Please read and fully understand the instrucons in this manual before
operaon. Keep this manual safe for future reference.
SIP Code 01480
SIP 10"Compact Cast Iron
Table Saw
Manual includes the assembly of the SIP Sliding Table
(SIP Code 01481) Optional Purchase.

1
1 Saw blade 14 Suction socket
2 Riving knife 15 Machine feet x 4
3 Work table 16 Rip fence guide profile with ruler
4 Rip fence 17 Rip fence bracket
5 Holder for suction hose 18 Handwheel saw blade tilting
6 Table extension 19 Hand wheel height adjustment saw blade
7 Suction hose 20 ON-OFF-switch
8 Saw blade guard 21 Locking handle saw blade tilting
9 Cross-cut fence
22 Connecting block work piece downholder
10 Stopper cross-cut fence 23 Cross-cut fence bracket
11 Sliding table 24 Work piece downholder
12 Sliding table base profile
25 Mitre fence
13 Guide profile without ruler
1.Components 01480 SIP 10" Compact Cast Iron Table Saw

2
Spez.
Voltage V/Hz 230 / 50
Motor power S1 100% W 2200
Table size mm 635 x 420
Table extension mm 635 x 580
Sliding table mm 400 x 250
Main Work table height mm 840
Main sawblade dimension mm 254 x 30 x 3.0/1.8
Main sawblade speed
min-1 4000
Sawblade tilt ° 0 - 45
Cutting height at 90° mm 67 (80)
Cutting height at 45° mm 45 (65)
Max. cutting width at parallel fence in mm mm 750
Max. cu tting length mm 570
Dust collector port ø
mm 100 / 70 / 30
Necessary air volume
m³/h 850
Vacuum dust collector
Pa 800
Net weight kg 84
Gross weight kg 98
Machine dimension mm 1450 x 1000 x 1000
Packaging dimensions (L x W x H) mm
Sound power level LWA (ISO 3746)* dB (A) 99 k=4
Sound pressure level L (ISO11202)* dB (A) 87 k=4
* (EN) Notice noise emission: The values given are emission values and therefore do not have to represent safe workplace values at the
same time. Although there is a correlation between emission and immission levels, it cannot be reliably deduced whether additional
precautions are necessary or not. Factors influencing the actual immission level at the workplace include the nature of the workspace and
other noise sources, i.e. the number of machines and other adjacent operations. The permissible workplace values may also vary from
country to country. However, this information should enable the user to make a better assessment of hazard and risk.
TS10E_230V
Box 1: 750x620x510
Box 2: 1110x175x80
Box 3: 740x450x200
2. Technical da ta

3
This section contains information and important notes on safe commissioning and handling of
the machine.
For your personal safety, please read these operating instructions carefully before
commissioning. This will enable you to handle the machine safely and prevent
misunderstandings as well as personal injury and damage to property. Also observe
the symbols and pictograms used on the machine as well as the safety and danger
information!
3.1 Intended use of the machine
The machine is intended exclusively for the following activities:
Longitudinal and cross-cutting of wood and materials with similar physical properties to wood,
using an effective dust collection system according to technical specifications and within
technical limits of the machine.
NOTE
SIP (Industrial Products ) Ltd assumes no responsibility or warranty for any other use or
use beyond this and for any resulting damage to property or injury.
3.1.1 Technical Restrictions
The machine is intended for use under the following ambient conditions:
Rel. Humidity: max. 65 %
Temperature (operational) +5° C bis +40° C
Temperature (Storage, Transport) -20° C bis +55° C
3.1.2 Prohibited Use / Forseeable Misuse
-Operation of the machine without adequate physical and mental aptitude.
-Operating the machine without knowledge of the operating instructions.
-Changes in the design of the machine.
-Operating the machine in a potentially explosive environment (machine can generate
ignition sparks during operation)-
-Operation of the machine in closed rooms without chip and dust extraction (a normal
household vacuum cleaner is not suitable as an extraction device).
-Operating the machine outside the limits specified in this manual.
-Remove the safety markings attached to the product.
-Modify, circumvent or disable the safety devices of the machine.
-Cutting of materials with dimensions outside the limits specified in this manual.
-Use of tools which do not meet the safety requirements of the standard for machine
3.2 User requirements
The machine is designed for operation by one person. The physical and mental aptitude as
well as knowledge and understanding of the operating instructions are prerequisites for
operating the machine. Persons who, because of their physical, sensory or mental
abilities or their inexperience or ignorance, are unable to operate the machinery safely
must not use it without the supervision or instruction by a responsible person.
Basic knowledge of woodworking especially the correlation of wood type, blade, cutting feed
and speeds.
Please note that local laws and regulations may determine the minimum age of the operator
and restrict the use of this machine!
Put on your personal protective equipment before working on the machine.
Work on electrical components or equipment may only be carried out by a qualified electrician
or under the instruction and supervision of a qualified electrician.
3. SAFETY
to
tools for woodworking (EN8471).
The improper use or disregard of the versions and instructions described in this manual will result in avoiding all
warranty and compensation claims against SIP (Industrial Products) Ltd.

