SJA SJ-5286 User manual

Next Generation GPS SkyTraq 65CH Bluetooth GPS Bluetooth GPS Receiver
Page 1
Bluetooth GPS Receiver Quick Installation Guide
Thank you for purchasing Bluetooth GPS Receiver and we wish you have the best consumer product
experience ever.
Main features:
Adopt Skytraq Venus 6 with 65-Channel for fast acquisition and reacquisition
High sensitivity (to -160dBm)
Excellent performance - Cold/Hot start time: 29/1 sec. (average)
Smart power saving / Up to 14~16 hours usage
Support standard NMEA-0183
Compatible with Bluetooth Serial Port Profile (SPP) in 10m wirelessly
WAAS / EGNOS supported
A. Standard Package
Bluetooth GPS Receiver (1) + Lithium-Ion Rechargeable Battery (2) + Cigarette Adapter (3) + Optional Travel Charger (4) + Quick
Installation Guide. (* Travel Charger plug type might be adjusted according to corresponding countries.)
1. 2. 3. 4.
(Option)
B. Appearance
C. Charging your battery
For the first time using the Bluetooth GPS Receiver, please charge battery until it is fully
charged. Take the power cable and connect it to the power jack and recharge through
travel charger or car cigarette adaptor. This will begin to charge the battery. Charging
time is 3 hours typically.
- When the Power LED is blinking, battery power is low status. Please recharge.
- When the Power LED is steady on, the battery is under charging mode.
- When the Power LED is Off, the battery is fully charged.
Bluetooth Status LED
Power LED
GPS Status LED
Power Switch
Carrying Strap Hole
Power Jack

Next Generation GPS SkyTraq 65CH Bluetooth GPS Bluetooth GPS Receiver
Page 2
This wonderful Bluetooth GPS Receiver is Made in Taiwan
D. Start to use
D-1 Fully charge the battery when using at the first time
A fully charged battery can last for 14~16 hours continuously operation.
D-2 Activate the Bluetooth function in your PDA/Smart phone or PC
Before activating the Bluetooth function in your PDA/PC, please power on Bluetooth GPS Receiver for paring and check if your device is
equipped with Bluetooth function. If not, you may need to acquire an optional CF/SD Bluetooth card or Bluetooth dongle.
NOTE: The pairing procedure is required to execute in the first time only. And the pass code is “0000”if required.
D-3 Automatically create a shortcut in Bluetooth Manager window
After the pairing complete, the system will then find a quick connect device “BT GPS”in Bluetooth Manager. In further use, you just need to
click it to connect to this Bluetooth GPS Receiver.
D-4 Check the Serial Port in Bluetooth Setting
After complete pairing with the Receiver, please click “Serial Port” to confirm the assigned COM port. If you use PDA/PC to pair the GPS
Receiver, please check “Outbound COM port”.
D-5 Set correct Serial Port in your map software
Activate your navigation software and make sure to select the correct “Serial Port”.
NOTE: In the map software such as TomTom, you might need to change preference and set “Other Bluetooth GPS”or “Other
Cable NMEA GPS”according to PDA/phone model. In some case please consult map software company to vary the setting if you
have issue on positioning.
E. OTHERS
E-1 LED Indicators
LED Status
Flash
ON
OFF
1
Bluetooth (Blue)
Flashing for every 6 seconds (in pairing mode)
Bluetooth connected
GPS not powered
2
Power (Red)
Low Power (Flashing for every 1 second)
Recharging (Red)
Sufficient Power (None)
3
GPS (Green)
GPS position is fixed (Flashing for every 1 seconds)
GPS connected
GPS not connected
E-2 Manufacturing Setting
Protocol: NMEA 0183 - GGA, GSA, GSV, RMC
Baud Rate: 9,600 bps; Datum: WGS-84
E-3 GPS Features
Skytraq Venus 6 GPS Receiver with super high sensitivity at -160dBm
Frequency: L1, 1575.42 MHz; C/A Code: 1.023 MHz chip rate
Acquisition time: Hot start 1 sec. / Cold start 29 sec. (averaged)
E-4 Bluetooth Features
Bluetooth Version: V1.2 / SPP profile
Class 2 with 10 meters in open space
E-5 Overall Features
Built-in rechargeable 850mAh Lithium-Ion battery (up to 14~16 hrs after fully charged)
Size: 80.0 (L) X 44.0 (W) X 23.0 (H) mm / Weight: 65g (Battery excluded)
F. Trouble Shooting
Problems
Reasons
Methods
No position output but timer is
counting
Weak or no GPS signal can be received at the
place of Bluetooth GPS Receiver
Find an open space for your Bluetooth GPS
Receiver
Execute fail
Bluetooth function unstable
Re-Start PDA or PC or re-install software
Can not turn on the
COM port
Install Bluetooth GPS Receiver incompletely or the
COM port of the device is being used
Install Bluetooth GPS Receiver completely or
stop other device that is being used.
Can not find out Bluetooth
GPS Receiver
Poor connection
Re-Start PDA or PC and re-install software.
No Signal
No action for few minutes may cause the Pocket
PC enter power saving mode. It may close the
COM port at the same time.
Close the application and execute it again to
re-open the COM port.
No Signal
Weak or no GPS signal when using Bluetooth GPS
Receiver indoor
Go outdoors to improve the poor GPS signal.
