SIP 01504 User manual

28
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
Ref: 250113
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
1
12” Double Bevel
Mitre Saw
Please read and fully understand the instructions in
this manual before operation. Keep this manual
safe for future reference
01504

2
27
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
12” Double Bevel Mitre Saw - SIP Pt. No. 01504
Conforms to the requirements of the following directive(s), as indicated.
2006/95/EC Low Voltage Directive
2006/42/EC Machinery Directive
2004/108/EC EMC Directive
2002/95/EC ROHS Directive
As Amended By
2008/35/EC
And the following harmonised standard(s)
EN 55014-1+A1:2009
EN 55014-2+A2:2008
EN 61000-3-2+A2:2009
EN 61000-3-11:2000
EN 61029-1:2009+A11
EN 61029-2-9:2009
Signed:
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 14/09/2012.
DECLARATION OF CONFORMITY

26
NOTES
3
Page No. Description
4. General Safety Instructions
6. Specific Safety Instructions
8. Technical Specifications
9. Electrical Connection
10. Guarantee
10. Contents and Accessories
11. Getting To Know Your Saw
12. Assembly Instructions
13. Operating Instructions
17. Maintenance
20. Exploded Diagram
21. Parts List
25. Notes
27. Declaration of Conformity
CONTENTS

4
GENERAL SAFETY INSTRUCTIONS
Please read the following instructions carefully, failure to do so could lead to serious
personal injury.
When using electric tools, basic safety precautions should always be followed to re-
duce the risk of fire, electric shock and personal injury.
Read all these instructions before operating the tool and save this user manual for fu-
ture reference.
SIP recommends that this tool should not be modified or used for any application oth-
er than that for which it was designed. If you are unsure of its relative applications do
not hesitate to contact us and we will be more than happy to advise you.
KNOW YOUR POWER TOOL: Read and understand the owner's manual and labels af-
fixed to the tool. Learn its applications and limitations, as well as the potential hazards
specific to this tool.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite
accidents. Floors must not be slippery due to oil, water or sawdust etc.
DO NOT USE THE TOOL IN DANGEROUS ENVIRONMENTS: Do not use power tools in
damp or wet locations, or expose them to rain. Provide adequate space surrounding
the work area. Do not use in environments with a potentially explosive atmosphere.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
STORE TOOLS SAFELY WHEN THEY ARE NOT IN USE: All tools should be stored in a dry,
locked cupboard wherever possible and out of the reach of children.
WEAR THE CORRECT CLOTHING: Do not wear loose clothing, neckties, rings, bracelets,
or other jewellery, which may get caught in moving parts. Non-slip footwear is recom-
mended. Wear protective hair covering to contain long hair. Roll long sleeves up
above the elbow.
USE SAFETY GOGGLES AND EAR PROTECTION: Wear CE approved safety goggles at all
times, Normal spectacles only have impact resistant lenses, they are NOT safety glass-
es. A face or dust mask should be worn if the operation is dusty and ear protectors
(plugs or muffs) should be worn, particularly during extended periods of operation.
PROTECT YOURSELF FROM ELECTRIC SHOCK: When working with power tools, avoid
contact with any earthed items (e.g. pipes, radiators, hobs and refrigerators, etc.). It is
advisable wherever possible to use an RCD (residual current device) at the mains
socket.
STAY ALERT: Always watch what you are doing and use common sense. Do not oper-
ate a power tool when you are tired or under the influence of alcohol or drugs.
DISCONNECT THE TOOL FROM THE MAINS SUPPLY: When not in use, before servicing
and when changing accessories such as cutters, blades etc.
AVOID UNINTENTIONAL STARTING: Make sure the switch is in the OFF position before
connecting the tool to the mains supply.
NEVER LEAVE THE TOOL RUNNING / CONNECTED WHILST UNATTENDED: Turn off the tool
and disconnect it from the mains supply between jobs. Do not leave machine until it
25
NOTES

24
PARTS LIST….cont
Ref No. Description SIP Part No. Ref No. Description SIP Part No.
