Simrad ES38-18/200-18C
Combi transducer
Installation Manual

404776/A
August2015©KongsbergMaritimeAS
SimradES38-18/200–18C
Combitransducer
Installationmanual
Thepurposeofthismanualistoprovidetheinformation,procedures
andbasicdrawingsrequiredforthephysicalinstallationoftheSimrad
ES38-18/200–18CCombitransducer.Themanualfurtherprovides
relevantdescriptionsandillustrationstoexplainthebasicprinciplesfor
locationandnoiseconsiderations.
Note
Theinstallationshipyardmustprovideallnecessarydesignand
installationdrawings,aswellastherelevantworkstandardsandmounting
procedures.
Ifrequired,thesedocumentsmustbeapprovedbythevessel’ snational
registryandcorrespondingmaritimeauthorityand/orclassication
society.Suchapprovalmustbeobtainedbeforetheinstallationcanbegin.
Theshipownerandshipyarddoingtheinstallationareresponsiblefor
obtainingandpayingforsuchapproval.

KongsbergMaritimeAS
www.kongsberg.com
Documentinformation
•Product:SimradES38-18/200–18C
•Document:Installationmanual
•Documentnumber:404776
•Revision:A
•Dateofissue:August2015
Copyright
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsbergMaritimeAS.Nopartof
thisdocumentmaybecopiedorreproducedinanyformorbyanymeans,andtheinformationcontainedwithin
itisnottobecommunicatedtoathirdparty,withoutthepriorwrittenconsentofKongsbergMaritimeAS.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhichitwasdesigned.
Improperuseormaintenancemaycausedamagetotheequipmentand/orinjurytopersonnel.Theuser
mustbefamiliarwiththecontentsoftheappropriatemanualsbeforeattemptingtooperateorworkonthe
equipment.
KongsbergMaritimedisclaimsanyresponsibilityfordamageorinjurycausedbyimproperinstallation,
useormaintenanceoftheequipment.
Disclaimer
KongsbergMaritimeASendeavourstoensurethatallinformationinthisdocumentiscorrectandfairlystated,
butdoesnotacceptliabilityforanyerrorsoromissions.
Supportinformation
Ifyourequiremaintenanceorrepair,contactyourlocaldealer.Y oucanalsocontactususingthefollowing
address:[email protected].Ifyouneedinformationaboutourotherproducts,visithttp:
//www.simrad.com.Onthiswebsiteyouwillalsondalistofourdealersanddistributors.

404776/A3
Tableofcontents
ABOUTTHISMANUAL..................................................................5
SIMRADES38-18/200-18C..........................................................7
Orderinformation...................................................................................................................8
Technicalspecications..........................................................................................................8
Supportinformation..............................................................................................................10
RULESFORTRANSDUCERHANDLING........................................12
Approvedanti-foulingpaints................................................................................................13
INSTALLINGTHETRANSDUCER.................................................15
Installationsummary.............................................................................................................16
Designingmanufacturingandmountingtheinstallationhardware......................................17
Installingthestufngtube....................................................................................................19
Designing,manufacturingandmountingthesteelconduit..................................................21
Unpackingthetransducerfromitstransportbox..................................................................22
Installingthetransducercable..............................................................................................24
Mountingthetransduceronasteelhull................................................................................26
Mountingthetransduceronawoodenorpolyesterhull.......................................................28
Mountingthetransduceronablisterordropkeel................................................................30
Splicingthetransducercable................................................................................................32
Connectingthetransducercabletothetransceiver...............................................................33
CABLELAYOUTANDINTERCONNECTIONS.................................35
TransducerES38-18/200-18CconnectiontoaGPTtransducersocket................................36
GPTTransducerplug............................................................................................................38
TransducerES38-18/200–18Cconnectiontoothertransceivers..........................................39
TRANSDUCERINSTALLATIONPRINCIPLES................................40
Streamlinedhousingmountedexternallyonasteelhull......................................................41
Streamlinedhousingmountedexternallyonawoodenorpolyesterhull.............................44
Transducerinstallationunderablister..................................................................................47
Transducerinstallationusingdropkeel................................................................................51
Smoothsurfaceisimportant.................................................................................................53
Useasuitabletoe-inangle....................................................................................................53
Useasuitableinclinationangle............................................................................................54
WHERETOINSTALLTHETRANSDUCER.....................................55
Introduction...........................................................................................................................56
Installationmanual

