Sloan Aqus User manual

Sloan®AQUS®Wat r Cons rvation
Syst m Installation Instructions
The Sloan®AQUS®Water Conservation
System is designed to reclaim sink water as
an alternative means for ushing toilets. It
operates with most, gravity-fed toilets.
The system prevents cross-contamination of
the fresh water system and does not interfere
with backow prevention.
The following instructions will serve as a
guide when installing the Sloan®AQUS®
Water Conservation System. As always, good
safety practices and care are recommended
during installation. If further assistance is
required, please contact your nearest Sloan
Representative ofce.
Model
HMA-7000
Code No: 0816444
Rev. 2 (05/10)
LIMITED WARRANTY
Sloan Valve Company warrants the Sloan AQUS Water Conservation System to be made of rst class materials, free from defects of material
or workmanship under normal use and to perform the service for which it is intended in a thoroughly reliable and efcient manner when
properly installed and serviced, for a period of 1 year from date of purchase. During this period, Sloan Valve Company will, at its option,
repair or replace any part or parts which prove to be thus defective if returned to Sloan Valve Company, at customer’s cost, and this shall be
the sole remedy available under this warranty. No claims will be allowed for labor, transportation or other incidental costs. This warranty
extends only to persons or organizations who purchase Sloan Valve Company’s products directly from Sloan Valve Company for purpose of
resale.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE
COMPANY RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 1

Hacksaw or metal tubing cutter
Channel lock
pliers
Philips and flathead
screwdrivers PVC tubing cutters
Pipe joint
compound
Teflon®tape
Drill
Utility knife
Tape
measure
Crescent wrench
12”
(305 mm)
PRIOR TO INSTALLATION
12
INSTALLATION
VANITY TANK AND TANK DRAIN INSTALLATION
TOOLS REQUIRED FOR INSTALLATION
Insert free end of Discharge Tubing and Control Module Wire through 7/8”
hole in vanity cabinet at back. Pull tubing from outside while sliding
Collection Tank into vanity cabinet.
Position the Collection Tank in cabinet leaving adequate room for drain
connections.
REMINDER: The center line of lavatory sink drain outlet should be minimum
of 12” above the vanity shelf.
2
Prepare the lavatory vanity before installing the
Sloan®AQUS®Water Conservation System.
Engage a certied electrician to install a 110-volt
electrical outlet inside the vanity.
Disconnect existing plumbing components
between sink pop-up and wall drain.
Drill one hole in the side of the vanity for
discharge hose and electrical wire. Drill the 7/8”
maximum hole as close to back wall and
baseboard as possible to allow for proper
coverage or tubing and wire.
Trim the threaded tailpiece to allow 1 1/4” to
extend beyond the pop-up assembly (see
illustration). Use Teon tape or pipe joint
compound on threaded portion of tailpiece before
repositioning onto pop-up assembly.
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 2

4
78
5
6
3
Install Bafe Tee onto 1 1/4" threaded tailpiece using 1 1/2" Slip oint Nut,
and 1 1/2" x 1 1/4" Slip oint Washer.
IMPORTANT: Do not tighten drain connections completely until all drain
ttings are in proper position.
Select the taller one of two threaded capped openings on Collection Tank for
Tablet Dispenser.
Unscrew Tablet Dispenser cap and remove. Insert three cleansing tablets. Replace cap.
WARNING: Read the handling instructions on Tablet package before opening.
After trimming to appropriate lengths, install waste arm to bottom of Bafe
Tee and Tablet Dispenser inlet using 1 1/2" Slip oint Nut and Slip oint
Washer. Adjust position of Collection Tank for proper t.
Connect P-Trap to the wall drain and Bafe Tee side outlet. Additional
provided ttings allow for alternative drain connections. Bafe Tee may need
to be turned to t to wall drain.
3
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 3