188 Screw WD01-00351 206 Washer WD01-00369
189 Lock handle WD01-00352 207 Shield lock piece WD01-00370
190 Fixture WD01-00353 208 Shield lock sheet WD01-00371
191 Locked nut WD01-00354 209 Spring WD01-00372
192 Pin WD01-00355 210 Washer WD01-00373
193 Role pin WD01-00356 211 Locknut WD01-00374
194 Lock bolt WD01-00357 212 Washer WD01-00375
195 Pressure plate WD01-00358 213 Spring washer WD01-00376
196 Washer WD01-00359 214 Screw WD01-00377
197 Screw WD01-00360 215 Spring washer WD01-00378
198 Lock washer WD01-00361 216 Wave washer WD01-00379
199 Head sunk screw WD01-00362 217 Nut WD01-00380
200 Orientation board WD01-00363 218 Dust bag WD01-00381
201 Spring washer WD01-00364 116-123 Complete laser assembly WD01-00382
202 Socket head screw WD01-00365 2,3,19,41-57 Complete motor assembly WD01-00383
203 Spring WD01-00366 2,62-73 Complete gear box assembly WD01-00384
204 Capacitor WD01-00367 53-54 Complete brush set WD01-00385
205 Screw WD01-00368
5
GENERAL SAFETY INSTRUCTIONS...cont
comes to a complete stop.
DO NOT ABUSE THE MAINS LEAD: Never carry the tool by the mains lead or pull it to re-
move the plug from the mains socket. Keep the mains lead away from heat, oil and
sharp edges. If the mains lead is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid unwanted hazards.
CHECK FOR DAMAGED PARTS: Before every use of the tool, a guard or other part that is
damaged should be carefully checked to determine that it will operate correctly and
perform its intended function. Check for alignment of moving parts, free running of
moving parts, breakage of parts, and any other conditions that may affect its opera-
tion. A guard or other part that is damaged should be correctly repaired or replaced
by an authorized service centre unless otherwise indicated in this instruction manual.
Have defective switches replaced by an authorized service agent. Do not use the tool
if the switch does not turn it on and off.
KEEP ALL GUARDS IN PLACE: And in full working order.
MAINTAIN TOOLS WITH CARE: Keep tools sharp and clean for the best and safest per-
formance. Follow instructions for lubricating and changing accessories. All extension
cables must be checked at regular intervals and replaced if damaged. Always keep
the hand grip on the tool clean, dry and free of oil and grease.
USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual for recommended
accessories. Follow the instructions that accompany the accessories. The use of im-
proper accessories may cause hazards and will invalidate any warranty you may
have.
REMOVE ADJUSTING KEYS AND WRENCHES: Form a habit of checking to see that keys
and adjusting wrenches are removed from the tool before every use.
SECURE THE WORKPIECE: Use clamps or a vice to hold the work-piece . This frees up
both hands to operate the tool.
DO NOT OVERREACH: Keep proper footing and balance at all times.
USE THE RIGHT TOOL: Do not use the tool or attachment to do a job for which it was
not designed.
DO NOT FORCE THE TOOL: It will do the job better and more safely at the rate which it
was designed.
DO NOT OPERATE POWER TOOLS IN EXPLOSIVE ATMOSPHERES: Do not use the tool in
the presence of flammable liquids, gases, dust or other combustible sources. Power
tools may create sparks which can ignite the dust or fumes.
DO NOT EXPOSE THE TOOL TO RAIN OR USE IT IN WET CONDITIONS: Water entering a
power tool will greatly increase the risk of electric shock.
HAVE YOUR TOOL REPAIRED BY A QUALIFIED PERSON: The tool is in accordance with the
relevant safety requirements. Repairs should only be carried out by qualified persons
using original spare parts, otherwise this may result in considerable danger to the user.

6
Use only the blade flange specified for this tool.
Be careful not to damage the arbor, flange (especially the installing surface).
Damage to these parts could result in blade breakage. And / or operator injury.
Make sure that the table base is properly secured so it will not move during op-
eration.
For your safety; remove the chippings and work debris etc. from the table top
and from inside the extraction port before each operation.
Avoid cutting nails / screws etc.; Remove all obstructions from the work-piece
before cutting.
Make sure that all keys and wrenches are removed before switching on the
saw.
Be sure that the blade does not come into contact with the table and / or table
insert when the blade is in operation.
Keep hands out of path of saw blade, never reach around saw blade.
