SKC AirChek 220-3100 User manual

skcinc.com PDP0008 Rev 0 Page 1
AirChek Essential+ Sample Pump
Cat. No. 220-3100
Operating Instructions
Figure 1. AirChek®Essential+ Overview
Table of Contents
Introduction..............................................................................................................................................3
Checking Pump Kit/Contents ....................................................................................................................3
Getting Started.........................................................................................................................................4
Charging the Battery Pack.........................................................................................................................4
Notes and Cautions...................................................................................................................................5
Turning Pump Power On/Off.....................................................................................................................6
Interpreting the Display..............................................................................................................................6
Determining Battery Charge Status...........................................................................................................7
Using the Touch Screen............................................................................................................................7
Navigating Menus and Screens ................................................................................................................7
Determining Pump Status..........................................................................................................................8
Main Menu Overview.................................................................................................................................9
Operation................................................................................................................................................10
Setting/Calibrating Pump Flow Rate .......................................................................................................10
Setting/Calibrating Flow Rate from 1 to 5 L/min......................................................................................11
Protective screen cover
On/off button
Belt clip in back
(not shown)
Charging
contacts
Battery pack
Front and side view
Top view
Inlet
housing/filter
Touch screen/display
LED Indicator
LED Indicator

skcinc.com PDP0008 Rev 0 Page 2
Setting/Calibrating Flow Rate from 5 to 500 ml/min................................................................................12
Sampling..................................................................................................................................................15
Fault Mode and Display...........................................................................................................................18
Maintenance...........................................................................................................................................19
Replacing the Battery Pack.....................................................................................................................19
Replacing the Screen Cover ...................................................................................................................19
Replacing the Belt Clip............................................................................................................................20
Replacing the Inlet Housing and/or Inlet Filter ........................................................................................20
Troubleshooting ....................................................................................................................................20
Pump Service ..........................................................................................................................................20
Accessories/Replacement Parts..........................................................................................................21
Appendix: Performance Profile............................................................................................................22

skcinc.com PDP0008 Rev 0 Page 3
INTRODUCTION
Checking Pump Kit/Contents
Use the following table to verify that you received all items associated with the Cat. No. ordered. If you
are missing items, contact SKC at 800-752-8472 (U.S. only) or 724-971-9701.
If you ordered Cat. No.
Your package should contain
220-3100
Pump only with Li-Ion battery and screwdriver set, requires Standard Charging
Cradle and power supply; see kits or accessories below
220-3100-S
Starter Kit includes pump as described above, Standard Charging Cradle, power
supply with cord, 3 feet (0.9 meter) of Tygon tubing, and collar clip with cable tie
100-240 V
220-3100-K
Single High Flow Kit includes pump as described above, Standard Charging Cradle,
power supply with cord, and filter cassette holder, in a soft-sided nylon carry case
100-240 V
220-3100-KD
Single High/Low Flow Kit includes pump as described above, Standard Charging
Cradle, power supply with cord, filter cassette holder, All-in-One adjustable tube
holder, and Type A protective tube cover, in a soft-sided nylon carry case 100-240 V
220-3100-K3D
3-pack High/Low Flow Pump Kit includes 3 pumps as described above and 3 each:
Standard Charging Cradles and power supply with cord, filter cassette holders, All-in-
One adjustable tube holders, and Type A protective tube covers, in a hard-sided case
100-240 V
220-3100-K5
5-pack High Flow Pump Kit includes 5 pumps as described above and 5 each:
Standard Charging Cradles and power supply with cord, and filter cassette holders, in
a hard-sided case 100-240 V
220-3100-K5D
5-pack High/Low Flow Pump Kit includes 5 pumps as described above and 5 each:
Standard Charging Cradles and power supply with cord, filter cassette holders, All-in-
One adjustable tube holders, and Type A protective tube covers, in a hard-sided case
100-240 V