4
9
Tighten all drain tting joints.
10
Remove toilet tank lid.
12
Install Water Inlet Assembly to back wall of toilet tank. Attach ll tube to
stand pipe.
13
Ferrule Nut Fitting Body
Tube StopTube
(A)
NUT
(B)
PLASTIC
GRIPPER
(C)
SLEEVE
Please follow the diagrams in assembling nut.
As shown below, insert gripper (B) into nut (A).
Push sleeve (C) into nut assembly.
Installation Instructions for Jaco Tube
Fittings
Assembly Instructions for Jaco Tube
1. Cut the tubing end squarely and remove the internal and
external burrs.
2. Insert the tubing through the back of the nut all the way through
the nut assembly to the tube stop in the tting body (see
illustration). If the tubing does not enter the nut easily, loosen
the nut one turn and then insert the tubing all the way to the
tube stop in the tting body.
3. Turn the nut hand tight.
4. Wrench tighten the nut 1-1/2 to 2 turns.
5. All nuts must be retightened when the system reaches
projected operating temperature.
NOTE: Squeaking sound when tightening nut is normal. For pipe
threaded connections, Teon Tape* must be used.
NOTE: It is not necessary to disassemble this tting for application.
Merely insert tubing to stop and tighten nut.
* Dupont’s Reg. T.M. Patent 1983
11
Install Level Sensor Assembly to back of toilet tank. Adjust sensor switch to
water line. Assure that none of the components interfere with the operation
of other components.
Insert gripper (B) into nut (A). Push sleeve (C) into nut assembly. Cut the
tubing end squarely and remove the internal and external burrs. Insert the
tubing through the back of the nut all the way through the nut assembly to
the tube stop in the tting body (see illustration). If the tubing does not enter
the nut easily, loosen the nut one turn and then insert the tubing all the way
to the tube stop in the tting body. Turn the nut hand tight. Wrench tighten
the nut 1-1/2 to 2 turns. All nuts must be retightened when the system
reaches projected operating temperature.
14
Place toilet tank lid support on back edge opposite of Lid Inlet Assembly.
Replace toilet tank with lid. Adjust that the tank lid seats rmly. Adjust toilet
lid support as necessary to assure a safely seated lid.
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 4