Make sure the blade is clear of the work-piece before the switch is turned on.
Before making the first cut using the saw, turn the blade by hand to ensure noth-
ing is catching, then turn the saw on and let it run for a while; Watch for vibration
or wobbling that could indicate poor installation or a poorly balanced blade.
Adjust or replace as necessary.
Allow the blade to run up to full speed before cutting.
Stop operation immediately if you notice anything abnormal.
Wait for the saw blade to stop completely and remove from mains supply be-
fore servicing or adjusting tool.
Be alert at all times, especially during repetitive, monotonous operations. Don't
be lulled into a false sense of security. Blades are extremely unforgiving.
Use of improper accessories such as abrasive wheels may cause damage to
the saw and surrounding area as well as increasing the risk of injury.
Turn off the saw and wait for it to complete stop before moving work-piece or
changing settings.
Do not modify the saw to do tasks other than those intended.
Do not perform any operation freehand. The work-piece must be secured firmly
against the base and guide fence with the clamp during all operations; Using
your hand may cause severe injury.
SPECIFIC SAFETY INSTRUCTIONS
Warning: The laser beam can potentially cause severe eye damage.
Never look or stare directly into the laser beam.
Warning: During use, do not point the laser beam at people, directly or indirectly
through reflecting surfaces.
23
PARTS LIST….cont
Ref No. Description SIP Part No. Ref No. Description SIP Part No.
125 Arm WD01-00289 156 Lock boot WD01-00320
126 Rubber ring WD01-00290 158 Lock bolt WD01-00321
127 Slide WD01-00291 159 Support bar WD01-00322
128 Bevel lock handle WD01-00292 160 Lock handle WD01-00323
129 Washer WD01-00293 161 Screw WD01-00324
130 Locknut WD01-00294 162 Lock handle cap WD01-00325
131 Washer WD01-00295 163 Base WD01-00326
132 Nut WD01-00296 164 Rubber foot WD01-00327
133 Socket head screw WD01-00297 165 Mitre scale WD01-00328
134 Bevel pointer WD01-00298 166 Detent Roll WD01-00329
135 Screw WD01-00299 167 Detent Spring WD01-00330
136 Bevel scale WD01-00300 168 Hex grub screw WD01-00331
137 Straight cut setting pin WD01-00301 169 Bolt knurled WD01-00332
138 Stud WD01-00302 170 Screw WD01-00333
139 Stud WD01-00303 171 Support bar WD01-00334
140 Locknut WD01-00304 172 Fence WD01-00335
141 Washer WD01-00305 173 Socket head screw WD01-00336
142 Socket head screw WD01-00306 174 Left attach fence WD01-00337
143 Screw WD01-00307 175 Screw WD01-00338
144 Orientation board WD01-00308 176 Clamp WD01-00339
145 Screw WD01-00309 177 Support arm WD01-00340
146 Cutting insert WD01-00310 178 Knob (short) WD01-00341
147 Screw WD01-00311 179 Work-piece knob WD01-00342
148 Turntable WD01-00312 180 Support pole WD01-00343
149 Mitre pointer WD01-00313 181 Socket head screw WD01-00344
150 Screw WD01-00314 182 Knob (short) WD01-00345
151 Turntable bolt WD01-00315 183 Knob (long) WD01-00346
152 Turntable bolt cover WD01-00316 184 Right attach fence WD01-00347
153 Screw WD01-00317 185 Socket head screw WD01-00348
154 Knob (long) WD01-00318 186 Slide stopper WD01-00349
155 Safety foot WD01-00319 187 Lock handle cap WD01-00350

22
PARTS LIST….cont
Ref No. Description SIP Part No. Ref No. Description SIP Part No.
