SK magic BID-S24D User manual

Electric Bidet Seat
BID-S24D
• Before using the product, please thoroughly read the safety precautions in this manual to ensure proper use.
• After reading this manual, keep it where users can readily access it.
• This product is intended for domestic use (USA) only. This product cannot be used in other countries with
different power supply and voltage requirements.
• The design and appearance of this product are subject to change without prior notice for quality improvement.
(REV.00)
Please scan for Customer Support Mobile Page
(rev00) BID-S24D_User_EN+MES.indb 1(rev00) BID-S24D_User_EN+MES.indb 1 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

Contents
2
English
Safety Information 3
Warning Instructions 7
Grounding Instructions 8
Product Features 9
Installation 10
How to Install 10
How to Remove 13
Product Description 14
Installation Parts 15
Control Panel 16
Before Use 17
How To Use 18
Rear Cleansing 18
Front Cleansing 20
Additional Features 22
Cleaning and Maintenance 24
How to Clean the Product 24
When NOT in Use for a Long Time (Drain the Water) 26
To Prevent Freezing in Winter 26
Mesh Part Cleaning 26
Troubleshooting 27
Technical Specifications 28
Warranty Information 30
(rev00) BID-S24D_User_EN+MES.indb 2(rev00) BID-S24D_User_EN+MES.indb 2 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

English
3
• The following precautions are for the safe and proper usage of this product. Be sure to
follow them to prevent unexpected risks and damage.
• If used incorrectly, safety-related precautions are classified according to the expected risk,
the magnitude of damage, and the level of risk.
WARNING
If these warnings are not observed, there is a possibility of serious injury or death.
CAUTION
If these cautions are not observed, there is a possibility of injury or product damage.
WARNING
Do not pull the power plug forcibly, and do not use a damaged power plug or cord,
or a loose power outlet.
• Failure to do so may cause an electric shock or fire.
• If the power plug is damaged, contact the place of purchase or SK magic Service Center.
Be careful water doesn’t get on the product when showering or cleaning.
(Waterproof rating IPX6)
• Moisture may cause an electric shock or fire.
• If foreign matter or water gets inside, unplug the power plug and contact SK magic Service
Center.
Only use outlets of 120V 10A or higher.
• Failure to do so may cause a malfunction or damage.
Do not plug or unplug the power plug with wet hands.
• Doing so may cause an electric shock.
When cleaning the exterior of the bidet, do not use odor eliminating sprays or the following
products: stove top cleaner, acid, sink cleaner, toilet cleaner, bathroom cleaner, benzene,
thinner, powdered cleanser, all stain removers.
• If any of the products listed above are used, the exterior of the bidet may be discolored or
damaged, and electrical problems may occur.
Do not block or put foreign matter in the warm air outlet, and be very careful water doesn’t
get in when cleaning.
• Failure to do so may cause fire or an electric shock.
• Never put your hand over the air opening when in operation.
Unplug the power plug if the product emits a strange odor, makes a strange noise, or if any
other abnormal conditions occur.
• Failure to do so may cause an electric shock or fire.
• Please contact SK magic Service Center.
Safety Information
(rev00) BID-S24D_User_EN+MES.indb 3(rev00) BID-S24D_User_EN+MES.indb 3 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

4
English
Detection (seat sensor) is turned off for the child function.
• Children should be supervised to ensure that they don't play with the product.
• The bidet is activated and water is sprayed. (The spray of water may make the floor or
interior slippery and cause injury)
If traveling, or if the product will not be in use for a long time, unplug the power plug and
drain all the water out of the tank.
• Otherwise, property damage may occur due to fire, etc.
Do not allow water droplets to appear or water to splash the product's surface.
Also, when using the product in a humid place such as a bathroom, install a fan to ensure
good ventilation.
• Failure to do so may cause an electric shock or fire.
The power plug must be unplugged when cleaning the product's interior and exterior, or
when removing the product.
• Failure to do so may cause an electric shock.
Periodically clean the power plug and check that it is inserted safely.
If water leaks from the water supply parts, turn off the Shutoff Valve, unplug the power plug,
and contact SK magic Service Center.
• Failure to do so may cause an electric shock or fire.
Those who are unable to use the product safely without supervision or instruction due to lack
of physical, sensory, or mental abilities, or due to lack of experience or knowledge (children
included), or those who have sensitive skin or a disease in the area to be cleaned (rear, etc.),
should adjust the water pressure, warm water temperature, and drying temperature to a
lower setting with help from someone around you.
• When set to a high temperature, beware that low-grade burns may occur because the high
temperature may not be felt.
• If the bidet water pressure is high, there may be a risk of anal bleeding, sphincter weakness,
etc.
-Low-grade burns refer to burns with no observable symptoms that occur when in contact with a
low heat for a long time.
• When sitting for a long time on the toilet seat, turn off the toilet seat heater and set the air
drying temperature to a low temperature.
Make sure to connect the product to the cold water pipe.
• Failure to do so may cause burns or product damage.
Do not use the product if it is broken, and never repair or disassemble the product.
• Failure to do so may cause an electric shock or fire.
• Immediately unplug the power plug, and turn off the Shutoff Valve.
• Do not operate the product if it has a damaged cord or plug, is not working properly, has
been dropped or submerged in water. Contact SK magic Service Center to get it inspected.
(rev00) BID-S24D_User_EN+MES.indb 4(rev00) BID-S24D_User_EN+MES.indb 4 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

