SKYDANCE EV3-H User manual

Technical Parameters
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Certification CE,EMC,LVD
EN60950
Safety standard(LVD)
Warranty and Protection
5 years
Protection Reverse Polarity
Warranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
LVD
3 or 4 Channel/12-60V/PWM signal input/Constant voltage output/3KV optoelectronic isolation
Mechanical Structures and Installations
Wiring Diagram
27mm
175mm
160mm
45mm
3/4 Channel 12-60V Constant Voltage Power Repeater
● 12-60V constant voltage power repeater.
● 3/4 channel, 5A max. per channel.
● To receive PWM signal control.
● Power repeater in series or in parallel to expand output unlimitedly.
● Apply to single color, dual color, RGB or RGBW constant voltage LED strip or module.
Features
Output type Constant voltage
Output power 3/4 x (60-300)W max.
Output voltage 3/4 x (12-60)VDC
Output current 3/4CH,5A max./CH
Input voltage 12-60VDC
Input current 15A max. (EV3-H)
20A max. (EV4-H)
Input and Output
● Parallel connection
User Manual Ver 1.0.2
Model No.: EV3-H / EV4-H
Page 1
Input signal PWM(3/4CH, 5-24V or 36-60V)
PWM input + (5-24V)
CH1/R PWM input -CH1/R LED output -
LED output +
Power input -
Power input +
Installation rack
CH2/G LED output -
CH3/B LED output -
EV3-H: NC
EV4-H: CH4/W LED output -
CH2/G PWM input -
CH3/B PWM input -
EV3-H: NC
EV4-H: CH4/W PWM input -
EV3-H/EV4-H
RGB/RGBW LED strip
W
Push -Dim
GND
AC100-240V
Power Supply
36-60VDC
Constant Voltage
Power Supply
12-24VDC
Constant Voltage
AC100-240V
PWM
IN PU T 12- 60VD C
OUT PUT
+
-
1 2 3
+
4
IN PUT 12-6 0VDC
OUTP UT
+
-
1 2 3
+
4
EV3-H EV4-H
412
3
INP UT PWM S IGNAL
36-60V
5-24V
V+
PWM input + (36-60V)
412
3
INPU T
PWM SI GNAL
36-60V
5-24V
V+
EV3-H/EV4-H
RGB/RGBW LED strip
W
AC100-240V
Power Supply
36-60VDC
Constant Voltage
IN PUT 12-6 0VDC
OUTP UT
+
-
1 2 3
+
4
412
3
INPU T PWM SI GNAL
36-60V
5-24V
V+
Controller
www.iskydance.pl

● Series connection
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid direct sun,rain and high humid ambient.
3. Good heat dissipation will prolong the working life of the controller, Please ensure good ventilation.
4. Please check if the output voltage of any power supplies used comply with the working voltage of the product.
5. Ensure all wire connections and polarities are correct and secure before applying power to avoid any damages
to the LED lights.
6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
Safety & Warnings
User Manual Ver 1.0.2 Page 2
RGB/ RGBW LE D strip
W
RGB/ RGBW LE D strip
W
Push -Dim
GND
W
W
AC100-240V
Power Supply
12-24VDC
Constant Voltage
AC100-240V
Power Supply
36-60VDC
Constant Voltage
Malfunctions analysis & troubleshooting
Wrong color 1. Wrong connection of R/G/B/W wires. 1. Reconnect R/G/B/W wires.
Malfunctions
Causes Troubleshooting
Uneven intensity
between front and
rear,with voltage drop
1. Output cable is too long.
2. Wire diameter is too small.
3. Overload beyond power supply capability.
4. Overload beyond controller capability.
1. Reduce cable or loop supply.
2. Change wider wire.
3. Replace higher power supply.
4. Add power repeater.
1. No power.
2. Wrong connection or insecure.
1. Check the power.
2. Check the connection.
No light
EV3-H,EV4-H 3/4 Channel 12-60V Constant Voltage Power Repeater
EV3-H/EV4-H
IN PUT 12-6 0VDC
OUTP UT
+
-
1 2 3
+
4
412
3
INPU T
PWM SI GNAL
36-60V
5-24V
V+
RGB/ RGBW LE D strip
W W
AC100-240V
Power Supply
36-60VDC
Constant Voltage
EV3-H/EV4-H
IN PUT
12-6 0VDC
OUTP UT
+
-
1 2 3
+
4
412
3
INPU T
PWM SI GNAL
36-60V
5-24V
V+
NOTE: The PWM input can be 5-24V or 36-60V, please select correct V+ wire terminal.
PWM
Controller
