SIP HG3000S SWF User manual

36
Ref: 220817
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with your
domestic waste. If your supplier offers a disposal facility please
use it or alternatively use a recognised re-cycling agent. This will
allow the recycling of raw materials and help protect the environ-
ment.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
1
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
05777
HG3000S SWF
Mig Inverter Welder

2
35
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
Product Enquiry
HG3000S SWF Mig Inverter Welder - SIP Part No. 05777
Conforms to the requirements of the following directive(s), as indicated.
2006/95/EC Low Voltage Directive
2004/108/EC EMC Directive
2011/65/EU RoHS Directive
Signed: …………………………………...
Mr P. Ippaso - Director - SIP (Industrial Products) Ltd
Date: 17/07/2017.
And the relevant harmonised standard(s), including
DECLARATION OF CONFORMITY
EN 60974-1:2012
EN 60974-10:2007

34
NOTES
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
11. Electrical Connection
12. Guarantee
13. Technical Specification
14. Contents and Accessories
15. Getting to Know Your Welder
17. Assembly Instructions
19. Operating Instructions
25. Maintenance
26. Troubleshooting
27. Wiring Diagram
28. Exploded Drawing - Main Unit
29. Parts List - Main Unit
30. Exploded Drawing - WFU & Interconnections
31. Parts List - WFU & Interconnections
32. Exploded Drawing - Torch
33. Parts List - Torch
34. Notes
35. Declaration of Conformity

4
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the mig
welder.
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
When using your inverter welder, basic safety precautions should always be followed
to reduce the risk of personal injury and / or damage to the welder.
Read all of these instructions before operating the welder and save this user manual
for future reference.
The welder should not be modified or used for any application other than that for
which it was designed.
This welder was designed to supply electric current for Mig or Arc welding.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before each use of the welder always check no parts are broken and that no parts are
missing.
Always operate the welder safely and correctly.
KNOW YOUR WELDER: Read and understand the owner's manual and labels affixed to
the welder. Learn its applications and limitations, as well as the potential hazards spe-
cific to it.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite
accidents. Floors must not be slippery due to oil, water or sawdust etc.
DO NOT USE THE WELDER IN DANGEROUS ENVIRONMENTS: Do not use the welder in
damp or wet locations, or expose it to rain. Provide adequate space surrounding the
work area. Do not use in environments with a potentially explosive atmosphere.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
33
PARTS LIST - TORCH
TORCH COMPONENTS
SIP CODE DESCRIPTION
1. 09103 TIP ADAPTOR/DIFFUSER
2. 09322 SHROUD SPRING
3. 09320 SWAN NECK
4. 09326 HANDLE LOCATOR
5. 02972 HANDLE
6. 09332 TRIGGER
7. 09328 LINER NUT
NOZZLES
A.
SIP CODE DESCRIPTION
02697 CONICAL SHROUD
CONTACT TIPS
B.
09070 0.6MM CONTACT TIP M6
09077 0.8MM CONTACT TIP M6
09078 1.0MM CONTACT TIP M6
02653 1.2MM CONTACT TIP M6
LINERS
C.
02975 RED STEEL LINER (3 METRE)
02973 RED STEEL LINER (4 METRE)
09173 TEFLON LINER (4 METRE)
Other parts may be available on request.
N/A 05505 TORCH COMPLETE (3 METRE)
N/A 05515 TORCH COMPLETE (4 METRE)
SPARE ROLLERS
0.6mm/0.8mm
V-groove
0.8mm/1.0mm
V-groove
1.0mm/1.2mm
V-groove
0.8mm/1.0mm
U-groove
1.0mm/1.2mm
U-groove
Description
WE02-00382 WE02-00119 WE02-00438 WE02-00445 WE02-00446SIP Part No.

