SKF LINCOLN GS30 Series User manual

Version 01
951-180-080-EN
EN
Operating instructions
according to Directive 2014/30/EU
Flow Sensors
of Series GS30XX

EU Declaration of Conformity
- 2 -
951-180-080-EN
Version 01
EN
EC Declaration of Conformity in accordance with Directive 2014/30/EU, Annex IV on the
electromagnetic compatibility of devices
The manufacturer, SKF Lubrication Systems Germany GmbH, Berlin Plant, Motzener Str. 35/37, DE - 12277 Berlin, hereby declares conformity of the device/
the electrical equipment:
Designation: Flow sensor
Series: GS30XX
Material number: GS300; GS304P; GS304N
Year of manufacture: See rating plate
with all relevant provisions of the following Directives at the time of placing on the market. Furthermore, the following
Directives and (harmonized) standards were applied in the applicable areas:
2014/30/EU EMC Electromagnetic Compatibility
2011/65/EU RoHS II Directive on the restriction of certain hazardous substances in electrical and electronic equipment
Standard Edition Standard Edition
DIN EN 61000-6-2 2006 DIN EN 61000-6-3 2011
Correction 2011 Correction 2012
DIN EN 50581 2013
Berlin, March 2018
Dr.-Ing. Holger Schmidt
Manager Development Center Berlin
SKF Lubrication Business Unit
Jürgen Kreutzkämper
Manager R&D Germany
SKF Lubrication Business Unit

- 3 -
951-180-080-EN
Version 01
EN
Masthead
Training
SKF conducts detailed training in order to
enable the maximum safety and efficiency.
SKF recommends taking advantage of this
training. For information, contact the rel-
evant SKF service address.
Copyright
© Copyright SKF
All rights reserved.
Warranty
The instructions do not contain any
information on the warranty. This can
be found in our General Terms and
Conditions.
Disclaimer of liability
The manufacturer shall not be held liable for
damage resulting from:
Improper usage,
assembly, operation, configuration,
maintenance, repair, or accidents
Improper reaction to malfunctions
Unauthorized modifications to the
product
Intentional or gross negligence
Use of non-original SKF spare parts
The maximum liability for loss or damage
resulting from the use of our products is
limited to the purchase price. Liability for
indirect damage of any kind is excluded.
Masthead
Manufacturer
SKF Lubrication Systems Germany GmbH
Address of manufacturer plants
Headquarters
Walldorf Plant
Heinrich-Hertz-Str. 2-8
69190 Walldorf
Germany
Tel: [phone]
Fax: [phone]
Berlin Plant
Motzener Strasse 35/37
12277 Berlin
Germany
Tel. [phone]
Fax [phone]
Hockenheim Plant
2. Industriestrasse 4
68766 Hockenheim
Germany
Tel. [phone]
Fax [phone]
E-mail: [e-mail]
www.skf.com/lubrication

- 4 -
951-180-080-EN
Version 01
EN Table of contents
Table of contents
Masthead .................................................................................................... 3
Explanation of symbols and signs .............................................................. 6
1. Safety instructions ........................................................................ 8
1.1 General safety instructions ....................................................................8
1.2 General behavior when handling the product .....................................8
1.3 Intended use ............................................................................................9
1.4 Foreseeable misuse ................................................................................ 9
1.5 Painting plastic components .................................................................9
1.6 Modifications to the product ................................................................10
1.7 Inspections prior to delivery ................................................................10
1.8 Notes on the rating plate .....................................................................10
1.9 Note on CE marking .............................................................................10
1.10 Persons authorized to use the product ..............................................11
1.10.1 Operator .............................................................................................11
1.10.2 Qualified mechanic ...........................................................................11
1.10.3 Qualified electrician ..........................................................................11
1.11 Operation ...............................................................................................11
1.12 Transport, assembly, maintenance, malfunction, repair, shutdown,
disposal ..................................................................................................12
1.13 First start-up .........................................................................................13
1.14 Cleaning .................................................................................................13
1.15 Residual risks .........................................................................................14
2. Lubricants ................................................................................... 15
2.1 General information .............................................................................15
2.2 Selection of lubricants ..........................................................................15
2.3 Material compatibility ...........................................................................15

