Electrical information 13Amp Class 1 Protection
CONNECTION OF THE MAINS PLUG
Important! The wires in the mains lead fitted to this product are coloured in
accordance with the following code:
Brown: live (L) or Red
Blue: Neutral (N) or Black
Green and Yellow or Green: Earth (E)
THIS PRODUCT REQUIRES A CONNECTION
TO EARTH. THE 3 PIN PLUG MUST COMPLY
TO BS1363/ A. The FUSE MUST COMPLY TO
B51362
If for any reason the 13 amp plug fitted to this product requires replac-
ing it must be wired in accordance with the following instruction:
Do not connect the brown (live) or blue (neutral) to the earth pin MARKED E on
the 3 pin plug.
Connect the Blue wire to the terminal marked Neutral (N).
Connect the Brown wire to the terminal marked live (L).
Connect the Green and Yellow wire to the terminal marked Earth E.
Ensure that the outer insulation is gripped by the cord grip and that the wires
are not trapped when replacing the plug cover. The mains lead on this product is
fitted with a 13 amp (BS1363/A) plug. A 13 amp (B51362) fuse must be fitted in
the plug. If in doubt consult a qualified electrician.
There are no user serviceable parts inside this product except those referred to
in this manual. Always refer servicing to qualified service personnel. Never re-
move any part of the casing unless qualified to do so; this unit contains danger-
ous voltages.
WARNING!
For your protection if this tool is to be used outdoors, do not expose it to rain or
use it in damp locations. Do not place the tool on damp surfaces, use a work-
bench if available. For added protection use a suitable residual current device (R.
C.D.) at the socket outlet.
If an extension cable is to be used with this machine it must be of 3 core con-
struction with the earth conductor connected at both the plug and socket. If in
doubt consult a qualified electrician.
19
Using the rip fence. (Pic 37)
Ripping, bevel ripping, and rebating are done using the rip fence.
Ripping.
Ripping is cutting a piece of wood with the grain or lengthwise (Pic 37).
This is done using the rip fence. Position the rip fence to the desired width of the rip and lock it in place. Be-
fore starting to cut be sure that the rip fence is parallel to the saw blade, and that the riving knife is correctly
aligned with the saw blade. When ripping long boards or large panels always use a work support. Hold the
piece against the fence and feed it through the blade with a smooth, steady pressure.
When the ripping width is wider than 150 mm (6") ,
use your right hand to feed the work piece until it is clear of the table. Use your left hand only to guide, not to
feed the work piece.
Bevel cutting. (Pic 38)
When bevel cutting material 150mm (6") or narrower use the fence on the right side of the blade only (Pic
38).
Blade Replacement (Pic 39)
Remove the blade guard and the table insert. Fully release the lock handle and turn the elevating handle in a
clockwise direction to raise the blade to its highest position. Remove the blade fixing nut (pic 39, 39.3) and
the outer flange (pic 39, 39.2) and remove the blade. Ensure that the motor shaft, blade mounting arbor,
inner and outer flanges and the securing nut are dean and free from sawdust build up. Fit the new blade (Be
sure that the teeth are facing downwards when viewed from the front of the machine). Ensure that the
flanges are clean and fitted the correct way round. Secure the blade in place by using the securing nut, Re-fit
the table insert and secure in place with the cross head screws. Re-fit the blade guard ensuring that it oper-
ates correctly.
Check the alignment of the riving knife as detailed In the specific safety instructions.
Before switching the table saw ON, make sure the blade guard is installed and operating correctly.
Check that the blade is set to 90° and at its lowest position.
Ensure that the table is clear of any tools or other materials.
Ensure that all nuts, bolts and other fastenings are secure.
If the machine makes any unusual noise or vibrates excessively, STOP the machine immediately and investi-
gate the cause and rectify. If the cause cannot be identified NO NOT use the machine and contact your near-
est service centre.
Lubrication. (Pic40)
Before lubricating, remove the bottom safety cover by removing the cross head pan screws. Lubricate the
blade tilting operating screw and both pairs of locking and adjustment nuts and the blade elevating threaded
rod once a month using a light machine oil or other similar lubricant.
Maintenance
Do not make any adjustment while the motor is in motion. Always make sure the machines plug has been
removed from the mains power source before changing brushes, lubricating or when doing any work or main-
tenance on the machine. After each use, check your machine for damage or broken parts and keep it in top
working condition by repairing or replacing parts immediately, clean out accumulated dust.
During use the carbon brushes will wear down, this will be indicated by a possible loss of power and excessive
sparking seen through the ventilation slots. When the brushes have worn down to approximately 4-5mm they
will require replacing. Remove the two round cover plates, one on either side of the motor casing (Pic 41).
Remove the worn carbon brush and replace it with the new one, and re-fit the round cover plate. Repeat this
operation for the other carbon brush.
NOTE: Carbon brushes must always be changed as a pair.
Caution: If you are unsure or if safety critical repairs are required always refer the saw to a qualified engi-
neer/service centre.