32
EXPLODED DRAWING - TORCH
5
SAFETY INSTRUCTIONS….cont
STORE THE WELDER SAFELY WHEN NOT IN USE: The welder should be stored in a dry
location and disconnected from the mains supply, and out of the reach of children.
USE SAFETY CLOTHING / EQUIPMENT: Use a CE approved welding mask at all times
with the correct shade of filter lens. A fume extractor should be used particularly where
there is little or no ventilation.
PROTECT YOURSELF FROM ELECTRIC SHOCK: When working with the welder, avoid con-
tact with any earthed items (e.g. pipes, radiators, hobs and refrigerators, etc.). It is ad-
visable wherever possible to use an RCD (residual current device) at the mains socket.
STAY ALERT: Always watch what you are doing and use common sense. Do not oper-
ate the welder when you are tired or under the influence of alcohol or drugs.
DISCONNECT THE WELDER FROM THE MAINS SUPPLY: When not in use and before ser-
vicing.
AVOID UNINTENTIONAL STRIKING: Make sure the switch is in the OFF position before
connecting the welder to the mains supply.
NEVER LEAVE THE WELDER CONNECTED WHILST UNATTENDED: Turn the welder off and
disconnect it from the mains supply between jobs. Do not leave the welder connect-
ed to the mains supply if no more welding is to be done.
DO NOT ABUSE THE MAINS LEAD: Never attempt to move the welder by the mains lead
or pull it to remove the plug from the mains socket. Keep the mains lead away from
heat, oil and sharp edges. If the mains lead is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order to avoid un-
wanted hazards. All extension cables must be checked at regular intervals and re-
placed if damaged.
CHECK FOR DAMAGED PARTS: Before every use of the welder, any damage found
should be carefully checked to determine that it will operate correctly, safely and per-
form its intended function. Any damaged, split or missing parts that may affect its op-
eration should be correctly repaired or replaced by an authorised service centre un-
less otherwise indicated in this instruction manual.
KEEP ALL PANELS IN PLACE: Never operate the welder with the panels removed, this is
extremely dangerous.
MAINTAIN THE WELDER WITH CARE: Keep the earth clamp, mig tip & shroud clean for
the best and safest performance.
USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or
SIP directly for recommended accessories. Follow the instructions that accompany the
accessories. The use of improper accessories may cause hazards and will invalidate
any warranty you may have.
SECURE THE WORKPIECE: Always use welding clamps to secure the workpiece. This
frees up both hands to operate the welder correctly.
DO NOT OVERREACH: Keep proper footing and balance at all times.
USE THE RIGHT TOOL: Do not use the welder to do a job for which it was not designed.
DO NOT OPERATE THE WELDER IN EXPLOSIVE ATMOSPHERES: Do not use the welder in
the presence of flammable liquids, gases, dust or other combustible sources. Welding
will create sparks which can ignite the dust or fumes.

6
SAFETY INSTRUCTIONS….cont
DO NOT EXPOSE THE WELDER TO RAIN OR USE IT IN WET CONDITIONS: Water entering
the welder will greatly increase the risk of electric shock and equipment damage.
HAVE YOUR WELDER REPAIRED BY A QUALIFIED PERSON: The welder is in accordance
with the relevant safety requirements. Repairs should only be carried out by qualified
persons using original spare parts, otherwise this may result in considerable danger to
the user.
Stop operation immediately if you notice anything abnormal.
Always disconnect the plug from the mains supply before cleaning or servicing etc.
Be alert at all times, especially during repetitive, monotonous operations; Don't be
lulled into a false sense of security.
Use of improper accessories may cause damage to the inverter welder and sur-
rounding area as well as increasing the risk of injury.
Do not modify the inverter welder to do tasks other than those intended.
To avoid injury, the workpiece should never be held with bare hands; The workpiece
will become hot during normal welding operations, and stay hot for a period after
the weld is complete.
Appropriate personal protective equipment must be worn and must be designed to
protect against all hazards created. Severe permanent injury can result from using
inappropriate or insufficient protective equipment - Eyes in particular are at risk.
The work should be clamped firmly whilst welding, If its loose it could result in person-
al injury or damage to the machine or item that is being welded.
Do not attempt any repairs to the welder unless you are a competent electrician or
engineer.
Ensure that the machine is connected to the correct supply voltage and protected
by a fuse or circuit breaker of the recommend rating.
Never allow the earth clamp and electrode holder to come into contact with each
other.
Understand the operating environment; Before each use the operator should as-
sess, understand and where possible reduce the specific risks and dangers associ-
ated with the operating environment. Bystanders should also be made aware of
any risks associated with the operating environment.
Electromagnetic fields can interfere with various electrical and electronic devices
such as pacemakers; Consult your doctor before using any electric welder or cut-
ting device.
Keep people with pacemakers away from your welding area when welding.
Do not wrap cable around your body while welding.
If the welder is to be used on business premises - ensure that all local and national
regulations are followed concerning the use of portable electrical appliances at
work.
31
PARTS LIST - WFU & INTERCONNECTIONS
Ref. No. Description Sip Part No. Ref. No. Description Sip Part No.
1. Spool Cover WE02-00357 13. Wire Feed Motor WE02-00370
2. Torch Holder WE02-00358 14. Plastic Hinge WE02-00371
3. Enclosure WE02-00359 15. Dinse socket WE02-00372
4. Potentiometer WE02-00360 16. Reel Hub Assembly WE02-00373
5. Front Panel WE02-00361 17. Control Socket WE02-00374
6. Potentiometer Knob WE02-00362 18. Cable Support WE02-00375
7. Inching Button WE02-00363 19. Solenoid Valve WE02-00376
8. Plastic Euro Surround WE02-00365 20. Control Cable WE02-00378
9. Euro Torch Socket WE02-00366 21. Gas Hose WE02-00379
10. Castor WE02-00367 22. Connecting Cable WE02-00380
11. Bottom Frame WE02-00368 23. Earth Lead Complete WE02-00381
12. Door WE02-00369