- 5 -
951-180-080-EN
Version 01
EN
Table of contents
3. Overview, functional description................................................. 16
3.1 General ...................................................................................................16
3.1.1 Calorimetric principle .......................................................................16
3.2 Function .................................................................................................16
3.3 Attachment ............................................................................................17
4. Technical data ............................................................................. 18
4.1 General technical data ..........................................................................18
5. Supply, returns, storage .............................................................. 19
5.1 Supply ....................................................................................................19
5.2 Return shipment ..................................................................................19
5.3 Storage ...................................................................................................19
6. Assembly ..................................................................................... 20
6.1 General information .............................................................................20
6.2 Assembly location .................................................................................21
6.2.1 Minimum mounting dimensions ....................................................21
6.3 Installation of the flow sensor .............................................................21
6.3.1 Electrical connection ........................................................................22
6.3.2 Assembly of plastic lubrication lines using
solderless pipe unions .....................................................................24
6.3.3 Assembly of the lubrication lines using quick
disconnect couplings ........................................................................24
7. First start-up .............................................................................. 26
7.1 Inspections before first start-up .........................................................26
8. Operation .................................................................................... 27
9. Cleaning ...................................................................................... 27
9.1 Cleaning agents .....................................................................................27
9.2 Exterior cleaning ...................................................................................27
9.3 Interior cleaning ....................................................................................27
10. Maintenance ............................................................................... 28
11. Malfunctions, causes, and remedies ........................................... 28
12. Shutdown, disposal ..................................................................... 29
12.1 Temporary shutdown ...........................................................................29
12.2 Permanent shutdown, disassembly ...................................................29
12.3 Disposal ..................................................................................................29
13. Accessories.................................................................................. 30

- 6 -
951-180-080-EN
Version 01
EN Explanation of symbols, signs, and abbreviations
Explanation of symbols and signs
General warning Risk of electrical shock
Risk of slipping Unauthorized persons must be kept away
Wear personal protective gear (protective clothing) Wear personal protective gear (gloves)
Wear personal protective gear (goggles) General notes
Unlock the product Disposal of waste electrical and electronic equipment
Warning level Consequence Probability
DANGER Death, serious injury Immediate
WARNING Serious injury Possible
CAUTION Minor
injury Possible
NOTE Property damage Possible
Symbol Meaning
Chronological instructions
Bullet list items
Indicates the requirements that must be met for the actions described in the following

- 7 -
951-180-080-EN
Version 01
EN
Explanation of symbols, signs, and abbreviations
Abbreviations and conversion factors
re regarding °C degrees Celsius °F degrees Fahrenheit
approx. approximately K Kelvin Oz. ounce
i.e. that is N Newton fl. oz. Fluid ounce
etc. et cetera h hour in. inch
poss. possibly s second psi pounds per square inch
incl. including d day sq.in. square inch
min. minimum Nm Newton meter cu. in. cubic inch
max. maximum ml milliliter mph miles per hour
min minute ml/d milliliters per day RPM revolutions per minute
etc. et cetera ccm cubic centimeter gal. Gallon
e.g. for example mm millimeter lb. pound
kW kilowatt l liter hp horsepower
U voltage db (A) sound pressure level kp kilopound
R Resistance > greater than fpsec feet per second
I current intensity < less than Conversion factors
V volt ± plus minus Length 1 mm = 0.03937 in.
Wwatt Ø diameter Area 1 cm² = 0.155 sq.in.
AC alternating current kg kilogram Volume 1 ml = 0.0352 fl.oz.
DC direct current RH relative humidity 1 l = 2.11416 pints (US)
A ampere ≈ approximately Mass 1 kg = 2.205 lbs
Ah ampere hour = equal to 1 g = 0.03527 oz.
Hz Frequency (Hertz) % percent Density 1 kg/cm³ = 8.3454 lb./gal(US)
NC normally closed contact ‰ per mil (thousandth) 1 kg/cm³ = 0.03613 lb./cu.in.
NO normally open contact ≥ greater or equal Force 1 N = 0.10197 kp
≤ less or equal Pressure 1 bar = 14.5 psi
mm2square millimeter Temperature °C = (°F-32) x 5/9
rpm Revolutions per minute Power 1 kW = 1.34109 hp
Acceleration 1 m/s² = 3.28084 ft./s²
Speed 1 m/s = 3.28084 fpsec
1 m/s = 2.23694 mph