4
3.3 Safety devices
The machine is equipped with the following safety devices:
•Safety guard (adjustable): saw blade guard is attached to the
riving knife to prevent contact with the saw blade.
Riving knife
•This measure is intended to prevent the workpiece from kick
back. The setting is in horizontal and vertical direction opposite
to the saw blade.
•Separating protective device (fixed)
(Access to motor / belt drive)
Rip fence
•Serves for precise guidance of the workpiece during
longitudinal cutting. It is made of destructible material
(aluminium).
•The adjustment of the rip fence is possible without using tools;
the position is read on a ruler.
Push stick
•For cutting operations where less than 120mm is cut, i.e. less
than 120mm distance to the right of the saw blade to the rip
fence. Do not feed the wood by hand, but with the push stick.
3.4 General safety instructions
To avoid malfunctions, damage and health hazards when working with the machine, in addition to
the general rules for safe working, the following points must be observed:
•Before start-up, check the machine for completeness and function. Only use the machine if
the guards and other non-parting guards required for machining have been fitted, are in
good operating condition and have been properly maintained.
•Choose a level, vibration-free, non-slip surface for the installation location.
•Ensure sufficient space around the machine!
•Ensure sufficient lighting conditions at the workplace to avoid stroboscopic effects!
•Ensure a clean working environment!
•Only use perfect tools that are free of cracks and other defects (e.g. deformations).
•Remove tool keys and other adjustment tools before switching on the machine.
•Keep the area around the machine free of obstacles (e.g. dust, chips, cut parts, etc.).
•Check the strength of the machine connections before each use.
•Never leave the running machine unattended. Switch off the machine before leaving the
working area and secure it against unintentional or unauthorised recommissioning.
•The machine may only be operated, serviced or repaired by persons who are familiar with it
and who have been informed of the dangers arising in the course of this work.
•Ensure that unauthorised persons maintain a safe distance from the machine and keep
children away from the machine.
•Wear close-fitting protective clothing and suitable protective equipment (eye protection,
dust mask, ear protection; gloves only when handling tools).
•Hide long hair under hair protection.
•Do not remove any sections or other parts of the workpiece from the cutting area while the
machine is running!
•Do not remove splinters and chips by hand!
•Always work with care and the necessary caution and never use excessive force.
•Do not overload the machine!
•Do not work on the machine if you are tired, not concentrated or under the influence of
medication, alcohol or drugs!
•Do not use the machine in areas where vapours from paints, solvents or flammable liquids
represent a potential danger (danger of fire or explosion!).
•Do not smoke in the immediate vicinity of the machine (fire hazard)!
•Shut down the machine and disconnect it from the power supply before carrying out any
adjustment, conversion, cleaning, maintenance or repair work. Before starting any work on
the machine, wait until all tools or machine parts have come to a complete standstill and
secure the machine against unintentional restarting.
3. SAFETY Cont...