4404776/A
Mountthetransducerdeep....................................................................................................56
Avoidprotrudingobjects.......................................................................................................57
Stayfarawayfromthepropellers.........................................................................................57
Chooseapositionfarawayfromthebowthruster(s)...........................................................57
Summaryandgeneralrecommendations..............................................................................58
DRAWINGFILE..........................................................................59
Aboutthedrawingsinthedrawingle.................................................................................60
ES38-18/200-18Coutlinedimensions..................................................................................61
SimradES38-18/200–18C

404776/A5
Aboutthismanual
Purposeofmanual
Thepurposeofthismanualistoprovidetheinformation,proceduresandbasicdrawings
requiredforthephysicalinstallationoftheSimradES38-18/200–18CCombitransducer.
Themanualfurtherprovidesrelevantdescriptionsandillustrationstoexplainthebasic
principlesforlocationandnoiseconsiderations.
Targetaudience
Themanualisintendedfortechnicalpersonnel;suchasskilledshipyardworkers,
electricians,qualiedengineersandnavalarchitects.Itisassumedthatyouunderstandthe
generalprinciplesofmaritimeelectronicequipment.Youmustalsobefamiliarwiththe
installationofelectronicandmechanicalproducts.
Installationinstructionsanddrawings
Theinformationinthisdocumentmustberegardedasgeneralguidelinesand
recommendationsonly.Theinstallationshipyardmustdesignandmanufactureinstallation
hardwaretoteachindividualtransducerandvessel.
Note
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,thesedocumentsmustbeapprovedbythevessel’ snationalregistryand
correspondingmaritimeauthorityand/orclassicationsociety.Suchapprovalmust
beobtainedbeforetheinstallationcanbegin.Theshipownerandshipyarddoingthe
installationareresponsibleforobtainingandpayingforsuchapproval.
Simradwillacceptnoresponsibilityforanydamageorinjurytothesystem,vesselor
personnelcausedbyequipmentthathasbeenincorrectlyinstalledormaintained,orby
drawings,instructionsorproceduresthathavenotbeenpreparedbyus.
Aboutthismanual

6404776/A
Applicablegenericoutlinedimensionand/orproductionsdrawingsareprovidedinthe
Drawinglechapter.DrawingsmayalsobedownloadedinPDFand/orDWGformats
fromourwebsite:http://www.simrad.com.
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
Simrad®,SIMRAD®andtheSimrad®logoareeitherregisteredtrademarks,ortrademarks
ofKongsbergMaritimeASinNorwayandothercountries.
SimradES38-18/200–18CInstallationmanual

404776/A7
SimradES38-18/200-18C
TheSimradES38-18/200-18Cisa"two-in-one"combitransducerdesignedforsheryand
sheryresearchapplications.Itcontainsa38kHzsplitbeamtransduceraswellasa200
kHzsinglebeamtransducer.Bothoffer18degreesbeamwidthattheirnominaloperational
frequencies.Thesplitbeamtransducerisdesignedwiththreeseparatesegments.
Thetransducerisstreamlined,anddesigned
tobemountedunderthehull.Flushmounting
isnotrecommended.
Afairingmustbedesignedtotbetween
thetopofthetransducersurfaceandthehull.
Thefairingshallofferthenecessaryinclination
angle,andprovidespaceforthecableservice
loop.
Note
Thefairingmustcovertheentiretopsurfaceofthetransducerhouse.Supportingonlyat
eachendofthetransducermaycausedamagetothetransducerifsubjectedtoslamming.
Thetransducerhousingisprovidedwithtwoholesformountingbolts.Theseshallpenetrate
thetransducerfastenittothefairing.
Thetransducercablepenetratesthehullusingastufngtubeandacablegland.
Topics
Orderinformation,page8
Technicalspecications,page8
Supportinformation,page10
SimradES38-18/200-18C