- 8 -
951-180-080-EN
Version 01
EN 1. Safety instructions
1. Safety instructions
1.1 General safety instructions
○The operator must ensure that the in-
structions are read by all persons tasked
with working on the product or who
supervise or instruct such persons. The
operator must also ensure that the staff
fully understands the content of the in-
structions. Putting the products into op-
eration or operating them without having
read the instructions is prohibited.
○Retain the instructions for further use.
○The products described here were
manufactured according to the state of
the art. Risks may, however, arise from
non-compliant usage and may result in
personal injury or damage to material
assets.
○Any malfunctions which may affect safety
must be remedied immediately. In ad-
dition to these instructions, the statu-
tory regulations for accident prevention
and environmental protection must be
observed.
1.2 General behavior when handling the
product
○The product may only be used in aware-
ness of the potential dangers, in proper
technical condition, and according to the
information in this manual.
○Familiarize yourself with the functions
and operation of the product. The speci-
fied assembly and operating steps and
their sequences must be observed.
○Any unclear points regarding proper
condition or correct assembly/operation
must be clarified. Operation is prohibited
until issues have been clarified.
○Unauthorized persons must be kept
away.
○Wear personal protective equipment.
○All safety regulations and in-house
instructions relevant to the particular
activity must be observed.
○Responsibilities for different activities
must be clearly defined and observed.
Uncertainty seriously endangers safety.
○Protective and safety mechanisms must
not be removed, modified, nor disabled
during operation and must be checked
for proper function and completeness at
regular intervals.
○If protective and safety mechanisms
must be removed, they must be rein-
stalled immediately following conclusion
of work and then checked for proper
function.
○Any malfunctions that occur must be
resolved according to responsibility. The
supervisor must be notified immediately
in case of malfunctions outside one's in-
dividual scope of responsibility.

1
- 9 -
951-180-080-EN
Version 01
EN
1. Safety instructions
○Use to feed, forward, or store hazardous
substances and mixtures as defined in
Annex I Part 2-5 of the CLP Regulation
(EC 1272/2008) that are marked with
hazard pictograms GHS01-GHS 09
○Use to feed / forward / store gases,
liquefied gases, dissolved gases, va-
pors, or fluids whose vapor pressure
exceeds normal atmospheric pressure
(1013 mbar) by more than 0.5 bar at
their maximum permissible operating
temperature
1.3 Intended use
The flow sensors GS300, GS300N, and
GS300P provide the ability to detect an
intermittent oil flow between metering and
lubrication points and to convey this flow to
the customer’s control unit (PLC).
Depending on the type, the flow sensors can
monitor metered quantities of oil from
10 mm3 to 600 mm3 per lubrication pulse.
The maximum number of pulses per minute
is 4 pulses at a maximum operating pres-
sure of 40 bar.
The specifications in the “Technical data”
chapter must be adhered to.
Any other or additional usage of the flow
sensors of the GS300 series is deemed
non-compliant with the intended use.
Usage is permitted exclusively in the context
of commercial or business activity by
professional users.
1.4 Foreseeable misuse
Any usage of the flow sensors differing from
the aforementioned conditions and stated
purpose is strictly prohibited. Particularly
prohibited are use:
○Use in an explosion protection zone
○Use outside the specified operating tem-
perature range
○Use of non-specified equipment
○Use in continuous operation
○Use in areas with aggressive, corrosive
substances (e.g., high ozone loads)
○in areas with damaging radiation (e.g.,
ionizing radiation)

