OWNER’S MANUAL
for Models 45, 90 and 190
Whole-House Drum Humidiers
Includes Safety, Operating
and Maintenance Instructions,
plus Warranty
CAUTION: Read these instructions
thoroughly before servicing humidier.
Save this manual for future reference.
Model No.:
Serial No.:
Installation Date:

Table of Contents
Page
Thank You!
...................................................................................................
1
Warranty Validation Notice
(Important. Please Read)
.....................................
1
How Your Humidier Works
.........................................................................
2
How to Operate Your Humidier
..................................................................
2
How to Check Your Humidier for Proper Operation
...................................
3
How Water Hardness Affects Scheduled Maintenance
...............................
3
How to Maintain Your Humidier
.................................................................
4
Skuttle Automatic, Programmable Flushing Timer
.......................................
5
FAQs about IAQ
..........................................................................................
6
The Skuttle “Happy House—Your Assurance of Enhanced IAQ
................
7
Skuttle High-Efciency Air Cleaners
............................................................
8
Skuttle Make-Up Air Control
........................................................................
8
Skuttle Limited One-Year Product Warranty
................................................
9
Contact Information
.....................................................................
Back Cover

1
Thank you for purchasing a Skuttle whole-house Drum Humidier. We
appreciate your business and are pleased to add your name to our list of
valued customers. We sincerely hope you are satised with our product and
its performance.
Skuttle is the oldest manufacturer of residential humidiers, having been in
business since 1917. Our longevity and dedication to our customers has
resulted in products that are unsurpassed in quality and ease of operation.
Features such as automatic controls, high-quality materials and superior
workmanship make this Skuttle Drum Humidier a valuable enhancement
to your home’s HVAC system. In addition to humidiers, we manufacture air
lters, make-up air controls and IAQ accessories.
As always, quality, performance and customer satisfaction are our highest
priorities. The following information will aid you and your HVAC contractor
with the periodic maintenance necessary to keep your humidier operating
at peak efciency. If, at some point, you need parts or service, follow these
simple procedures:
First, try calling the heating and air conditioning dealer who installed your
humidier. This information may be located on the back of this booklet, or
the dealer may have placed a reference label on your heating system.
If you cannot locate your original installer, check the Yellow Pages or
the Internet (e.g., Switchboard.com) under “Heating and Air Conditioning
Contractors.
If these attempts at nding parts or service fail, email Skuttle Indoor Air
Quality Products at [email protected], or call us toll-free at
[phone]. We’ll be glad to assist you.
For further information regarding the benets, operation and maintenance
of your new Skuttle Drum Humidier, refer to the applicable sections of this
manual.
•
•
•
Important: Warranty Validation
The completion and return of the Warranty Registration Card
(enclosed separately in your Skuttle humidier carton) is required
for warranty coverage.
The warranty described herein (see page 9) is not valid unless the Warranty
Card is completed and mailed to Skuttle Manufacturing Company within
15 days of equipment installation.

2
How Your Humidier Works
Your Skuttle Drum Humidier uses the same principle of evaporation that
you see in nature: a warm breeze passing over an expanse of water will
evaporate the water and raise the relative humidity (RH), just as it does after
a summer shower.
Inside your humidier, a polyurethane foam evaporator pad lifts water from
the water pan into the warm air stream. The pad’s multiple holes and con-
necting strands signicantly increase the area from which the water can
evaporate. This ample source of moisture and the warm air in your heating
system are what make the humidier effective.
It’s important to note that water evaporated from the humidier leaves behind
all the impurities (calcium, iron, lime, bacteria, etc.) that are originally con-
tained in the water. As a result, these impurities are not dispersed through-
out your home, which keeps your living environment cleaner and your family
safer from harmful contaminants.
How to Operate Your Humidier
Your humidier’s output is controlled by a humidistat, which monitors the
relative humidity in your home and activates or deactivates the humidier
accordingly. It is installed either on the cold air return of your HVAC system
or on an interior wall of your home.
As you can see by the chart below, recommended humidistat settings increase
as the outdoor temperature rises. This is to guard against condensation.
(See “FAQs about IAQ, page 6.)
Outdoor Humidity
Temperature Setting
-20°F Low
-10°F Low
0°F Med
+10°F Med
+20°F High
Over 20°F High
An unusually high frequency or prolonged period of indoor activities (such
as showering, cooking, clothes drying, etc.) may cause indoor humidity to
rise to an excessive level, causing condensation to accumulate on windows.
If this condition lasts for more than a few hours, turn your humidier off until
normal indoor activity resumes. If the condition persists, you should ventilate
your home to remove excess moisture.