English
5
Connect this product to a grounded outlet only.
• Failure to do so may cause a malfunction or electric shock.
• Check with a qualified electrician or serviceman for grounding and other electrical jobs.
Do not use multiple power plugs in one outlet.
• Doing so may cause heat or fire.
Keep lit cigarettes and other open flames away from this product and do not dispose of them
in the toilet.
• Failure to do so may cause fire or product damage.
Do not install or store the product where it can fall or into a tub or sink.
Eye damage may result from directly viewing the light produced by the lamp in this apparatus.
Always turn off lamp before opening protective cover.
CAUTION
Do not close or lean on the seat or seat cover with excessive force. Do not step on or place
heavy objects on the seat cover.
• Increased load may cause malfunction or damage.
This product is only intended for use in the bathroom. Do not use it for purposes (abnormal
purposes not intended for this product) other than those described in the User Manual.
• Do not install on moving vehicles such as RVs or boats.
• Do not use outdoors. Do not use in environments where aerosol (spray) products are in use
or in oxygen-poor environments.
• Doing so may cause fire, electric shock, malfunction, or damage.
Do not pull the Water Supply Hose or connecting hose with undue force. Do not allow the
Water Supply Hose to touch the power cord.
• Failure to do so may cause leakage, malfunction, or electric shock.
When not in use for a long time, run the rear or front function two or three times before using it.
• For the purpose of hygiene and cleanliness.
Do not place vases, cups, cosmetics, containers with medicines and water, or small metal
objects on top of the product.
• Doing so may result in fire or an electric shock.
Do not allow urine to come in contact with the nozzle or the warm air outlet.
• Failure to do so may cause odor or a malfunction.
Be careful of freezing.
• If frozen, the pipes or product may be damaged and water may leak.
• Do not install the product in an environment where freezing may occur.
(rev00) BID-S24D_User_EN+MES.indb 5(rev00) BID-S24D_User_EN+MES.indb 5 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

6
English
Use genuine SK magic products for installation parts and filters.
• Failure to do so may result in water leakage or product damage.
Only use tap water or underground water. Do not use industrial water, reclaimed water, or
seawater.
Do not directly connect the power to a ceiling light in the bathroom.
Do not press the buttons on the control panel unless sitting on the toilet seat.
This product is not intended to be used by those who lack physical, sensory, or mental abilities,
or by those who lack experience and knowledge (including children) about how to safely use
the device without supervision or instruction.
The new hose set supplied with this device must be used. It is not recommended to reuse a
worn hose set.
Do not touch the power plug during thunder and lightening. Refrain from using the product
when drowsy or tired.
Do not expose the product to direct sunlight.
(rev00) BID-S24D_User_EN+MES.indb 6(rev00) BID-S24D_User_EN+MES.indb 6 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

English
7
Warning Instructions
READ ALL INSTRUCTIONS BEFORE USING
DANGER - To reduce the risk of electrocution:
1. Do not use while bathing.
2. Do not place or store the product where it can fall or be pulled into a tub or sink.
3. Do not place in or drop into water or other liquid.
4. Do not reach for the product when it has fallen into water. Unplug it immediately.
Warning - To reduce the risk of burns, electrocution, fire, or injury to persons:
1. Close supervision is necessary when this product is used by, on, or near children or invalids.
2. Use this product only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, is not working properly, has
been dropped or damaged, or has been dropped in water. Return the product to a service
center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never block the air openings on the product or place it on a soft surface, such as a bed or
couch, where the air openings may be blocked. Keep the air openings free of lint, hair, and
other similar items.
6. Never use while sleepy or drowsy.
7. Never drop or insert any object into any opening or hose.
8. Do not use outdoors. Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
9. Connect this product to a properly grounded outlet only. See "Grounding Instructions”.
10. The tank should be filled with water only.
(rev00) BID-S24D_User_EN+MES.indb 7(rev00) BID-S24D_User_EN+MES.indb 7 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