63 Gear case cover WD01-00227 94 Linkage (B) WD01-00258
64 Bearing WD01-00228 95 Torsion spring WD01-00259
65 Shaft gear WD01-00229 96 Spring bushing WD01-00260
66 Flat key WD01-00230 97 Trench depth bracket WD01-00261
67 Bearing WD01-00231 98 Spring piece WD01-00262
68 Key WD01-00232 99 Wave washer WD01-00263
69 Spindle WD01-00233 100 Screw WD01-00264
70 C clip WD01-00234 101 Pivot shaft WD01-00265
71 Bearing WD01-00235 102 Steel wire baffle ring WD01-00266
72 Gear WD01-00236 103 Bracket WD01-00267
73 Bearing WD01-00237 104 Linear bearing WD01-00268
74 Fixed guard WD01-00238 105 Bearing cover WD01-00269
75 Dust pipe run WD01-00239 106 Screw WD01-00270
76 Sunk screw WD01-00240 107 Linear bearing WD01-00271
77 Nut WD01-00241 108 Spring loop WD01-00272
78 Plate guarding (big) WD01-00242 109 Knob (long) WD01-00273
79 Plate guarding (small) WD01-00243 110 Socket head screw WD01-00274
80 Moving guard plate WD01-00244 111 Lock pin WD01-00275
81 Big washer WD01-00245 112 Rolled pin WD01-00276
82 Screw WD01-00246 113 Lock pin spring WD01-00277
83 Spring WD01-00247 114 Lock pin cap WD01-00278
84 Cast centre WD01-00248 115 Bearing cover WD01-00279
85 Screw WD01-00249 116 Laser fixed plate WD01-00280
86 Rivet WD01-00250 117 Screw WD01-00281
87 Screw WD01-00251 118 Dual laser carrier WD01-00282
88 Moving guard WD01-00252 119 Screw WD01-00283
89 Moving guard cover WD01-00253 120 Laser WD01-00284
90 Shoulder Screw WD01-00254 121 Screw WD01-00285
91 Linkage (A) WD01-00255 122 Laser case WD01-00286
92 Rivet WD01-00256 123 Laser window WD01-00287
93 Socket head screw WD01-00257 124 Hex grub screw WD01-00288
7
SPECIFIC SAFETY INSTRUCTIONS...cont
This laser complies with class 2 according to EN 60825-1:2007.
The unit includes no servicing components. Do not open the housing for any
reason. If the unit is faulty/damaged, have it repaired/replaced by an author-
ized repair agent.
Do not stare directly at the laser beam, never aim the beam at any person or
an object other than the work-piece.
Do not deliberately aim the beam at personnel and ensure that it is not di-
rected towards the eye of a person.
Always ensure the laser beam is aimed at a sturdy work-piece without reflective
surfaces. wood or rough coated surfaces are acceptable. Bright shiny reflective
surfaces are not suitable for laser use as the reflective surface could direct the
beam back at the operator.
Always remember to switch off the laser on/off switch (2) after finishing a job,
only turn the laser beam on when the work-piece is on the mitre saw table.
This mitre saw is double insulated; This means the operator is separated
from the tool's electrical system by two complete sets of electrical insu-
lation. This extra layer of insulation is intended to protect the user from
electrical shock due to a break in the wiring insulation. All exposed met-
al parts are isolated from the internal metal motor components with
protecting insulation. Double insulated tools do not need to be ground-
ed (earthed). Servicing of a tool with double insulation requires extreme
care and knowledge of the system and should be performed only by a
suitably qualified person.
When using the saw always ensure the operator as well as those in the
area wear ear protection.
When using the saw always ensure the operator as well as those in the
area wear eye protection.
Some wood and wood composites have the potential to be highly tox-
ic; always wear a face mask when operating saw.

8
Caution: The warnings and cautions mentioned in this user manual can
not cover all possible conditions and situations that may occur. It must
be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be applied.
TECHNICAL SPECIFICATIONS
Part number 01504
Input voltage 230v ~ 50hz
Power 2000 w
No load speed 4500 rpm
Blade Ø 305 mm
Blade bore 30 mm
Blade teeth 40 TCT
Minimum blade thickness 2mm
Maximum blade thickness 4mm
Mitre table angles -45˚/0˚/45˚
Straight cut at 0˚x 0˚ 340mm x 102mm
Mitre cut at 45˚x 0˚ 240mm x 102mm
Left bevel cut at 0˚ x45˚ 340mm x 55mm
Right bevel cut at 0˚ x45˚ 340mm x 40mm
Left compound mitre cut at 45˚x 45˚ 240mm x 55mm
Right compound mitre cut at 45˚x 45˚ 240mm x 40mm
Weight 18kg
Sound Pressure Level (LpA) * 101 dB(A)
Sound Pressure Level (LpA) * (at operators ear) 96 dB(A)
Sound Power Level (LwA) ** 114 dB(A)
SPECIFIC SAFETY INSTRUCTIONS….cont
*Tested according to EN ISO 11201
**Tested according to EN ISO 4871: 3dB uncertainty
21
PARTS LIST
Ref No. Description SIP Part No. Ref No. Description SIP Part No.
