SIP 01315 User manual

24
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
Ref: 061216
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
1
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
01308 / 01315
14” Abrasive Cut Off Saw

2
23
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
14” Abrasive Cut Off Saw - SIP Part No. 01308
14” Abrasive Cut Off Saw (110v) - SIP part No. 01315
Conforms to the requirements of the following directive(s), as indicated.
2006/42/EC Machinery Directive
2014/30/EU EMC Directive
2011/65/EU RoHS Directive
Signed: …………………………………...
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 06/12/2016.
And the relevant harmonised standard(s), including
DECLARATION OF CONFORMITY
EN61029-1:2009+A11:2010
EN61029-2-10:2010+A11:2013
EN55014-1:2006+A1:2009+A2:2011
EN55014-2:2015
EN61000-3-2:2014
EN61000-3-11:2000

22
NOTES
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
9. Electrical Connection
10. Guarantee
10. Contents and Accessories
11. Technical Specification
12. Getting to Know Your Abrasive Cut Off Saw
13. Operating Instructions
14. Maintenance
15. Wiring Diagram
16. Exploded Drawing
17. Parts List - 01308
19. Parts List - 01315
23. Declaration of Conformity

4
When using your abrasive cut off saw, basic safety precautions should always be fol-
lowed to reduce the risk of personal injury and / or damage to the abrasive cut off
saw.
Read all of these instructions before operating the abrasive cut off saw and save this
user manual for future reference.
The abrasive cut off saw should not be modified or used for any application other
than that for which it was designed.
This abrasive cut off saw is designed to cut all types of ferrous metals.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before each use of the abrasive cut off saw always check no parts are broken and
that no parts are missing.
Always check that the disc bolt is tight before, during and after operation.
Always operate the abrasive cut off saw safely and correctly.
KNOW YOUR ABRASIVE CUT OFF SAW: Read and understand the owner's manual and
labels affixed to the abrasive saw. Learn its applications and limitations, as well as the
potential hazards specific to it.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite
accidents. Floors must not be slippery due to oil, water or sawdust etc.
DO NOT USE THE ABRASIVE CUT OFF SAW IN DANGEROUS ENVIRONMENTS: Do not use
the abrasive cut off saw in damp or wet locations, or expose it to rain. Provide ade-
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the abra-
sive cut off saw.
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
21
NOTES

