SkyLine GARDWALK Instruction Manual

INSTALLATION &
USER MANUAL
GARDWALK
PAVER WALKWAY
Support: [phone] www.skylinegroupintl.com

WARNING
Serious injury or death may result if this product is misused or not installed
properly. Skyline Group provides these instructions and relies on the
purchaser and the end user to train personnel at all times, and to make
sure the user of this product fully understand the importance of following
these instructions. Skyline Group expressly disclaims any liability from
injury, damage, or other loss resulting from the improper or unauthorized
installation or use of the GardWalk Paver Walkway.
Note: This information is valid as of the revision date:
2020-06-27
INSTALLATION & USER MANUAL
GARDWALK
PAVER WALKWAY
2
Support: [phone] www.skylinegroupintl.com

CONTENTS
COMPONENT/TOOL REFERENCE GUIDE .................... 3
Common Tools ............................................................................................................................. 3
Common Components.............................................................................................................. 4
INSTALLATION INSTRUCTIONS....................................... 5
Gardwalk Paver Walkway.......................................................................................................... 5
Gardwalk Corner Kit................................................................................................................... 9
OPERATION & MAINTENANCE....................................... 14
3
Support: [phone] www.skylinegroupintl.com

COMPONENT/TOOL
REFERENCE GUIDE
Quick & Easy to Install
The GardWalk Paver Walkway & Corner Kit system comes
with many components pre-assembled and is super quick
and easy to install while meeting rigorous requirements.
Common Tools:
CORDLESS DRIVER
SUITABLE SOCKET
ADAPTER
5/16” HEX BIT
SOCKET
17MM WRENCH
4
Support: [phone] www.skylinegroupintl.com

COMPONENT/TOOL
REFERENCE GUIDE
Common Components:
RAILS
& POSTS
1
2
PAVER FRAME
5
Support: [phone] www.skylinegroupintl.com

INSTALLATION INSTRUCTIONS
Gardwalk Paver Walkway
1 2
Lay out the base frame sections *for
corner kit assembly refer to page 10.
Align with front and rear frame
sections and bolt side mount posts to
base frame using M10x30mm bolts.
6
Support: [phone] www.skylinegroupintl.com
3Bolt side mount posts to base frame using M10x30mm bolts.

INSTALLATION INSTRUCTIONS
GardWalk Paver Walkway
7
Support: [phone] www.skylinegroupintl.com
4
5
Attach top rails to posts using x4 20mm tek screws per post. *For Manitoba installations,
trim down posts so the top rail is 1060mm from the walkway surface.
Attach mid rails to posts using x2 48mm tek screws per post.

INSTALLATION INSTRUCTIONS
GardWalk Paver Walkway
8
Support: [phone] www.skylinegroupintl.com
6
7 8
If additional walkway sections are required, assemble as per previous steps. Connect top
rails and mid rails with splice joins, fastened with x4 20mm tek screws per splice join.
For corners refer to page 10.
Overlap front and rear of adjacent
walkway frames and fasten with
x4 20mm tek screws.
At ends of walkway insert top rail
and mid rail end caps. Fasten with
one 20mm tek screw per cap.

INSTALLATION INSTRUCTIONS
GardWalk Paver Walkway
9
Support: [phone] www.skylinegroupintl.com
9
10
Insert concrete pavers into frame. *Maximum Paver size 23 5/8” x 23 5/8”
Installation Complete.

INSTALLATION INSTRUCTIONS
GardWalk Corner Kit Assembly
10
Support: [phone] www.skylinegroupintl.com
1Lay out the base frame sections. Align with front and rear frame sections and bolt using
M10x30mm bolts.
2Bolt outer side angle to base frame using M10x30mm bolts.

INSTALLATION INSTRUCTIONS
GardWalk Corner Kit Assembly
11
Support: [phone] www.skylinegroupintl.com
3
4
Align base fram with adjacent walkway sections and fasten with x4 20mm tek screws.
Insert splice joins into top and mid rails and fasten with x2 20mm tek screws.

INSTALLATION INSTRUCTIONS
GardWalk Corner Kit Assembly
12
Support: [phone] www.skylinegroupintl.com
6Insert 90 degree elbows into top and mid rails and fasten with x4 20mm tek screws per
elbow.
5Insert 90 degree elbows into top and mid rails of adjacent walkway sections and fasten
with x4 20mm tek screws per elbow.

INSTALLATION INSTRUCTIONS
GardWalk Corner Kit Assembly
7 8
Fasten top rail to posts with x2 48mm
tek screws per post.
Fasten mid rail to posts with x2
48mm tek screws per post.
13
Support: [phone] www.skylinegroupintl.com
9Installation Complete.

1. Only use system in accordance with applicable codes
and regulations.
2. An annual inspection of the system is required to ensure
that all fasteners are correctly tightened and the system is
performing correctly. Skyline Group can provide this for a
fee, upon request.
3. Installation instructions to be read in conjunction with
provided drawings.
Please note that this information is valid as of the revision date noted.