8404776/A
Orderinformation
ToordertheES38-18/200–18C,oranyoftheoptionalitemsprovidedwithit,contactyour
localdealer.Ifyoudonothavearegulardealer,alistofallourdistributorsanddealerscan
befoundonourwebsite.Yourdealerwillalsobeabletohelpyouwithadetailedquotation
includingpriceanddeliveryinformation.
Transducer
Product/ItemOrdernumberInthebox
ES38-18/200-18C398445•TheES38-18/200–18Ctransducer
•Stufngtube
•Cablegland(oncable)
•Documents
Optionalitems
TheseitemsarenotincludedwiththeES38-18/200–18Cdelivery,andmustbeordered
separately.
Theordernumberforthetransducercableisincludedincasethecablettedtothe
transduceristooshort.
Product/ItemOrdernumberInthebox
Transducercable382189Transducercable
Technicalspecications
Thetechnicalspecicationsandrequirementsprovidedarethosevalidwhenoperatingatthe
nominalfrequencywithallsectorsexcitedsimultaneously.
Note
InKongsbergMaritime,wearecontinuouslyworkingtoimprovethequalityand
performanceofourproducts.Technicalspecicationsmaythereforebechangedwithout
priornotice.
Performancespecications
•Nominalfrequency
–Low:38kHz
SimradES38-18/200–18CInstallationmanual

404776/A9
–High:200kHz
•Frequencyrange
–Low:34to45kHz
–High:190to230kHz
Thefollowingspecicationsarevalidforthenominalfrequency.
•Beamwidth:18degrees
•Figureofmerit
–38kHz:–9dB
–200kHz:–22dB
•Max.sourcelevel
–38kHz:215dB
–200kHz:213dB
•Transmitsensitivity(Su)
–38kHz:175dB
–200kHz:171dB
•Receivesensitivity(Mt)
–38kHz:–184dB
–200kHz:–193dB
•Sidelobelevel
–38kHz:–20dB
–200kHz:–19dB
•Backradiationlevel
–38kHz:Lessthan–25dB
–200kHz:Lessthan–30dB
•Impedance(eachsector)
–38kHz:60Ω
–200kHz:65Ω
Powerspecications
•Max.inputpower
–38kHz:500W
–200kHz:250W
SimradES38-18/200-18C

10404776/A
•Max.pulselength
–38kHz:16ms
–200kHz:4ms
•Max.dutycycle:2%
Weightsandoutlinedimensions
•Physicaldimensions
–Length:416mm
–Height:94mm(body)
•Weight(withoutcable)
–Inair:9.5kg(withcable)
–Inwater:2.3kg
•Cablelength:20meters
•Bendingradius:185mm
Environmentalrequirements
•Storagetemperature
–Max.:+60°C
–Min.:–20°C
•Operatingtemperature
–Max.:+40°C
–Min.:–5°C
Supportinformation
IfyouneedtechnicalsupportforyourSimradES38-18/200–18Cyoumustcontactyour
localdealer,oroneofoursupportdepartments.Alistofallourofcesanddealersis
providedonourwebsite.Y oucanalsocontactourmainsupportofceinNorway.
Norway(Mainofce)
•Companyname:KongsbergMaritimeAS/Simrad
•Address:Strandpromenaden50,3190Horten,Norway
•Telephone:[phone]
SimradES38-18/200–18CInstallationmanual

404776/A11
•Telefax:[phone]
•Website:http://www.simrad.no
•E-mailaddress:[email protected]
Spain
•Companyname:SimradSpain
•Address:PoligonoPartidaTorres38,03570Villajoyosa,Spain
•Telephone:[phone]
•Telefax:[phone]
•Website:http://www.simrad.es
•E-mailaddress:[email protected]
USA
•Companyname:KongsbergUnderwaterTechnologyInc/SimradFisheries
•Address:1921033rdAveW,Lynnwood,W A98036,USA
•Telephone:[phone]
•Telefax:[phone]
•Website:http://www.simrad.com
•E-mailaddress:[email protected]
Malaysia
•Companyname:KongsbergMaritimeMalaysiaSdn.Bhd
•Address:Unit27-5SignatureOfces,TheBoulevard,MidV alleyCity,LingkaranSyed
Putra,59200KualaLumpur,Malaysia
•Telephone:[phone]
•Telefax:[phone]
•Website:http://www.simrad.com
•E-mailaddress:[email protected]
SimradES38-18/200-18C