20
PARTS LIST - 01315….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
61. Gear Case Cover WK08-00061 78. Rubber Pole WK08-00078
62. Screw WK08-00062 79. Cap WK08-00079
63. Check Ring WK08-00063 80. Lower Handle WK08-00080
64. 6204 Bearing WK08-00064 81. Capacitor WK08-00081
65. Spindle WK08-00065 82. Switch WK08-00082
66. Key WK08-00066 83. Trigger WK08-00083
67. Fixed Guard WK08-00067 84. Soft Start WK08-00084
68. Spring Washer WK08-00068 85. Upper Handle WK08-00085
69. Screw WK08-00069 86. Screw WK08-00086
70. Inner Flange WK08-00070 87. Carry Handle WK08-00087
71. Outer Flange WK08-00071 88. Screw WK08-00088
72. Washer WK08-00072 89. Screw WK08-00089
73. Screw WK08-00073 90. Screw WK08-00090
74. Lock Nut WK08-00074 91. Mains Lead Gland WK08-00091
75. Moving Guard WK08-00075 92. Mains Lead WK08-00092
76. Special Screw WK08-00076 93. Cable Clamp WK08-00093
77. Special Screw WK08-00077
5
SAFETY INSTRUCTIONS….cont
quate space surrounding the work area. Do not use in environments with a potentially
explosive atmosphere.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
STORE THE ABRASIVE CUT OFF SAW SAFELY WHEN NOT IN USE: The abrasive cut off saw
should be stored in a dry location and disconnected from the mains supply, and out
of the reach of children.
WEAR THE CORRECT CLOTHING: Do not wear loose clothing, neckties, rings, bracelets,
or other jewellery, which may get caught in moving parts. Non-slip footwear is recom-
mended. Wear protective hair covering to contain long hair. Roll long sleeves up
above the elbow.
USE SAFETY CLOTHING / EQUIPMENT: Wear CE approved safety goggles at all times,
normal spectacles only have impact resistant lenses, they are NOT safety glasses. A
face or dust mask should be worn if the operation is dusty and ear protectors (plugs or
muffs) should be worn, particularly during extended periods of operation.
PROTECT YOURSELF FROM ELECTRIC SHOCK: When working with the abrasive saw,
avoid contact with any earthed items (e.g. pipes, radiators, hobs and refrigerators,
etc.). It is advisable wherever possible to use an RCD (residual current device) at the
mains socket.
STAY ALERT: Always watch what you are doing and use common sense. Do not oper-
ate the abrasive cut off saw when you are tired or under the influence of alcohol or
drugs.
DISCONNECT THE ABRASIVE CUT OFF SAW FROM THE MAINS SUPPLY: When not in use,
before servicing and when changing accessories such as the abrasive disc, etc.
AVOID UNINTENTIONAL STARTING: Make sure the switch is in the OFF position before
connecting the abrasive cut off saw to the mains supply.
NEVER LEAVE THE ABRASIVE CUT OFF SAW RUNNING / CONNECTED WHILST UNATTEND-
ED: Turn the abrasive cut off saw off and disconnect it from the mains supply between
jobs. Do not leave the abrasive cut off saw until it comes to a complete stop.
DO NOT ABUSE THE MAINS LEAD: Never attempt to move the abrasive cut off saw by
the mains lead or pull it to remove the plug from the mains socket. Keep the mains
lead away from heat, oil and sharp edges. If the mains lead is damaged, it must be
replaced by the manufacturer or its service agent or a similarly qualified person in or-
der to avoid unwanted hazards.
CHECK FOR DAMAGED PARTS: Before every use of the abrasive cut off saw, the guards
or any other part that is damaged should be carefully checked to determine that it will
operate correctly and perform its intended function. Check for alignment of moving
parts, free running of moving parts, breakage of parts, and any other conditions that
may affect its operation. Guards or any other part that are damaged should be cor-
rectly repaired or replaced by an authorised service centre unless otherwise indicated
in this instruction manual. Have defective switches replaced by an authorised service
agent. Do not use the abrasive cut off saw if the switch does not turn the saw on and
off.

