1. Getting Started
1.1. Preparation Before Use
You will need the following hardware and software to use the C2000-A2-SDXA000-AX1.
• C2000-A2-SDXA000-AX1 module
• A power source that provides 9 to 27 VDC, and several wires
• A PC running a Windows 7 or later versions, and an Ethernet cable
• KonNaD Settings Utility software, Download
1.2. Wiring
Refer to Port Description for the recommended wires.
Check the following items after the device is powered on：
• The PWR is steady red, and the RUN is flashing, which indicates the device is powered normally.
• Connect the device to the host computer through RS485 to USB converter, and you can acquire the value of DI
Value through the software.
Refer to Indicators for the meaning of LED indicators.
C2000-A2-SDXA000-AX1 User Manual
4 / 26
SinoCon Co., Ltd. www.sinoconsys.com

1.3. Software Installation & Device Debugging
1.3.1. Software Installation
Download the software on "Download" above. Unzip the folder and run KonNaD.Setup.exe as administrator. The
setup wizard will pop up to direct you to complete the installation.
1.3.2. Device Debug
Search Devices
Select Search for serial devices and Click Edit button to set the search parameters:
· COM ID: select the correct port for RS485 to USB;
· Baud rate: default 9600;
· Parity: default None;
· Data bit: default 8;
· Stop bit: default 1;
· Address range: range from 1 to 255, default 1 to 10;
· Timeout interval (ms): default 200.
Click Search to find the device through the port for RS485 to USB.
Note: if no device can be found.
C2000-A2-SDXA000-AX1 User Manual
5 / 26
SinoCon Co., Ltd. www.sinoconsys.com

• Check whether to install and run as administrator ;
• Check whether the RS485 to USB converter is correctly connected to the device and whether the converter is
faulty;
• Check whether the search parameters are correct (default value: 9600 None 8 1, and address is 1).
Communication
Select the device that has been searched, click the Refresh button at the bottom right screen and you can see all
the point value of the device.
· DI1 ~ DI16: The value 0 indicates "Open", the value 1 indicates "Short to GND". Use a wire to short the DI1 and
GND, you can see that the DI1 indicator is on.
As shown below:
Note:
Refer to Software Tools for more detailed information.
Refer to Registers for information on "Secondary Development".
C2000-A2-SDXA000-AX1 User Manual
6 / 26
SinoCon Co., Ltd. www.sinoconsys.com

2. Hardware Description
2.1. Specifications
Classification Parameter Specification
Digital Input DI Channels 16
DI Connector Terminal block
Input Type Dry contact
DI Mode Logic level & pulse count
Digital Filtering Time Interval 6 sample periods
Counter Frequency 1kHz
Upstream Serial Port Serial Standrad RS485
No. of Ports 1
Connector Terminal block
Industrial Protocol Standard Modbus RTU Protocol
Power Power Connector Terminal block
Input Voltage 9~27VDC
Current 80mA @ 12VDC
Physical Characteristics Dimensions 75*105*30mm
Installation Din-rail or wall
Environmental Limits Operating Temperature -40℃ ~ 85℃
Storage Temperature -60℃ ~ 125℃
Ambient Relative Humidity 5% ~ 95% RH, non-condensing
C2000-A2-SDXA000-AX1 User Manual
7 / 26
SinoCon Co., Ltd. www.sinoconsys.com

2.2. Apprearance
C2000-A2-SDXA000-AX1 User Manual
8 / 26
SinoCon Co., Ltd. www.sinoconsys.com

2.3. Indicators
Classification Indicator Description Meaning
Digital Input DIx Digital input
indicators (dry
contact)
Steady on：Short to GND
Off：Open
Downstream
Serial Port
RXD RS485 data receive
indicator
Steady on：RS485 line fault, please check if the positive
and negative poles of 485 line are reversed
Flashing：RS485 receiving data
Off：RS485 no receiving data
TXD RS485 data
transmit indicator
Flashing：RS485 transmitting data
Off：RS485 no transmitting data
Power PWR Power indicator Steady on：Normal power supply
Off：No power or abnormal power supply, please
check if the voltage range is 9~27VDC
RUN RUN Running indicator Steady on：Device exception
Flashing：Flashes every 1 second when the device is
ready
Off：Device exception
C2000-A2-SDXA000-AX1 User Manual
9 / 26
SinoCon Co., Ltd. www.sinoconsys.com

