Skil Masters 1220 User manual

BELT SANDER
1220 (F0151220 . . )
SKIL Europe BV - Konijnenberg 60 09/11 2610Z02885
4825 BD Breda - The Netherlands
 ORIGINAL INSTRUCTIONS 5
NOTICE ORIGINALE 7
ORIGINALBETRIEBSANLEITUNG 11
 ORIGINELE GEBRUIKSAANWIJZING 14
BRUKSANVISNING I ORIGINAL 17
 ORIGINAL BRUGSANVISNING 19
ORIGINAL BRUKSANVISNING 20
 ALKUPERÄISET OHJEET 22
MANUAL ORIGINAL 25
MANUAL ORIGINAL 28
ISTRUZIONI ORIGINALI 31
EREDETI HASZNÁLATI UTASÍTÁS 34
 PŮVODNÍM NÁVODEM K POUŽÍVÁNÍ 37
 ORİJİNAL İŞLETME TALİMATI 43
 INSTRUKCJA ORYGINALNA 46
 ПОДЛИННИК РУКОВОДСТВА
ПО ЭКСПЛУАТАЦИИ 49
 ОРИГІНАЛЬНА ІНСТРУКЦІЯ
З ЕКСПЛУАТАЦІЇ 53
 ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ 57
 INSTRUCŢIUNI DE FOLOSIRE
ORIGINALE 60
 ОРИГИНАЛНО РЪКОВОДСТВО
ЗА ЕКСПЛОАТАЦИЯ 63
 PÔVODNÝ NÁVOD NA POUŽITIE 67
 ORIGINALNE UPUTE ZA RAD 70
 ORIGINALNO UPUTSTVO ZA RAD 73
 IZVIRNA NAVODILA 76
 ALGUPÄRANE KASUTUSJUHEND 78
 ORIĢINĀLĀ LIETOŠANAS PAMĀCĪBA 81
 ORIGINALI INSTRUKCIJA 84
 92
 90
www.skilmasters.com

2
1220
1
˄˃ÅÅ
ˁ˂˄ÅÅ
ʿƓ˅ÿ
ʽʾƯʿʽʽˀ
¹ÌÌ
˃˂ʽ
ʾˀʽÐ˄˃ÅÅ ˀʽʽÅƯÅÁÆ
ʿˀʽ
Ƙ
ʿˁʽ




 



2
3

3


5


4

4
grit 60 2610373177
grit 80 2610373178
grit 100 2610373179
ACCESSORIES SKIL nr.
8
6

7

5

Belt sander 1220
INTRODUCTION
• This tool is intended for dry sanding with high removal
performance of wood, plastic, metal, ller and painted
surfaces
• Read and save this instruction manual 3
TECHNICAL SPECIFICATIONS 1
TOOL ELEMENTS 2
A On/o switch
B Knob for locking on/o switch
C Lever for changing sanding belt
D Arrow
E Screw for adjusting belt centering
F Dust bag
G Vacuum cleaner adapter
H Ventilation slots
J Sanding frame
SAFETY
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury. Save
all warnings and instructions for future reference. The
term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair
can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.