- 10 -
951-180-080-EN
Version 01
EN 1. Safety instructions
1.5 Painting plastic components
The painting of all plastic components and
seals of the products described here is pro-
hibited.
Completely remove or mask affected com-
ponents before painting the main machine.
1.6 Modifications to the product
Unauthorized modifications and changes
can have an unpredictable effect on safety.
Unauthorized modifications and changes
are therefore prohibited.
1.7 Inspections prior to delivery
The following tests were performed prior to
delivery:
○Safety and functional tests
○For electrically operated products: Elec-
trical tests according to DIN EN
60204-1:2007, VDE 0113-1:2007
GS300.06
18...30VDC
3BU
PNP
Power
BN
BK
1
4
-
10mA
+
Signal
1.8 Notes on the rating plate
To avoid loss of this data in case the type
plate becomes illegible, the type designation
should be entered in the manual.
Type 
GS300
GS304P
GS304N

1
- 11 -
951-180-080-EN
Version 01
EN
1. Safety instructions
Note on Pressure Equipment Directive
2014/68/EU
Due to its performance characteristics, the
product does not reach the limit values
defined in Article 4, Paragraph 1, Subpara-
graph (a) item (i) and is, pursuant to Article
4, Paragraph 3, excluded from the scope of
Pressure Equipment Directive 2014/68/EU.
1.10 Persons authorized to use the
product
1.10.1 Operator
A person competent due to training, knowl-
edge, and experience to execute the func-
tions and activities associated with normal
operation; this also includes the avoidance
of possible hazards that may arise during
operation.
1.10.2 Qualified mechanic
A person with appropriate technical train-
ing, knowledge, and experience who can
recognize and avoid the hazards that may
occur during transport, assembly, first start-
up, operation, maintenance, repair, and
dismantling
1.10.3 Qualified electrician
A person with appropriate technical training,
knowledge, and experience who can recog-
nize and avoid hazards that may result from
electricity
1.9 Note on CE marking
The CE marking is based on the require-
ments of the applied Directives:
2014/30/EU
Electromagnetic compatibility
2011/65/EU
(RoHS II) Directive on the restriction of
the use of certain hazardous substances
in electrical and electronic equipment
Note on Low-Voltage Directive 2014/35/EU
The protection objectives of the Low-Volt-
age Directive 2014/35/EU are met in accor-
dance with Annex I, No. 1.5.1 of Machinery
Directive 2006/42/EC.

- 12 -
951-180-080-EN
Version 01
EN 1. Safety instructions
1.11 Operation
The following must be observed during first
start-up and operation:
○All information within this manual and
all information within the referenced
documents
○All laws and regulations that the operator
must observe
1.12 Transport, assembly, maintenance,
malfunction, repair, shutdown,
disposal
○All relevant persons must be informed of
the activity prior to the start of this work.
Precautionary operational measures,
work instructions must be observed.
○Prior to performing work, the product
and the machine in which the product
will be integrated must be de-energized,
depressurized, and secured against un-
authorized activation.
○Take appropriate measures to ensure
that moving, detached parts are im-
mobilized during the work and that no
limbs can be pinched by unintended
movements.
○Assemble the product only outside the
operating range of moving parts, at an
adequate distance from sources of heat
or cold. Other units of the machine must
not be damaged or impaired in their
function by the installation.
○Dry any wet, slippery surfaces or cover
appropriately.
○Cover hot or cold surfaces appropriately.
○Work on electrical components may be
performed only by qualified electricians.
Note possible waiting times for discharge.
○Work on electrical components may be
performed only in a voltage-free state
and using tools suitable for electrical
work.
○Establish the electrical connection only in
accordance with the valid circuit diagram
and in observance of the relevant regula-
tions and the local electrical operating
conditions.
○Do not touch cables or electrical compo-
nents with wet or moist hands.
○Drill required holes only on non-critical,
non-load-bearing parts. Use existing