30
EXPLODED DRAWING - WFU & INTERCONNECTIONS
20
21
22
23
1
2
3
4
5
6
7
8
910
11
1213
14
15
16
17
18
19
7
SAFETY INSTRUCTIONS….cont
Electric welders have the potential to cause a shock that could lead to injury or death.
Touching electrically ‘hot’ parts can cause fatal shocks and severe burns; While weld-
ing, all metal components connected to the welder are electrically ‘hot’.
Keep your body and clothing dry. Never work in a damp area without ade-
quate insulation against electrical shock, stay on a dry duck board, or rubber
mat when dampness or sweat can not be avoided. Sweat, sea water or mois-
ture between the body and an electrically ’hot’ part or grounded metal reduces
the body surfaces electrical resistance enabling dangerous and possibly lethal
currents to flow through the body.
Never allow live metal parts to touch bare skin or any wet clothing, be sure
welding gloves are dry.
Before welding, check for continuity; Be sure the earth clamp is connected to
the workpiece as close to the welding areas as possible. Grounds connected to
building frame work or other remote locations from the welding area reduce
efficiency and increase the potential electric shock hazard. Avoid the possibility
of the welding current passing through lifting chains, crane cables or other elec-
tric paths.
Frequently inspect leads for wear, splits, cracks and any other damage. Imme-
diately replace those with worn or damaged insulation to avoid a possibly lethal
shock from bare leads.
During normal operation, the heat and sparks created during the welding process
have the potential to ignite flammable liquids, gases or other combustible material.
All inflammable materials must be removed from the area.
Have a suitable fire extinguisher available close by.
Causes of fire and explosion include; combustibles reached by the arc, flame,
flying sparks, hot slag or heated material, misuse of compressed gases and
cylinders and short circuits.
Flying sparks or falling slag can pass through cracks along pipes, through win-
dows or doors and through walls or floor openings and out of sight of the opera-
tor; Sparks and slag can fly up-to 10 metres.
Keep equipment clean and operable; Free of oil, grease and of metallic parti-
cles (in electrical parts) that can cause short circuits.
If combustibles are in the area. Do not weld , move the work if practical to an
area free of combustibles, avoid paint spray rooms, dip tanks, storage areas
and ventilators. If the work can not be moved, then move the combustibles at
ELECTRIC SHOCK
FIRE