1 Screw WD01-00165 32 Screw WD01-00196
2 Spring washer WD01-00166 33 Upper handle WD01-00197
3 Washer WD01-00167 34 Binding post WD01-00198
4 Belt cover WD01-00168 35 Switch WD01-00199
5 Socket head screw WD01-00169 36 Lower handle WD01-00200
6 Washer WD01-00170 37 Depth of cut knob WD01-00201
7 Belt WD01-00171 38 Socket head screw WD01-00202
8 Gear lock pin WD01-00172 39 Nut WD01-00203
9 Gear lock pin spring WD01-00173 40 Knurled thin nut WD01-00204
10 E clip WD01-00174 41 Motor support WD01-00205
11 Belt pulley (big) WD01-00175 42 Screw WD01-00206
12 Belt pulley (small) WD01-00176 43 Bearing WD01-00207
13 Screw WD01-00177 44 Fan baffle WD01-00208
14 Hex grub screw WD01-00178 45 Stator WD01-00209
15 Exhaust port WD01-00179 46 Armature WD01-00210
16 Washer WD01-00180 47 Bearing WD01-00211
17 Spring washer WD01-00181 48 Wave washer WD01-00212
18 Screw WD01-00182 49 Rubber boot WD01-00213
19 Screw WD01-00183 50 Motor housing WD01-00214
20 Laser switch WD01-00184 51 Screw WD01-00215
21 Laser switch cap WD01-00185 52 Brush hold WD01-00216
22 Cable plug WD01-00186 53 Brush spring WD01-00217
23 Cord protector WD01-00187 54 Brush WD01-00218
24 Cold clamp WD01-00188 55 Screw WD01-00219
25 Screw WD01-00189 56 Motor cover WD01-00220
26 Cold clamp WD01-00190 57 Logo cap WD01-00221
27 Screw WD01-00191 58 Blade bolt WD01-00222
28 Transformer WD01-00192 59 Blade flange outer WD01-00223
29 Trigger WD01-00193 60 Blade WD01-00224
30 Screw WD01-00194 61 Blade flange inner WD01-00225
31 Carry handle WD01-00195 62 Screw WD01-00226

20
EXPLODED DIAGRAM
9
ELECTRICAL CONNECTION
This saw is fitted with a standard UK type 230v ~ plug. Before using the tool inspect the
cable and plug to ensure that neither are damaged. If any damage is visible have
the tool inspected / repaired by a suitably qualified person. If it is necessary to replace
the plug a heavy duty impact resistant plug would be preferable.
The wires for the plug are coloured in the following way:
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows:
The wire which is coloured blue, must be connected to the terminal marked
with N or coloured black.
The wire which is coloured brown, must be connected to the terminal, which is
marked L or coloured red.
Always secure the wires in the plug terminal carefully and tightly. Secure the ca-
ble in the cord grip carefully.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always re-
place the fuse with the same value as the original.
Warning: Never connect live or neutral wires to the earth terminal of the plug. Only fit
an approved plug with the correct rated fuse. If in doubt consult a qualified electri-
cian.
Note: If an extension lead is required in order to reach the mains supply; en-
sure that this too is rated for the correct voltage and fuse rating.
Note: The cross section of the extension lead should be checked so that it is
of sufficient size so as to reduce the chances of voltage drops.
This mitre saw is double insulated. This means the operator is separated from
the tool's electrical system by two complete sets of electrical insulation.

10
GUARANTEE
Guarantee:
This SIP 12” double bevel saw is covered by a 12 month parts and labour warranty
covering failure due to manufacturers defects. This does not cover failure due to mis-
use or operating the saw outside the scope of this manual - any claims deemed to
be outside the scope of the warranty may be subject to charges Including, but not
limited to parts, labour and carriage costs. Consumable items such as fuses and
blades are not covered by the warranty.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Proof of purchase will be required before any warranty can be honoured.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
CONTENTS AND ACCESSORIES
Note: If any parts are missing, contact your distributor for the missing parts to
be replaced.