6
SAFETY INSTRUCTIONS….cont
KEEP ALL GUARDS IN PLACE: And in full working order.
MAINTAIN THE ABRASIVE CUT OFF SAW WITH CARE: Keep discs clean for the best and
safest performance.
All extension cables must be checked at regular intervals and replaced if damaged.
ALWAYS: Keep the vice handle knob on the abrasive cut off saw clean, dry and free
of oil and grease.
USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or
SIP directly for recommended accessories. Follow the instructions that accompany
the accessories. The use of improper accessories may cause hazards and will invali-
date any warranty you may have.
REMOVE ADJUSTING KEYS AND WRENCHES: Form a habit of checking to see that keys
and adjusting wrenches are removed from the abrasive cut off saw before every use.
SECURE THE WORKPIECE: Always use the vice to hold the workpiece. This frees up both
hands to operate the abrasive saw.
DO NOT OVERREACH: Keep proper footing and balance at all times.
USE THE RIGHT TOOL: Do not use the abrasive cut off saw to do a job for which it was
not designed.
DO NOT FORCE THE ABRASIVE CUT OFF SAW: It will do the job better and more safely
at the rate which it was designed.
DO NOT OPERATE THE ABRASIVE CUT OFF SAW IN EXPLOSIVE ATMOSPHERES: Do not
use the abrasive cut off saw in the presence of flammable liquids, gases, dust or other
combustible sources. Abrasive sawing operations may create sparks which can ignite
the dust or fumes.
DO NOT EXPOSE THE ABRASIVE CUT OFF SAW TO RAIN OR USE IT IN WET CONDITIONS:
Water entering the abrasive cut off saw will greatly increase the risk of electric shock.
HAVE YOUR ABRASIVE CUT OFF SAW REPAIRED BY A QUALIFIED PERSON: The tool is in
accordance with the relevant safety requirements. Repairs should only be carried out
by qualified persons using original spare parts, otherwise this may result in considera-
ble danger to the user.
DO NOT dismantle, tamper with or use the abrasive cut off saw without all guards fit-
ted as this may be dangerous and will invalidate the warranty.
Keep hands out of the path of the abrasive disc, never reach around the abra-
sive disc.
Make sure the abrasive disc is clear of the workpiece before the trigger switch is
pressed in.
Stop operation immediately if you notice anything abnormal.
Wait for the abrasive disc to stop completely and remove the plug from the
mains supply before servicing or adjusting the abrasive cut off saw or changing
the abrasive disc.
Be alert at all times, especially during repetitive, monotonous operations. Don't
be lulled into a false sense of security. Abrasive discs can be extremely unforgiv-
ing.
19
PARTS LIST - 01315
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Lock Bolt WK08-00001 31. Clamp Nut WK08-00031
2. Screw WK08-00002 32. Screw WK08-00032
3. Washer WK08-00003 33. Spring Washer WK08-00033
4. Locking Handle WK08-00004 34. Roll Pin WK08-00034
5. Rubber Foot WK08-00005 35. Split Pin WK08-00035
6. Base WK08-00006 36. Washer WK08-00036
7. Fixed Clamp Jaw WK08-00007 37. Screw WK08-00037
8. Washer WK08-00008 38. Motor Cover WK08-00038
9. Lock Washer WK08-00009 39. Brush Spring WK08-00039
10. Bolt WK08-00010 40. Brush Set WK08-00040
11. Spark Deflector WK08-00011 41. Screw WK08-00041
12. Bolt WK08-00012 42. Brush Holder WK08-00042
13. Pivot Shaft WK08-00013 43. Screw WK08-00043
14. Lock Pin WK08-00014 44. Housing WK08-00044
15. Ring WK08-00015 45. Rubber Cover WK08-00045
16. Lock Pin Cap WK08-00016 46. 608 Bearing WK08-00046
17. Screw WK08-00017 47. Stator WK08-00047
19. Nut WK08-00019 48. Fan Baffle WK08-00048
20. Washer WK08-00020 49. Screw WK08-00049
21. Lock Nut WK08-00021 50. Armature WK08-00050
22. Torsion Spring WK08-00022 51. Screw WK08-00051
23. Nut WK08-00023 52. Spring Washer WK08-00052
24. Small Lead Screw WK08-00024 53. Bearing Cap WK08-00053
25. Thread Pin WK08-00025 54. Flange Lock Pin WK08-00054
26. Clamp Jaw WK08-00026 55. Bearing WK08-00055
27. Washer WK08-00027 56. Spring WK08-00056
28. Spring Washer WK08-00028 58. Arm WK08-00058
29. Nut WK08-00029 59. Bearing WK08-00059
30. Clamp Base WK08-00030 60. Gear WK08-00060

