Siqura XSNet 3300MC User manual

XSNet 3300MC
Manual
Quick Start Guide
This quick start guide describes how to install and use the Dual Rate SFP media
converter. The converter introduced here provides one channel media conversion
solution.
Physical Description
Product Overview
This Dual Rate SFP media converter is a plug-and-play device. Connect the supplied
AC to DC power adaptor to the receptacle on the rear panel of the Dual Rate SFP media
converter, and then attach the plug into a standard AC outlet.
DIP Switch
No. Down Up
1 Disable LFPT Enable LFPT LFPT:
Link-Fault-Pass-Through
function
2 Enable Auto-Negotiation for TX port Enable Force mode for TX
port
3 TX port Force mode: Full-duplex TX port Force mode:
Half-duplex
4 TX port Force mode: 100Mbps TX port Force mode:
10Mbps
5 SFP at 100Mbps SFP at 1000Mbps
6 Function reserved Function reserved
<Note> Power must be off/on after re-setting LFPT function.
1

XSNet 3300MC
The 10/100/1000Base-TX and SFP Connectors
The 10/100/1000Base-TX Connection
The following lists the pinouts of
10/100/1000Base-TX port.
The SFP Connection
The SFP socket for 100Base and
1000Base fiber optic expansion.
For SFP expansion
The Port Status LEDs
LEDs State Indication
Steady Power on
PWR stands for POWERPWR Off Power off
Steady LFPT function enabled
LFPT Off LFPT function disabled
Steady Copper port: A valid network connection established
LNKC stands for LINK/CopperLNKC Off No connection
Steady Green: Connection at the speed of 1000Mbps
Amber: Connection at the speed of 100Mbps
G:GE
A:100 Off Connection at the speed of 10Mbps
Steady Fiber port: A valid network connection established
LNKF stands for LINK/Fiber
LNKF Off No connection
Steady Force fiber port to 1000Base
GE Off Force fiber port to 100Base
2

XSNet 3300MC
3
Functional Description
Complies with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.3ab 1000Base-T,
and IEEE802.3z 1000Base-SX/LX.
Supports IEEE802.3x Flow control: Flow control for Full-duplex and Back pressure for
Half-duplex.
SFP fiber interface supports 100Base and 1000Base dual rate fiber transmission.
DIP switch configuration for “Link-Fault-Pass-Through”.
Gigabit transmission supports 9K Bytes jumbo frame.
1000Mbps-Auto/Full-duplex, 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX.
Full wire-speed forwarding rate.
Operating voltage and Max. current consumption: 0.23A @ 12VDC. Power consumption: 2.76W
Max.
Power Supply: 12VDC external universal PSU.
0°C to 50°C (32°F to 122°F) operating temperature range.
Aluminum case.
Supports Wall Mounting installation.

XSNet 3300MC
4
FCC Statement
The FCC (Federal Communications Commission) restricts the amount of radio frequency emission and
radiation coming from computer equipment.
The equipment introduced in this manual has been tested and found to comply with the limits for a
Class A digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user is required to correct the interference at his/her own expense.
Any changes or modifications not expressly approved by the manufacture would void the user’s
authority to operate the equipment.
Trademarks
Product names mentioned in this manual may be trademarks or registered trademarks of those
products.
All trademarks or brand names mentioned are properties of their respective companies.
Preface
This manual describes how to install and use the Dual Rate SFP Media Converter. The Converter
introduced here provides one channel media conversion solution:
10/100/1000Base-TX to 100Base and 1000Base dual rate SFP fiber interface with
link-fault-pass-through function
The Dual Rate SFP Media Converter fully complies with IEEE802.3 10Base-T, IEEE802.3u
100Base-TX/FX, IEEE802.3ab 1000Base-T, and IEEE802.3z 1000Base-SX/LX Ethernet standards.
In this manual, you will find:
Product overview
Features on the media converter
Illustrative LED functions
Installation instructions
Specifications

XSNet 3300MC
5
Table of Contents
QUICK START GUIDE ............................................................. 1
PHYSICAL DESCRIPTION...............................................1
FUNCTIONAL DESCRIPTION...........................................3
FCC STATEMENT ................................................................... 4
TRADEMARKS ......................................................................... 4
PREFACE.................................................................................. 4
TABLE OF CONTENTS............................................................. 5
INTRODUCTION....................................................................... 6
PRODUCT OVERVIEW...................................................6
PRODUCT FEATURES ...................................................7
PACKING LIST..............................................................8
ONE-CHANNEL MEDIA CONVERTER .................................... 9
PHYSICAL PORTS.........................................................9
PORT STATUS LEDS....................................................9
INSTALLATION......................................................................10
SELECTING A SITE FOR THE EQUIPMENT .....................10
CONNECTING TO POWER............................................10
SPECIFICATIONS ...................................................................11