3
How to Check Your Humidier
for Proper Operation
For preseason startup, or to check your humidier for proper operation (for
example, after it has been serviced), follow this four-step procedure:
Turn on the water at the valve which leads directly to the humidier.
Make sure the water level is set at 1-3/8 inches. Turn the valve adjustment
screw clockwise () to lower the water level; turn it counterclockwise ()
to raise the water level.
Turn the humidistat to its highest setting and observe the humidier evap-
orator pad. If it does not rotate, turn your furnace on by setting the ther-
mostat higher until the furnace blower comes on. This should cause the
humidier evaporator pad to rotate.
NOTE: Wiring the unit to operate independently of or in conjunction with
the furnace blower is up to the discretion of the installer. On installations
where the unit is closely sized (i.e., the cubic footage of the home is at
or near the humidier’s peak volume capacity), independent operation
allows the unit to operate throughout the full blower cycle, thereby elimi-
nating the lag time involved in starting the humidier.
IMPORTANT: Reset the thermostat and humidistat to their correct
positions for automatic operation.
How Water Hardness Affects
Scheduled Maintenance
Your humidier will accumulate minerals, such as calcium and lime, after
operating for a short period—a sure sign that the humidier is producing
humidity. The amount of accumulation depends on the hardness of the water
in your area, which means that cleaning frequency will vary from region to
region. You can recognize that cleaning is necessary when the pores in the
evaporator pad begin to become plugged with mineral deposits.
At a minimum, your humidier will need to be cleaned at the end of every
humidifying season (i.e., the months when you heat your home). Depending
on the hardness of your water, mid-season cleaning may also be necessary.
In areas with particularly hard water, installation of a Skuttle Automatic
Flushing Timer (see page 5) will increase the intervals between cleanings.
WARNING: Excessive buildup of minerals is detrimental to the internal
parts of your humidier, as well as to the evaporative process.
NOTE: Under normal heating system conditions, the evaporative pad should
last one-to-two heating seasons before replacement is necessary. Prolonged
exposure to UV germicidal lamps will shorten the pad’s lifespan.
1.
2.
3.
4.

4
How to Maintain Your Humidier
At the end of each humidication season (i.e., in the spring), clean the
humidier thoroughly, and turn off the water and electrical power to
the unit until the following humidication season.
CAUTION: Do not leave water in the humidier pan over the non-
humidifying months!
For standard maintenance, follow these instructions:
NOTE: The model number of your unit should be handwritten on the cover
of this manual.
MODEL 45 MODEL 90 MODEL 190
Turn the water off at the valve which leads directly to the humidier by
turning the handle clockwise ().
2. For Models 45 and 90, remove the humidier cover (1) by lightly prying
down and out on the bottom lip of the cover.
For Model 190, remove the cover (1) by lifting up on the bottom of the
cover.
Remove the drum assembly (2) by lifting the drum shaft from the bear-
ing (3) and pulling it out of the motor coupling. Next, remove the drum
from the unit.
Remove the rubber valve seat (4) from the valve by grasping it between
your thumb and forenger and lifting it upward.
Raise the oat up to remove the water pan (5) for cleaning.
1.
3.
4.
5.
Replacement Pad
No. A04-1725-033
Replacement Pad
No. A04-1725-034
Replacement Pad
No. A04-1725-034

5
Clean all parts in a 50/50 solution of vinegar and water. (For stubborn
deposits, soak parts overnight.)
For reassembly, reverse Steps 1 through 6. To ensure proper humidier
operation, see “How to Check Your Humidier for Proper Operation,
page 3.
7.
8.
Skuttle®Automatic Flushing Timer
Programmable Flushing of Reservoir and Steam Humidiers
Provides ow-thru technology for
reservoir and steam humidiers.
Automatically ushes the humidier
water pan with fresh, clean water
every two hours.
Programmable to 10-, 20- and 30-
second ushes per cycle.*
Reduces or eliminates servicing
during the humidication season.
Uses minimal electricity; reduces water usage by up to 98 percent
when compared to conventional ow-thru units.
Quick and easy to install—usually less than 20 minutes.
Adaptable to any make or model of reservoir or steam humidier.
*Factory setting is for 10-second ushing cycle every two hours.
•
•
•
•
•
•
•
See the diagram below for disassembly and reassembly of the drum. 6.