8
least 10 metres away and out of the reach of sparks and heat or protect
against ignition with suitable and snug fitting, fire resistant covers or shields.
Walls touching combustibles on opposite sides should not be welded on, walls,
ceilings and the floor near the work area should be protected by heat resistant
covers or shields.
Openings (concealed or visible) in floors or walls within 10 metres may expose
combustibles to sparks.
Combustibles adjacent to walls, ceilings, roofs or metal partitions can be ignit-
ed by radiant or conducted heat.
After the work is done, check that the area is free of sparks, glowing embers and
flames.
An empty container that has held combustibles, or that can produce flamma-
ble or toxic vapours when heated, must never be welded, unless the container
has first been cleaned. Consult HSE INDG214, HSG250 and CS15. HSE docu-
ment CS15 includes information on cleaning by thorough steam or solvent/
caustic cleaning followed by purging and inserting with nitrogen, carbon diox-
ide or water filling just below working level.
A container with unknown contents should be treated as if it contained combus-
tibles (see previous paragraph), Do not depend on sense of smell or sight to
determine if it is safe to weld.
Hollow items must be vented before welding as they can explode.
Explosive atmosphere; Never weld when the air may contain flammable dust,
gas or liquid vapours (such as petrol).
SAFETY INSTRUCTIONS….cont
The welding arc produces ultraviolet (UV) and infrared (IR) rays as well as extreme tem-
peratures that can cause injury to your eyes and skin. Do not look at the welding arc
without proper eye protection.
The electric welding arc must not be observed with the naked eye. Always use a
welding mask; Ensure the welding mask is fitted with the correct shade of filter
lens for the welding current level, and covers the entire face from neck to the
top of the head.
Welding gauntlet gloves should be worn to protect the hands from burns, non-
synthetic overalls with buttons at the neck and wrist, or similar clothing should be
worn. Greasy overalls should not be worn. Wear suitable protective footwear.
Always wear correctly rated protective clothing which covers all areas of the
body; The operator should not weld with any bare skin showing to reduce the
chance of burns etc.
Avoid oily or greasy clothing, a spark may ignite them.
Hot metal such as electrode stubs and workpieces should never be handled
GLARE AND BURNS
29
Ref. No. Description Sip Part No. Ref. No. Description Sip Part No.
1. Plastic Edge WE02-00541 25. Loading Board WE02-00565
2. Handle WE02-00542 26. Bracket For Heat Sink-II WE02-00566
3. Left Side Panel WE02-00543 27. Rectifier Filter Board WE02-00567
4. Front Panel WE02-00544 28. IGBT Power Amplifiers PCB WE02-00568
5. Potentiometer knob WE02-00545 29. Fan WE02-00569
6. Voltage / Amps Display WE02-00546 30. Timing Sequence PCB WE02-00570
7. Wire Feed Support Column WE02-00547 31. Drive board for wire feed WE02-00571
8. Wire Feed Fixed Plate WE02-00548 32. Beam WE02-00572
9. Top Panel WE02-00549 33. Right Side Panel WE02-00573
10. Median Plate WE02-00550 34. Shield For Heat Sink - II WE02-00574
11. Rectifier Board WE02-00551 35. Rubber Wheel WE02-00575
12. Shield For Heat Sink - I WE02-00552 36. Bottom Panel Bracket WE02-00576
13. Strut WE02-00553 37. Amps Sampling Board WE02-00577
14. Switch Holder WE02-00554 38. Bracket For Transformer WE02-00578
15. Switch WE02-00555 39. Main Transformer WE02-00579
16. Rear Panel WE02-00556 40. Bracket For Transformer WE02-00580
17. Chain WE02-00557 41. Output Reactor WE02-00581
18. Two Core Socket WE02-00558 42. Bottom Panel WE02-00582
19. Fan - II WE02-00559 43. Castor WE02-00583
20. Mains Lead WE02-00560 44. LED Holder WE02-00584
21. Filter WE02-00561 45. Welding Mode Selector Switch WE02-00585
22. Power PCB WE02-00562 46. Potentiometer Knob WE02-00586
23. Control Transformer WE02-00563 47. Dinse Connector WE02-00587
24. Bracket For Heat Sink - I WE02-00564 48. Interconnection Lead Socket WE02-00588
PARTS LIST - MAIN UNIT