skcinc.com PDP0008 Rev 0 Page 4
GETTING STARTED
Charging the Battery Pack
Set up the charging train (Figure 2) and completely charge the battery pack(s) before operating the pump.
1. Prepare charging cradle(s).
a. Single cradle: Insert connector on Single Cradle Power Supply Cat. No. 220-600 into
power port on side of Standard Charging Cradle Cat. No. 220-800. Insert wall cube into a
100 to 240-volt wall outlet.
b. Up to five cradles: Press together the connector on the side of the first cradle with the
connector on the side of the next cradle. Repeat the connection to chain up to five
Standard Charging Cradles. Insert the connector of Multi Cradle Power Supply Cat.
No. 220-700 into the power port on the side of the last cradle in the chain. Insert the wall
cube into a 100 to 240-volt wall outlet.
2. Align the contacts on the bottom edge of the pump with the contacts inside the cradle and place
the pump in the cradle. Repeat for each additional pump/cradle.
3. Charge the battery completely (approximately 3 hours). The left LED on the cradle will indicate
charging status. See Reading Charge Status on Cradle LED and LED Activity Description.
Figure 2. Charging Train, Single and Multiple Cradles
100-240 V
Wall outlet
Single cradle power supply
Power port
Charging contacts
Charging cradle
Charge status
Pump
Multi cradle power supply

skcinc.com PDP0008 Rev 0 Page 5
Reading Charge Status on Cradle LED
LED Action
Charge Status
Red
steady
Charge in progress
Red
3 sec
Green
1 sec
(Pattern
repeats)
Approximately 75% charged
Green
steady
Charge completed/trickle charge
Notes and Cautions
•Power off pump before removing battery.
•Use only the SKC charging cradle Cat. No. 220-800 or 220-900 for pump.
•Failure to follow warnings, notes, and cautions may cause injuries and voids any warranty.
•WARNING: Substitution of components may impair intrinsic safety. AVERTISSEMENT: La substitution de
composants peut compromettre la Sécurité Intrinsèque.
•CAUTION: The battery used in this device may present a risk of fire or explosion when heated above 212 F
(100 C) or incinerated. Replace battery with SKC Battery Pack model P75718 only. Use of another battery may
present a risk of fire or explosion.
•WARNING: To prevent ignition of a hazardous atmosphere, batteries must only be changed [removed and
replaced] in an area known to be non-hazardous. AVERTISSEMENT: Afin de prévenir l’inflammation
d’atmosphères dangereuses, ne changer les batteries que dans des emplacements désignés non dangereux.
•Maximum charge input voltage is Um= 12 V
•CAUTION: Risk of Fire and Burns. Do Not Disassemble, heat above 212 F (100 C), or incinerate. Keep battery
out of reach of children and in original package until ready to use. Dispose of used batteries promptly according
to [all state and] local recycling or waste regulations.
•User may replace external components such as the inlet filter, battery, protective screen cover, and/or belt clip.
Service must be done by SKC to maintain performance and IS rating. Warranty is void if pumping compartment
is opened by user.
For more information on SKC pump lithium-ion (Li-Ion) battery packs, visit
www.skcinc.com/knowledgecenter.

skcinc.com PDP0008 Rev 0 Page 6
Turning Pump Power On/Off
Turn on: Press the recessed power on/off button on the side of the pump (Figure 1). The screen will light
up and the Sample menu will be displayed (see below).
Turn off: Press the recessed power on/off button on the side of the pump. Note: To conserve battery
power, a non-sampling pump will power off automatically after 5 minutes of inactivity.
Note: The power on/off button also locks/dims and unlocks/undims the touch screen during sampling.
(See Options on Pump Screen During Sampling on page 17.)
Interpreting the Display
The battery status icon (charge remaining) is displayed at the top of every screen.
Elapsed run time is displayed during sampling. The lock icon indicates that the screen is locked to
prevent accidental tap errors or tampering (see Auto Lock) during sampling. When the power button is
pressed to unlock or AutoLock is set to Off, the screen on the right is displayed.
Display during sampling when Auto Lock is off
Elapsed
run time
Battery status
indicator
Locked
indicator
Elapsed
run time
Display during sampling when Auto Lock is on

