sks ForTwo 450 II G User manual

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
1
Cornering Light System ForTwo 450 II G
make by SmartKits SKs - MDC
Thank you choosing our cornering light system for Smart Car. You can add with our system the
Daytime driving lights and Coming-Leaving Home function.

lease you read the instruction before the installation!
Wire connection
Grey Cable: CAN-BUS to connect by Speedometer.
Orange Wire: Left Light (+12V)
Yellow Wire: Right Light (+12V)
Green Wire: On (activation) Light (+12V)
Red Wire: Main Supply, orange fuse holder with fuse (+12V)
Blue Wire: Coming Home/Leaving Home optional (+12V signal by Direction light)
lease for more information contact your dealer/installer or SmartKits SKs
Telefono : [phone]
E-Mail : SmartK[email protected]et
Sito : www.SmartKits.net

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
2
Remove the speedometer
Unhook the speedometer by unscrewing the 4 screws on the bottom shell. Look in the back side of
the speedometer you will find the white connector
ull the flap of the white connector and turn the safety catch to unhook the white connector of the
speedometer

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
3
Connect the cable of the car to the SKs cable connector
Hook the SKs cable to speedometer

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
4
osition back SKs cable (be careful not to touch the steering rod) and put on the speedometer in the
original position
Connecting wires
Get off the front Body annell
ass the Yellow, Orange and Green wires towards the light, through the rubber stopper

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
5
Cut the Yellow/Violet wire of the left bottom light. Connect first part of the Yellow/Violet wire of the
left light to the Orange wire and connect the other part of the Yellow/Violet wire to the Green wire
Cut the Yellow/Violet wire of the right bottom light. Connect the Yellow/Violet wire of the right light
to the Yellow wire and tape the other terminal of Yellow/Violet wire using the electrical tape (as there
is no need to be connected)

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
6
Connection unit
Connect the SKs Cable connectors to the SKs main Unit
Connect the fuse holder on the position 5 on the SAM

Installation Cornering Light System ForTwo 450
Cornering Light System ForTwo 450
www.SmartKits.net
7
Coming ome/Leaving ome – Optional
Connect the Blue wire of the SKs unit to signal of the light direction (+12V)
Work Test
•Blue led flashing on in the SKs unit
•Turn the steering wheel to the Left at least 90°, Bottom Left Light - ON
•Turn the steering wheel to the Right at least 90°, Bottom Right Light - ON
•Steering wheel straight, Left Light direction ON, Bottom Left Light - ON
•Steering wheel straight, Right Light direction ON, Bottom Right Light - ON
•Cornering Light System ForTwo 451 works between 35 e 55 Km/h
•Coming Home, close the car with the remote control, Lights Left-Right ON for 30 second
•Leaving Home, open the car with the remote control, Lights Left-Right ON for 30 second
•Daytime driving lights ON with engine ON and rojection headlights OFF
•Daytime driving lights OFF with engine ON and rojection headlights ON
•Daytime driving lights OFF with engine OFF and rojection headlights OFF