6
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations dierent
from those intended could result in a hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
SAFETY INSTRUCTIONS FOR SANDERS
• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working
• Always keep the cord away from moving parts of the tool;
direct the cord to the rear, away from the tool
• Secure the workpiece (a workpiece clamped with
clamping devices or in a vice is held more securely than
by hand)
• When you put away the tool, switch o the motor and
ensure that all moving parts have come to a complete
standstill
• Use completely unrolled and safe extension cords with a
capacity of 16 Amps (U.K. 13 Amps)
• In case of electrical or mechanical malfunction,
immediately switch o the tool and disconnect the plug
• SKIL can assure awless functioning of the tool only
when original accessories are used
• This tool should not be used by people under the age of
16 years
• The noise level when working can exceed 85 dB(A); wear
ear protection
• Hold power tool by insulated gripping surfaces,
because the belt may contact its own cord (cutting a
“live” wire may make exposed metal parts of the power
tool “live” and could give the operator an electric shock)
• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug
• Never use the tool when cord is damaged; have it
replaced by a qualied person
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools with
a rating of 230V or 240V can also be connected to a
220V supply)
• This tool is not suitable for wet sanding
• Do not work materials containing asbestos (asbestos
is considered carcinogenic)
• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause allergic
reactions and/or respiratory diseases to the operator or
bystanders); wear a dust mask and work with a dust
extraction device when connectable
• Certain kinds of dust are classied as carcinogenic (such
as oak and beech dust) especially in conjunction with
additives for wood conditioning; wear a dust mask and
work with a dust extraction device when
connectable
• Follow the dust-related national requirements for the
materials you want to work with
• When sanding metal, sparks are generated; do not use
dustbag/dustbox/vacuum cleaner and keep other
persons and combustible material from work area
• Do not touch the running sanding belt
• Do not continue to use worn, torn or heavily clogged
sanding belts
• Wear protective gloves, safety glasses, close-tting
clothes and hair protection (for long hair)
• Always disconnect plug from power source before
making any adjustment or changing any accessory
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut o the cord of this tool,
it must be disposed of safely and not left unattended
USE
• On/o switch
- switch on/o the tool by pulling/releasing trigger A 2
! before the sanding surface reaches the
workpiece, you should switch on the tool
! before switching off the tool, you should lift it
from the workpiece
• Switch locking for continuous use
- pull trigger A 2
- press knob B 2 with your thumb
- release the trigger
- unlock the switch by pulling again trigger A 2 and
then releasing it
• Changing of sanding belts 4
! disconnect the plug
- lift lever C
- remove sanding belt
- insert new belt with arrows printed at inner side of belt
pointing in same direction as arrow D on tool
- push lever back
! change sanding belts in time
! never fold sanding belts
• Automatic belt centering (ABC)
- centers belt automatically when switching on tool
- keeps belt centered while sanding
In case belt runs o tool (mostly caused by inferior belt
quality), you should
- switch on the tool
- adjust screw E 2 till the sanding belt is running in line
with the at side of the tool
- use new belt, if belt still runs o tool
• Dust suction 5
! empty dustbag F regularly for optimal dust
pick-up performance
- when using tool with vacuum cleaner, mount vacuum
cleaner adaptor G as illustrated
! do not use dustbag/vacuum cleaner when
sanding metal

7
• Holding and guiding the tool 6
- guide the tool parallel to the working surface
! while working, always hold the tool at the
grey-coloured grip area(s)
! do not apply too much pressure on the tool; let
the sanding surface do the work for you
- do not tilt the tool in order to avoid unwanted sanding
marks
- keep ventilation slots H 2 uncovered
APPLICATION ADVICE
• For sanding bare wood surfaces move the tool in straight
movements in line with the grain
• For sanding all other surfaces move the tool in oval
movements over the material
• Mount sanding frame J for equalizing surfaces without
scratches or grooves, and ensure it is in place securely 7
! sanding frame J becomes hot during use; do not
touch it before it has cooled down
• Never use the same sanding belt for wood and metal
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially ventilation
slots H 2)
- remove adhering sanding dust with a brush
! disconnect the plug before cleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol 8 will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
• We declare under our sole responsibility that this product
is in conformity with the following standards or
standardized documents: EN 60745, EN 61000, EN
55014, in accordance with the provisions of the directives
2004/108/EC, 2006/42/EC, 2011/65/EU
• Technical file at: SKIL Europe BV (PT-SEU/PJE),
4825 BD Breda, NL
ÊÆÇιÆ¼½ÊÄÇÇÌ
Á»½ʽËÁ¼½ÆÌ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
¹ÆÊÇÅŽĽÆ
ÈÈÊÇιÄ¹Æ¹¿½Ê
21.09.2011
NOISE/VIBRATION
• Measured in accordance with EN 60745 the sound
pressure level of this tool is 87 dB(A) and the sound
power level 98 dB(A) (standard deviation: 3 dB), and the
vibration 2.1 m/s² (hand-arm method; uncertainty
K = 1.5 m/s²)
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintained accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns

Ponceuse à bande 1220
INTRODUCTION
• Cet outil est conçu pour le ponçage à sec avec une
grande capacité à enlever la matière du bois, plastique,
métal et mastic et des surfaces peintes
• Lisez et conservez ce manuel d’instruction 3
SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 2
A Interrupteur marche/arrêt
B Bouton de verrouillage de l’interrupteur marche/arrêt
C Levier pour changer la bande de ponçage
D Flèche
E Vis pour régler le centrage de la bande
F Sac à poussière
G Adaptateur de l’aspirateur
H Fentes de ventilation
J Support de ponçage
