Skytech RCAF-LMF-V
Model: RCAF-LMF-V
INSTALLATION AND OPERATING INSTRUCTIONS
SINGLE-FUNCTION WIRELESS REMOTE CONTROL SYSTEM
FOR OPERATING VALVES WITH HI/LO DC MOTOR DRIVE
INTRODUCTION
This remote control system was developed to provide a safe, reliable, and user-friendly remote control system for the AFLMF valve kit.
The system is operated manually from the transmitter. The system operates on radio frequencies (RF) within a 20-foot range using
non-directional signals. The system operates on one of 255 security codes that are programmed into the transmitter at the factory; the
remote receiver must learn the transmitter code prior to initial use.
TRANSMITTER
This remote control SYSTEM offers the user a battery-operated remote control to
power an ON/OFF latching solenoid such as the one used with the AFLMF valve
kit.
The circuit uses the battery power from the receiver to operate a HI/LO DC motor
drive. The circuit has reversing polarity software that reverses the positive (+)
and negative (-) output of the receiver's battery power to operate the DC motor
drive (ON/HI-LO-OFF FLAME). The SYSTEM is controlled by the remote
transmitter.
The transmitter operates on a 12V battery made specifically for remote controls
and electronic lighters. Before using the transmitter install the 12 volt (A-23)
battery in the battery compartment.
It is recommended that ALKALINE batteries always be used for longer battery life
and maximum operational performance.
The transmitter has ON/HI, LO and OFF functions that are activated by pressing
the button on the face of the transmitter. When a button on the transmitter is
pressed, a signal light on the transmitter illuminates to verify that a signal is being
sent. Upon initial use, there may be a delay of three seconds before the remote
receiver will respond to the transmitter. This is part of the system's design. If the
signal light does not illuminate, check the position of the transmitter's battery.
INSTALLING THE HI/LO DC MOTOR DRIVE
NOTE: The AFLMF valve kit comes with a brass cap fitting that must be removed before the HI/LO DC motor drive can be installed.
Under this brass cap fitting there is a unique safety seal that prevents gas leakage after the brass cap fitting has been removed. This
allows the brass cap fitting to be removed and the HI/LO DC motor drive to be installed with out shutting off the main gas valve that
supplies gas to the AFLMF valve kit.
1. Remove the (2) screws from the front metal faceplate then remove the faceplate on the AFLMF valve kit and set aside.
2. Using a screwdriver remove the brass cap fitting. Note Figure 1 (Retain the brass cap fitting so if the DC motor drive is
removed the brass cap fitting can be reinstalled)
3. Install the HI/LO DC motor drive into the threaded hole on the AFLMF that the brass cap fitting was removed from and
screw into place and do not over tighten. NOTE: Figure 2
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT
ATTEMPT TO INSTALL OR OPERATE
www.FireplaceRemoteControls.com
1.888.977.6849

___________________________________________________________________________________________________________
Rev. 7/10/15 Page 2 of 5
Skytech RCAF-LMF-V
4. Replace the AFLMF front original faceplate that came installed on the AFLMF with the new faceplate supplied with the
RCAF-LMF-V and reinstall the (2) screws and tighten. Note: the new faceplate has (2) large holes.
5. Make sure to locate the RED & BLACK wires so they come out the back of the AFLMF to connect to the receiver.
Figure #1 Figure #2
WIRING INSTRUCTIONS
CONNECTING THE RECEIVER TO THE AFLMF VALVE KIT WITH THE HI/LO DC MOTOR DRIVE
1. Connect the BLACK 18 gauge stranded wire with the 1/4’ female terminal from the receiver to the BLACK wire with the 1/4” male
terminals from the HI/LO Dc motor drive.
2. Connect the RED 18 gauge stranded wire with the 1/4’ female terminal from the receiver to the RED wire with the 1/4” male
terminals from the HI/LO Dc motor drive
3. After receiver wires are connected to the valve solenoid wire make sure the receiver shield is located over the receiver and then
locate the receiver in an area that will not exceed the 130° F. This location will always be away from the AFLMF towards the front of
the firebox.
IMPORTANT NOTE: Operation of these controls is dependent on which wire is attached to which terminal. If operation of control
does not correspond to operating buttons on transmitter, reverse wire installation at the receiver or at the control.
NOTE: Up to 6.3 VDC of power is provided at the receiver terminal.
www.FireplaceRemoteControls.com
1.888.977.6849