1
- 13 -
951-180-080-EN
Version 01
EN
1. Safety instructions
1.13 First start-up
Ensure that:
○All safety mechanisms are fully present
and functional.
○All connections are properly connected.
○All parts are correctly installed.
boreholes. Do not damage lines or cables
when drilling.
○
Observe any possible wearing spots. Pro-
tect components appropriately.
○All components used must be designed
for:
-The maximum operating pressure
-The lubricant to be delivered
-The operating and ambient conditions
at the place of use.
○No parts may be subjected to torsion,
shear, or bending.
○Check parts for contamination before use
and clean if necessary.
○Adhere to the specified torques. Use
a calibrated torque wrench when
tightening.
1.14 Cleaning
There is a fire hazard from the use of
flammable cleaning agents. Use only
non-flammable cleaning agents that are
suitable for the intended purpose.
○Do not use corrosive cleaning agents.
○Do not use stream-jet equipment or
high-pressure cleaners. This may dam-
age electrical components.
○Observe the IP protection class.
○Cleaning work must not be performed on
conducting components.
○Mark wet areas accordingly.

- 14 -
951-180-080-EN
Version 01
EN 1. Safety instructions
1.15 Residual risks
Residual risk Possible in
lifecycle Avoidance / Remedy
Personal injury / property damage due
to electric shock resulting from power
lead damage
B, C, D,
E, F, G
• Inspect power leads for damage prior to initial use and then at regular intervals. Do not install
the cable on moving parts or wearing spots. If this cannot be avoided, use anti-kink coils and/or
conduits.
Personal injury / property damage due
to spilled, leaked lubricant
B, C, D, F,
G, H, K
• Be careful when connecting or disconnecting the lubricant piping. Use only hydraulic screw
unions and lubrication piping suitable for the specified pressure. Do not install lubrication piping
on moving parts or wearing spots. If this cannot be avoided, use flexible hose lines or anti-kink
coils and/or conduits.
Contamination by foreign substances B, C, D,
F, G, H • Remove any foreign substances and establish a contamination-free environment.
Destruction by electrostatic discharge B, C, D,
F, G, H • Avoid electrostatic charges
Destruction due to lubrication that is
corrosive or aged D
• Use only oils of viscosity class 10 bis 2000 mm2/s and fluid grease of NLGI Grades 000,00
These must not contain any corrosive components or additives that could lead to destruction of
the flow sensor. If necessary, the customer must performed a suitability test.
• Monitor lubricant level, replace lubricant if aged
Lifecycles: A = Transport, B = Assembly, C = First start-up, D = Operation, E = Cleaning, F = Maintenance, G = Malfunction, repair,
H = Shutdown, K = Disposal

2
- 15 -
951-180-080-EN
Version 01
EN
2. Lubricants
2. Lubricants
2.1 General information
Lubricants are used specially for specific
applications. To fulfill the task, lubricants
must meet various requirements to varying
degrees. The most important requirements
for lubricants are:
Reduction in friction and wear
Corrosion protection/noise reduction
Protection against contamination/ in-
gress of foreign matter
Cooling (primarily for oils)
Durability (physical/chemical stability)
Compatible with as many materials as
possible
Economic and environmental aspects
2.2 Selection of lubricants
SKF Lubrication Systems considers lubri-
cants to be an element of system design.
The selection of a suitable lubricant should
reasonably be made during the design of
the machine and forms the basis for plan-
ning the centralized lubrication system.
The manufacturer/operator of the machine
should preferably make the selection with
the supplier of the lubricant on the basis of
the requirements profile of the specific task.
If you have no or little experience selecting
lubricants for centralized lubrication sys-
tems, please contact SKF.
Only lubricants specified for the
product may be used (see “Technical
data” chapter). Unsuitable lubricants
may lead to failure of the product.
Do not mix lubricants. This can
have unpredictable effects on the
usability and this function of the
centralized lubrication system.
2.3 Material compatibility
The lubricants must generally be compatible
with the following materials:
Steel, gray cast iron, brass, copper,
aluminum
NBR, FKM (FPM), ABS, PA, PU
1

