SIP 01954 User manual

1
01954
3hp Dust Collector
Single Bag
Please read and fully understand the instructions in
this manual before operation. Keep this manual
safe for future reference
1
01954
3hp Dust Collector
Single Bag
Please read and fully understand the instructions in
this manual before operation. Keep this manual
safe for future reference

2
2

3
CONTENTS
Page No. Description
3 Contents
4 General Safety Instructions
6 Specific Safety Instructions
8 Technical Specifications
8 Contents and Accessories
9 Guarantee
10 Electrical Connection
11 Assembly Instructions
15 Operating Instructions
15 Maintenance
16 Exploded Drawing
17 Parts List
18 Notes
3
CONTENTS
Page No. Description
3 Contents
4 General Safety Instructions
6 Specific Safety Instructions
8 Technical Specifications
8 Contents and Accessories
9 Guarantee
10 Electrical Connection
11 Assembly Instructions
15 Operating Instructions
15 Maintenance
16 Exploded Drawing
17 Parts List
18 Notes

4
GENERAL SAFETY INSTRUCTIONS
1. KNOW YOUR POWER TOOL. Read this owner's manual carefully. Learn the tool's ap-
plications and limitations, as well as its specific potential hazards.
2. KEEP GUARDS IN PLACE and in working order, never use the tool if any damage is
present.
3. REMOVE ADJUSTING KEYS AND WRENCHES. Form a habit of checking to see that
adjusting tools and wrenches are removed from machine before turning it on.
4. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
5. DON’T USE IN DANGEROUS ENVIRONMENTS. Don't use power tools in damp or wet
locations, or expose them to rain. Keep work area well lit. Don't use the tool in the pres-
ence of flammable liquids or gases.
6. KEEP CHILDREN AWAY. All visitors should be kept a safe distance from work area.
7. MAKE THE WORKSHOP CHILD PROOF with padlocks, master switches or by removing
starter keys.
8. DON’T FORCE THE TOOL. It will do the job better and safer at the rate for which it was
designed.
9. USE THE CORRECT TOOL. Don't force the tool or attachment to do a job for which it
was not designed; for example, don't use a circular saw for cutting tree limbs or logs.
10. WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings, brace-
lets, or other jewellery which may get caught in moving parts. Non-slip footwear is rec-
ommended. Wear protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use a face or dust mask if cutting operation is
dusty everyday, eyeglasses only have impact resistant lenses, they are NOT safety
glasses.
12. SECURE WORK. Use clamps or a vice to hold work when practical. It's safer than
using your hand and it frees both hands to operate tool.
13. DON’T OVERREACH. Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest per-
formance. Follow instructions for lubricating and changing accessories.
15. DISCONNECT THE TOOL. Before servicing; when changing accessories such as
blades, bits, cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure the switch is in the OFF
position before plugging in or inserting battery if applicable.
17. USE RECOMMENDED ACCESSORIES. Consult the owner's manual for recommend-
ed accessories. The use of improper accessories may cause risk of injury to persons or
damage to the tool.
18. NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted.
19. CHECK FOR DAMAGED PARTS. Before every use of the tool, check the guard or
other parts for damage, check to determine that it will operate properly and perform
its intended function - check for alignment of moving parts, binding of moving parts,
its operation. A guard or other part that is damaged should be properly repaired or
replaced.
4
GENERAL SAFETY INSTRUCTIONS
1. KNOW YOUR POWER TOOL. Read this owner's manual carefully. Learn the tool's ap-
plications and limitations, as well as its specific potential hazards.
2. KEEP GUARDS IN PLACE and in working order, never use the tool if any damage is
present.
3. REMOVE ADJUSTING KEYS AND WRENCHES. Form a habit of checking to see that
adjusting tools and wrenches are removed from machine before turning it on.
4. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
5. DON’T USE IN DANGEROUS ENVIRONMENTS. Don't use power tools in damp or wet
locations, or expose them to rain. Keep work area well lit. Don't use the tool in the pres-
ence of flammable liquids or gases.
6. KEEP CHILDREN AWAY. All visitors should be kept a safe distance from work area.
7. MAKE THE WORKSHOP CHILD PROOF with padlocks, master switches or by removing
starter keys.
8. DON’T FORCE THE TOOL. It will do the job better and safer at the rate for which it was
designed.
9. USE THE CORRECT TOOL. Don't force the tool or attachment to do a job for which it
was not designed; for example, don't use a circular saw for cutting tree limbs or logs.
10. WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings, brace-
lets, or other jewellery which may get caught in moving parts. Non-slip footwear is rec-
ommended. Wear protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use a face or dust mask if cutting operation is
dusty everyday, eyeglasses only have impact resistant lenses, they are NOT safety
glasses.
12. SECURE WORK. Use clamps or a vice to hold work when practical. It's safer than
using your hand and it frees both hands to operate tool.
13. DON’T OVERREACH. Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest per-
formance. Follow instructions for lubricating and changing accessories.
15. DISCONNECT THE TOOL. Before servicing; when changing accessories such as
blades, bits, cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure the switch is in the OFF
position before plugging in or inserting battery if applicable.
17. USE RECOMMENDED ACCESSORIES. Consult the owner's manual for recommend-
ed accessories. The use of improper accessories may cause risk of injury to persons or
damage to the tool.
18. NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the
cutting tool is accidentally contacted.
19. CHECK FOR DAMAGED PARTS. Before every use of the tool, check the guard or
other parts for damage, check to determine that it will operate properly and perform
its intended function - check for alignment of moving parts, binding of moving parts,
its operation. A guard or other part that is damaged should be properly repaired or
replaced.