28
EXPLODED DRAWING - MAIN UNIT
9
SAFETY INSTRUCTIONS….cont
Ventilation must be adequate to remove the smoke and fumes during welding
(see the relevant safety standard for acceptable levels).
Toxic gases may be given off when welding, especially if zinc or cadmium
coated materials are involved, welding should be carried out in a well ventilat-
ed area and the operator should always be alert to fume build-up.
Areas with little or no ventilation should always use a fume extractor.
Vapours of chlorinated solvents can form the toxic gas phosgene when ex-
posed to U.V radiation from an electric arc. All solvents, degreasers and poten-
tial sources of these vapours must be removed from the arc area.
Severe discomfort, illness or death can result from fumes, vapours, heat, oxygen
enrichment or depletion that welding (or cutting) may produce. This will be pre-
vented by adequate ventilation or using a fume extractor. NEVER ventilate with
oxygen.
Lead, cadmium, zinc, mercury, beryllium bearing and similar materials when
welded may produce harmful concentrations of toxic fumes. Adequate ventila-
tion must be provided for every person in the area. The operator should also
wear an air supplied respirator, for beryllium both must be used.
Metals coated with or containing materials that emit toxic fumes should not be
heated unless coating is removed from the work surface. The area should be
well ventilated or the operator should wear an air supplied respirator.
Work in a confined space only while it is being ventilated and if necessary whilst
wearing an air supplied respirator.
Gas leaks in a confined space should be avoided, leaking gas in large quanti-
ties can change oxygen concentration dangerously. DO NOT bring gas cylin-
ders into a confined space.
Leaving a confined space you must shut off the gas supply at the source to
prevent possible accumulation of gases in the space if down stream valves are
left open. Check to be sure that the space is safe before re-entering it.
without gloves.
First aid facilities and a qualified first aid person should be available for each
shift unless medical facilities are close by for immediate treatment of flash burns
to the eyes and skin.
Flammable hair products should not be used by persons intending to weld.
Warn bystanders not to watch the arc and not to expose themselves to the
welding arc rays or to hot metal.
Keep children away whilst welding, they may not be aware that looking at an
arc can cause serious eye damage.
Protect other nearby personnel from arc rays and hot sparks with a suitable non-
flammable partition.
VENTILATION

10
SAFETY INSTRUCTIONS….cont
Some metals and metal composites have the potential to be highly
toxic; always wear a face mask .
When using the welder always ensure the operator as well as those
in the area use a welding mask with the correct shade filter lens.
CAUTION: The warnings and cautions mentioned in this user manual can not
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which can-
not be built into this product, but must be applied.
Vapours from chlorinated solvents can be decomposed by the heat of the arc
(or flame) to form phosgene a highly toxic gas and other lung and eye-irritating
products. The ultra violet (radiant) energy of the arc can also decompose tri-
chloroethylene and perchlorethylene vapours to form phosgene. DO NOT
WELD or cut where solvent vapours can be drawn into the welding atmosphere,
or where the radiant energy can penetrate to atmospheres containing even
minute amounts of trichloroethylene or perchlorethylene.
27
WIRING DIAGRAM

26
TROUBLESHOOTING
Note: If none of the above solutions work then contact your local distributor
for repair, or contact SIP technical for more advise.
11
ELECTRICAL CONNECTION
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the power supply:
The HG3000S welder is supplied without a plug fitted, it must not be connected to a
standard 13A supply; Consult the technical specification table (page 13) for the re-
quired rating, if in doubt contact a qualified electrician. Before using the welder, in-
spect all the leads and plugs to ensure that none are damaged. If any damage is
visible have the welder inspected / repaired by a suitably qualified person.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows:
The wire which is coloured brown, must be connected to the terminal, which is
marked L or coloured red (or brown).
The wire which is coloured blue, must be connected to the terminal marked with N or
coloured black (or blue).
The wire which is coloured yellow / green should be connected to the terminal which
is coloured the same or marked with this symbol
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.

12
Warning: Never connect live or neutral wires to the earth terminal of the
plug. Only fit an approved plug with the correct rated fuse. If in doubt
consult a qualified electrician.
ELECTRICAL CONNECTION….cont
This SIP mig welder is covered by a 24 month parts and labour warranty covering fail-
ure due to manufacturers defects. This does not cover failure due to misuse or operat-
ing the mig welder outside the scope of this manual - any claims deemed to be out-
side the scope of the warranty may be subject to charges Including, but not limited to
parts, labour and carriage costs.
Failure to regularly clean your mig welder will shorten its working life and reduce perfor-
mance.
The warranty does not cover consumable items such as tips, shrouds, clamps, etc.
GUARANTEE
Note: Proof of purchase will be required before any warranty can be hon-
oured.
Note: If an extension lead is necessary in order to reach the mains supply; The
cross section should be checked so that it is of sufficient size so as to reduce the
chances of voltage drops. Always fully unwind the lead during use.
Note: Due to the input current required to run the inverter welder, it is advisa-
ble not to use an extension lead.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse, type and rating, is used.
25
MAINTENANCE
Clear dust from the machine at regular intervals, if used in a dirty environment
the machine should be cleaned once a month.
Check all connections are clean and tight, if there is any oxidization clean the
connection with a mild abrasive or wire brush.
Check all cable for damaged or degradation to the insulation, replace if any
found.
Check earth clamp condition ensure they clamp tightly, replace if damaged or
loose.
If the machine is not to be used for a long time, store it in the original packing a
dry place.
Mig tip and shroud must be cleaned frequently to remove spatter, or replaced.
Replace the torch Mig tip regularly good electrical contact between the tip and
wire is essential.
The torch liner should be blown through with dry compressed air from time to
time, if the wire does not pass freely through the liner it should be replaced.
Remove the liner nut from the torch.
Pull the old liner completely out.
Hold the torch as straight as possible.
Push the new liner back through the torch.
Re-fit the liner nut.
Liner nut
Liner
REPLACING THE LINER