12404776/A
Rulesfortransducerhandling
Tosecurelonglifeandaccurateresults,eachtransducermustbehandledcorrectly.
Transducerhandling
Atransducermustalwaysbehandledasadelicateitem.Wrongfulactionsmaydamagethe
transducerbeyondrepair.
Observetheserules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donotliftthetransducerbythecable.
•Donotsteponthetransducercable.
•Donothandlethetransducerroughly,avoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotusehighpressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducerface.
Transportprotection
Sometransducersaredeliveredwithacoverplatetoprotectthefaceduringtransport.
Letthisplatestayonaslongaspossible,butdonotforgettoremoveitbeforethevessel
goestosea.
Cleaningthetransducerface
Wheneveropportunityarise,forexamplewhenthevesselisdrydocked,thetransducerface
shouldbecleanedforshellsandothermarinefouling.
•Becarefulnottomakecutsorotherphysicaldamagetothetransducerface.
•Useapieceofsoftwoodoraverynegradeemerypaper.
•Donotusehighpressurewaterorsandblasting.
SimradES38-18/200–18CInstallationmanual

404776/A13
Paintingthetransducerface
Anti-foulingpaintmaybeappliedtothetransducerface.Becausesomepainttypesmaybe
aggressivetothepolyurethaneinthetransducer,consultourlistofapprovedpaints.
Specialrulesforacousticwindows
Arctictankshaveacousticwindowsmadeofpolycarbonate.
Thesemustneitherbepaintednorcleanedwithchemicals.
Acousticwindowsmustnotbeexposedtodirectsunlight.
Approvedanti-foulingpaints
Thisisourlistofapprovedantifoulingpaintsforalltransducertypes.Alwaysrefertothe
manufacturer'sdocumentationanddatasheetsforacompleteprocedureandforrelevant
safetyinformation.
Important
Donotpaintthetransducerwithtraditionalhullplatingpaint.Useonlythecorrecttypeof
approvedpaintspeciedbelow.
Donotusemetaltoolsorhighpressurewateronthetransducer.
Jotun
P.O.Box2021,N-3248Sandefjord,Norway
http://www.jotun.com
•Racing
•Non-stop
•SafeguardUniversalprimer(125micron)withAntifoulingSeaQuantumUltra(125
micron)
•AntifoulingSeaguardian
InternationalMarineCoatings
www.international-marine.com
•Intersleektiecoat+425FCS
–BXA386/BXA390/BXA391Grey
–HKA563/HKA570/HKA571Yellow
Rulesfortransducerhandling

14404776/A
•Intersmooth360EcoloexSPC
•MicronExtra
SimradES38-18/200–18CInstallationmanual

404776/A15
Installingthetransducer
Topics
Installationsummary,page16
Designingmanufacturingandmountingtheinstallationhardware,page17
Installingthestufngtube,page19
Designing,manufacturingandmountingthesteelconduit,page21
Unpackingthetransducerfromitstransportbox,page22
Installingthetransducercable,page24
Mountingthetransduceronasteelhull,page26
Mountingthetransduceronawoodenorpolyesterhull,page28
Mountingthetransduceronablisterordropkeel,page30
Splicingthetransducercable,page32
Connectingthetransducercabletothetransceiver,page33
Installingthetransducer