5
3.5 Electrical safety
•Make sure that the machine is grounded.
•Only use suitable extension cables.
•A damaged or tangled cable increases the risk of electric shock. Handle the cable with
care. Never use the cable to carry, pull or disconnect the power tool. Keep the cable away
from heat, oil, sharp edges or moving parts.
•Proper plugs and outlets reduce the risk of electric shock.
•Water entry into the machine increases the risk of electric shock. Do not expose the
machine to rain or moisture.
•The machine may only be used if the power supply is protected by a residual current
circuit breaker.
•Use the machine only when the ON-OFF switch is in good working order.
•Before connecting the machine always make sure that it is switches off.
3.6 Special safety instructions for woodworking machines
•Work with gloves on rotating parts is not permitted!
•During operation of the machine wood dust is generated. Therefore, connect the machine
to a suitable dust collection system for dust and chips during installation!
•Always switch on the dust collection system before you start machining the workpiece!
•Never remove sections or other parts of the workpiece from the cutting area while the
machine is running.
•Excessive noise can cause hearing damage and temporary or permanent hearing loss. Wear
hearing protection certified to health and safety regulations to limit noise exposure.
•Replace cracked and deformed saw blades immediately, they cannot be repaired.
•Use a push stick for cutting operations where less than 120mm is cut, i.e. less than 120mm
distance to the right of the saw blade from the rip fence. Do not feed the wood by hand, only
with the push stick!
•Select the number of teeth of the saw blade so that at least 2-3 teeth cut through the
workpiece at the same time. A lower number of teeth leads on the one hand to an unclean
cut, on the other hand the danger of vibrations and noise pollution increases due to
increased kickback.
3.7 Hazard warnings
Despite its intended use, certain residual risks remain:
•Risk of injury to fingers and hands from the rotating saw blade if the workpiece is guided
improperly.
•Injuries caused by the workpiece being thrown away by improper mounting or guidance,
such as working without a stop.
•Danger to health from wood dust or chips. It is essential to wear personal protective
equipment such as eye protection and a dust mask. Use a dust collection system!
•Injuries due to defective saw blade. Check the saw blade regularly for damage.
•Risk of electric shock if incorrect electrical connections are used.
Residual risks can be minimized if the "Safety instructions" and the "Intended use" as well as the
operating instructions are observed.
Due to the design and construction of the machine, hazardous situations may occur when
handling the machines, which are identified as follows in this operating instruction:
DANGER
A safety instruction designed in this way indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
Such a safety instruction indicates a potentially hazardous situation which, if not
avoided, may result in serious injury or even death.
3. SAFETY Cont...

6
CAUTION
A safety instruction designed in this way indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
NOTICE
A safety notice designed in this way indicates a potentially hazardous situation which,
if not avoided, may result in property damage.
Irrespective of all safety regulations, your common sense and appropriate technical
suitability/training are and remain the most important safety factor for the fault-free operation of
the machine. Safe working depends first and foremost on you!
4TRANSPORT
WARNING
Damaged or insufficiently strong hoists and load slings can cause serious injuries or
even death. Always check hoists and load slings for sufficient load-bearing capacity
and that they are free of obstacles, fasten the loads carefully and never stand under
suspended loads.
To ensure proper transport, also observe the instructions and information on the transport
packaging regarding centre of gravity, attachment points, weight, means of transport to be used
and the prescribed transport position, etc..
Transport the machine in its packaging to
the installation site. To manoeuvre the
machine in the packaging, a pallet truck or
a forklift with appropriate lifting power can
be used.
If you transport the machine with a vehicle, make sure that the load is adequately secured!
NOTICE: To transport the machine, you need a forklift truck with the appropriate load capacity
and a fork of at least 1200 mm length. The fork of the truck should be positioned under the
machine.
After the machine has been assembled, it can be transported for short distances with the
transport device or transported by crane or forklift truck using belts of appropriate load capacity
and length.
NOTICE: Do not carry the machine at the work tables, these are not designed to withstand the
tensile load of the machine weight.
5.1 Checking scope of supply
Always note visible transport damages on the delivery note and check the machine
immediately after unpacking for transport damage or missing or damaged parts. Report any
damage to the machine or missing parts immediately to your retailer or freight forwarder.
5.2 The workplace
Choose a suitable place for the machine.
Pay attention to the safety requirements and the dimensions of the machine.
The selected location must ensure a suitable connection to the electrical supply as well as the
possibility of connection to an extraction system. Make sure that the machine is placed on a solid
and level surface and that the ground can support the load of the machine. The machine must
be levelled at all support points. It is also necessary to guarantee a distance of at least 0.8 m
around the machine. In front of and behind the machine, the necessary distance must be
provided for the feeding of long workpieces.
3. SAFETY Cont...
4. TRANSPORT
5. ASSEMBLY

