SKF FS-1 User manual

EN
for measuring relative humidity in machine tool spindles
FS-1 Humidity Sensor
Version 03
Component Lifecycle Manual (CLM)

2
Masthead
Masthead
Warranty
The instructions do not contain any infor-
mation on the warranty. This can be found
in the General Conditions of Sales, which
are available at:
www.skf.com/lubrication.
Copyright / Integration of instructions
© SKF Lubrication Systems Germany AG.
All rights reserved.
These instructions are protected by copy-
right.
The use of the contents for the purpose of
integration into the documentation of the
machine manufacturer in whose product it
will be integrated is expressly allowed. This
also includes making copies solely for inter-
nal training purposes.
Any other usage of any kind without writ-
ten permission of the copyright holder is
prohibited and constitutes a breach of
copyright.
Manufacturer and service address
If you have questions, please contact:
SKF Lubrication Systems Germany GmbH
Berlin Plant
Motzener Strasse 35/37
12277 Berlin
Germany
Tel. [phone]
Fax [phone]
www.skf.com/lubrication
Hockenheim Plant
2. Industriestrasse 4
68766 Hockenheim
Germany
Tel. [phone]
Fax [phone]
www.skf.com/lubrication
EN

3
Table of contents
Masthead 2
Warranty 2
Manufacturer and service address 2
Table of contents 3
Explanation of symbols and signs 4
1. Safety instructions 6
1.1 General safety instructions 6
1.2 General behavior when handling
the product 6
1.3 Qualified technical personnel 7
1.4 Operation 7
1.5 Assembly / maintenance / malfunction /
decommissioning / disposal 7
1.6 Intended use 8
1.7 Foreseeable misuse 8
1.8 Disclaimer of liability 8
1.9 Residual risks 8
2. Functional description 9
2.1 Installation in a machine tool spindle 9
3. Technical data 10
3.1 General technical data 10
4. Delivery, returns, and storage 12
4.1 Checking the delivery 12
4.2 Returns 12
4.3 Storage 12
4.4 Note on the rating plate 12
5. Assembly 13
5.1 General information 13
5.2 Assembly of the FS-1
Humidity Sensor 13
6. Operation/configuration, ecommissioning
and disposal 15
6.1 Operation/configuration 15
6.2 Decommissioning and disposal 15
7. Maintenance 16
7.1 General information 16
8. Malfunctions, causes, and remedies 17
8.1 Commissioning, product, and system
malfunctions 17
9. Accessories 18
EN
Table of contents

4
EN
Possible symbols
Meaning
Note
Electric shock hazard
Slipping hazard
Hazard from hot surfaces
Risk of being drawn into machinery
Crushing hazard
Danger from suspended load
Pressure injection hazard
Explosion-proof component
Electrostatic sensitive components
Wear personal safety equipment
(goggles)
Secure (lock) the machine against
accidental starting
Environmentally sound disposal
Explanation of symbols and signs
Explanation of symbols and signs
Activities that present specific hazards to
persons or material assets are indicated
with warnings.
Read the instructions completely and follow
all operating instructions and the warning
and safety instructions.
Text formats
Symbol Meaning
Prompts an action
Used for itemizing
Refers to causes / consequence or other facts
Provides additional information within procedures
Warning level Consequence Probability
DANGER Death / serious injury Immediate
WARNING Serious injury Possible
CAUTION Minor injury Possible
NOTE Property damage Possible
Symbol

5
EN
Explanation of symbols and signs
Instructions placed on a unit, machine, or
equipment, such as:
Rotation arrows
 Fluid connection labels must be
followed and kept in fully legible
condition.
 Warnings
Read the lifecycle manual thoroughly and
follow the safety instructions.
Abbreviations and conversion factors
Abbreviations
re regarding oz. ounce
approx. approximately psi pounds per square inch
°C degrees Celsius hp horsepower
s seconds lb. pound
dB (A) sound pressure level sq.in. square inch
i.e. that is cu.in. cubic inch
etc. et cetera mph miles per hour
poss. possibly fpsec feet per second
< less than °F degrees Fahrenheit
± plus or minus fl.oz. fluid ounce
> greater than in. inch
e.g. for example gal. gallon
if
necessary
if necessary
etc. et cetera Conversion factors
usually usually Length 1 mm = 0.03937 in.
Ø diameter Area 1 cm² = 0.155 sq.in.
incl. including Volume 1 ml = 0.0352 fl.oz.
K Kelvin 1 l = 2.11416 pints (US)
kg kilogram Mass 1 kg = 2.205 lbs
RH relative humidity 1 g = 0.03527 oz.
kW kilowatt Density 1 kg/cm³ = 8.3454 lb./gal.
(US)
l liter 1 kg/cm³ = 0.03613 lb./cu.in.
Min. minute Force 1 N = 0.10197 kp
max. maximum Speed 1 m/s = 3.28084 fpsec
min. minimum 1 m/s = 2.23694 mph
mm millimeter Acceleration 1 m/s² = 3.28084 ft./s²
ml milliliter Pressure 1 bar = 14.5 psi
N Newton Temperature °C = (°F-32) x 5/9
Nm Newton meter Power 1 kW = 1.34109 hp