___________________________________________________________________________________________________________
Rev. 7/10/15 Page 3 of 5
Skytech RCAF-LMF-V
POWER SETTING – RCAF-LMF-V
The RECEIVER comes from the factory programmed to provide continuous DC voltage (5.5) VDC to 6.3 VDC) to the HI/LO DC motor
drive.
REMOTE RECEIVER
IMPORTANT
THE REMOTE RECEIVER SHOULD BE POSITIONED WHERE AMBIENT
TEMPERATURES DO NOT EXCEED 130° F.
The remote receiver (right) operates on four 1.5V AA-size batteries. It is
recommended that ALKALINE batteries be used for longer battery life and
maximum microprocessor performance. IMPORTANT: New or fully charged
batteries are essential to proper operation of the remote receiver as a latching
solenoid power consumption is substantially higher than standard remote control
systems.
NOTE: The remote receiver will only respond to the transmitter when the 2-position slide button on the remote receiver is in the
REMOTE position. The remote receiver houses the microprocessor that responds to commands from the transmitter to control system
operation.
FUNCTIONS:
1. With the slide switch in the REMOTE position, the system will only
operate if the remote receiver receives commands from the
transmitter. Upon initial use or after an extended period of no use, the
ON/HI button may have to be pressed for up to three seconds to
activate the motor drive. If the system does not respond to the
transmitter on initial use, see LEARNING TRANSMITTER TO
RECEIVER section.
2. With the slide in the OFF position, the system is OFF.
3. With the slide switch in the ON position (toward the LEARN button), the
receiver will manually send power for five seconds to open the motor drive. It will remain ON until the slide switch is placed in
the OFF or REMOTE position.
4. It is suggested that the slide switch be placed in the OFF position if you
will be away from your home for an extended period of time. Placing
the slide switch in the OFF position also functions as a safety "lock out"
by both turning the system OFF and rendering the transmitter
inoperative.
INSTALLATION INSTRUCTIONS
WARNING
DO NOT CONNECT REMOTE RECEIVER DIRECTLY TO 110-120VAC POWER. THIS WILL BURN
OUT THE RECEIVER. FOLLOW INSTRUCTIONS FROM MANUFACTURER OF GAS VALVE FOR
CORRECT WIRING PROCEDURES. IMPROPER INSTALLATION OF ELECTRIC COMPONENTS
CAN CAUSE DAMAGE TO GAS VALVE AND REMOTE RECEIVER.
INSTALLATION
The remote receiver can be mounted on or near the fireplace hearth. PROTECTION FROM EXTREME HEAT IS VERY IMPORTANT.
Like any piece of electronic equipment, the remote receiver should be kept away from temperatures exceeding 130º F inside the
receiver case. Battery life is also significantly shortened if batteries are exposed to high temperatures.
Make sure the remote receiver switch is in the OFF position. For best results it is recommended that 18 gauge stranded wires should
be used to make connections and no longer than 20-feet.
www.FireplaceRemoteControls.com
1.888.977.6849

___________________________________________________________________________________________________________
Rev. 7/10/15 Page 4 of 5
Skytech RCAF-LMF-V
GENERAL INFORMATION
LEARNING TRANSMITTER TO RECEIVER
Each transmitter uses a unique security code. It will be necessary to press the LEARN button on the receiver to accept the transmitter
security code upon initial use, if batteries are replaced, or if a replacement transmitter is purchased from your dealer or the factory. In
order for the receiver to accept the transmitter security code, be sure the slide button on the receiver is in the REMOTE position; the
receiver will not LEARN if the slide switch is in the ON or OFF position. The LEARN button in located on the front face of the receiver;
inside the small hole labeled LEARN. Using a small screwdriver or end of a paperclip gently press and release the black LEARN
button inside the hole. When you release the LEARN button the receiver will emit an audible “beep”. After the receiver emits the beep
press the transmitter ON/HI button and release. The receiver will emit several beeps indicating that the transmitter’s code has been
accepted into the receiver.
The microprocessor that controls the security code matching procedure is controlled by a timing function. If you are unsuccessful in
matching the security code on the first attempt, wait 1 - 2 minutes before trying again--this delay allows the microprocessor to reset its
timer circuitry--and try up to two or three more times.
TRANSMITTER WALL CLIP
The transmitter can be hung on a wall using the clip provided. If the clip is
installed on a solid wood wall, drill 1/8" pilot holes and install with the screws
provided. If it is installed on a plaster/wallboard wall, first drill two 1/4" holes into
the wall. Then use a hammer to tap in the two plastic wall anchors flush with the
wall; then install the screws provided.
OPERATION
4. This remote control will operate the gas valve DC motor drive ON/HI to open the gas flow to full ON.
5. When the ON/HI button is depressed the transmitter sends a RF signal to the receiver. The receiver then will send 5 seconds of
continuous 6 volts of power to the DC motor drive. The DC motor drive then opens the gas flow to the burner then to full ON.
6. When the LO button is pressed the receiver will send a continuous 6 volts of power to the DC motor drive for as long as the button
is pressed to lower the main burner flame.
7. When the OFF button is depressed the transmitter sends a RF signal to the receiver. The receiver then will send 5 seconds of
continuous 6 volts of power to the DC motor drive. The DC motor drive then closes the gas flow to the burner then to full OFF.
8. The remote control will only work with the hand held transmitter. The receiver slide switch is only for positive OFF or REMOTE
operation.
NOTE: Extensive use of the HI/LO DC motor drive will reduce the receiver's battery life significantly.
BATTERY LIFE
Life expectancy of the alkaline batteries in the RCAF-LMF-V can be up to 12 months depending on use of the solenoid function.
Replace all batteries annually. When the transmitter no longer operates the remote receiver from a distance it did previously (i.e., the
transmitter's range has decreased) or the remote receiver does not function at all, the batteries should be checked. It is important that
the remote receiver batteries are fully charged, providing combined output voltage of at least 5.0 volts. The transmitter should operate
with as little as 9.0 volts battery power. NOTE: Extensive use of the Solenoid will reduce the receiver's battery life significantly.