7
5.3 Preparation of the surface
NOTICE
The use of paint thinners, gasoline, corrosive chemicals or abrasive cleaners will result
in damage to the surface! Therefore use only mild cleaning agents.
Before you install and commission the machine at the intended location, carefully remove the
anti-corrosion protection and grease residues. This can be done with the usual solvents. Under
no circumstances should you use nitro thinner or other cleaning agents that could attack the
machine's paint.
5.4 Assembling the machine
The machine has been disassembled for transport and must be assembled before use. Follow
the instructions below:
WARNING
Handling the machine with the mains supply intact can result in serious injury or
death. Therefore, do not connect the machine to the power supply before
completing the assembly.
1. Assembly socket
The socket consists of 2 different socket
elements (1).
•The socket elements are assembled with 3
screws M6x20, washers and nuts each (2).
NOTE: Make sure that the threaded holes for the
machine feet are located at the bottom.
5. ASSEMBLY Cont...

8
2. Assembly machine feet
•Screw the 4 machine feet into the threaded
holes at the corners of the socket (1).
NOTE: Make sure that the machine is aligned
horizontally (spirit level).
3. Disassembly of wooden transport base
•Tilt the machine onto a carton base.
•Remove the transport screws with a wrench.
•If the nuts rotate in the machine, it is possible
to grip laterally into the machine to secure
the nuts against rotation.
•Remove the components, included in the
delivery content, from the inside of the
machine.
4. Assembly socket on machine
•Because the machine is heavy, it is
recommended to tilt the socket (1) and the
machine (2) and to connect them while lying
on a horizontal surface.
•Socket and machine are connected at the
boreholes in the corners (3) with screws
M6x20, washers and nuts.
NOTE: The machine is heavy! 2 persons are
required to raise the machine.
5. Assembly suction hose Ø 70 mm
5.1. Suction socket
•Mount the suction socket laterally on the
machine with 4 Phillips screws M5x15,
washers and nuts (1).
5.2. Suction hose Ø 70 mm
•Attach one end of the suction hose Ø 70 mm
(2) with a hose clamp (3) at the suction socket
(4) on the inside of the machine.
•Attach the other end of the suction hose Ø 70
mm (2) to the outlet (5) of the lower saw blade
guide with a hose clamp (3).
5. ASSEMBLY Cont...

9
6. Assembly handwheel saw blade tilting
•Place the handwheel for saw blade tilting on
the shaft.
•The flattened side at the shaft (1) must be
exactly in line with the Allen screw (2) on the
handwheel.
•Push the handwheel completely onto the
shaft and tighten the Allen screw (2) with
Allen key (3).
7. Check saw blade alignment to main table
•The T-slots on the main table must be aligned
parallel to the saw blade.
•If the deviation is greater, the following
adjustments can still be made.
1. Loosen the mounting screws (1) and the
saw unit parallel by the play of the screws.
2. Tighten the screws again after the
adjustment.
8. Assembly sliding table
SIP Code 01481 (Optional)
8.1. Sliding table brackets
•Unscrew the two screws (2) at the two sliding
table brackets (1).
•Insert 2 Allen screws (2) each in the
corresponding boreholes (3) on both sides of
the worktable (4).
•Position the two sliding table brackets (1)
laterally at the underside of the worktable
and tighten the Allen screws (2) well at the
top using an Allen key.
5. ASSEMBLY Cont...

10
8.2. Sliding table base profile
•Loosen 4 nuts (1) per sliding table bracket.
•Slide the screw heads (2) of both sliding table
brackets into the left and right T-slot (4) of the
sliding table base profile (3).
•Slightly tighten the nuts (1) in the in the
middle position.
8.3. Sliding table
•Loosen the screw to remove the stopper (1)
from the sliding table base profile.
•Loosen the screws (2) on the upper side of the
sliding table very slightly.
•Loosen the 4 nuts (3), which fix the guide rolls
(4), with a wrench until the largest width is
reached.
•The 4 guide rolls on the underside of the
sliding table (5) are inserted laterally (6) at the
sliding table base plate.
•Tighten the 4 nuts (3) on the underside of the
sliding table with a wrench until the sliding
table can be moved without any play.
NOTE: Do not overtighten nuts (3) so that the
sliding table can still be moved easily!
5. ASSEMBLY Cont...