5
TROUBLESHOOTING GUIDE
1. CONNECTIONS INSIDE VANITY WILL NOT FIT.
a. Wall drain is either not 18” off nished oor and/ or wall drain is not 12”
off wall cabinet shelf.
b. If wall drain is too low, either cut opening in vanity oor to recess reservoir
or use shallow P-Trap or alternative PVC parts.
c. If wall drain is too high, shim the tank higher.
2. PUMP IS NOISY.
Under normal operation, the sound is no louder than an icemaker or
electric shaver.
To check if pump is failing, turn water on in sink for 2-3 minutes. Flush
toilet. Has noise level reduced?
YES Continue normal operations.
NO Possible pump failure.
3. PUMP RUNS TOO LONG, TOO SHORT OR INTERMITTENTLY.
This indicates a circuit board timer failure. Call for service.
4. TOILET BOWL WATER IS DISCOLORED OR CONTAINS BUBBLES.
Colored liquids, such as coffee or cola, poured down sink will transfer to
bowl. To clear, rinse water down drain and ush toilet. Heavy usage of hand
soaps/detergents can result in bubbles. Flush a few times to dilute soaps.
5. REUSED WATER IS NOT FILLING TANK.
a. If system is unplugged, replug into wall outlet.
b. If switch on has failed, call for service.
c. If pump isn’t running; flush toilet several times to allow pump to prime, or
call for service.
d. If hose is clogged, call for service.
DO NOT pour drain unclogging products down sink. These products may
damage system.
6. TOILET WILL NOT FLUSH.
a. Fresh water supply is off. Turn on supply.
7. TOILET TANK IS SLOW TO REFILL.
Pump is intended to provide effective reused water supply at a distance of
less than 25 feet with a 4-foot head pressure. As distance exceeds 15 feet,
ll takes longer.
8. WATER IS BACKING UP INTO THE SINK.
There’s a clog in P-trap or waste line downstream from vanity tank. DO NOT
pour unclogging products down drain. These products may damage system.
Call plumber to clear obstruction.
9. THERE’S AN UNPLEASANT ODOR.
Chlorine tables have dissolved and reservoir has grown odor-causing
bacteria.
a. Turn water on in sink and pour a capful of chlorine bleach down drain to
shock odor.
b. Replace tablets.
FINAL ADJUSTMENTS
Check for any interference inside
tank.
a. Turn on lavatory faucet. Check all
connections for leaks.
b. When system is full of reused
water, plug 12 volt Transformer
into wall outlet.
c. Flush toilet to check operation.
d. Make any adjustments, as
necessary, to allow smooth
operation of Level Sensor.
ANNUAL MAINTENANCE REQUIREMENTS
Replace Cleansing Tablets
Replace the cleansing tablets annually. Replacement tablets may be
purchased from Sloan Valve Company and its representatives. Remove tablet
dispenser cap, insert three (3) tablets and resecure the dispenser cap.
Clean Filter Screen
The lter basket should be removed, rinsed and reinstalled annually. The
basket is secured in place under the lower cap. Cut the zip-tie, remove the
lter access cap and pull the basket straight up from the Collection Tank.
After the screen has been rinsed of any residue. Replace cap and resecure it
by looping a zip-tie through the tab on the side of the cap.
Snap Wall Molding
cover closed
Snap on Wall Molding
Corner Trim piece
FINISH RUNNING TUBING AND GREY CABLE THROUGH
WALL MOLDING (PURCHASED SEPARATELY)
Tuck 1/2” Polyethylene Tubing
and Fill Control Module wiring
(grey cable) into Wall Molding
channel. Pull tubing and/or wiring
into vanity as required to take up
slack.
Install Corner Trim at the vanity
end of wall channel to complete
installation of Wall Molding.
Fill Control
Module Wiring
(grey cable) from
hole in vanity
along side tubing
1/2” Polyethylene Tubing
from Vanity Tank
15
Feed enough wire to reach from the vanity to the backside of the toilet tank
and connect to Sensor Assembly.
16
Connect wires from Collection Tank (wire running from vanity) to Level
Sensor (on toilet tank). Note: Wall molding may be used to hide discharge
tubing and control module. Not supplied.
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 5

6
The information contained in this document is subject to change without notice.
Air Delights, Inc
9974 SW Arctic Dr.
Beaverton, Or. 97005
Phone: [phone] or 1-503-352-1201
Fax: [phone]
www.airdelights.com
Copyright © 2010 Sloan Valve Company
Rev. 2 (05/10)
Collection Tank/Toilet Tank Parts
Item #Part No.Description
1HMA-1-A Collection Tank Assembly
Tank Assembly, 2 Access Caps, Basket Screen, 12 VAC Power Plug with cord
½” Polythylene Tube (12 feet), Pump Cartridge Assembly, O-Rings, Tank Pad,
Screw Pan Head
2HMA-65 Disinfectant Tablets (3)
3HMA-60-A Toilet Tank Installation Kit
Water Inlet Assembly, Level Sensor Assembly, Lid Support, Wire Nuts
4HMA-55-A Drain Installation Starter Kit
Bafe Tee PVC, 2 L-Bend PVC Pipes, Straight PVC, 1½” Slip oint Washer, 1½” Slip Nut
NOTE:Cartridge Assembly can be rotated 90 degrees to adapt to the installation by removing the 4 screws hold the
Cartridge Cover. Disconnect the Tank Cover level sensor wires from circuit board (remember what terminal the wires
came from, you will need to reconnect them). Remove the Cartridge Assembly by removing the 2 screws on the
sides. Reposition the housing as needed and reassemble. Route the Level Sensor Wires through the slots in the
Cartridge and Cover.
Refer to the Sloan Water Conservation System Maintenance Guide for additional
Troubleshooting and Repair Part information.
If further assistance is required, call the Sloan Valve Company
Installation Engineering Department at
1-847-671-4300 or 1-800-9-VALVE-9.
PARTS LIST
1
4
3
see note
below
2
AQUS WCS Installat on Instruct ons 5/25/10 2:01 PM Page 6