2.4. Port Description
Classification Port Description Recommended
wiring
Digital Input DIx Digital input RVV 2*0.5
GND Dry contact input common RVV 2*0.5
Upstream Serial
Port
485+、
485-
RS485+, RS485- (upstream) RVSP 2*0.5
Power Input V+、V- Power supply input positive, power supply input
negative
RVV 2*1.0
PE Used for reliable grounding of the device, surge
protection
RVV 2*0.5
C2000-A2-SDXA000-AX1 User Manual
10 / 26
SinoCon Co., Ltd. www.sinoconsys.com

2.5. Product Dimensions
unit: mm（inch）
2.6. Installation Method
C2000-A2-SDXA000-AX1 User Manual
11 / 26
SinoCon Co., Ltd. www.sinoconsys.com

3. Product Features
3.1. DI Data Acquisition
3.1.1. DI Type
Dry contact: Short DI and GND, the point value is 1; otherwise the point value is 0.
Note: The start register address of DI status is 10100, 2-byte unsigned integer, and the 0x02 function code is
used to read DI status.
3.2. Other Features
3.2.1. DI Pulse Mode
• Positive/negative pulse state
Indicate the current input pulse status. When the DI is open, the positive pulse status register value is set to 1.
When short the DI and GND, the negative pulse register value is set to 1. Writing 0 will clear the detected pulse
state and writing other values is invalid.
• Positive/negative pulse count
Indicate the number of positive/negative pulse changes. The initial value can be written. After writing, it can be
counted from the initial value to the maximum value of 65535, and then it can be re-counted from 0.
• Logic level count
Indicate the sum of the number of positive/negative pulse changes. The initial value can be written. After writing,
it can be counted from the initial value to the maximum value of 65535, and then it can be re-counted from 0.
3.2.2. Filter Parameters
The DI signal must be kept for several sampling periods before it can be confirmed. The default value is 0x6, which
means that 6 sample periods are required to be confirmed. This value can be modified according to the site
conditions, and the range is 0-20.
3.2.3. Zeroing
When set to auto-zero, the DI positive/negative pulse count or DI logic level count value will be automatically
cleared after each reading.
When set to manually clear, DI positive/negative pulse count and DI logic level count value will not be cleared
every time, and need to be cleared manually. (Manually write the value 0 to clear)
C2000-A2-SDXA000-AX1 User Manual
12 / 26
SinoCon Co., Ltd. www.sinoconsys.com

4. Software Tools
4.1. Main Screen
The main screen displays the results of a broadcast search for the device.
Main Screen
1. Set: Set the device parameters
2. Remote Set: For Ethernet type devices, when the device is in the LAN but crosses multiple routers and
cannot be searched, the device parameters can be modified through Remote Set.
3. Change Password: Modify password of Ethernet type devices
4. Clear Password: Clear password of Ethernet type devices. If you need to clear the password, please contact
customer service.
5. Assistant: Help you debug the device, including Network Assistant, Serial Port Assistant, Analog
Conversion, Binary Conversion.
C2000-A2-SDXA000-AX1 User Manual
13 / 26
SinoCon Co., Ltd. www.sinoconsys.com

6. Search for Ethernet devices: Used to search Ethernet type devices
7. Search for serial devices: Used to search serial port devices
8. Listening settings: Used to connect the device in client mode to the software tool.
9. Search: Used to search for Ethernet and serial type devices.
10. Devices List: Display all searched devices.
11. Device Information: Display name, IP address, point value, etc. of the device, and you can modify the
point value of the device.
12. Refresh: Used to refresh the point value of the device after it changes.
4.2. Use Software
4.2.1. Device Settings
Open the software, select Search for serial devices and click Edit button to set the search parameters:
· COM ID: select the correct port for RS485 to USB;
· Baud rate: default 9600;
· Parity: default None;
· Data bit: default 8;
· Stop bit: default 1;
· Address range: range from 1 to 255, default 1 to 10;
· Timeout interval (ms): default 200.
Click Search to find the device, and select the device found, click Set in the header toolbar or double-click the
device found to set parameters for the device.
C2000-A2-SDXA000-AX1 User Manual
14 / 26
SinoCon Co., Ltd. www.sinoconsys.com

· Model: Unchangeable;
· Version: Unchangeable;
· Name: You can modify the device's name;
· Address: The RS485 address for the device ranges from 1 to 255.
4.2.2. View Device Status
Click Refresh at the bottom left screen to view the device point value information, as shown below:
C2000-A2-SDXA000-AX1 User Manual
15 / 26
SinoCon Co., Ltd. www.sinoconsys.com