5
GENERAL SAFETY INSTRUCTIONS….cont
20. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rota-
tion of the blade or cutter only.
21. NEVER LEAVE THE TOOL RUNNING UNATTENDED. TURN the power off. Don't leave
the tool until it comes to a complete stop.
22. DON’T ABUSE CORD. Never carry the tool by the cord or pull it to disconnect the
plug from the mains socket. Keep cord away from heat, oil and sharp edges.
23. USE SUITABLE VOLTAGE. Before connecting the machine to a power source, be
sure that the voltage supplied is the same as that specified on the nameplate of the
machine.
5
GENERAL SAFETY INSTRUCTIONS….cont
20. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rota-
tion of the blade or cutter only.
21. NEVER LEAVE THE TOOL RUNNING UNATTENDED. TURN the power off. Don't leave
the tool until it comes to a complete stop.
22. DON’T ABUSE CORD. Never carry the tool by the cord or pull it to disconnect the
plug from the mains socket. Keep cord away from heat, oil and sharp edges.
23. USE SUITABLE VOLTAGE. Before connecting the machine to a power source, be
sure that the voltage supplied is the same as that specified on the nameplate of the
machine.

6
SPECIFIC SAFETY INSTRUCTIONS
The filtration housing contains a high speed fan that can amputate fingers, grab
loose clothing and neckties, propel dust and chips of wood at high velocities.
DO NOT OPERATE WITHOUT ALL GUARDS AND PARTS IN PLACE.
Do not attempt to clean the extractor, remove the dust bags, or service the unit
when the power is ON. Turn the extractor OFF and disconnect the mains lead
from the power supply and allow the internal fan to come to a complete stop
prior to any adjustment, cleaning or maintenance.
Static shocks are common in dry areas or when the relative humidity of the air is
too low, The use of a humidifier in the work place will help raise the relative hu-
midity, and may reduce static shocks.
DO NOT vacuum, or use the dust collector near flammable or combustible liq-
uids, gases, petrol or any other fuels or liquids.
DO NOT vacuum anything that is burning, hot or smoking, such as cigarettes,
matches, or hot ashes.
Be aware what is likely to get sucked into the machine, avoid sucking up metal
objects such as nails etc. This extractor is designed for the sole purpose of ex-
tracting wood chippings or similar. Internal damage could occur if this rule is not
followed.
Use the extractor on a stable, level surface.
Position the vacuum hose and mains lead away from heavy traffic areas.
Do not use the extractor without the dust / filter bag and the chip bag in place.
Always ensure the mains supply matches what is written on the specification
plate of the dust extractor (or in this manual), and that the supply is correctly
earthed.
Use only the correct heavy duty bags when replacing the filter or the collection
bag.
CAUTION: Using this dust collector should help to keep airborne dust within ac-
ceptable limits, you must regularly monitor airborne dust and maintain your dust
collector accordingly to avoid exceeding these limits. Each application is
unique, your maintenance schedule must therefore be tailored to your specific
use of this dust extractor. Safety is a combination of common sense, staying
