SMARDY HWF 300 User manual

Pre Filtre
Instruction manual EN

Contents
1. Unpacking
2. Scope of supply
3. Insertion of the filter
4. Installation
5. First commissioning
6. Consumables
7. Technical data
8. Filter change
9. Filter order
1. Unpacking
Remove all packaging material. Make sure that the filtration system does not show
any external damage.
2. Scope of supply
1. smardy HWF 300
2. CTO Filter
3. Sediment filter
4. Sediment Filtercore
5. Key for filter housing

3. Insertion of the filter
1. The housing is unscrewed clockwise with the key.
2. Remove the packaging film of the filter
3. Now insert the filter into the housing.
4. Screw down the housing counterclockwise. Attention! When closing, the housing
seal must not cant.
Activated carbon filter Sediment filter Sediment Filtercore

4. Installation
•Caution! Please check the flow direction before installation
5. Technical data
•Nominal pressure (max.) 10 bar
•Working pressure (max.) 5 bar (0.5 Mpa)
•Water temperature 55 °C
•Water flow 5000 l/h
•Connections Input: 1" internal thread and Output : 1" internal thread .
flow direction marked with arrows
Facilities:
Vent (1)
brass internal thread (2)
Filter housing (3)

7. Consumables
For your system you need the following replacement filters :
item N°
Description
Change interval
N° 4
Activated carbon filter
Every 6 months
Daily output
up to 2.000 L
N° 6
Sediment filter
Every 6 months
N° 7
Sediment Filtercore
Every 6 months
Just smardy original filters ensure a trouble-free functioning!!
6. First commissioning
•Before you open the water supply, check again that the filter housing is screwed
•The unit have to be checked for possible leaks. If required, the connections can be
retightened.
•Let the water run through the filter for approx. 10 minutes. Some coal dust can be
rinsed out. This is normal and harmless.
• Perform a Visual inspection of the unit before each use.
• Do not use uniit, if Safety devices are damaged or worn.
• Never override safety devices.
• Use the unit exclusively according to the purpose specified in this instruction
manual.
• You are responsible for security in the workspace
• The filter must be necessarily emptied before frost damage, to prevent damage
of system

8. Filter change
Recommended change interval
N° 4 6 months
N° 6 6 months
N° 7 6 months
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore
Date:
oN° 4 Activated carbon filter
oN° 6 Sediment filter
oN° 7 Sediment Filtercore

9. Filter order

smardy©
Robert-Bosch-Str. 6b
86830 Schwabmünchen
Germany
[email protected]
Zubehörlink:
https://www.amazon.co.uk/dp/B06Y177SB8