24
OPERATING INSTRUCTIONS….cont
Connect the electrode lead (+) and earth lead (-) to the appropriate terminal
on the front of the welder.
Fit the required electrode securely into the electrode holder.
Switch the welder on.
Select the ARC welding mode on the welding selector switch (15).
Set the amperage control to match your electrode size.
Place a face mask over your face.
Bring the electrode into contact with the workpiece using a light tapping action
and withdrawing to create a gap of 1.5 mm –3.0 mm.
When the arc is created, proceed steadily in one direction keeping the gap
between the electrode and the workpiece constant.
When the weld is complete simply remove the electrode from the workpiece.
Remove any excess weld / slag with a wire brush / hammer (not supplied).
WELDING - ARC
Caution: Ensure all protective equipment is worn and bystanders are not in
the vicinity.
Note: In order to arc (MMA) weld with the welder, you will need to purchase
an electrode holder and lead - SIP part number 10230.
Caution: Be aware that the electrode is now live, simply touching any part
of the workpiece will create a spark.
13
TECHNICAL SPECIFICATION
Model SIP HGT3000S SWF
Part Number 05777
Input Voltage 230V ~ 50/60Hz
Input Current 40.3A
Maximum OCV 55V (DC)
Output Current - Mig 50A - 250A
Output Current - Arc 30A - 200A
Welding Output Voltage - Mig 16.5V - 26.5V
Welding Output Voltage - Arc 21.2V - 28V
Wire Diameter 0.8mm - 1.0mm
Wire Spool Size 5Kg - 15Kg
Wire Type Solid / Flux Cored
Wire Feed Speed 1.5 - 20 m/min
Weld Material Mild Steel, Stainless Steel, Aluminium
Duty Cycle @ 20°C - Mig
250 amps @ 80%
224 amps @ 100%
200 amps @ 80%
Duty Cycle @ 20°C - Arc
179 amps @ 100%
Duty Cycle @ 40°C - Mig 250 amps @ 60%
192 amps @ 100%
Duty Cycle @ 40°C - Arc 200 amps @ 60%
154 amps @100%
Insulation Class H
Protection IP21S

14
CONTENTS AND ACCESSORIES
Note: If any of the above are missing or damaged, contact your distributor
immediately.
HG3000S SWF Mig Inverter Welder.
HG3000S Wire Feed Unit (separate box).
Instruction Manual.
MB25 Mig Torch.
5M Interconnecting Cable.
Earth Return lead with Clamp.
Spare Mig Tips x 2.
Mig Torch Spanner.
2 x Pair of Wire Feed Rollers.
Gas Bottle Support Chain.
Wire-feed support column.
Torch Holder.
23
OPERATING INSTRUCTIONS….cont
There are no hard and fast rules by which a particular gauge of electrode is selected,
usually this is determined by the type of welding required and the thickness of the
workpiece e.g. a butt weld in 1.5mm (1/16”) sheet metal can be done by a 1.6mm or
2.0mm electrode, the difference being that the 2.0mm electrode will do the job
more quickly.
The table below gives a guide as to which electrode is most suitable according to the
material thickness. This table is only a guide, and values given are an indication only.
These welding current values are for the E6013 electrodes, for other types of electrode
consult their data sheet.
Electrode Size mm Material Thickness mm Welding Current (A)
1.6 1 - 1.6 25 - 40
2.0 1.6 - 2.6 40 - 70
2.5 2.6 - 4.0 60 - 100
3.25 3.0 - 5.0 80 - 130
4.0 5.0 - 7.0 130 - 170
Note: The above is a guide only; always try a short weld test at the setting
selected. It is normal to make minor adjustments to achieve the required
weld.
The welder should be set to a specific amperage to match the electrode size (see
above table).
The amperage control is operated by rotating the Arc welding output control knob
(16) on the front of the welder; Rotate the knob clockwise to increase the amperage
and anti-clockwise to reduce the amperage. Once the amperage control is set do a
short weld and check for correct fusion.
AMPERAGE CONTROL
Clean the area to be welded, and the earthing point of all rust, paint and con-
taminants etc.
Place the earth clamp on to a cleaned area of the workpiece.
Connect the welder to the electrical supply but do not switch on.
PREPARATION FOR WELDING - ARC
ARC WELDING