XSNet 3300MC
Introduction
The Dual Rate SFP Media Converter provides one channel for media conversion between
10/100/1000Base-TX to 100Base and 1000Base dual rate SFP fiber interface with
link-fault-pass-through function.
Product Overview
Figure 1:
Dual Rate SFP Media Converter with link-fault-pass-through function
6

XSNet 3300MC
7
Product Features
Complies with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.3ab 1000Base-T,
and IEEE802.3z 1000Base-SX/LX.
Supports IEEE802.3x Flow control: Flow control for Full-duplex and Back pressure for
Half-duplex.
SFP fiber interface supports 100Base and 1000Base dual rate fiber transmission.
DIP switch configuration for “Link-Fault-Pass-Through”.
Gigabit transmission supports 9K Bytes jumbo frame.
1000Mbps-Auto/Full-duplex, 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX.
Full wire-speed forwarding rate.
Operating voltage and Max. current consumption: 0.23A @ 12VDC. Power consumption: 2.76W
Max.
Power Supply: 12VDC external universal PSU.
0°C to 50°C (32°F to 122°F) operating temperature range.
Aluminum case.
Supports Wall Mounting installation.
DIP Switch
No. Down Up
1 Disable LFPT Enable LFPT LFPT: Link-Fault-Pass-Through
function
2 Enable Auto-Negotiation for TX port Enable Force mode for TX
port
3 TX port Force mode: Full-duplex TX port Force mode:
Half-duplex
4 TX port Force mode: 100Mbps TX port Force mode:
10Mbps
5 SFP at 100Mbps SFP at 1000Mbps
6 Function reserved Function reserved
<Note> Power must be off/on after re-setting LFPT function.

XSNet 3300MC
8
Packing List
When you unpack this product package, you will find the items listed below. Please inspect the
contents, and report any apparent damage or missing items immediately to your authorized reseller.
The Media Converter
User’s Manual
AC to DC Power Adaptor

XSNet 3300MC
One-Channel Media Converter
Physical Ports ual
Rate SFP Media Converter
This converter provides one TX port and one 100Base and 1000Base dual rate SFP socket. For the
100Base and 1000Base dual rate SFP socket, it provides options of multi-mode/single-mode or WDM
multi-mode/single-mode fiber. For the TX port, it uses RJ-45 connector and supports auto MDIX for
uplink purpose.
PortStatusLEDs
The LED indicators give you instant feedback on status of the converter:
Figure 2:
Dual Rate SFP Media Converter with link-fault-pass-through function
LEDs State Indication
Steady Power on
PWR stands for POWER
PWR Off Power off
Steady LFPT function enabled
LFPT Off LFPT function disabled
Steady Copper port: A valid network connection established
LNKC stands for LINK/Copper
LNKC Off No connection
Steady Green: Connection at the speed of 1000Mbps
Amber: Connection at the speed of 100Mbps
G:GE
A:100 Off Connection at the speed of 10Mbps
Steady Fiber port: A valid network connection established
LNKF stands for LINK/Fiber
LNKF Off No connection
Steady Force fiber port to 1000Base
GE Off Force fiber port to 100Base
9

XSNet 3300MC
10
Installation
This chapter gives step-by-step installation instructions for the Converter.
Selecting a Site for the Equipment
As with any electric device, you should place the equipment where it will not be subjected to extreme
temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet
the following requirements:
The ambient temperature should be between 32 and 122 degrees Fahrenheit (0 to 50 degrees
Celsius).
The relative humidity should be less than 95 percent, non-condensing.
Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards for
IEC 801-3, Level 2 (3V/M) field strength.
Make sure that the equipment receives adequate ventilation. Do not block the ventilation holes of
the equipment.
The power outlet should be within 1.8 meters of the product.
ConnectingtoPower
This Converter is a plug-and-play device.
Connect the supplied AC to DC power adapter to the receptacle at the back of the
converter.
Attach the plug into a standard AC outlet.

XSNet 3300MC
11
Specifications
Applicable Standards IEEE802.3 10Base-T
IEEE802.3u 100Base-TX/FX
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-SX/LX
Fixed Ports
1 10/100/1000Base-TX port 1 100Base and 1000Base dual rate SFP fiber interface
Speed
10Base-T
100Base-TX/FX
1000Base-T
1000Base-SX/LX
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
2000Mbps for full-duplex
2000Mbps for full-duplex
Forwarding rate 14,880pps for 10Mbps
148,810pps for 100Mbps
1,488,100pps for 1000Mbps
LED Indicators PWR; LFPT; LNKC; Copper Port Speed; LNKF; SFP Port Speed
Dimensions 80.3mm (W) × 109.2mm (D) × 23.8mm (H)
(3.16” (W) × 4.3” (D) × 0.94” (H))
Weight 150g (0.33lb.)
Power External power adaptor
0.23A @ 12VDC
Power Consumption 2.76W Max.
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature -10°C ~ 70°C (14°F ~ 158°F)
Humidity 5 ~ 95%, non-condensing
Emissions FCC part 15 Class A, CE Mark Class A