6
FAQs about IAQ
(Frequently Asked Questions about Indoor Air Quality)
Why do I need a humidier?
More and more homeowners are realizing that, during the winter months,
they live in a “sick house. Family members suffer from dry, itchy skin,
parched throats and annoying coughs. Furniture creaks, oors moan, the
piano slips out of tune and static electricity zaps the cat. In general, every-
one feels miserable because they’re living in an environment that can be
drier than a desert!
Proper home humidication reduces static electricity, revitalizes dry skin
and soothes scratchy throats. It adds moisture to dry, cracked furniture
and wilting houseplants. It protects valuable artwork, antiques and musical
instruments. It even saves money on winter heating bills. That’s because
properly humidied air feels warmer, allowing you to turn your thermostat
down a few degrees.
Why should I lower my humidistat setting when the outside temperature
drops?
This practice may seem illogical at rst. After all, you increase the temperature
on your thermostat as the weather becomes colder. Why not do the same
with your humidistat?
The answer is that the relative humidity (RH) must be reduced in extreme
cold weather to prevent condensation on windows and interior surfaces.
Otherwise, the excess moisture will eventually cause damage to your home.
RH refers to the percentage of water vapor in the air at a specic temperature.
Because air expands when heated, the relative humidity decreases unless
moisture is added. Conversely, air that is cooled contracts, causing relative
humidity to increase until it reaches dew point—the temperature at which
the air becomes saturated and water condenses (just as it does on a glass
of ice water on a warm, humid day). For recommended humidistat settings,
see page 2.
I just installed a Skuttle humidier in my house. Why don’t I feel any
difference?
The period of adjustment can take up to three weeks—the time needed for
your furniture, woodwork, carpeting, plaster and houseplants to absorb their
natural levels of moisture.
Should I run my humidier during the summer months?
In most areas of the country, summer air is naturally more humid. Therefore,
it’s not necessary to humidify your home until colder, drier weather sets in.
For additional answers to your questions, visit our website at www.skuttle.com.

7
The Skuttle “Happy House”—
Your Assurance of Enhanced IAQ
The indoor air quality (IAQ) in many of today’s homes is
not nearly as healthful as it should be. Aside from being an
agreeable temperature, healthful, comfortable indoor air
is virtually free of contaminants, and contains appropriate
levels of moisture and fresh air.
Humidication
In cold weather, dry indoor air often makes homes drier than a desert. Acting
like a sponge, the parched air absorbs moisture wherever it can nd it—
furniture, plants, pets...even people. The result is a variety of discomforts and
problems, including dry skin, stuffy noses, hacky coughs, sore throats, aller-
gies, damage to furniture and woodwork, wilted plants and static electricity.
Too much or too little humidity in a home promotes an increase in bacteria,
viruses, fungi, respiratory ailments and other unhealthy conditions. Skuttle
humidiers restore a home’s relative humidity to a balanced, healthier, more
comfortable 30-to-45 percent range.
Filtration
Your body’s respiratory system is designed to lter out airborne particles
that are three-to-ve microns in diameter. Smaller particles can be inhaled,
potentially causing serious health problems. The smallest contaminants (a
single micron or less) are dispersed through HVAC ductwork and make up
about 99 percent of the particles circulating through a typical home.
Skuttle whole-house air cleaners (page 8) capture most of these contami-
nants in a deep-pleated lter that traps far more particles over a longer peri-
od than standard, at-lter designs. The results are cleaner indoor air, longer
lter life, longer furnace life and a healthier living environment.
Ventilation
A primary cause of “sick house syndrome is negative air pressure buildup,
resulting from a lack of fresh air exchanges throughout the home. Negative
air pressure can also contribute to mold growth. To help eliminate these
problems, Skuttle manufactures two ventilation products:
The Make-Up Air Diffuser supplies additional combustion air to appliances
that have inadequate combustible air sources.
The Model 216 Make-Up Air Control automatically draws fresh, outside
air into the furnace, where it is ltered, heated or cooled, and circulated
through your home’s duct system. As a result, a slight pressure builds
up in the home, keeping untreated air from seeping in around windows
and doors.
•
•