Dust Bag
Work Clamps
Blade Socket Wrench
Side Support Bar (x 2)
6mm Hex. Key
Instruction Manual
19
MAINTENANCE….cont
As well as oiling the moving parts regularly, the grease in the gearbox will require re-
placement after extensive use of the saw. Refer to an authorised service agent to pro-
vide this service.
Caution! Water must never come into contact with the tool.
GENERAL INSPECTION:
Cleaning and maintenance of this saw is mainly common sense some points for
guidance are as follows:
Regularly check that all the fixing screws are tight, particularly the outer flange.
They may vibrate loose over time.
The mains lead of the saw and any extension cord used should be checked
frequently for damage. If damaged, have the mains lead replaced by an au-
thorised service facility. Replace the extension cord if necessary.
Keep the air vents of the saw clear at all times.
After each use brush off any wood chippings with a soft brush. Pay special at-
tention to the inside of the dust extraction port (where the dust bag fits to the
saw) as this is where there will be a large build up if left for extended periods.
The motor of the saw should be cleared of any wood chippings as there would
be a risk of fire if they are allowed to build up over time (a soft brush or dry air
could be used to clear the motor).
Empty the bag at least after each use; the bag should be emptied before it
gets half full to ensure its efficiency. There is a zip on the bag to allow for easy
disposal of wood chippings.
Ensure the blade guard is kept clean with a damp cloth (do not clean the
guard or any part of the saw with a corrosive solvent) to reduce the risk of injury.
Periodically oil all the moving parts on the saw to extend the life of the saw.
Inspect the carbon brushes (in the motor) at frequent intervals (depending on
the amount of use) and change them if the wear reaches the worn limit line or
is below 10mm, they should also be checked to ensure that the brushes move
in and out easily.
LUBRICATION:

18
MAINTENANCE….cont
Loosen the locking nut on one of the bevel adjustment screws (33 or 34).
Loosen the bevel lock (16).
Pull out the bevel positive stop knob (39) whilst pushing the saw head to 45° ei-
ther left or right depending on which adjustment screw has been loosened.
Place a set square with an accurate 45° angle against the main table of the
saw and the blade.
Use a hex wrench to adjust the screw until the blade is at 45°.
Re-tighten the locking nut ensuring that the angle is kept.
If required loosen the screw on the angle pointer and adjust so that it reads 45°.
Re-tighten the screw.
Follow these instructions on the opposite side to ensure that the blade is set to 45° in
both directions.
CHANGING THE BLADE:
Caution: Always ensure that the replacement blade matches the specifi-
cations, as shown on page 8. Never fit a blade which is smaller or bigger
than that stated.
Pull on the release knob (6) and turn it through 90˚ to lock it “open”
lift the saw arm (5) to its full height.
Press the release latch (35) and slide the blade guard above the blade.
With the blade guard held in place; remove the blade guard screw (14).
Slide the black plate up to reveal the blade retaining bolt and flange.
Press and hold the spindle lock button (26) whilst slowly turning the blade until
the lock locates and stops the blade from spinning.
Turn the blade retaining bolt clockwise (the bolt has a left handed thread) to
loosen and remove.
Slide the flange and the blade from the spindle and fit the new blade.
Follow these instructions in reverse to secure the blade, ensuring that the blade
direction is correct and that the contact surfaces of the blade and flange are
flat and clean.
Caution: Ensure all screws / bolts are completely tight and that the blade
guard works correctly before re-using the saw.
11
GETTING TO KNOW YOUR SAW
27 13 8
7
35
9
14
12
18
23
25
222138
37
36
17
28
31
5
32
30
15
11 24 10 16
33 34 26
2 3 1 4 6 29
20
19
36
39