alert, and knowing how your dust collector works.
Do not uplift workshop floor debris if it contains stones, nails, screws etc, the ex-
tractor is only designed for wood and wood by-products.
Be aware that wood dust is an explosive medium. Do not allow any ‘naked’ light
source to occur anywhere near the machine, this includes cigarettes, matches,
etc, and do not place the extractor near any unprotected light bulbs, or other
Caution! If used incorrectly, woodworking machines can be dangerous;
for this reason always comply with the safety instructions mentioned in this
manual.
6
SPECIFIC SAFETY INSTRUCTIONS
The filtration housing contains a high speed fan that can amputate fingers, grab
loose clothing and neckties, propel dust and chips of wood at high velocities.
DO NOT OPERATE WITHOUT ALL GUARDS AND PARTS IN PLACE.
Do not attempt to clean the extractor, remove the dust bags, or service the unit
when the power is ON. Turn the extractor OFF and disconnect the mains lead
from the power supply and allow the internal fan to come to a complete stop
prior to any adjustment, cleaning or maintenance.
Static shocks are common in dry areas or when the relative humidity of the air is
too low, The use of a humidifier in the work place will help raise the relative hu-
midity, and may reduce static shocks.
DO NOT vacuum, or use the dust collector near flammable or combustible liq-
uids, gases, petrol or any other fuels or liquids.
DO NOT vacuum anything that is burning, hot or smoking, such as cigarettes,
matches, or hot ashes.
Be aware what is likely to get sucked into the machine, avoid sucking up metal
objects such as nails etc. This extractor is designed for the sole purpose of ex-
tracting wood chippings or similar. Internal damage could occur if this rule is not
followed.
Use the extractor on a stable, level surface.
Position the vacuum hose and mains lead away from heavy traffic areas.
Do not use the extractor without the dust / filter bag and the chip bag in place.
Always ensure the mains supply matches what is written on the specification
plate of the dust extractor (or in this manual), and that the supply is correctly
earthed.
Use only the correct heavy duty bags when replacing the filter or the collection
bag.
CAUTION: Using this dust collector should help to keep airborne dust within ac-
ceptable limits, you must regularly monitor airborne dust and maintain your dust
collector accordingly to avoid exceeding these limits. Each application is
unique, your maintenance schedule must therefore be tailored to your specific
use of this dust extractor. Safety is a combination of common sense, staying
alert, and knowing how your dust collector works.
Do not uplift workshop floor debris if it contains stones, nails, screws etc, the ex-
tractor is only designed for wood and wood by-products.
Be aware that wood dust is an explosive medium. Do not allow any ‘naked’ light
source to occur anywhere near the machine, this includes cigarettes, matches,
etc, and do not place the extractor near any unprotected light bulbs, or other
Caution! If used incorrectly, woodworking machines can be dangerous;
for this reason always comply with the safety instructions mentioned in this
manual.

