.6 m drop cable, male-female Micro-C plugs (included)
BMicro-C T-connector (included)
CNMEA 2000 backbone
DSimNet to Micro-C adapter cable
ESimNet Multi-joiner
FSimNet backbone
BCC
A
D
E
F F
Fixing
Removing