12
GETTING TO KNOW YOUR SAW….cont
1 Laser assembly 21 Mitre table
2 Laser light on/off switch 22 Mitre scale
3 Laser cover 23 Table insert
4 Laser pitch control 24 Switch trigger
5 Saw arm 25 Mitre lock
6 Release knob 26 Spindle lock button
7 Operating handle 27 Dust extraction port
8 Carrying handle 28 Slide bars
9 Upper fixed blade guard 29 Slide lock
10 Clamp assembly 30 Trenching depth adjustment screw
11 Clamp assembly lock 31 Trenching stop
12 Moving blade guard 32 Trenching depth lock nut
13 Guard retraction arm 33 Bevel adjustment screw
14 Blade guard screw 34 Bevel adjustment screw
15 Dust bag 35 Release latch
16 Bevel lock 36 Side support bars
17 Bevel scale 37 Side support bar location holes
18 Fence 38 Clamp assembly
19 Blade wrench 39 Positive stop knob
20 Hex key (6mm)
ASSEMBLY INSTRUCTIONS
1
2 The dust bag (1) fits in the dust extractor port (2).
Note: For efficient operation, empty the dust bag when it is no more than
half full, this allows better air flow through the bag.
Fitting The Dust Bag:
17
MAINTENANCE
CHECKING AND SETTING THE MITRE ANGLE:
This saw is set up at the factory and should need no adjustment; however time and
careless use can affect the angles and some adjustment may be required.
Loosen the slide lock (29); push the saw head back as far as it will go and re-
tighten the slide lock (29).
Loosen the mitre lock (25); turn the main table until the positive stop for 0° en-
gages and the angle guide pointer is close to 0°.
Re-tighten the mitre lock.
If the pointer is not exactly set to 0° loosen the screw and turn the pointer until it
is.
Loosen the 4 (2 on each side of the saw) rear fence locking bolts and lower the
blade to its lowest point; lock the saw head down with the release knob (6).
Place a square against the blade and rear fence and adjust the fence until an
angle of exactly 90° is achieved.
Proceed to tighten the rear fence locking bolts whilst ensuring that an angle of
90° is maintained.
Rear Fence Locking Bolts
CHECKING AND SETTING THE BEVEL ANGLE:
Loosen the slide lock (29); push the saw head back as far as it will go and re-
tighten the slide lock (29).
Loosen the mitre lock (25); turn the main table until the positive stop for 0° en-
gages and the angle guide pointer shows 0°.
Re-tighten the mitre lock.
Warning! Always ensure that the saw is turned off and that the plug is disconnected
from the mains supply before carrying out any adjustments, repairs or maintenance.

16
A compound mitre cut involves using a mitre angle and a bevel angle at the same
time. It is used in making picture frames, to cut mouldings, making boxes with sloping
sides and for roof framing. It is a good idea to make a test cut on a piece of scrap
wood before cutting into the good material. Use the slide action when cutting wide
work-pieces.
OPERATING INSTRUCTIONS….cont
USING THE DEPTH STOP:
Slide the depth stop bracket to the right to engage the depth stop.
Loosen the lock-nut.
Adjust screw to the required depth.
Once set to the desired depth; Tighten the lock-nut against the retaining brack-
et to lock the depth stop and ensure there is no movement due to vibration etc.
Function:
Once the depth stop is set; the blade will not cut all the way through the work-piece
(depending on the depth that it is set to). This will allow the operator to easily cut slots
out of the work-piece if used in conjunction with the sliding function of the saw, it is
advisable to check the cut depth on a scrap piece of wood.
Make a cut as explained in the main instruction manual then raise the main saw head
above the work-piece. Move the work-piece (left or right) slightly and make another
cut until the desired amount of wood is removed and the slot is complete.
Note: It may be necessary to clean the slot with a sharp chisel or by sand-
ing.
Lock-nut
Screw
Bracket
13
Do not stare directly at the laser beam, never aim the beam at any person or
an object other than the work-piece.
Do not deliberately aim the beam at personnel and ensure that it is not di-
rected towards the eye of a person.
Always ensure the laser beam is aimed at a sturdy work-piece without reflective
surfaces. wood or rough coated surfaces are acceptable. Bright shiny reflective
surfaces are not suitable for laser use as the reflective surface could direct the
beam back at the operator.
Always remember to switch off the laser on/off switch (2) after finishing a job,
only turn the laser beam on when the work-piece is on the mitre saw table.
Warning: Do not stare into the laser beam as this is dangerous and will
damage your eyes.
OPERATING INSTRUCTIONS
Place the work-piece flat on the table with one edge securely against the fence
(18).
Turn on the laser by pressing the laser On/Off switch (2).