7
SPECIFIC SAFETY INSTRUCTIONS….cont
heat sources.
If you are not using ‘clear’ extraction hose, periodically remove the hose to
check that the inlet to the machine is not getting restricted. (The safety guard
grill of the inlet duct can be particularly prone to blockage particularly if the op-
eration produces large amounts chippings such as when the extractor is con-
nected to a planer or thicknesser.
Keep the dust bag clean, the machine relies on its ability to ‘blow’ air through
the dust bag, to generate good suction. If the cloth of the bag starts to clog,
this reduces the air flow and hence the machine becomes less efficient.
Empty the bag as often as possible (and is practical); as the bag fills up there is
less free area of the bag to allow the air to flow through, again reducing the
efficiency of the machine.
Before using your dust extractor:
Fully complete the assembly, mounting, and alignment of all parts of the dust
extractor.
Learn the function and correct use of the on / off (NVR) switch.
Read and understand all the safety instructions and operating procedures
throughout this manual.
Before each use:
Inspect your dust collector, If any parts are missing, damaged, bent, or fail in
any way, or any electrical components do not work correctly, turn off the dust
collector and remove the plug from the mains supply.
Replace damaged, missing, or failed parts immediately.
When cleaning the collection bags, always wear a dust mask and eye protec-
tion.
WARNING! Before connecting the dust collector to the mains supply be
sure that the voltage supply is the same as that specified on the name-
plate of the tool. A power source with a voltage greater or lower than that
specified for the tool can result in serious injury to the user, as well as dam-
age to the tool. If in doubt, do not plug the tool into the mains supply.
Always turn the machine off and remove the plug from the mains socket
before making any adjustments or maintenance.
CAUTION: The warnings and cautions mentioned in this user manual can
not cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be applied.
7
SPECIFIC SAFETY INSTRUCTIONS….cont
heat sources.
If you are not using ‘clear’ extraction hose, periodically remove the hose to
check that the inlet to the machine is not getting restricted. (The safety guard
grill of the inlet duct can be particularly prone to blockage particularly if the op-
eration produces large amounts chippings such as when the extractor is con-
nected to a planer or thicknesser.
Keep the dust bag clean, the machine relies on its ability to ‘blow’ air through
the dust bag, to generate good suction. If the cloth of the bag starts to clog,
this reduces the air flow and hence the machine becomes less efficient.
Empty the bag as often as possible (and is practical); as the bag fills up there is
less free area of the bag to allow the air to flow through, again reducing the
efficiency of the machine.
Before using your dust extractor:
Fully complete the assembly, mounting, and alignment of all parts of the dust
extractor.
Learn the function and correct use of the on / off (NVR) switch.
Read and understand all the safety instructions and operating procedures
throughout this manual.
Before each use:
Inspect your dust collector, If any parts are missing, damaged, bent, or fail in
any way, or any electrical components do not work correctly, turn off the dust
collector and remove the plug from the mains supply.
Replace damaged, missing, or failed parts immediately.
When cleaning the collection bags, always wear a dust mask and eye protec-
tion.
WARNING! Before connecting the dust collector to the mains supply be
sure that the voltage supply is the same as that specified on the name-
plate of the tool. A power source with a voltage greater or lower than that
specified for the tool can result in serious injury to the user, as well as dam-
age to the tool. If in doubt, do not plug the tool into the mains supply.
Always turn the machine off and remove the plug from the mains socket
before making any adjustments or maintenance.
CAUTION: The warnings and cautions mentioned in this user manual can
not cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be applied.

8
TECHNICAL SPECIFICATIONS
Part Number 01954
Input Voltage 230v ~ 50hz
Power 3 hp (2237 watts)
Air Flow 2526 m³/hour
Inlet Ø 2 x 100 mm
Impellor Ø 300 mm
Net Weight 47 Kg
CONTENTS AND ACCESSORIES
8
TECHNICAL SPECIFICATIONS
Part Number 01954
Input Voltage 230v ~ 50hz
Power 3 hp (2237 watts)
Air Flow 2526 m³/hour
Inlet Ø 2 x 100 mm
Impellor Ø 300 mm
Net Weight 47 Kg
CONTENTS AND ACCESSORIES