8
English
Grounding Instructions
This product should be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electrical current. The plug must
be plugged into an outlet that is properly installed and grounded.
DANGER - Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to
either flat blade terminal.
Check with a qualified electrician or serviceman if the grounding wire instructions are not
completely understood, or if in doubt as to whether the product is properly grounded.
This product is factory equipped with a specific electric cord and plug to permit connection to
a proper electric circuit. Make sure that the product is connected to an outlet having the same
configuration as the plug. No adapter should be used with this product. Do not modify the
plug provided - if it will not fit in the outlet, have the proper outlet installed by a qualified
electrician. If the product must be reconnected for use on a different type of electric circuit,
the reconnection should be made by qualified service personnel.
If it is necessary to use an extension cord, use only a three wire extension cord that has a
three blade grounding plug, and a three-slot receptacle outlet that will accept the plug on the
product.
Replace or repair a damaged cord.
Save these instructions.
Grounding
Pin
(rev00) BID-S24D_User_EN+MES.indb 8(rev00) BID-S24D_User_EN+MES.indb 8 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

English
9
Natural air bubble cleansing
• A large amount of air has improved the gentleness and cleaning ability of the rear/front
cleansing functions.
Rear/front cleansing move function
• When using the rear/front cleansing functions, the nozzle moves forward and backward to
cleanse more thoroughly.
UV nozzle sterilization function
• Use the automatic nozzle cleaning function and UV nozzle sterilization to keep the nozzle
clean at all times.
NOTE
• Nozzle sterilization uses UV and sterilized water made with an electrolysis system.
Child function
• Children can use the bidet comfortably with its automatic bidet function for children.
User detection (Doesn’t apply to child function)
• There is no risk of malfunction because the sensor detects the user sitting on the toilet seat.
NOTE
• If the main unit is installed in the bathroom, without proper ventilation, water droplets
on the toilet seat may be falsely detected and cause activation.
Massage
• The cleansing water is sprayed as the cleansing nozzle moves back and forth.
Water tank automatic sterilization function
• During extended standby, water stored in the tank is periodically electrolyzed to prevent
bacterial growth.
NOTE
• The water tank sterilization cannot be performed by the user. It operates automatically
every 2 hours for about 30 seconds without using the front/rear functions.
• During sterilization, the indicator on the “Water tank sterilization” display will flash
3 times, and light will flow from the left to the right to show that sterilization is in
progress.
Toilet bowl sterilization function
• The sterilized water made with the electrolysis system is sprayed on the inside of the toilet
bowl to sterilize it.
Quiet and clean, warm air drying function
• After use, dry the wet areas with warm, clean air.
Product Features
(rev00) BID-S24D_User_EN+MES.indb 9(rev00) BID-S24D_User_EN+MES.indb 9 2021-06-07 �� 2:07:422021-06-07 �� 2:07:42

10
English
How to Install
Existed
seat nuts
• Remove existing toilet seat and seat cover.
-Loosen the under bolts and nuts.
-Store the separated seat, seat cover and
other parts.
-Wipe the surface on the toilet before install
a bidet seat.
NOTE
• Scan QR code for installation
video.
Shutoff Valve
Bowl tank
hose
• Turn off the Shutoff Valve on the wall.
• Push the bowl flush lever to empty the
toilet bowl tank.
• Disconnect existing Bowl tank hose under
toilet bowl tank.
-Be careful as water may flow from the
toilet bowl tank.
-Don’t disconnect hose from the wall valve.
T-Shaped
Connector
• Assemble a enclosed T-Shaped Connector
under the toilet bowl tank.
• Connect the Bowl tank hose to the
T-Shaped Connector.
-Be careful as water may flow from the
toilet bowl tank.
-If excessive force may damage the parts.
-Check the Rubber in the T-Shaped
Connector and Hoses when you assemble
it.
-Make sure the hose is not kinked.
Installation
(rev00) BID-S24D_User_EN+MES.indb 10(rev00) BID-S24D_User_EN+MES.indb 10 2021-06-07 �� 2:07:432021-06-07 �� 2:07:43