22
OPERATING INSTRUCTIONS….cont
Clean the area to be welded, and the earthing point of all rust, paint and con-
taminants etc.
Place the earth clamp on to the cleaned area of the workpiece.
Connect the welder to the electrical supply.
Note: In order to use gas you will need to purchase gas, gas hose fitting
and a gas regulator suitable for the type of welding required.
Use the main On/Off switch (21) to turn the welder on.
Select the Mig welding mode on the welding selector switch (15).
Set the welding output (11), Wire Speed (8), burn back (4), inductance (3), and
2T/4T function (9) as required by adjusting the appropriate controls.
Press the torch trigger and feed the wire out a little.
Cut the wire about 3mm from the MIG contact tip.
Connect the gas pipe to the gas regulator (not supplied) (where applicable).
Turn the gas on (where applicable).
Place a welding mask/shield (not supplied) over your face.
Position the torch so the Mig tip is around 6mm from the point where the weld-
ing is to commence.
Press the torch trigger (depending on 2T/4T setting) and move the torch slowly in
the chosen direction.
Once the weld is complete, release the torch trigger (depending on the 2T/4T
setting).
Note: If the welder has a humming sound and a blob forms on the tip end, then you have insufficient wire
feed speed and it should be increased. If the welder has an erratic sound and the torch feels that the wire
is hitting against the work, then you have the wire feed speed to high and it should be reduced, when the
wire feed speed is correct you should get a steady crackling sound.
Note: For future reference make a note of the voltage and wire speed set-
ting for the material that has been welded.
PREPARATION FOR WELDING - MIG
WELDING - MIG
nents might become too high due to over use; The internal thermal protector will then
prevent the unit from operating. Its Intervention is Indicated by the alarm light on the
front panel, If this happens leave the machine switched on with the fan running and
allow It to cool down. The thermal protector will re-set automatically after a short peri-
od of time when the components have cooled you will be able to restart welding.
15
GETTING TO KNOW YOUR WELDER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Ref. No. Description Ref. No. Description
1. Output Connection (+) 13. Power Indicator
2. Wire Feed Control Connector 14. Thermal Overload Indicator
3. Inductance Control 15. Welding Mode Selector
4. Burn back Control 16. Arc Welding Output Control
5. Output Voltage Display 17. Output Connection (-)
6. Mig Torch Connection 18. Castor
7. Inching Button 19. Wire Feed Control Connector
8. Wire Feed Control 20. Welding Cable Connector
9. 2T / 4T Switch 21. Main On/Off Switch
10. Torch Holder 22. Main Lead Input
11. Welding Output Control 23. Wheel
12. Output Current Display 24. Gas Bottle Rack