16404776/A
Installationsummary
TheinstallationoftheES38-18/200–18Ctransducerisakeytaskforsuccessfulinstallation
oftheechosoundersystem.Notonlywillyouneedtopenetratethevessel’shull,you
mustalsotoselectaphysicallocationformaximumperformanceandminimumacoustic
andelectricnoise.
Prerequisites
Togetafulloverviewoftheinstallation,youwillneedalltherelevantvesseldrawings,as
wellasthedrawingsprovidedfortheES38-18/200–18Ctransducer.
Context
Theoutlinedimensionsofthetransducerandtherelevantinstallationitemsarefoundin
theDrawingle.Thesourcedrawings(inAutoCadformat)canbedownloadedfromour
website.
•http://www.simrad.com
Atransducermustalwaysbehandledasadelicateitem.Wrongfulactionsmaydamagethe
transducerbeyondrepair.
Observetheserules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donotliftthetransducerbythecable.
•Donotsteponthetransducercable.
•Donothandlethetransducerroughly,avoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotusehighpressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducerface.
Procedure
1Basedontheshapeandpropertiesofthehull,determinethephysicallocationofthe
transducer.
Makesurethatallpossibleconsiderationsaremadetoreducethenoise.
2Basedontheshapeofthetransducerhousing,andthemountingdevicesavailable,
determinetheinstallationmethod.
3Design,manufactureandmountthenecessaryfairing,installationblister,keelbox
and/ortankthatisrequiredtomountthetransducer.
4Installthestufngtube.
SimradES38-18/200–18CInstallationmanual

404776/A17
5Design,manufactureandmountthesteelconduitforthetransducercable.
6Unpackthetransducerfromitstransportcrate.
7Positionthetransducerunderthemountinglocation.
8Pullthetransducercableupthroughthesteelconduit.
9Tightenthepackingnutonthecableglandproperlytoavoidleaks.
10Mountthetransducer.
11Sealthetopofthesteelconduittopreventwaterleaks.
12Connectthetransducercabletothetransceiver.
Relatedtopics
Designingmanufacturingandmountingtheinstallationhardware,page17
Installingthestufngtube,page19
Designing,manufacturingandmountingthesteelconduit,page21
Unpackingthetransducerfromitstransportbox,page22
Installingthetransducercable,page24
Mountingthetransduceronasteelhull,page26
Mountingthetransduceronawoodenorpolyesterhull,page28
Mountingthetransduceronablisterordropkeel,page30
Splicingthetransducercable,page32
Connectingthetransducercabletothetransceiver,page33
Designingmanufacturingandmountingthe
installationhardware
Oncethephysicallocationofthetransducerhasbeendetermined,theinstallationhardware
mustbedesigned,manufacturedandmounted.
Prerequisites
•Allrelevantvesselandtransducerdrawingsmustbeavailable.
•Allrelevantworkinstructions,proceduresandstandardsmustbeavailable.
•Thephysicallocationofthetransducerhasbeendetermined.
•Theinstallationmethodhasbeendetermined.
•Thecablegland(stufngbox)hasbeeninstalled.
•Allrelevantpersonnel(navalarchitects,designers,skilledshipyardworkers)andtools
mustbeavailable.
Installingthetransducer

18404776/A
Context
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,thesedocumentsmustbeapprovedbythevessel’snationalregistryand
correspondingmaritimeauthorityand/orclassicationsociety.Suchapprovalmustbe
obtainedbeforetheinstallationcanbegin.Theshipownerandshipyarddoingtheinstallation
areresponsibleforobtainingandpayingforsuchapproval.
Relevantoutlinedimensionsandproductiondrawingscanbedownloadfromourwebsite.
MostdocumentsareavailableinPDForAutoCad(DWG)formats.
Procedure
1Basedonthevesseldrawings,thephysicalpropertiesofthehullandtheshapeofthe
transducerhousing,designtheinstallationhardware.
2Manufacturethehardwareaccordingtotherelevantproductionstandards.
3Mounttheinstallationhardwareunderthevessel’shull.
Note
Makesurethatthesurfaceoftheresultinginstallationissmoothandstreamlined.
Mountingscrewsorboltsmustnotbeextrudingfromthehullorfromtheinstallation
hardware.Ensurethatthesurfaceofthetransducerface,thehullplatingandputty
aroundthetransducerisasevenandsmoothaspossible.Obstructionsonthese
surfacesmaycreateproblemswithnoise.
4Ifrelevant,allowtherelevantmaritimeauthorityand/orclassicationsocietytoinspect
andapprovethedesignandinstallation.
Relatedtopics
Installationsummary,page16
ES38-18/200-18Coutlinedimensions,page61
SimradES38-18/200–18CInstallationmanual