English
11
• Assemble a enclosed Water Supply
Hose with middle port of the T-Shaped
Connector.
-Check the Rubber in the Water Supply
Hose.
Mounting Bracket
Mounting Plate
• Assemble the Mounting Plate on the toilet.
• You can adjust position of Bidet seat with
the Mounting Brackets.
-Set the location of the product in
consideration of the toilet bowl size.
-Assemble carefully in the order parts.
(Mounting Bolts, Mounting Nuts, Rubber
Washers, Washers etc.)
Fixing Bolt
Rubber Washer
Mounting Washer
Mounting Nut
(rev00) BID-S24D_User_EN+MES.indb 11(rev00) BID-S24D_User_EN+MES.indb 11 2021-06-07 �� 2:07:432021-06-07 �� 2:07:43

12
English
Click !
• Set the Bidet seat into slot between
Mounting Plate and the toilet bowl.
• Push the Bidet seat from both sides in the
direction of the arrow until hearing ‘Click‘
sound.
• Fasten the Mounting Nuts after selecting
position of the Bidet seat.
-If the position of the Bidet seat is not
correct, adjust the position of the Mounting
Plate and Mounting Bracket.
-Make sure the Bidet seat doesn’t move after
assembly is completed.
• Connect the Water Supply Hose with Bidet
seat.
• Turn on the Shutoff Valve on the wall.
(rev00) BID-S24D_User_EN+MES.indb 12(rev00) BID-S24D_User_EN+MES.indb 12 2021-06-07 �� 2:07:432021-06-07 �� 2:07:43

English
13
• Connect the Power plug of Bidet seat.
-After 1~2 minutes, water fills and flows out
of the middle hole of the Bidet seat (Nozzle
hole).
-Don’t connect the power plug before
supplying water.
CAUTION
• Don’t allow water to come in contact with the Bidet seat.
• Make sure to use a grounded outlet.
• After installation, check if water is leaking from each connecting parts (Water Supply Hose,
Shutoff Valve etc.).
• When installing in a place where the temperature of the bathroom in winter goes below
freezing, insulate the water supply pipe.
• Never connect the power if the product is not installed.
How to Remove
Button
To remove the product from the Toilet bowl,
hold the both sides of the product while
pressing the button at the bottom right of the
product and pull it forward to lift it.
(rev00) BID-S24D_User_EN+MES.indb 13(rev00) BID-S24D_User_EN+MES.indb 13 2021-06-07 �� 2:07:432021-06-07 �� 2:07:43

14
English
01
03
02
04
05
07
06
12
10
11
08
09
Sterilizing status indicator
Product Description
Bottom Side
(rev00) BID-S24D_User_EN+MES.indb 14(rev00) BID-S24D_User_EN+MES.indb 14 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

English
15
01 Seat Cover 02
Sterilization Indicator
(Water Tank / Nozzle /
Toilet Bowl)
03 Control Panel
04 Seat Sensor 05 Heated Seat 06 Power Plug
07 Protective Cover 08 Warm Air Outlet 09 Nozzle Outlet
10 Install Slot 11 Toilet Bowl Sterilization
Nozzle 12 Inlet Port (Mesh Filter)
Installation Parts
Mounting Bolt (2) Mounting Bracket (2) Mounting Nut (2) Rubber Washer (2)
T-Shaped Connector,
Washer
Water Supply Hose Mounting Plate Mounting Washer (2)
(rev00) BID-S24D_User_EN+MES.indb 15(rev00) BID-S24D_User_EN+MES.indb 15 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

16
English
Control Panel
01
07 08 09 10 11 12 13
02 03 04 05 06
Display / Button Description
01 STOP
• Stop the operation. (Wash, Massage etc.)
02 REAR/MOVE
• For the rear wash.
• Press again, nozzle moves back and forth.
03 FRONT/MOVE
• For the front wash.
• Press again, nozzle moves back and forth.
04 CHILD/MASSAGE
(3 SEC)
• CHILD: Automatically operate functions suitable for children.
(Work without seat sensor)
• MASSAGE: Come out water and automatically move nozzle.
(Hold down the button for 3 seconds)
05 NOZZLE UV CLEAN
• Automatically nozzle clean/sterilize with UV and sterilized water.
06 TOILET STERILIZER
• Spray the sterilized water to bowl.
07 NOZZLE POSITION
• Adjust nozzle position during wash. (Forward or Backward)
08 PRESSURE
• Adjust water pressure to 3 steps. (Low, Mid, High)
09 WATER TEMP.
• Adjust water temperature to 4 steps. (Off, Low, Mid, High)
10 SEAT TEMP.
• Adjust seat temperature to 4 steps. (Off, Low, Mid, High)
11 DRY
• Come out warm wind.
• Adjust dry temperature to 3 steps. (Low, Mid, High)
12 ECO
• When not in use, Seat/Water temperature is forcibly set low to reduce
electricity usage.
13 POWER
• Turn On or Off the product.
(rev00) BID-S24D_User_EN+MES.indb 16(rev00) BID-S24D_User_EN+MES.indb 16 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

