Sinope TH1400NP User manual

CONNECTION OF THE FLOOR SENSOR
(OPTIONAL)
TH1400NP
Installation Guide
Non-Programmable
Low Voltage Thermostat (24 Vac)
WIRING LAYOUT
INSTALL YOUR THERMOSTAT
Unlock and lift the
thermostat cover.
Depending on the heating system,
insert each wire into its terminal
and screw firmly. (See connection
layouts outlined in the following
pages.)
Use the provided screws and
wall anchors to fix the
thermostat base on the wall.
Replace back and lock the
thermostat cover.
12
45Power up the thermostat.
6
If necessary, mark and drill the
appropriate fastening holes, using the
installation template. If needed, use
the wall anchors included.
3
AUXILIARY OUTPUT
The thermostat provides an auxiliary heating output that
can act as a second stage of heating when controlling
ambient temperature.
If the room temperature is too far from the setpoint or the
main stage of heating has difficulties raising the
temperature, the auxiliary output activates the secondary
heating source to reach the set temperature.
Both outputs can control different types of heating load and
can be configured in the user settings.
Electric baseboard
Electric baseboard
Floor sensor
Electric floor heating
Electric baseboard
Electric floor heating with electric
baseboard on the 2nd heating stage
C
W1
R
W2
S1
S 2
120 V
240 V
347 V
24 V 24 Vac
normally open
Valve
Floor sensor
For use in floor or ambient
mode with floor limit.
Not required for ambient
mode alone.
Hot water valve
Only for control applications in floor (F) mode or with floor limit.
Sensor
Set
Set
Set
Set
Increasing or lowering the temperature
To adjust the temperature, press or . The requested temperature
will blink to confirm the new setpoint.
When installing your floor heating system: add a
second sensor in the floor and store the tip in the
thermostat housing. This additional sensor can be
plugged in and used as a replacement without
haltering your floor heating system.

660-0736-0004-A
USER SETTINGS PARAMETERS THAT CAN BE CONTROLLED
FROM THE DEVICE (continued):
Lower the setpoint to its minimum and hold the button for
10 seconds to access the menu.
Press the or the button to change the setting.
Press the and the buttons simultaneously to save and go
to the next parameter. Continue to press until the end of the list
to exit the menu.
2) The thermostat features two temperature control modes:
A mode (default): Regulation of ambient temperature with the possibility
to limit floor temperature through an external temperature sensor.
F mode: Regulation of floor temperature through an external temperature
sensor with the possibility to limit ambient temperature.
#
Parameters & settings DisplayName
Aux 2nd
Stage Cyc
9
10
11
Backlight
12
PE
Sensor
Floor sensor
10K or 12K – (Default: 10K)
Circulator pump's anti-seizure
ON or OFF (Default: OFF)
3
Air
Max Limit
7
Maximum ambient temperature limit
(Only visible in F mode)
41 °F to 97 °F or OFF (default: OFF)
Minimum setpoint
41 °F to 97 °F – (Default: 41 °F)
Cycle lenght / Auxiliary output
OFF, 15 sec, 5 min, 10 min, 15 min, 20 min,
25 min, 30 min – (Default: OFF)
Backlight control
ON, OFF or BED – (Default: ON)
ON (backlight always active, will dim
according to ambient light)
OFF (will only turn on when a button
is pressed)
BED (bedroom mode - backlight will dim
according to ambient light and will turn
OFF below 20% of luminosity)
8
1st Stage
Cyc
5
Limit
Floor Max
Maximum floor temperature limit
(Only visible in A mode)
45 °F to 97 °F or OFF – (Default: OFF)
6
FLR Min
Limit
Minimum floor temperature limit
(Only visible in A mode)
41 °F to 93 °F or OFF (default: OFF)
Cycle lenght / Main output
15 sec, 5 min, 10 min, 15 min, 20 min,
25 min, 30 min – (Default: 15 min)
8) et 9) Main and auxiliary output cycle length
The thermostat has a main and an auxiliary output. Select the
appropriate cycle length based on your heating system. The selection
of an inappropriate cycle length may damage your unit.
PARAMETERS THAT CAN BE CONTROLLED FROM
THE DEVICE (CONTINUED):
12) Circulator pump's anti-seizure
When the thermostat is not heating for an extended period, this
parameter will activate the main output during 1 minute every
24 hours to ensure the hydronic system pump does not seize.
0.15 5 10 15 20 25 30
Convector or baseboard heater
activated by electronic relay (SSR)
Minimum cycle length
Fan-forced convector activated
by electronic relay (SSR)
Fan-forced convector or
baseboard heater activated by
mechanical relay
Hydronic heating pump system
Furnace
TECHNICAL SPECIFICATIONS
Operating voltage: 24 Vac
Maximum load: 1 Amp
Setpoint range: 5 ˚C to 36 ˚C (41 ˚F to 97 ˚F)
Display range: 0 ˚C to 70 ˚C (32 ˚F to 99 ˚F)
Resolution: ±0,5 ˚C (±1 ˚F)
Storage: -20 ˚C to 50 ˚C (-4 ˚F to 122 ˚F)
Auxiliary output: 24 Vac / Vdc / 0.1 A
Compatible with:
• Baseboard heater activated by mechanical relay or
electonic relay (SSR)
• Fan-forced convector activated by mechanical relay
or electronic relay (SSR)
• Electric floor heating (activated by a relay)
• Hydronic floor heating
• Hydronic heating system
• Furnace (without fan control)
3-year limited warranty
SINOPE TECHNOLOGIES INC. warrants the components of their products against
defects in material and workmanship for a 3-year period from the date of purchase,
under normal use and service, when proof of purchase of such is provided to the
manufacturer. This warranty does not cover any transportation costs that may be
incurred by the consumer. Nor does it cover a product that has been improperly
installed, misused or accidentally damaged.
The obligation of SINOPÉ TECHNOLOGIES INC., under the terms of this warranty,
will be to supply a new unit and this releases the manufacturer from paying the
installation costs or other secondary charges linked to replacing the unit or the
components.
PARAMETERS THAT CAN BE CONTROLLED
FROM THE DEVICE:
#
Parameters & settings Display
2
Name
Control
Setpoint
Min
4
Maximum setpoint
41 °F to 97 °F – (Default: 97°F)
Setpoint
Max
1
Display
Temperature format
°C or °F – (Default: °F)
Control mode of thermostat
A (Air), F (Floor) – (Default: A)
OFF MODE
To put the thermostat in OFF mode, hold the buttons and
for 10 seconds.
To exit the OFF mode, hold the buttons and for
10 seconds or raise/lower the setpoint.
Set
Hold for 10 sec.
Set
Hold for 10 sec.
TROUBLESHOOTING GUIDE
What should I do if the E1F code appears on
my thermostat's display?
The E1F code means that the thermostat is in
“Floor” mode and there is no connected
sensor. If your thermostat is not intended to
control a heated floor, change the thermostat’s
control mode for the “A mode”.
5) Maximum floor temperature limit (A mode)
The thermostat limits floor heating to the set temperature to ensure it
does not exceed the selected limit. This parameter is ideal for
protecting engineered wood floors. (Verify with your flooring
manufacturer to determine heat limit.)
This parameter can only be used when a floor sensor is connected to
the thermostat.
6) Minimum floor temperature limit (A mode)
The thermostat limits the minimum temperature of the floor in order to
keep it at a comfortable temperature.
This parameter can only be used when a floor sensor is connected to
the thermostat.
7) Maximum limit of the ambient temperature (F mode)
Thermostat limits floor heating so as not to exceed the set ambient
temperature limit.
