Sistemalux V68 Assembly instructions

V68
MODEL : V68 - NC/RF
INSTALLATION SHEET PAGE: 1 OF 2
JP - R2
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: February 28, 2020
A- REMOVE THE PHILLIPS HEAD SCREW (INCLUDED) OF THE CONNECTION HOUSING AND REMOVE COVER.
B- INSTALL BX CABLES (BY OTHERS) WITH 6" OF WIRE IN THE CONNECTION BOX.
C- MAKE ALL NECESSARY CONNECTIONS (SEE WIRING DIAGRAM). * DAISY CHAIN CONNECTIONS NOT POSSIBLE FOR 0-10V DIMMING.
D- CLOSE CONNECTION BOX COVER AND SECURE WITH THE PHILLIPS HEAD SCREW.
A + B
E + F
POWER
CABLE
COVER
PHILLIPS HEAD
SCREW
QUICK
CONNECTOR
A
E- CONNECT THE FIXTURE TO THE LED DRIVER HOUSING USING THE QUICK CONNECTOR.
F- STARTING WITH THE CONNECTION BOX, CAREFULLY INSERT THE ASSEMBLY THROUGH THE CUT-OUT.
CLOSE FIXATION BRACKETS TO FIT INSIDE CUT-OUT.
G- INSERT FIXTURE INTO THE CEILING. TO SECURE THE FIXTURE INSIDE THE HOUSING SCREW THE FIXATION BRACKET ADJUSTMENT
SCREW (2) WITH A DRILL (RECOMMENDED). FIXATION BRACKETS WILL OPEN AUTOMATICALLY WHILE SCREWING.
*FOR WALL WASHER OPTIC, ORIENT THE TRIM ARROW MARK TOWARDS THE WALL.
INS-615
JP - R2
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: February 28, 2020
RETAINING
CABLE
NEW CONSTRUCTION WITH PLASTER FRAME (NC) / REMODEL (RF) , NON-IC RATED
INTEGRAL DRIVER (120 / 277V)
DIMMING TRIAC/ELV - 0-10V
CONNECTION BOX
FLEXIBLE CONDUIT
B
C
FIXTURE CABLES
CONNECTION
BOX
QUICK
CONNECTOR
(INCLUDED)
LIVE
(black)
NEUTRAL
(white)
GROUND
(green)
DIMMING (LTE)
TRIAC/ELV (120V ONLY)
WIRING DIAGRAM
CONNECTION
BLOCK
FIXTURE CABLES
LIVE
(black)
NEUTRAL
(white)
DIM +
(purple)
DIM -
(gray)
DIMMING 0-10V
120-277V
GROUND
(green)
BX CONNECTOR
BX CABLE
QUICK
CONNECTOR
CEILING
CUT-OUT
PLASTER FRAME (NC)
LED DRIVER
HOUSING
CLICK
E
F
CONNECTION
BOX
G
BEAM
WALL
WALL WASHER
BEAM ORIENTATION
FIXATION
BRACKETS
FIXATION BRACKET
ADJUSTMENT SCREW
TRIM
ARROW MARK
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
DISCONNECT THE MAIN LINE BEFORE WIRING SECONDARY CONNECTORS.

BAFFLE ASSEMBLY
A- INSERT THE BAFFLE INTO THE TRIM AND TURN IT UNTIL IT LOCKS INTO PLACE.
*FOR WALL WASHER OPTIC, ALIGN BAFFLE DOT MARK WITH THE TRIM ARROW MARK AND TURN CLOCKWISE UNTIL IT LOCKS
IN PLACE.
V68
MODEL : V68 - NC/RF
INS-615
INSTALLATION SHEET PAGE: 2 OF 2
JP - R2
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: February 28, 2020
A
WALL WASHER BAFFLE
BAFFLE
TRIM ARROW MARK BAFFLE DOT MARK
DIMMERS LIST RECOMMANDATION
Manufacturer Model
Lutron Diva DVCL-153P
Lutron Skylark S-600P
SELV-300P-WHLutron Skylark
Lutron DVTV-WH