· DI Value: Short DI and GND, value is 1; otherwise, the value is 0
· DI Positive/Negative pulse count: Number of pulse changes, readable and writable. When DI Automatic
zeroing is set to "Automatic", the pulse count will be clear automatically after each reading. When DI Automatic
zeroing is set to "Manual", the pulse count will not be clear after each reading (the maximum value is 65535 and
then reset to zero), which needs to be manually cleared (manually write value 0 to clear).
4.2.3. Control Device Status
The software can change the state of the device by changing the point value.
C2000-A2-SDXA000-AX1 User Manual
16 / 26
SinoCon Co., Ltd. www.sinoconsys.com

C2000-A2-SDXA000-AX1 User Manual
17 / 26
SinoCon Co., Ltd. www.sinoconsys.com

5. Protocol
The device uses the standard Modbus RTU protocol. If you have any questions about the protocol, you can refer
to the relevant Modbus documentation or consult with our customer service.
5.1. Registers
Start
Address
(decimal)
Number Parameter Name Read/Write
Status
Description Function Code
40001 1 Model R - 0x03
40002 1 Version Re.g. 5.2 (1282D) -> 1st:
5 (main version), 2st: 2
(secondary version)
0x03
40003 10 Name RW Less than 20
characters are padded
with 0. The high byte
is first e.g. read 2
registers with name
"1234" and return
0x32 0x31 0x34 0x33
40013 1 Address RW Range from 1 to 255,
default 1.
0x03，0x06，0x10
40014 1 Baud rate code RW Refer to the baud rate
code table. The
default value is 3,
which is 9600.
0x03，0x06，0x10
40015 1 AI parameter
recovery factory
mode
WOnly valid for devices
with AI channels,
restore AI
configuration
parameters after
writing. It does not
work for other devices
without AI channels.
0x06，0x10
40016 1 Reserved field RW Reserved
C2000-A2-SDXA000-AX1 User Manual
18 / 26
SinoCon Co., Ltd. www.sinoconsys.com

40017 1 Parity RW 0: None (default) 1:
Odd 2: Even Writing
other value is invalid.
0x03，0x06，0x10
40018 1 Restart WThe first time
write 0xa55a, the
second time
write 0x5aa5 within 2s,
the system restarts.
0x06，0x10
40019 1 Write-protected W Write 0x5A01 0x06，0x10
10100 16 DI1 ~ DI16 value R 0: OFF, 1: ON 0x02
40200 16 DI1 ~ DI16 positive
pulse active state
RW 0: no valid positive
pulse has been
generated yet. 1: a
valid positive pulse has
been generated Write
0 to clear, other values
are invalid
0x03，0x06，0x10
40216 8 DI1 ~
DI16 negative pulse
active state
RW 0: no valid
negative pulse has
been generated yet. 1:
a valid negative pulse
has been generated
Write 0 to clear, other
values are invalid
0x03，0x06，0x10
40232 16 DI1 ~ DI16 positive
pulse count
RW Range from 0x0000-
0xffff, any value can
be written. After
writing, count from
the written value
0x03，0x06，0x10
40248 16 DI1 ~
DI16 negative pulse
count
RW Range from 0x0000-
0xffff, any value can
be written. After
writing, count from
the written value
0x03，0x06，0x10
C2000-A2-SDXA000-AX1 User Manual
19 / 26
SinoCon Co., Ltd. www.sinoconsys.com

40264 16 DI1 ~ DI16 level
change count
RW Range from 0x0000-
0xffff, any value can
be written. After
writing, count from
the written value
0x03，0x06，0x10
40280 16 DI1 ~ DI16 filter
parameters
RW Default 0x6, and 6
sampling periods can
be confirmed. Range
from 0x1-0xffff, failed
to write 0 value.
0x03，0x06，0x10
40296 1 DI1 ~
DI16 automatic
zeroing
RW 0: manual zeroing 1:
automatic zeroing
0x03，0x06，0x10
Note: It's necessary to write the protection register, before modifying the serial port parameters. After
writing 0x5a01, the serial port parameters and name address can be modified within 10s.
5.1.1. Baud Rate Code
Value of register Baud rate
0x0000 1200
0x0001 2400
0x0002 4800
0x0003 9600
0x0004 19200
0x0005 38400
0x0006 57600
0x0007 115200
C2000-A2-SDXA000-AX1 User Manual
20 / 26
SinoCon Co., Ltd. www.sinoconsys.com