11
•Tighten the 4 screws (2) on the upper side of
the sliding table so that the sliding table can
be pushed easily without play.
•Push the stopper (1) back into the T-slot of the
sliding table base plate and tighten the screw.
8.4. Align sliding table with work table
•Loosen the 4 nuts (1) on both brackets so that
the sliding table base profile still can be
moved.
•Level the edge of the sliding table with that of
the work table (straight piece of wood / spirit
level) until it is horizontally aligned without
gaps (2).
•After alignment, tighten all nuts (1) on both
sliding table brackets.
9. Assembly components on sliding table
9.1. Work piece downholder
The work piece downholder is used for secure
fastening of workpieces.
NOTE: There are 2 positions possible for
mounting the work piece downholder on the
sliding table (1): (V) for front position and (H) for
rear position.
•Insert the work piece downholder (2) with the
bracket (3) into the desired position (V) or (H).
•To secure the work piece downholder, tighten
the screw (4) with an allen key (5).
5. ASSEMBLY Cont...

12
9.2. Cross-cut fence
•Push the slot stone of the bracket (2) for the
cross-cut fence into the T-slot (1) at the sliding
table.
•Loosen the locking screws (3) on the bracket
on the work piece downholder and on the
bracket for the cross-cut fence.
•Push the slot stones into the T-slot (4) on the
cross-cut fence (5).
•Tighten the locking screws (3) again.
•By means of the scale (6) you can set the
cross-cut fence at any angle to the saw blade.
•Mount the stopper (7) onto the cross-cut
fence.
•Loosen the slot stone of the stopper (7) with
the winged screw (8) until it can be inserted
into the T-slot (9) of the cross-cut fence.
•The stopper (7) can be moved along the T-slot
at the cross-cut fence into the desired
position and fixed again with the wing screw
(8).
10. Assembly guide profiles
At the work table there are brackets at the front
and at the rear where the guide profiles are
attached.
•Loosen the nuts (1) of the 2 screws of each
bracket until their heads can be inserted into
the T-slot of the guide profile.
NOTE: Ensure that the wide slot (2) of the guide
profiles is located lateral outside and that the
ruler (3) of the guide profile for the rip fence
faces upwards.
10.1. Adjustment of sliding table
NOTE: Make sure that the measuring scale (3) on
the rip fence guide profile is adjusted to the saw
blade.
•Measure the distance between saw blade (1)
and rip fence (2).
5. ASSEMBLY Cont...

13
•This measured distance must also be
readable on the ruler (3).
•Then tighten the nuts (4) on the brackets
again to fix the guide rail.
11. Assembly table extension
•Loosen the screws (1) at the table extension
(2) so far that they can be inserted into the T-
slot (3) of the guide profiles on the left and
right.
•Push the first table extension (2) to the main
table (4).
•Mount the second table extension (5) as
described above.
•Retighten the screws (1) of the two table
extensions.
17. Assembly rip fence
Screw the adapter as shown on the aluminum
•
profile and slide it into the rip fence guide profile.
5. ASSEMBLY Cont...

14
•Place the bracket (3) of the rip fence on the
front guide profile (5).
•The rip fence can be moved along the guide
profile to any position and fixed with the
screw (6).
11.1. Adjustment of rip fence
The rip fence must be adjusted so that it is
parallel to the saw blade. This can be achieved
by adjusting the guide profiles:
•Push the rip fence towards the saw blade.
•If the rip fence is not in exact contact with the
saw blade, first loosen the screws (1) on the
brackets.
•The guide profile is to be adjusted with the
adjusting screw (2).
•At the rear side, the adjusting screw (2) can be
screwed in or out further with an Allen key (3)
as required.
•Retighten the screws (1).
NOTE: Use a wooden strip (with a length of
approx. 0.5m) which you can saw through in the
length.
•The difference, measured at the ends of the
wooden strip, has to be readjusted on the rip
fence guide profile.
12. Assembly mitre fence
•Insert the slot stone (2) of the mitre fence (1)
into the T-slot (3) on the work table.
•The mitre stop (1) can be moved along the T-
slot (3) on the work table and fixed in the
desired position with the star screw (4).
•The set angle can be read off the scale (5).
13. Assembly holder for the suction hose
The holder of the suction hose (2) can be moved
along the T-slot of the rear guide profile and is
installed as follows:
•Loosen the screw (1) that serves as a slot
stone, until it can be inserted into the T-slot
(3) of the rear guide profile.
•Retighten the screw (1) by turning the holder
(2).
5. ASSEMBLY Cont...