skcinc.com PDP0008 Rev 0 Page 7
Determining Battery Charge Status
The battery status icon at the top right of the pump display screen has four bars that decrease in number
as battery charge is depleted. Use the table below to interpret the battery status.
Icon Displayed
Battery Charge Remaining
Four bars
Full battery charge, approximately 75 to 100%
Three bars
Approximately 50 to 75%
Two bars
Approximately 25 to 50%
One bar
Approximately 5 to 25%
No bars
Low battery fault is imminent. Pump will stop and power off eventually. “FAULT!”
will appear on the screen once the pump is restarted.
Using the Touch Screen
Use fingertip to gently touch screen buttons in the active zones indicated below.
Navigating Menus and Screens
AirChek Essential+ operates through a series of menus and screens. When the pump is powered on, the
Sample menu appears (see below), from which you can set or calibrate flow rate and/or sample
immediately. The navigation touch panel below the screen contains buttons used to move among screens
or increase/decrease values as described in the table below. Also see Main Menu Options and Screen
Touch Buttons.
Sample
menu
Navigation touch panel
(Back, up, down, and
Main menu buttons)
Screen button two
Screen button four
Screen button three
Back
Main menu
Down
Up
Screen button one

skcinc.com PDP0008 Rev 0 Page 8
Navigation Buttons
Back
Returns to previous
screen
Up Arrow
Increases value in
0.01-L/min increments
in Set/Cal
Touch to adjust flow
setting; touch and hold
to speed increment of
flow setting.
Down Arrow
Decreases value in
0.01-L/min increments in
Set/Cal
Touch to adjust flow
setting; touch and hold to
speed decrement of flow
setting.
Main menu
Opens Main menu with
Auto Lock, Info, and
Sample options.
Screen Touch Buttons
Button
General Function
Saves flow rate after calibration, resets accumulated sample
run time, and returns to Main menu or Sample menu
Decreases or increases flow in 0.5-L/min increments in
Set/Cal
Starts sampling
Pauses sampling. Elapsed time accumulation pauses. When
Start is touched, sampling will resume and time will continue
to accumulate.
Stops sampling
Determining Pump Status
The status LEDs that bracket the screen display (Figure 1) indicate pump status:
Green, flashing = Running/sampling
Red, flashing = Flow or low battery fault
Note: Status LEDs will flash red/green to indicate that the pump is out of flow tolerance just before
entering flow fault mode and during each auto-restart attempt while in flow fault mode.

skcinc.com PDP0008 Rev 0 Page 9
Main Menu Overview
Main menu options Info, Auto Lock, and Sample are described below.
Info displays pump firmware version and name.
Auto Lock prevents accidental tap errors during sample runs. When activated, Auto Lock locks the pump
display as soon as the pump starts sampling. To unlock and reactivate the screen, press the power on/off
button on the side of the pump during sampling.
When Auto Lock is off, the screen will remain active. To manually lock the screen (make it inactive) at any
time during sampling, press the power on/off button on the side of the pump. The pump is shipped with
Auto Lock set to Off. Turn on Auto Lock as follows:
In the Auto Lock menu, touch On to activate the feature (or Off to deactivate it). When Auto Lock is
activated, a lock indicator with a message to press the power button to unlock will appear on the screen
during sampling (below right).
Sample displays the options to set/calibrate flow rate and start sampling.

skcinc.com PDP0008 Rev 0 Page 10
OPERATION
Setting/Calibrating Pump Flow Rate
Flow rate is set and calibrated through the Sample menu as described below. Also see the procedures for
setting/calibrating flow at 1 to 5 L/min and 5 to 500 ml/min, respectively.
1. In Sample menu, touch Set/Cal.
2. In Set/Cal screen, touch left and right buttons to decrease or increase flow rate in approximately
0.5-L/min increments on the 1 to 5-liter scale or use up and down arrows to adjust flow in
approximately 0.01-L/min increments. Actual flow rate is displayed on a calibrator only.
3. Touch check mark in Set/Cal screen to save desired flow rate and return to Sample menu.