Use the clamp assembly (10) to secure the work-piece.
CROSS-CUTTING (WITHOUT SLIDE ACTION):
Note: When cutting a narrow piece of wood it is not necessary to use the
slide mechanism. In these cases ensure that the saw head is pushed back
and the slide lock (29) is tight to prevent the saw arm from sliding.
A crosscut is made by cutting across the work-piece, a 90˚ crosscut is made with the
mitre table set at 0˚. Mitre crosscuts are made with the table set at any other angle.
Pull on the release knob (6) and turn it through 90˚ to lock it “open”
lift the saw arm (5) to its full height.
Loosen the mitre lock (25).
Rotate the mitre table (21) until the pointer aligns with the desired angle.
Retighten the mitre lock (25).
Warning! Be sure to tighten the mitre lock before making a cut. Failure to do
so could result in the table moving during the cut and cause serious per-
sonal injury.

14
OPERATING INSTRUCTIONS….cont
Unscrew the slide lock (29).
Pull on the release knob (6), raise the saw arm (5) to its highest position and slide
(pull) it towards you.
Loosen the mitre lock (25).
Rotate the mitre table (21) until the pointer aligns with the desired angle.
Retighten the mitre lock (25).
Place the work-piece flat on the table with one edge securely against the fence
(18).
Turn on the laser by pressing the laser On/Off switch (2).
Use the clamp assembly (10) to secure the work-piece.
Hold the operating handle (7) firmly and squeeze the switch trigger (24); allow
the blade to reach maximum speed.
Press the release latch (35) and slowly lower the blade onto and through the
work-piece whilst sliding (pushing) it away from you at the same time until the
work-piece is cut.
Release the switch trigger (24) and allow the saw blade to stop rotating before
raising the blade out of the work-piece.
Ensure that the blade has stopped and that the saw head is returned to a posi-
tion so that the guard is covering the blade before removing the work-piece.
Note: It is possible to remove the clamp assembly (10) by loosening the
clamp assembly lock (11) and moving it to the other side of the table.
Make sure the clamp assembly lock is tight before using the clamp.
Hold the operating handle (7) firmly and squeeze the switch trigger (24); allow
the blade to reach maximum speed.
Press the release latch (35) and slowly lower the blade into and through the work
-piece.
Release the switch trigger (24) and allow the saw blade to stop rotating before
raising the blade away from the work-piece.
Ensure that the blade has stopped and that the saw head is returned to a posi-
tion so that the guard is covering the blade before removing the work-piece.
Note: When cutting long pieces of timber, support the opposite end of
the timber with the side support bars (36), a roller stand or a work surface
that is level with the saw table.
CROSS-CUTTING (WITH SLIDE ACTION):
15
OPERATING INSTRUCTIONS….cont
MAKING A BEVEL CUT:
MAKING A MITRE CUT:
A bevel cut of up to 45° (to the left or to the right) can be achieved by using the fol-
lowing method:
Loosen the bevel lock handle (16) which is situated at the rear of the saw.
Pull the positive stop knob (39) whilst pushing the saw head to the left or right,
depending on the angle required.
A mitred angle of 45° left or right can be obtained using the following method.
Loosen the mitre lock (25).
Turn the table until the desired angle is indicated by the mitre scale (22).
Note: A compound mitre cut can also be performed by adjusting both
angles (bevel and mitre) away from 90°
MAKING A COMPOUND MITRE CUT:
Note: The positive stop knob (39) will stop the saw head at popular angles
15°, 30° & 45° left and right when released, but any angle between 0 and
45 can be selected by locking the bevel lock.
Use the bevel scale (17) and pointer to set the head to the desired angle.
Tighten the bevel lock handle (16) to secure the head at the desired angle.
Follow the previous instructions to perform the cut depending on the dimensions of
the work-piece (see “cross cut with sliding action” or “cross cut without sliding action”).
Tighten the mitre lock (25) to hold the desired angle.
Follow the previous instructions to perform the cut depending on the dimensions of
the work-piece (see “cross cut with sliding action” or “cross cut without sliding action”).
Note: The mitre angle guide has positive stops at popular angles 15°,
22.5°, 30° & 45° left and right, but any angle between 0 and 45 can be
selected by tightening the mitre lock (25).