- 16 -
951-180-080-EN
Version 01
EN 3. Overview, functional description
3. Overview, functional description
3.1 General
- See Figure 1
Flow sensors of series GS30XX can monitor
minimal lubricant volumes, which are gen-
erated in pulses by a metering device, on the
way to the lubrication point.
The sensors are suitable for oils and fluid
greases. Minimal lubricant volumes can be
detected in the range from 0.01 to 0.6 cm³
per metering pulse.
The variants of the GS30XX all operate
according to a calorimetric measuring prin-
ciple and differ in terms of the number and
design of their signal outputs (see Figure 3).
The sensors are not suitable for the detec-
tion of continuous lubricant flows.
3.1.1 Calorimetric principle
The process is based on the physical laws of
thermal conduction and thermal transfer in
liquids and gases. A body with a higher tem-
perature emits energy into its environment
in the form of heat. The amount of energy
transfer depends on the temperature differ-
ence and the mass flow.
3.2 Function
If the GS30XX sensors, which operate un-
der a calorimetric measuring principle (see
Chapter 3.3.1), detect a lubricant volume
occurring in pulses, the evaluation electron-
ics generate a discrete electrical output
signal for 3 seconds. The yellow LED on the
sensor lights up in the process.
The output signal can be evaluated by the
user, for example using a PLC.
Due to the calorimetric measuring principle,
the sensor element in the sensor requires
an interval time (pause) after a lubricant
pulse. During this time, the energy previ-
ously extracted from it by the evaluation
electronics is returned so that a defined
sensor sensitivity is achieved.
The interval time depends on various pa-
rameters, such as the lubricant volume, the
flow velocity, and the lubricant temperature.
The most important factor determining the
interval time is the lubricant volume flowing
past the sensor element. A small lubricant
volume draws less energy from the sensor
element than does a larger quantity of lubri-
cant. Less time is thus needed to replenish
the extracted energy.
Maintaining an interval time of 15 seconds
ensures that the sensors reliably detect a

3
- 17 -
951-180-080-EN
Version 01
EN
3. Overview, functional description
Overview, Fig. 1
SPS
lubricant pulse across the entire applicable
temperature and quantity range.
In applications in which metered quantities
in the detection range of 0.01 – 0.10 cm3
are to be monitored, the required interval
time may in individual cases be less, result-
ing in monitoring intervals of less than 15
seconds.
If metering pulses are monitored at an in-
terval of less than 15 seconds, the interval
time between lubricant pulses that yields
reliable detection by the sensor must be de-
termined for the specific application.
3.3 Attachment
Flow sensors of series GS30XX are attached
using assembly holes located on the sensor
housing that are designed for M4 screws.
Both lubrication piping are screwed into the
sensor housing using M8x1 screw unions or
SKF quick disconnect coupling.
The flow direction of the lubricant must
be paid attention to during assembly; it is
marked by a direction arrow applied to the
housing.
The electrical connection is established ac-
cording to the wiring diagram applied to
the housing or according to the description
Chapter 6, “Assembly.”