18
PARTS LIST - 01308….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
61. Gear Case Cover WK08-00061 78. Rubber Pole WK08-00078
62. Screw WK08-00062 79. Cap WK08-00079
63. Check Ring WK08-00063 80. Lower Handle WK08-00080
64. 6204 Bearing WK08-00064 81. Capacitor WK08-00081
65. Spindle WK08-00065 82. Switch WK03-00305
66. Key WK08-00066 83. Trigger WK08-00083
67. Fixed Guard WK08-00067 84. Soft Start WK03-00307
68. Spring Washer WK08-00068 85. Upper Handle WK08-00085
69. Screw WK08-00069 86. Screw WK08-00086
70. Inner Flange WK08-00070 87. Carry Handle WK08-00087
71. Outer Flange WK08-00071 88. Screw WK08-00088
72. Washer WK08-00072 89. Screw WK08-00089
73. Screw WK08-00073 90. Screw WK08-00090
74. Lock Nut WK08-00074 91. Mains Lead Gland WK08-00091
75. Moving Guard WK08-00075 92. Mains Lead WK03-00315
76. Special Screw WK08-00076 93. Cable Clamp WK08-00093
77. Special Screw WK08-00077
7
SAFETY INSTRUCTIONS….cont
Use of improper accessories may cause damage to the abrasive cut off saw
and surrounding area as well as increasing the risk of injury.
Do not modify the abrasive cut off saw to do tasks other than those intended.
When sawing always use the vice to hold the material; To avoid injury, the work
piece should never be held with the bare hands.
Remove all tools from the machine base after adjustments are made.
Appropriate personal protective equipment MUST be worn and MUST be de-
signed to protect against all hazards created. Severe permanent injury can re-
sult from using inappropriate or insufficient protective equipment - Eyes in partic-
ular are at risk.
Do not overload the abrasive disc. Allow the abrasive disc to operate at its opti-
mum speed for maximum efficiency.
Always ensure that the accessories such as abrasive discs are rated / designed
for use with this abrasive cut off saw as well as the required application, and are
correctly and securely fastened before connecting the abrasive cut off saw to
the mains supply.
The work must be clamped firmly whilst sawing, If its loose it could result in per-
sonal injury or damage to the abrasive disc or machine.
Keep hands away from the abrasive disc.
Never use this abrasive cut off saw with the disc guards or rear motor cover re-
moved.
Round tubing can have a tendency to roll whilst being cut and can cause the
abrasive disc to slip, DO NOT cut such items without clamping the material with
the vice.
Do not start the abrasive cut off saw until the material is secure and the abrasive
disc has been lowered to just above the material.
Never use damaged, expired or lower rpm rated abrasive discs, this is extremely
dangerous and could split or even shatter, and could injury you or any one in
the vicinity.
Note: If the abrasive cut off saw is used in a place of work all rules and laws
etc. relating to the use of portable electrical appliances should be fol-
lowed.