16
GETTING TO KNOW YOUR WELDER ….cont
A
B
C
D
E
F
G
H
WIRE FEED UNIT
Ref. No. Description Ref. No. Description
A. Wire Retaining Nut E. Pressure Adjustment Knobs
B. Wire Spool Cover (rear) F. Door
C. Wire Spool Cover (front) G. Tension Arms
D. Wire Feed Motor H. Wire Feed Rollers
A
G
F
F
G
A
B
C
D E
Ref. Description Ref. Description
A. Shroud E. Swan Neck
B. Contact Tip F. Torch Handle
C. Tip Adaptor G. Trigger Switch
D. Gas Diffuser
MIG TORCH
21
OPERATING INSTRUCTIONS….cont
Feed the wire through the inlet guide spring, over the wire feed rollers and
through the guide tubes (you may need to straighten the first 50mm or so of
wire if it doesn't fit in to the guide tube easily).
Lower the tension arms and ensure the wire sits in the groove of the wire feed
rollers.
Push the pressure adjustment knob back over the tension arms.
Screw the pressure adjustment knob down, but not too tight as it will crush the
wire.
Plug the welder in to the mains supply and turn it on.
Lay the mig torch out as straight as possible.
Press and hold the “inching” button until the wire comes out from the end of the
torch.
Release the “inching” button.
Re-fit the mig tip and shroud.
Guide Spring
Guide Tubes
Caution: Ensure that no body parts are in line with the torch when the wire
comes out as the wire could be sharp.
Note: Be sure the wire feeds from the bottom of the spool and not from the
top.
These units can be set to deliver different output currents at a duty cycle that is written
as a percentage on page 13. This percentage represents the welding time in a 10
minute cycle, e.g. 60% means that the welding time is 6 minutes and the rest time is
4 minutes. If a unit is used beyond its duty cycle the temperatures of some compo-
IMPORTANT INFORMATION

20
OPERATING INSTRUCTIONS….cont
Before feeding the wire, you should ensure that the correct wire feed rollers are fitted.
To check / change the roller:
Pull the pressure adjustment knobs on the wire feed motor forwards so it takes
the pressure from the tension arms.
Loosen and remove the roller retaining screws and spacer.
The size of the roller should be clearly marked on the side.
Change as required by simply pulling the roller from the roller shaft.
To refit the rollers ensure that the 2 roller drive pins line up with the 2 holes on the
roller.
Refit and tighten the spacer and retaining screw to secure the roller in place.
The wire can now be fed through the torch:
Remove the shroud from the torch by rotating the shroud clockwise and pulling
at the same time.
Unscrew and remove the Mig contact tip.
Pull the pressure adjustment knobs forwards so it takes the pressure from the ten-
sion arms.
Remove the free end of the Mig wire from the side of the wire spool, trim off the
distorted end of the wire with a pair of wire cutters; Hold the wire carefully as it
will try to unwind from the spool.
Pressure adjustment Knob
Roller Retaining Screws
Tension Arms Pressure adjustment Knob
FEEDING THE WIRE
Spacer
17
ASSEMBLY INSTRUCTIONS
Remove the wire-feed unit from its box.
Remove the packaging from the main unit.
Check that the contents of the accessory box match those on page 14.
Caution: The welder and wire-feed unit are heavy; Use the correct lifting
equipment to remove the welder / wire-feed unit from their packaging.
Fit and fully tighten the wire-feed support column (above, left).
Carefully place the wire-feed unit onto the support column (above, right).
Support Column
Cable Clamp
Guide Hole
Remove the cable clamp from the wire-feed unit.
Fit both parts of the interconnecting cable, and the gas pipe through the guide
hole at the rear of the wire-feed unit.
Connect both cables and the gas pipe to the relevant connectors; Refit and
tighten the cable clamp to secure in place.
FITTING & CONNECTING THE WIRE-FEED UNIT

18
ASSEMBLY INSTRUCTIONS….cont
Danger: Ensure that the gas pipe is secure and leak free before operation.
Connect both parts at the opposite end of the interconnecting cable to the
front of the welder (see below).
Align the 2 torch pins on the welding torch with the 2 connector holes on the euro
adaptor.
Push the welding torch in to the euro adaptor.
Screw the torch locking ring on to the euro adaptor and tighten to secure.
Locking ring Euro adaptor
Torch pins
Holes
CONNECTING THE TORCH
Note: Connect the lead to the positive (+) terminal for standard welding
and negative (-) for flux cored welding.
19
ASSEMBLY INSTRUCTIONS….cont
Lift up the wire spool cover.
Turn the wire retaining nut clockwise to loosen and remove it.
Retaining Nut
Fit the welding wire over the spool holder so that the wire will feed from the
bottom of the roll.
Refit the retaining nut, and secure in place by tightening it.
Retaining Screws
Loosen the torch holder retaining screws.
Fit the torch holder.
Retighten the retaining screws.
FITTING THE TORCH HOLDER
LOADING THE WIRE
OPERATING INSTRUCTIONS