15
14. Assembly saw blade guard
Fix the saw blade guard (1) to the riving knife (3)
with the locking screw (2).
NOTE: The saw blade guard should be positioned
as close as possible to the workpiece.
15. Assembly suction hose
•Attach the 32 mm suction hose (1) to the saw
blade guard (3) with a hose clamp (2), then
hook the suction hose into the holder.
NOTE: Ensure that the suction hose is not kinked
and that there is sufficient distance between the
suction hose and the work area.
•Fasten the other end of the 32 mm suction
hose (1) with a hose clamp (2) to the suction
socket (3).
•One end of the 100 mm suction hose is
attached to the suction socket (4) with a hose
clamp (not included in the delivery content).
•The other end of the suction hose is
connected to a dust collection system (not
included in delivery).
5.5 Electrical connection
WARNING
Dangerous electrical voltage!
The machine may only be connected to the mains supply and the associated
checks carried out by a qualified electrician or under the instruction and
supervision of a qualified electrician!
•Check, whether the neutral connection (if existing) and the protective grounding
function properly.
•Check, whether the supply voltage and the frequency correspond to the specifications of
the machine.
5. ASSEMBLY Cont...

16
6.1 Initial check before start
•Before any adjustments, the machine must be disconnected from the power supply to avoid
the risk of accidental switching on the machine!
•Check that the max. speed of the machine is lower than the max. permissible speed of the
used saw blade and direction is correct.
•Use only sawblades with a diameter according to technical data.
•Make sure that the inner diameter of the saw blade corresponds to the diameter of the drive
shaft.
•Check if the riving knife is correctly adjusted.
•The saw blade guard must be mounted on the riving knife. Working with the machine without
saw blade protection guard is prohibited.
•Ensure connection to a dust collection system.
6.2 Operation
6.2.1 Starting/stoping the machine
Starting:
Push green ON-button (I)
Stoping:
Push red OFF-button (0)
6.2.2 Saw blade height adjustment
The handwheel for height adjustment (1) is located at the front of
the machine. Turn the handwheel anticlockwise to lift the saw
blade upwards. Turn the handwheel clockwise to lower the saw
blade. The height of the saw blade must be adjusted so that the
teeth hit the top of the workpiece.
6.2.3 Adjustment of the saw blade tilt
Push the clamping lever (2) down to release the hand wheel.
Turn the hand wheel (1) clockwise to tilt the saw blade. Turn the
hand wheel anticlockwise to move the saw blade in a vertical
position again. The saw blade can be tilted from 0° to 45°. The
current position can be seen on the scale. Afterwards push the
clamping lever (2) upwards again.
NOTICE
After adjusting the saw blade tilt, adapt the rip fence and/or the cross-cut fence so that
they do not become contact with the tilted saw blade.
6.2.4 Adjustment of the cutting width on the rip fence
The cutting width can be adjusted on the rip fence and can be
read off the ruler (1). The rip fence can be fixed by tightening the
star screws.
The rip fence can be mounted on the front or rear guide profile.
6. OPERATING INSTRUCTIONS

17
6.2.5 Blocking cross-cut fence
The cross stop is secured laterally at the sliding table with a
stopper (1) against unintentional movement. With the screw (2)
the blocking can be raised or lowered.
6.2.6 Mitre fence
The mitre fence can be inserted into the T-slots of the work
table on the right or left side of the saw blade.
By pivoting the mitre fence, cross cuts can be made at all angles
(see illustration on the left).
6.3 Notes on using the machine
6.3.1 Selection of the saw blade
Apart from the material of the workpiece, the saw blade teeth play the most important role in
achieving precise cuts. The number of teeth, as well as their shape, arrangement and position
are associated with a specific function. To enhance the cutting quality, make sure that at least 2-
3 teeth cut through the workpiece at the same time. If only one tooth works, a poor working
surface results, the risk the vibrations and the noise exposure increases before setback increase:
adequate saw blade inadequate saw blade
Only work with well-sharpened saw blades.
•Adjust the height of the saw blade so that the gear rim is reliably covered by the circular
saw blade guard (distance between saw blade guard and workpiece (maximum distance
of 5 mm).
•Use the push stick at the end of cutting when the distance between the saw blade and
the ruler is less than 120 mm.
•Make sure that the machine works without vibrations.
•Cracked and deformed saw blades cannot be repaired. They must be sorted out
immediately as scrap and replaced by proper ones.
•Feed the workpiece evenly, without thrusts and without taking it back, until the end of
cutting is reached.
6.3.2 Longitudinal cuts
When performing this operation, the following equipment shall be used for safe working:
•Rip-fence
•the guard of the saw blade
•the riving knife
•the insert in the table
6.OPERATING INSTRUCTIONS Cont...