8
CAUTION: The warnings and cautions mentioned in this user manual can not
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which can-
not be built into this product, but must be applied.
SAFETY INSTRUCTIONS….cont
This abrasive cut off saw is double insulated; This means the operator is
separated from the tool's electrical system by two complete sets of electri-
cal insulation. This extra layer of insulation is intended to protect the user
from electrical shock due to a break in the wiring insulation. All exposed
metal parts are isolated from the internal metal motor components with
protecting insulation. Double insulated tools do not need to be grounded
(earthed). Servicing of a tool with double insulation requires extreme care
and knowledge of the system and should be performed only by a suitably
qualified person.
Some metals and metal composites have the potential to be high-
ly toxic; always wear a face mask when operating saw.
When using the saw always ensure the operator as well as those in
the area wear ear protection.
When using the saw always ensure the operator as well as those in
the area wear eye protection.
17
PARTS LIST - 01308
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Lock Bolt WK08-00001 31. Clamp Nut WK08-00031
2. Screw WK08-00002 32. Screw WK08-00032
3. Washer WK08-00003 33. Spring Washer WK08-00033
4. Locking Handle WK08-00004 34. Roll Pin WK08-00034
5. Rubber Foot WK08-00005 35. Split Pin WK08-00035
6. Base WK08-00006 36. Washer WK08-00036
7. Fixed Clamp Jaw WK08-00007 37. Screw WK08-00037
8. Washer WK08-00008 38. Motor Cover WK08-00038
9. Lock Washer WK08-00009 39. Brush Spring WK08-00039
10. Bolt WK08-00010 40. Brush Set WK03-00267
11. Spark Deflector WK08-00011 41. Screw WK08-00041
12. Bolt WK08-00012 42. Brush Holder WK08-00042
13. Pivot Shaft WK08-00013 43. Screw WK08-00043
14. Lock Pin WK08-00014 44. Housing WK08-00044
15. Ring WK08-00015 45. Rubber Cover WK08-00045
16. Lock Pin Cap WK08-00016 46. 608 Bearing WK08-00046
17. Screw WK08-00017 47. Stator WK03-00274
19. Nut WK08-00019 48. Fan Baffle WK08-00048
20. Washer WK08-00020 49. Screw WK08-00049
21. Lock Nut WK08-00021 50. Armature WK03-00277
22. Torsion Spring WK08-00022 51. Screw WK08-00051
23. Nut WK08-00023 52. Spring Washer WK08-00052
24. Small Lead Screw WK08-00024 53. Bearing Cap WK08-00053
25. Thread Pin WK08-00025 54. Flange Lock Pin WK08-00054
26. Clamp Jaw WK08-00026 55. Bearing WK08-00055
27. Washer WK08-00027 56. Spring WK08-00056
28. Spring Washer WK08-00028 58. Arm WK08-00058
29. Nut WK08-00029 59. Bearing WK08-00059
30. Clamp Base WK08-00030 60. Gear WK08-00060

16
EXPLODED DRAWING - 01308 / 01315
9
This abrasive cut off saw (01308) is fitted with a standard UK type 230v ~ plug. Before
using the tool inspect the cable and plug to ensure that neither are damaged. If any
damage is visible have the tool inspected / repaired by a suitably qualified person. If it
is necessary to replace the plug a heavy duty impact resistant plug would be prefera-
ble. The abrasive cut off saw (01315) is supplied with no plug fitted.
The wires for the plug are coloured in the following way:
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows:
The wire which is coloured blue, must be connected to the terminal marked
with N or coloured black.
The wire which is coloured brown, must be connected to the terminal, which is
marked L or coloured red.
Always secure the wires in the plug terminal carefully and tightly. Secure the ca-
ble in the cord grip carefully.
Warning: Never connect live or neutral wires to the earth terminal of the
plug. Only fit an approved plug with the correct rated fuse (where appli-
cable). If in doubt consult a qualified electrician.
This abrasive cut off saw is double insulated. This means the operator is sepa-
rated from the tool's electrical system by two complete sets of electrical insu-
lation.
ELECTRICAL CONNECTION
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always
replace the fuse with the same value as the original (where applicable).
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating.
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.

10
Guarantee:
This SIP abrasive cut off saw is covered by a 12 month parts and labour warranty cov-
ering failure due to manufacturers defects. This does not cover failure due to misuse or
operating the abrasive cut off saw outside the scope of this manual - any claims
deemed to be outside the scope of the warranty may be subject to charges Includ-
ing, but not limited to parts, labour and carriage costs.
Failure to regularly clean your abrasive cut off saw will shorten its working life and re-
duce performance. The warranty does not cover consumable items such as motor
brushes and abrasive discs etc.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
GUARANTEE
Note: If any of the above are missing or damaged, contact your distributor
immediately.
CONTENTS AND ACCESSORIES
Abrasive Cut Off Saw Manual Hex. key
15
MAINTENANCE….cont
REPLACING THE BRUSHES
Remove the rear motor cover by loosening and removing the 2 screws (M)
(Photo 006).
Pull up the brush spring (N) and pull the old brush out (O) (Photo 007).
Pull the brush wire off the connection (P) (Photo 008).
Fit the new brush in reverse order.
Repeat for the other side.
006
M
N
007
O
008
P
WIRING DIAGRAM