skcinc.com PDP0008 Rev 0 Page 11
Setting/Calibrating Flow Rate from 1 to 5 L/min
•Allow pump to equilibrate after moving it from one temperature extreme to another.
•Charge pump battery completely before calibration and sampling.
•To achieve the best results, run the pump for 10 to 15 minutes before calibration.
1. Turn on the pump.
2. Prepare the calibrator. See calibrator instructions.
3. Set up a calibration train with representative sample medium in line (Figure 3).
4. Set/calibrate flow rate on pump.
a. In Sample menu, touch Set/Cal.
b. In Set/Cal screen, touch left and right buttons to decrease or increase flow rate in
0.5-L/min increments shown on the scale or use up and down arrows on navigation panel
to set values between increments. Actual flow rate is displayed on calibrator only.
Representative sample medium
Suction port
Tubing
Tubing
On/off button
Pump inlet
chek-mate calibrator
Pump
Figure 3. Calibration Train (1 to 5 L/min)

skcinc.com PDP0008 Rev 0 Page 12
c. Touch check mark in Set/Cal screen to save desired flow rate and return to Sample
menu.
5. Disconnect the pump from the representative sample medium and calibrator. Go to Sampling.
Setting/Calibrating Flow Rate from 5 to 500 ml/min
•Allow pump to equilibrate after moving it from one temperature extreme to another.
•Charge pump battery completely before calibration and sampling.
•Single-tube sampling requires the All-in-One adjustable tube holder; see the All-in-One operating
instructions for details on operation.
•Multiple-tube sampling can be done using a Constant Pressure Controller (CPC) (Figure 5) and a
Dual, Tri, or Quad Adjustable Low Flow Tube Holder accessory. See CPC and Adjustable Low
Flow Tube Holder operating instructions for details on operation.
•Calibrate/verify pump flow rate before and after each sampling operation using the tube holder
and pump to be used for sampling.
•To achieve the best results, run the pump for 10 to 15 minutes before calibration.
Prepare Sorbent Tube(s)
1. Determine number and type of sorbent tubes needed for pre-sample calibration and sampling.
2. Break tips off representative sorbent tubes for pre-sample calibration.
3. If performing multiple-tube sampling, label tubes.
Prepare Pump
1. Turn on the pump.
2. Prepare the calibrator per calibrator instructions.
3. Using flexible tubing, connect the calibrator outlet (suction port) to the pump inlet.
4. Set pump flow rate to the following as appropriate (see Setting/Calibrating Pump Flow Rate):
•Single-tube sampling—1.5 L/min.
•Multiple-tube sampling—the sum of all flows +15%. Note: Do not exceed 500 ml/min
flow rate per tube for multiple-tube sampling
5. Disconnect tubing from the pump inlet.
Prepare All-in-One Adjustable Tube Holder (single-tube sampling)
1. On the tube holder, insert an opened representative sorbent tube (arrow on tube pointing toward
the pump) into the rubber sleeve on the port. See Figure 4.
2. Using a small flat-head screwdriver, turn counterclockwise the
brass flow adjust screw directly beneath the port.

skcinc.com PDP0008 Rev 0 Page 13
Tubing
Flow adjust screw
Suction port
Prepare Dual, Tri, or Quad Adjustable Low Flow Tube Holder (multiple-tube sampling)
1. On the tube holder, insert an opened representative sorbent tube
(arrow on tube pointing toward the pump) into the rubber sleeve on
the port. Repeat for the desired number of tube samples. See
Figure 5. Note: Place an unopened (inactive) tube in any unused port
to “seal” it.
2. Label ports on the adjustable tube holder to match labels on tubes.
3. Using a small flat-head screwdriver, turn counterclockwise the brass
flow adjust screw directly beneath the port holding the first active tube to be calibrated.
Set Up Calibration Train
Connect the calibrator to the single sorbent tube or the first of multiple sorbent tubes as shown in
Figures 4 and 5, respectively.
Figure 4. Calibration Train (5 to 500 ml/min) for Single Tube
chek-mate Calibrator
Pump
All-in-One
Tubing
Sorbent tube
Pump inlet
Suction port
Tubing
Flow adjust screw