9
CONTENTS AND ACCESSORIES….cont
A. Hose H. Filter / Collection Bags
B. Impellor / Motor Assembly I. Gasket
C. Collector Body J. Castors
D. Base Plate K. Fixing kit / Tools
E. Filter Bag Support L. Outlet Adaptor
F. Collector Body Supports M. Hose Clamps
G. Inlet Adaptor O. Bag Clamps
GUARANTEE
Guarantee:
This SIP dust collector is covered by a 24 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the machine outside the scope of this manual.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Proof of purchase will be required before any warranty can be honoured.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
9
CONTENTS AND ACCESSORIES….cont
A. Hose H. Filter / Collection Bags
B. Impellor / Motor Assembly I. Gasket
C. Collector Body J. Castors
D. Base Plate K. Fixing kit / Tools
E. Filter Bag Support L. Outlet Adaptor
F. Collector Body Supports M. Hose Clamps
G. Inlet Adaptor O. Bag Clamps
GUARANTEE
Guarantee:
This SIP dust collector is covered by a 24 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the machine outside the scope of this manual.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Proof of purchase will be required before any warranty can be honoured.
Note: Proof of purchase will be required before any warranty can be hon-
oured.

10
ELECTRICAL CONNECTION
Connecting to the power supply:
This SIP dust collector is fitted with a standard 230v ~ 13 amp plug. Before using the
machine, inspect the mains lead and plug to ensure that neither are damaged. If
any damage is visible have the lathe inspected / repaired by a suitably qualified per-
son. If it is necessary to replace the plug a heavy duty impact resistant plug would be
preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be connect-
ed to the terminal, which is marked L or coloured red. The wire which is coloured yel-
low / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Note: Always make sure the mains supply is of the correct voltage and
the correct fuse protection is used. In the event of replacing the fuse al-
ways replace like for like.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating (230v ~
13 amps).
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.
Warning: Never connect live or neutral wires to the earth terminal of the
plug. Only fit an approved plug with the correct rated fuse. If in doubt
consult a qualified electrician.
10
ELECTRICAL CONNECTION
Connecting to the power supply:
This SIP dust collector is fitted with a standard 230v ~ 13 amp plug. Before using the
machine, inspect the mains lead and plug to ensure that neither are damaged. If
any damage is visible have the lathe inspected / repaired by a suitably qualified per-
son. If it is necessary to replace the plug a heavy duty impact resistant plug would be
preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be connect-
ed to the terminal, which is marked L or coloured red. The wire which is coloured yel-
low / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Note: Always make sure the mains supply is of the correct voltage and
the correct fuse protection is used. In the event of replacing the fuse al-
ways replace like for like.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating (230v ~
13 amps).
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.
Warning: Never connect live or neutral wires to the earth terminal of the
plug. Only fit an approved plug with the correct rated fuse. If in doubt
consult a qualified electrician.

11
ASSEMBLY INSTRUCTIONS
Firstly; attach the 4 x casters to the relevant
holes on the corners of the base plate using
the screws, washers and nuts provided. Fully
tighten to secure. FIG. 1.
Fit the collector body / motor housing to the
motor support bracket as shown, using the
bolts, washers and nuts provided. Then fit the
whole assembly to the main base using the
bolts and washers provided. Fully tighten all
nuts / bolts to secure. FIG. 2.
Fit the gasket to the outlet opening of the col-
lector body / motor housing. FIG. 3.
Fit the inlet adaptor over the gasket ensuring
that the holes all line up. Secure in place with
the bolts, washers and nuts provided. Fully
tighten secure in place. FIG. 4.
11
ASSEMBLY INSTRUCTIONS
Firstly; attach the 4 x casters to the relevant
holes on the corners of the base plate using
the screws, washers and nuts provided. Fully
tighten to secure. FIG. 1.
Fit the collector body / motor housing to the
motor support bracket as shown, using the
bolts, washers and nuts provided. Then fit the
whole assembly to the main base using the
bolts and washers provided. Fully tighten all
nuts / bolts to secure. FIG. 2.
Fit the gasket to the outlet opening of the col-
lector body / motor housing. FIG. 3.
Fit the inlet adaptor over the gasket ensuring
that the holes all line up. Secure in place with
the bolts, washers and nuts provided. Fully
tighten secure in place. FIG. 4.