14
DO NOT use the abrasive cut off saw if it is, or has parts that are worn, dam-
aged or missing; remove from service and have the parts repaired / replaced
using original spare parts.
Clean the abrasive cut off saw after each use.
Check the disc and guards for wear or damage before each use.
The abrasive cut off saw should be stored in a clean and dry environment.
Note: Disconnect the abrasive cut off saw from the mains supply before changing
accessories, servicing or performing maintenance. Replace or repair damaged
parts. Use genuine parts only. Non-authorised parts may be dangerous and will
invalidate the warranty.
MAINTENANCE
CHANGING THE DISC
Remove the 2 nuts (G) and remove the moving disc guard (H) (Photo 004).
Rotate the disc until you find the inner flange cut out (I) (Photo 005).
Place a hex. key (L) on to the disc bolt (J) (Photo 005).
Push the disc lock pin (K) inwards so it sits inside the inner flange cut out (this will
hold the abrasive disc so it wont be able to move whilst you undo the disc bolt)
(Photo 005).
Whilst the disc lock pin is still pushed inwards, turn the hex. key (L) anti-clockwise
to undo the disc bolt (Photo 005).
Remove the disc bolt, washer, outer flange and abrasive disc, place the new
disc over the shaft and follow these steps in reverse to fit and secure the new
disc.
Note: The abrasive disc must be rated above 3800rpm and be within the
expiry date, any disc rated below this or expired could shatter and possibly
cause injury to the operator or people nearby.
004
G
H
005
I
J
K
L
11
TECHNICAL SPECIFICATION
SIP Part No. 01308 01315
Input Voltage 230V 110V
No Load Speed 3600 rpm 3400 rpm
Input Power 2400W 2000W
Disc Size 355mm 355mm
Bore Size 25.4mm 25.4mm
Round Tube @ 0˚ 130mm 130mm
Round Tube @ 45˚ 110mm 110mm
Square Box Section @ 0˚ 120mm x 120mm 120mm x 120mm
Square Box Section @ 45˚ 90mm x 90mm 90mm x 90mm
Rectangular Box Section @ 0˚ 180mm x 85mm 180mm x 85mm
Rectangular Box Section @ 45˚ 100mm x 80mm 100mm x 80mm
Angle Iron @ 0˚ 140mm x 140mm 140mm x 140mm
Angle Iron @ 45˚ 90mm x 90mm 90mm x 90mm

12
GETTING TO KNOW YOUR ABRASIVE CUT OFF SAW
Ref. No. Description
1. Trigger switch
2. Handle
3. Spark deflector
4. Vice
5. Vice handle knob
6. Moving guard
2
3
4
5
6
1
13
OPERATING INSTRUCTIONS
TO RAISE THE HEAD
To raise the head prior to cutting, push the head down
and pull out the head lock pin (Photo 001) and the
head will raise.
MAKING A CUT
The vice jaw can be set in 3 different positions depending on the size of material to be
cut, the vice can be adjusted to 45˚left or right; To set the vice jaw follow the steps
below.
Remove the 2 bolts (A), if required (Photo 002).
Move the vice jaw (B) over hole (C or D), de-
pending on what size material is too be cut.
Refit the 2 bolts but do not tighten yet.
Move the vice jaw to the angle to be cut be-
tween 0˚& 45˚ left or right.
Retighten both bolts.
Place the material against the vice jaw (B), lift
the clamp nut (E) (Photo 003) and push the vice
handle knob (F) up against the material, push
the clamp nut (E) down and tighten using the
Vice handle knob (F).
Plug the machine in to the mains supply and
switch on.
Depress the trigger switch on the handle to start
the machine, once the cut is made let go of
the trigger switch and the machine will stop.
Head lock pin
001
A
002
B C D
Danger / Caution: The abrasive disc bolt must be tight at all times, check
before each use and at regular intervals during operation.
E
F
003