skcinc.com PDP0008 Rev 0 Page 14
Calibrate Flow Rate with All-in-One (single tube, see Figure 4)
1. In the Sample menu, touch the Start button to run the pump. Note: It is good practice
to allow the pump to run for 10 to 15 minutes before calibrating flow rate.
2. Using a small flat-head screwdriver, turn the flow adjust screw on the port clockwise to
decrease flow or counterclockwise to increase flow until the method-specified flow rate is
indicated on the calibrator.
3. Once flow is calibrated for the tube, it is recommended practice to recheck the flow rate before
removing the tube. Any adjustment should be minimal.
4. Stop the pump and return to the Sample menu.
5. Disconnect the pump from the representative sample tube and calibrator. Replace representative
sorbent tube with a newly opened unexposed method-specified sorbent tube to complete the
sampling train. Proceed to Sampling.
Calibrate Flow Rate with Dual, Tri, or Quad Adjustable Low Flow Tube Holder (see Figure 5)
See appropriate adjustable flow holder instructions.
1. In the Sample menu, touch the Start button to run the pump. Note: It is good practice
to allow the pump to run for 10 to 15 minutes before calibrating flow rate.
2. Using a small flat-head screwdriver, turn the brass flow adjust screw on the first active port
clockwise to decrease flow or counterclockwise to increase flow until method-specified flow
rate is indicated on the calibrator.
3. Remove calibrator tubing from the current tube and install it on the next active tube. Use small
flat-head screwdriver to turn counterclockwise the brass flow adjust screw directly beneath the
port holding the tube to be calibrated and repeat Step 2.
4. Repeat Steps 2 and 3 for each remaining active tube.
5. Stop the pump and return to the Sample menu.
chek-mate Calibrator
Sorbent
tube
Dual adjustable low flow holder
Flow adjust screw
Tubing
Tubing
Suction port
CPC
Pump inlet
Figure 5. Calibration Train (5 to 500 ml/min) for Multiple Tubes
Pump

skcinc.com PDP0008 Rev 0 Page 15
6. Disconnect the pump from the representative sample tube and calibrator. Replace representative
sorbent tubes with newly opened unexposed method-specified sorbent tubes to complete the
sampling train. Proceed to Sampling.
Sampling
•Allow pump to equilibrate after moving it from one temperature extreme to another.
•Charge pump battery completely before sampling.
•Use of an unapproved battery and/or charging cable could damage the pump and will void any
warranty.
•Use of any device (including charging cradle) or battery pack other than Cat. No. P75718 to
power the pump voids intrinsic safety certifications and any warranty.
•Pump can be operated from cradle.
•If using sample tubes as media, calibrate/verify pump flow rate before and after each sampling
operation using the tube holder and pump used for sampling.
1. After setting/calibrating flow rate, ensure that calibrator and tubing have been removed and
representative method-specified sample medium used for calibration has been replaced with
newly opened unexposed method-specified sample medium to complete the sampling train. See
Figure 6.
Figure 6. High Flow Sample Train
Sample medium
Tubing
Pump inlet

skcinc.com PDP0008 Rev 0 Page 16
2. In Sample menu, touch the Start button.
3. When the required sampling period is complete, touch the Stop button to stop sampling. Note: To
pause sampling, touch the Pause button (see Options on Pump Screen During Sampling).
4. Total sample run time will be displayed. Touch the check mark to reset accumulated run time.

skcinc.com PDP0008 Rev 0 Page 17
Options on Pump Screen During Sampling
Stop sampling. Touch the Stop button to stop sampling.
Touch check mark to reset accumulated run time display.
Pause sampling. Touch the Pause button to pause sampling
and retain accumulated run time display.
Touch the Start button to resume sampling and run time
accumulation.
Unlock touch screen (AutoLock is on). Press the power
on/off button on the side of the pump (see Figure 1). This will
unlock/activate and undim the touch screen.
Note: When Auto Lock is off,press the power button to lock
touch screen while sampling and this screen will be displayed.
Fault. A fault may occur when there is restriction in airflow
(e.g., kinked tubing) that remains uncorrected and the pump
can no longer compensate flow, or when battery voltage is too
low. See Fault Mode and Display for details on pump
operation during flow fault.
FAULT!

skcinc.com PDP0008 Rev 0 Page 18
Fault Mode and Display
During a sample run, overloaded sampled media or kinked tubing can restrict airflow and cause back
pressure to build to a point at which the pump can no longer compensate flow within ± 5%. This also may
happen when battery voltage is too low to maintain set flow. If this condition is sustained for 3 to
10 seconds, the pump will go into fault mode as follows:
1. The pump stops sampling and status LEDs on the pump flash red. Elapsed time stops and
“FAULT!” is displayed on the screen.
2. After 20 seconds in fault, the pump will attempt to restart up to 5 times.
a. If full airflow is restored during the restart attempts, the pump will continue the sample
run.
b. If full airflow is not restored during 5 faults and four restart attempts within 5 minutes, the
pump will end the sample run. The LEDs will flash red with decreasing frequency.
3. The fault screen below will be displayed. Touch the check mark to clear the flow fault and return
to the Sample menu.
FAULT!