12
ASSEMBLY INSTRUCTIONS….cont
Fit the 3 x collector supports to the base as
shown with the bolts and washers provided.
Fully tighten to secure. FIG. 5.
Fit the collector as shown with the bolts and
washers provided. Note: Only fit the 2 x side
supports with bolts at this point; leave the 3rd
one free. FIG. 6.
Fit the upper bag support to the 3rd support as
shown and fully tighten all bolts to secure. FIG.
7.
12
ASSEMBLY INSTRUCTIONS….cont
Fit the 3 x collector supports to the base as
shown with the bolts and washers provided.
Fully tighten to secure. FIG. 5.
Fit the collector as shown with the bolts and
washers provided. Note: Only fit the 2 x side
supports with bolts at this point; leave the 3rd
one free. FIG. 6.
Fit the upper bag support to the 3rd support as
shown and fully tighten all bolts to secure. FIG.
7.

13
ASSEMBLY INSTRUCTIONS….cont
Now fit a hose clamp over the hose and slide
one end of the hose over the outlet adaptor; fit
the 2nd hose clamp over the other end of the
hose and slide that end over the opening in
the collector. FIG. 8.
Fit the collection / filter bags over the collector
as shown. Secure in place with the bag
clamps provided. FIG. 9.
Fit the double inlet adaptor over the inlet on
the collector body / motor housing and secure
in place with the screw provided. FIG. 10.
13
ASSEMBLY INSTRUCTIONS….cont
Now fit a hose clamp over the hose and slide
one end of the hose over the outlet adaptor; fit
the 2nd hose clamp over the other end of the
hose and slide that end over the opening in
the collector. FIG. 8.
Fit the collection / filter bags over the collector
as shown. Secure in place with the bag
clamps provided. FIG. 9.
Fit the double inlet adaptor over the inlet on
the collector body / motor housing and secure
in place with the screw provided. FIG. 10.

14
ASSEMBLY INSTRUCTIONS….cont
When the dust collector has been fully assembled, a second check should be carried
out to ensure that all of the nuts, bolts and bags etc. are fitted correctly and are fully
secure. After the re-inspection, you can connect the machine to a power source and
have a trial run (see page 15 for operating instructions).
NOTE: The trial run should be done according to the Safety Rules and care should be
taken to ensure nothing that could get sucked in is close to the inlet of the dust collec-
tor.
14
ASSEMBLY INSTRUCTIONS….cont
When the dust collector has been fully assembled, a second check should be carried
out to ensure that all of the nuts, bolts and bags etc. are fitted correctly and are fully
secure. After the re-inspection, you can connect the machine to a power source and
have a trial run (see page 15 for operating instructions).
NOTE: The trial run should be done according to the Safety Rules and care should be
taken to ensure nothing that could get sucked in is close to the inlet of the dust collec-
tor.