8
Skuttle® Model 216 Make-Up Air Control
Provides Year-Round, Filtered Fresh Air
The Skuttle Make-Up Air Control...
Draws outside air into the furnace,
where it is ltered, heated or cooled,
and circulated through your home’s
duct system.
Combats interior air pollution created
by today’s tightly constructed homes.
Reduces drafts and uncontrolled air in
ltration to provide year-round comfort.
Adjusts automatically; uses no elec-
tricity.
Improves furnace efciency by provid-
ing proper combustion air.
Is made from corrosion-resistant stain-
less steel to ensure long life.
•
•
•
•
•
•
Skuttle® High-Efciency Air Cleaners
Help Homeowners Breathe Easier
Skuttle Air Cleaners...
Trap most of the in-home, airborne
contaminants that are potentially harm-
ful to your health.
Provide high-efciency, high-capacity
ltration with minimal airow resistance.
Contain deep-pleated lter media to
permit extended, high-volume service
for six months or longer.
Feature a sleek, injection-molded
thermoplastic door to dress up any
installation.
Are housed in sturdy, 20-gauge, zinc-coated steel cabinets (protected
by a 10-year warranty) to support up to 500 pounds of HVAC equip-
ment and accessories.
Are available in three sizes to t virtually any furnace installation.
•
•
•
•
•
•

9
Skuttle® Limited One-Year Product Warranty
This limited one-year warranty covers the Skuttle product as designated on the return
portion of the warranty registration card, excluding wiring, plumbing and installation.
Skuttle Mfg. Co. (a.k.a. Skuttle Manufacturing Company and Skuttle Indoor Air Quality
Products) warrants that this product is free from defects in material and workmanship under
normal, noncommercial use and service. Skuttle will remedy any such defects if they appear
within 12 months from the date of the original installation as evidenced by receipt of the
warranty registration card, subject to the terms and conditions of this limited one-year warranty
stated below:
THIS LIMITED ONE-YEAR WARRANTY IS GUARANTEED BY SKUTTLE MFG. CO.,
101 MARGARET STREET, MARIETTA, OH 45750.
This warranty shall extend only to any noncommercial owner who has purchased this
residential product other than for purposes of resale.
The completion and return of the warranty registration card is a condition precedent to
warranty coverage and performance. Warranty is not valid unless this card is completed
and mailed to the factory within fteen (15) days of equipment installation.
All components are covered by this limited warranty except expendable items.
If, within the warranty period, this product or any component requires service, it must be
performed by a competent heating and/or plumbing contractor (preferably the installing
contractor). Skuttle will not pay shipping or labor charges to remove or replace such
defective parts or components. If the part or component is found by inspection to contain
such defective material and/or workmanship, it will be either repaired or exchanged, free
of charge, at Skuttle’s option, and returned freight collect.
In order to obtain the benets of this limited one-year warranty, the owner must notify the
dealer or distributor in writing of any defects within thirty (30) days of the discovery. If,
after reasonable time, he or she has not received an adequate response from the dealer
or distributor, notify in writing: Skuttle Mfg. Co., 101 Margaret St., Marietta, OH 45750.
SKUTTLE WILL RECEIVE, FREIGHT PREPAID, ONLY REMOVABLE PARTS OR
COMPONENTS OF SUCH DEFECTIVE PARTS.
This limited warranty does not apply to any part or component that is: damaged in transit
or handling; has been subject to abuse, neglect or accident; has not been installed,
operated and serviced according to Skuttle’s instructions; has been operated beyond the
factory-rated capacity, or altered in any such way that its performance is affected. There is
no warranty due to neglect, alteration or ordinary wear and tear. Skuttle’s liability is limited
to replacement of defective parts or components and does not include the payment of the
cost of labor charges to remove or replace such defective components or parts.
Skuttle will not be responsible for loss of use of any product, loss of time, inconvenience, or
any other indirect, incidental or consequential damages with respect to person or property,
whether as a result of breach of contract, neglect or otherwise. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THAT LIMITATION OR EXCLUSION IN THE PRECEDING SENTENCE
MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Any warranty work will be performed within a reasonable time, usually within one-
hundred-twenty (120) days after notice of defect and delivery to the Skuttle factory,
subject to delays beyond the manufacturer’s control.
Any warranty by Skuttle of merchantability, tness or use or any other warranty (express,
implied or statutory), representation or guarantee other than what was set forth herein
shall expire at the expiration date of this limited warranty. SOME STATES DO NOT
ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
LIMITATION IN THE PRECEDING SENTENCE MAY NOT APPLY TO YOU.
Skuttle reserves the right to make changes in the design and material of its products
without incurring any obligation to incorporate such changes in the units completed prior
to the effective date of such change.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.

If you have questions about your Skuttle humidier, or to learn which Skuttle
IAQ products are right for your home, contact your local heating and air
conditioning contractor:
Or contact:
101 Margaret Street, Marietta, OH 45750
Phone [phone]; Fax: [phone]
Email: [email protected]
Web: www.skuttle.com
Skuttle and the “Happy House character
are registered trademarks of Skuttle Mfg. Co.
Rev 12/07  ©2007, Skuttle Mfg. Co. Part No. 000-0756-250