skcinc.com PDP0008 Rev 0 Page 19
MAINTENANCE
Replacing the Battery Pack
Ensure that pump is turned off before removing the battery pack and that no tubing or media
are attached to the pump.
1. Turn the pump off by pressing the on/off button.
2. Remove the existing battery pack.
a. Use a 2.5-mm hex driver (Allen wrench) to loosen two screws on the bottom of the
battery pack housing.
b. Pull the battery pack housing away from the pump case.
c. If replacing the battery pack with a new Cat. No. P75718, dispose of the used battery
promptly.
Do not disassemble the battery pack. Do not dispose of in fire. Dispose of used batteries
promptly according to all state and local recycling of waste regulations.
3. Install a new battery pack or reinstall the existing battery pack.
a. Align the battery pack with the bottom of the pump case. Note: The connector on top of
the battery pack should align with the protruding power control board contacts on the
bottom of the pump case.
b. Press the two parts together until snug. Note: When the battery pack is attached, the
pump screen will display a 20-second countdown as the zero setting of the flow sensor is
performed.
c. Use a 2.5-mm hex driver (Allen wrench) to tighten two screws on the bottom of the
battery pack housing. Tighten the screws in an alternating fashion.
d. Charge the new battery pack completely before use; if reinstalling the existing battery
pack, ensure that it is charged to at least 25% (battery status icon upon startup shows
two bars). See Charging the Battery Pack.
Replacing the Screen Cover
1. Remove the two screws from the top of the screen cover mounting block.
2. Lift off the screen cover and mounting block.
3. Align and press-fit the mounting block onto the new screen cover posts (i.e., with the underside of
the mounting block facing up and its straight edge facing away from the cover). Rotate the
mounting block away from the screen cover until it is stopped by the inside edge of the screen
cover.
4. Align the screen cover/mounting block with the holes in the top of the belt clip/top pump case.
5. Gently insert the two screws through the mounting block into the belt clip. Tighten until snug.
6. Ensure that the screen cover closes properly.

skcinc.com PDP0008 Rev 0 Page 20
Replacing the Belt Clip
1. Remove the screen cover.
a. Remove the two screws from the top of the screen mounting block.
b. Lift off the screen cover and mounting block. Note: Do not remove the two lower hex nuts
from the main case.
2. Remove the screw from the bottom of the belt clip and pull the screw through the opening in the
clip.
3. Lift the belt clip away from the pump. Ensure that the hex nut in the top of the case does not fall
out.
4. Push the new belt clip into place until it fits snugly.
5. Gently insert the belt clip screw through the opening in the belt clip and into the pump case.
Tighten the screw until engaged. Do not tighten completely.
6. Replace the screen cover.
a. Place the screen cover and mounting block so that the two holes are aligned with the
holes in the top of the belt clip. Insert the two screws into the mounting block and tighten
until snug.
b. Ensure that the screen cover closes properly.
7. Tighten the screw under the belt clip until snug.
Replacing the Inlet Housing and/or Inlet Filter
1. Remove the four screws from the inlet housing.
1. Pull the inlet housing away from the pump.
2. Remove the O-ring and filter.
3. Insert the new or existing filter and O-ring into the inlet recess. Ensure that the O-ring is fully flat.
4. Align the new or existing inlet housing with the inlet recess.
5. Insert the four screws into the inlet housing. Tighten the screws only until the gap between the
inlet housing and pump is closed.
TROUBLESHOOTING
Issue
Possible Solutions
The pump is not responding to touch or the pump
screen displays uncommon characters.
Remove and reinstall the battery (see Replacing
the Battery Pack). If these problems persist,
contact SKC.
Pump Service
Pumps under warranty should be sent to SKC Inc. for servicing. See Limited Warranty and Return Policy.
User may replace external components such as the inlet filter, battery, screen protector,
and/or belt clip. Service must be performed by SKC to maintain performance and intrinsic
safety rating. Warranty is void if pumping compartment is opened by user.