18
•push stick when cutting small workpieces (distance between saw blade and fence
<120mm) and rip-fence with small
NOTICE
When cross-cutting round timber, a template or a holding device is necessary to
secure the workpiece against twisting and the use of a suitable saw blade is
necessary.
6.3.3 Mitre cuts (cross-cuts) and wedge-cutting
When performing this operation, the following equipment shall be used for safe working:
•Mitre gauge
•the saw blade guard
•the riving knife
•the tableinsert
Cross-cuts:
Mitre cuts in the range 0-90° can be carried out by pressing the workpiece to be cut firmly
against the stop surface of the mitre gauge.
Wedge cuts:
To do this, set the rotary part mitre fence to 0° and secure it with the adjusting handle. Position
the workpiece and saw through with even pressure.
WARNING
Only remove workpieces (wedges) after the machine has come to a standstill. To do
this, switch off the machine and wait for the saw blade to come to a standstill.
6.3.4 Cutting boards
When performing this operation, the following equipment shall be used for safe working:
•The table extension
•Cross-cut-fence or rip fence with support for the workpiece
•the saw blade guard
•the riving knife
•the workpiece downholder
•the table insert
•push stick when cutting small workpieces
•(distance between saw blade and fence <120mm)
6.4 After working process
NOTICE
After the working process the machine must be turned off:
•Switch off the machine
•Disconnect the machine from the power supply.
•Retract saw blade completely.
CAUTION
Feed only with the hand on the mitre gauge (hands away from the wood).
6.OPERATING INSTRUCTIONS Cont...

19
WARNING
Danger due to electrical voltage!
Handling the machine with connected power supply may result in serious injury or
death.
Always disconnect the machine from the power supply before maintenance or
repair work and secure it against unintentional reconnection.
7.1 Cleaning
NOTE
Wrong cleaning agents can attack the varnish of the machine. Do not use solvents, nitro
thinners, or other cleaning agents that could damage the machine's paint. Observe the
information and instructions of the cleaning agent manufacturer!
Regular cleaning is also a prerequisite for the safe operation of the machine and its long service
life. Therefore, clean the device after each use and remove dust and dirt. Use personal protective
equipment (gloves and eye protection or dust musk). Ensure that the saw blade protection is
free from wood residues and sawdust and make sure that you keep the table surface free of
resin.
7.2 Maintenance
The machine is low-maintenance and only a few parts have to be serviced. Nevertheless,
malfunctions or defects which could impair the safety of the user must be rectified immediately!
•Before each operation, check that the safety devices are in perfect condition.
•Check the connections for a tight fit at least once a week.
•Check regularly that the warning and safety signs on the machine are in good condition
and legible.
7.2.1 Maintenance schedule
The type and degree of machine wear depend on the operating conditions. The following
intervals apply when the machine is used within the specified limits:
interval components activity
Before usage machine Cleaning the machine
Before usage machine Removal of all loose parts / tools
1 x month V-Belt tension Check and readjust belt tension if necessary.
1 x month Moving parts Greasing / lubrication of guides / gear racks / wheels
On demand Saw blade Exchange saw blade if necessary
CAUTION
Before any manual tool change, stop the spindles, wait for standstill of all tools and
prevent an unintentional restart = unplug the power supply.
CAUTION
When handling circular saw blades when changing tools, please use safety gloves to
avoid risk of injury.
7.2.2 Cleaning the saw blade
Any deposition of resin on the teeth of the saw blade will cause the saw blade to jam during the
processing of a workpiece. For the purpose of maintenance, remove the saw blade from the drive
shaft and clean it with white spirit. After cleaning, the saw blade should be sprayed with silicone
spray.
7. CLEANING, MAINTENANCE, STORAGE & DISPOSAL
