SINO SinoV-AP-W500 User manual

http://www.sinovoip.com.cn
IEEE 802.11n 150Mbps In Wall Access Point
SinoV-AP-W500 Quick Install Guide
The Access Point is properly installed in hotel
rooms,hospital,school and villa as it could keep previous face of
wall and need not any position to place the device.You only
unscrew old panel of wall box and connect the RJ45 connector to
the AP WAN port and insert the AP to wall box and screw it then
cover the face panel.It decrease the OPEX and Plug and Play.
Hardware installation
Step1 screw the metal bracket in the access point then adjust the
bracket position suitable of wall box.
Step2 fasten tightly into the Bottom Faceplate until it’s flushed into
the wall.
Step 3 cover the top faceplate on the bottom faceplate.
For rooms of hotel,hospital or school
You have to connect the access point of each room to IEEE 802.3af switch by using the UTP-5 cable.The
network block diagram as the following:
Internet
802.3af PoE Switch
16/24-ports PoE Dump Switch
SinoV-PSE-16-M-AF
In Wall Access Point
SinoV-AP-W500 Ethernet UTP-5 cable
iPad/tablet iPhone/
smart phone
laptop
WiFi
In Wall Access Point
SinoV-AP-W500
iPad/tablet iPhone/
smart phone
laptop
WiFi
Router/gateway
Room#1001 Room#1009

http://www.sinovoip.com.cn
LED Light:
1) Power ,light when PoE power supply OK
2) System ,access point system status
3) WLAN ,WLAN link and data transmit indicator
4) Link ,LAN link data transmit
5) LAN ,LAN connection
Button
6) Reset ,push about 7 seconds to reset configuration
7) WPS ,push to authenticate with WLAN client
Port/interface
8) LAN ,wire ethernet LAN port
9) Telephone ,connect to telephone
10) WAN ,connect to uplink router or gateway
11) Tel Line in,connect to PBX or subscribe line
Package list
I) One in wall access point
II) Two metal brackets
III) Two faceplates(top and bottom)
IV) Three screws
V) Quick install guide
Software configuration
Default IP address of access point:192.168.1.254
Subnet mask:255.255.255.0
Default SSID:802.11bgn-SSID
Problem Check Workflow
A) First,check the power supply.If PWR light is bright
GREEN,it's OK.The access point is powered by IEEE
802.3af standard PoE SWITCH or Midspan by connecting
through the Ethernet UTP-5 cable to the AP WAN port at
back side and the PoE power supply equipment. Then the
WLAN light shall flash when you boot up the AP.
Second,connect your WiFi client to the AP. The
default IP of AP is 192.168.1.254,you can browse in your
browsers such as IE or Firefox. If WiFi is connected,but
could not access the AP web management web
page,please click the "Details..." button in wireless
connection property dialog,see the DHCP enabled and
the client IPv4 address as 192.168.1.*.
B) If it have still any problem,please connect PC and
the AP LAN port at the front panel used the Ethernet
UTP-5 cable, configuration your PC in "Network and
Sharing Center" in control panel.select the Local
Connection and set IPv4 address manually,It may display
as the following picture:
CE certification
Certification NO: GST120820284E
http://www.gstslab.com
Access Point Operation Mode
The default mode is gateway mode.If you want to
set access point from WAN,please enable WAN web
access ,ping,IGMP proxy in WAN interface setting.The
WAN port shall configuration as static IP otherwise it may
not know actually IP address of AP and can not access
from WAN port.
We suggest the uplink gateway assign private class
B IP ranges:172.16.0.0~172.31.255.255,subnet mask as
255.255.0.0 then there’re above 256 up 60000 access
points in same network.
If you set access point as bridge mode,please
disable LAN DHCP server in LAN interface setting.
Moreover to access from WAN port ,set static IP address
of the LAN interface and must set the default
gateway ;WAN port is set DHCP client.
User manual and specification
To protect the earth and decrease the paper
consumption,please find more detail user manual and
specification from website: http://www.sinovoip.com.cn