15
OPERATING INSTRUCTIONS
On / Off NVR Switch:
Once fully assembled an inlet pipe can be fitted to the inlet adaptor and the desired
woodworking machine.
To start the dust collector; lift the yellow cover and press the green button (I).
To stop the dust collector; press the red (0) button, or alternatively close the yellow
cover.
Your SIP dust collector is fitted with a safety NVR (No Volt Release) switch. This means
that if power is cut to the dust collector (such as in a power failure); the motor will not
start to run once the power is returned without the operator following the above in-
structions to restart the dust collector.
Ensure all clamps, hose and bag, are secure and follow the instructions above to start
the motor.
Once the operation is complete; follow the instructions above to stop the motor.
Always check the collector bag, and empty as often as possible / is practical.
Note: To maximise the air-flow and suction capabilities of the dust extractor always
remove the 2nd pipe (if connected) from the double inlet adaptor and fit the adaptor
cover, when you are only working on one planer / saw etc.
MAINTENANCE
This dust extractor needs very little maintenance a common sense approach should
give you years of good service.
Ensure all nuts / bolts etc are tight before each use.
Empty and clean bags regularly.
Ensure that all hoses are clear from debris regularly.
Always keep the motor free from contamination.
If your collection / filter bags become damaged or if you need a spare set they are
available on the following SIP part numbers: 35 Micron set - 65800
5 Micron set - 65801
15
OPERATING INSTRUCTIONS
On / Off NVR Switch:
Once fully assembled an inlet pipe can be fitted to the inlet adaptor and the desired
woodworking machine.
To start the dust collector; lift the yellow cover and press the green button (I).
To stop the dust collector; press the red (0) button, or alternatively close the yellow
cover.
Your SIP dust collector is fitted with a safety NVR (No Volt Release) switch. This means
that if power is cut to the dust collector (such as in a power failure); the motor will not
start to run once the power is returned without the operator following the above in-
structions to restart the dust collector.
Ensure all clamps, hose and bag, are secure and follow the instructions above to start
the motor.
Once the operation is complete; follow the instructions above to stop the motor.
Always check the collector bag, and empty as often as possible / is practical.
Note: To maximise the air-flow and suction capabilities of the dust extractor always
remove the 2nd pipe (if connected) from the double inlet adaptor and fit the adaptor
cover, when you are only working on one planer / saw etc.
MAINTENANCE
This dust extractor needs very little maintenance a common sense approach should
give you years of good service.
Ensure all nuts / bolts etc are tight before each use.
Empty and clean bags regularly.
Ensure that all hoses are clear from debris regularly.
Always keep the motor free from contamination.
If your collection / filter bags become damaged or if you need a spare set they are
available on the following SIP part numbers: 35 Micron set - 65800
5 Micron set - 65801

16
EXPLODED DRAWING
16
EXPLODED DRAWING

17
PARTS LIST
Ref No. Description Ref No. Description
1. Universal Caster 29. Main Fan Assembly Outlet Seal
2. Nut M8 30. Main Fan Assembly Outlet
3. Base Plate 31. Hose clamp
4. Washer 8 mm 32. Main On-board Hose
5. Motor Support Bracket 33. Collector assembly
6. Bolt M8 x 16 34. Bag clamp
7. Mains Lead 35. Filter bag
8. Motor 36. Collector bag
9. Switch 37. Inlet adaptor cover
10. Capacitor
11. Switch box
12. Bolt M8 x 25
13. Upper bag support
14. Collector Support
15. Bolt M6 x 20
16. Washer 6 mm
17. Key
18. Packing
19. Nut M6
20. Washer
21. Screw Hex
22. Turbo Fan
23. Screw M6 Cross head
24. Double Inlet Adaptor
25. Inlet cover
26. Screw Hex
27. Washer
28. Screw hex
17
PARTS LIST
Ref No. Description Ref No. Description
1. Universal Caster 29. Main Fan Assembly Outlet Seal
2. Nut M8 30. Main Fan Assembly Outlet
3. Base Plate 31. Hose clamp
4. Washer 8 mm 32. Main On-board Hose
5. Motor Support Bracket 33. Collector assembly
6. Bolt M8 x 16 34. Bag clamp
7. Mains Lead 35. Filter bag
8. Motor 36. Collector bag
9. Switch 37. Inlet adaptor cover
10. Capacitor
11. Switch box
12. Bolt M8 x 25
13. Upper bag support
14. Collector Support
15. Bolt M6 x 20
16. Washer 6 mm
17. Key
18. Packing
19. Nut M6
20. Washer
21. Screw Hex
22. Turbo Fan
23. Screw M6 Cross head
24. Double Inlet Adaptor
25. Inlet cover
26. Screw Hex
27. Washer
28. Screw hex

18
NOTES
18
NOTES

19
NOTES
19
NOTES

20
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR.
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
Ref:180311
20
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR.
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
Ref:180311