EN 4. Technical data
- 18 -
951-180-080-EN
Version 01
4. Technical data
4.1 General technical data
Mounting position Any, taking into account the flow direction
Installation location Immediately before the lubrication point
Operating temperature range + 50 °F to 122 °F (+ 10 °C to + 50 °C)
Operating pressure Max. 40 bar
Weight 0.1kg
Measuring principle Calorimetric
Suitable for metered quantities from 0.01 to 0.6 cm3 /pulse
Operating frequency
(After switching on, the sensor needs a warm-up phase of 30
seconds.)
One pulse every 15 seconds (4 pulses/min.)
Medium Oil (10 to 2000 mm2/s) and fluid grease of NLGI Grades 000, 00
Vibration resistance 20 g (DS/EN 60068-2-6, 10 -2000 Hz)
Impact resistance 50 g (DS/EN 60068-2-27, 11 ms)
Electrical data
Nominal voltage UN24 V DC
Residual ripple 10 %
Operating range UA 18 to 30 V DC
Power consumption IEMax. 25 mA
Outlet signal Pulse with duration of 3 seconds
Load current IA per output GS300 Max. 10 mA GS304 Max. 500 mA
Outlet protection Short-circuit protection
Connector plug Circular connector with M12x1 screw cap
Protection class IP 67

5
EN
5. Delivery, returns, storage
4
- 19 -
951-180-080-EN
Version 01
5. Supply, returns, storage
5.1 Supply
After receipt of the supply, it must be in-
spected for any shipping damage and for
completeness according to the shipping
documents. Immediately inform the trans-
port carrier of any shipping damage.
The packaging material must be preserved
until any discrepancies are resolved. Safe
handling must be ensured during on-site
transport.
5.2 Return shipment
Before return shipment, all contaminated
parts must be cleaned and properly packed
(i.e., according to the requirements of the
recipient country).
The product must be protected from me-
chanical effects such as impacts. There are
no restrictions for land, air, or sea transport.
5.3 Storage
The following conditions apply to storage:
○Dry, low-dust, vibration-free, in closed
rooms
○No corrosive, aggressive substances at
the storage location (e.g., UV rays, ozone)
○Protected against animals (insects,
rodents)
○If possible, keep in original package
○Protected from nearby sources of heat
or cold
○In case of large temperature fluctua-
tions or high humidity, take appropriate
measures (e.g., heating) to prevent the
formation of condensation water.
○The permissible storage temperature
range corresponds to the operating tem-
perature range (see “Technical data”).
The following must be marked on the pack-
aging of return shipments:

EN 6. Assembly
- 20 -
951-180-080-EN
Version 01
6.1 General information
NOTE
Persistent contamination with foreign sub-
stances can distort the measuring results.
Appropriate measures must therefore be
taken to prevent contamination.
Only qualified technical personnel may
install the products specified in the
instructions.
During assembly, pay attention to the
following:
Due to the nature of the system, the sen-
sor element located between the lubricant
inlet and the lubricant outlet in the sensor
housing is designed so that the ambient
atmosphere directly reaches the measuring
element. The electronic components are
thus exposed directly to the lubricant. Dur-
ing assembly, it must therefore be ensured
that no solid object, lubricant particles, con-
taminated lubricant or any kind of cleaning
agent touches the sensor board. This could
result in destruction of the sensor element
and thus failure of the flow sensor.
Further, it should be note that lubricants
that are corrosive or have degraded
through aging can also corrode electronic
components.
Prior to installing the flow sensor, the cus-
tomer must check the ambient and medium
influences on the sensor.
If necessary, consult SKF Lubrication Sys-
tems Germany GmbH.
The flow sensor does not require calibration.
Further:
○Connect the flow direction of the flow
sensor according to the “†“ direction ar-
row affixed to the sensor housing.
○Other units must not be damaged by as-
sembly work.
○The product must not be installed within
range of moving parts.
○The product must be installed at a suf-
ficiently large distance from sources of
heat or cold.
○Observe the IP protection class of the
product
○Maintain safety clearances and comply
with statutory regulations for assembly
and accident prevention.
○The mounting position requirements
in “Technical data” (Chapter 4) must be
observed.
6. Assembly