English
17
120 V
1. After checking the voltage, plug the power plug into a 120V
outlet.
• The lamps on the control panel light up.
• Use an outlet attached to a ground terminal.
2. Please open the seat cover and sit down.
NOTE
• Using the seat sensor. It can be operated only when someone is sitting
to prevent malfunction. (Doesn’t apply to child function)
3. Set the water temperature, seat temperature, water pressure,
and drying temperature on the control panel.
• Water temperature - Press the [WATER TEMP.] button to set the
water temperature.
- Each time the [WATER TEMP.] button is pressed, it selects in
the order of Low (green), Medium (orange), High (red), and
OFF.
- It is set to OFF when first connected to power.
• Seat temperature - Press the [SEAT TEMP.] button to set the seat
temperature.
- After the initial setup, it takes 4 to 5 minutes to warm up.
- Each time the [SEAT TEMP.] button is pressed, it selects in the
order of Low (green), Medium (orange), High (red), and OFF.
- The seat is set to OFF when first connected to power.
• Water pressure - Press the [PRESSURE] button set the strength.
- Each time the [PRESSURE] button is pressed, it changes in the
order of Low (green), Medium (orange), High (red).
- The water pressure is set to Medium (level 2) when first
connected to power.
• Drying temperature - Press the [DRY] button set the temperature.
- Press the [DRY] button to operate it.
- While drying, press [DRY] button and it will change in the
order of Low (green), Medium (orange), High (red).
- The dryer is set to Medium (level 2) during the initial
operation.
Before Use
(rev00) BID-S24D_User_EN+MES.indb 17(rev00) BID-S24D_User_EN+MES.indb 17 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

18
English
Rear Cleansing
1. Rear Cleansing
While sitting on the toilet seat, press the
[REAR/MOVE] button.
• Cleansing water runs for 1 minute.
NOTE
• Press the
[ NOZZLE ] button to adjust the
nozzle position.
• Press the [PRESSURE] button to adjust the
strength.
• When using the cleansing functions, water-
saving and cleansing effects are maximized
through injection of natural bubbles.
• It is recommended not to exceed 10
time cleansing consecutively to prevent
malfunction.
2. Move
Press the [REAR/MOVE] button during
cleansing operation.
• The cleansing water is sprayed as the
nozzle moves back and forth.
• It continues to run while the cleansing
function operates.
3. Drying
Press the [DRY] button.
• To dry more quickly, lightly wipe off any
moisture before using drying.
• Dry runs for 3 minutes.
NOTE
• While drying, press the [DRY] button to set
the air temperature.
How To Use
(rev00) BID-S24D_User_EN+MES.indb 18(rev00) BID-S24D_User_EN+MES.indb 18 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

English
19
4. Stop
Press the [STOP] button.
• Stop the all function.
• The UV nozzle sterilization function
performs automatically after use.
(rev00) BID-S24D_User_EN+MES.indb 19(rev00) BID-S24D_User_EN+MES.indb 19 2021-06-07 �� 2:07:442021-06-07 �� 2:07:44

20
English
Front Cleansing
1. Front Cleansing
While sitting on the toilet seat, press the
[FRONT/MOVE] button.
• Cleansing water sprays for 1 minute.
NOTE
• Press the [NOZZLE] button to adjust the
nozzle position.
• Press the [PRESSURE] button to adjust the
strength.
• When using the cleansing functions, water-
saving and cleansing effects are maximized
through injection of natural bubbles.
• It is recommended not to exceed 10
time cleansing consecutively to prevent
malfunction.
2. Move
Press the [FRONT/MOVE] button during
cleansing operation.
• The cleansing water is sprayed as the
nozzle moves back and forth.
• It continues to run while the cleansing
function operates.
3. Drying
Press the [DRY] button.
• To dry more quickly, lightly wipe off
any moisture before using the dryer.
• Dry runs for 3 minutes.
NOTE
• While drying, press the [DRY] button to set
the air temperature.
(rev00) BID-S24D_User_EN+MES.indb 20(rev00) BID-S24D_User_EN+MES.indb 20 2021-06-07 �� 2:07:452021-06-07 �� 2:07:45
