ControlOMatic POOLWARDEN PW-Plus User manual

POOLWARDEN
Installation Manual
Including
PW-Plus and TrueDPD
Automated Pool & Spa Chemical Controller
And Data Recorder
ControlOMatic, Inc.
12659 Arbor Lane, Grass Valley, CA 95949
[phone] • www.controlomatic.com • www.poolwardentraining.com
Manuals also available at:
https://www.controlomatic.com/support/documents

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 2
IMPORTANT WARNING AND SAFETY INSTRUCTIONS 3
POOLWARDEN OVERVIEW 5
PoolWarden Plus 5
SYSTEM COMPONENTS 5
Maximum Electrical Specifications 6
Environmental Specifications 6
Certifications 6
Models and Options 7
POOLWARDEN INSTALLATION 8
Mounting PoolWarden 8
Flow Cell To Circulation Plumbing 8
Sensor Wire Connection 11
Supply 110/240 Vac Input Selection 11
Load/Equipment Connection & Installation 12
Supported Auxiliary Dry Contact Loads/Equipment 13
POOLWARDEN PLUS - Option 14
TRUEDPD FREE CHLORINE SENSOR - Option 15
TrueDPD Replacement Parts 16
POOLWARDEN REPLACEMENT PARTS 17
Table of Contents

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 3
1 READ AND FOLLOW ALL INSTRUCTIONS
2 SAVE THESE INSTRUCTIONS
3 WARNING – To reduce the risk of injury, do not permit children to
use this product
4 DANGER – Risk of injury
4.1 Replace damaged cord immediately.
4.2 Do not bury cord.
4.3 Connect to a grounded, grounding type receptacle only.
4.4 Do not use an extension cord.
5 WARNING – This product is provided with a ground-fault circuit-
interrupter at the end of the power cord. The GFCI must be tested
before each use. Turn the PoolWarden off by placing the ON/OFF
switch to the OFF position. Next, push the test button on the GFCI
and place the ON/OFF switch to the ON position. The PoolWarden
should not operate. Now push the reset button on the GFCI and the
PoolWarden should now operate normally. When the product fails to
operate in this manner, there is a ground current flowing indicating
the possibility of an electric shock. Disconnect the power until the
fault has been identified and corrected.
6 It is very important to follow the safety guidelines in this manual to
ensure safe installation and programming. Safety of any system
incorporating this equipment is the responsibility of the assembler
of the system. Upon installation, it is important to properly train all
personnel basic water quality management techniques, proper
operation and programming to anyone who operates or services
PoolWarden.
7 All applicable local installation codes and ordinances must also be
adhered to. Improper installation will create an electrical hazard
which could result in death or serious injury to pool users, installers
or others due to electrical shock, and may also cause damage to
property. The PoolWarden must be installed by a licensed or
certified electrician or a qualified pool professional:
7.1 United States: National Electrical Code (NEC), NFPA 70
7.2 Canada: Canadian Electrical Code (CEC), CSA C22.1.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 4
8 WARNING – Disconnect all power to PoolWarden prior to any
service including the main AC power and any other AC sources that
may be connected to the AUX relays. Never apply power when
PoolWarden service door is unlocked or in the open position. Only
qualified and licensed technicians should perform any service or
repair.
9 WARNING – Do not install load bearing leads and/or sensor cables
longer than 3 meters.
10 WARNING – Always mount PoolWarden in safe and dry area. Never
mount PoolWarden above any other electrical equipment.
11 WARNING – Install PoolWarden in a location that is not accessible
to the public.
12 WARNING – Pool and Spa Chemical Safety
12.1 Never mix sodium hypochlorite and muratic acid!
12.2 When mixing acid and water, always add acid to the water,
never add water to the acid.
13 CAUTION – TEST THE GROUND FAULT CIRCUIT INTERRUPTER
BEFORE EACH USE OF THE POOL/SPA
14 CAUTION – CONNECT ONLY TO A CIRCUIT PROTECTED BY A
CLASS A GROUND FAULT CIRCUIT INTERRUPTER
15 Do not dispose in trash. Please visit www.controlomatic.com
for recycling information.
1 ATTENTION: TOUJOURS VÉRIFIER L’EFFICACITÉ DU
DISJONCTEUR DIFFÉRENTIEL AVANT D’UTILISER LE BAIN
2 ATTENTION: LIRE LA NOTICE TECHNIQUE
3 AVERTISSEMENT: DÉCONNECTER DU CIRCUIT D’ALIMENTATION
ÉLECTRIQUE AVANT L’ENTRETIEN
4 ATTENTION: CONNECTER UNIQUEMENT À UN CIRCUIT PROTÉGÉ
PAR UN DISJONCTEUR DIFFÉRENTIEL DE CLASSE A
IMPORTANT WARNING AND SAFETY INSTRUCTIONS

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 5
PoolWarden measures pH, sanitizer and temperature on up to two bodies of water and will control
the appropriate feed equipment to keep the measurements within a preprogrammed range. Using ORP
(oxidation reduction potential) technology the control of sanitizer takes into account the effects of pH, and
a pH lockout feature is also included for high pH values. Controls chemical feed equipment using relays to
keep the pool or spa water in balance. Water measurements are taken continuously while PoolWarden's
internal relay programing determines if chemical adjustments are needed. PoolWarden then
communicates the adjustment signals through relays which control the chemical feed equipment.
PoolWarden also contains additional dry-contact auxiliary relays that can be used to control
heaters, pumps, chlorine backup and external alarm notifications.
PoolWarden Plus
When adding the PW-Plus communication module, the software feature set will also be updated. Where
there are differences that will be pointed out.
System Components
tCONTROLLER: PoolWarden is a microprocessor based, modular automation system that is capable of
continuous monitoring locally onsite or remotely offsite.
tINTERFACE: PoolWarden uses a 16-button built in keypad, and an easy to read 80 character liquid crystal
display. The display’s internal back-light provides controller viewing in pool rooms with low light.
tMEMORY: PoolWarden is designed with nonvolatile memory which preserves all internal programming in case
of power loss. Internal memory is preserved for up to 10 years without having power applied.
tRELAYS: PoolWarden S (single pool) includes 4 relays (2 of which are dry contact relays). PoolWarden
D (two pools) includes 8 relays. Four of the 8 relays are dry contact relays (2 for each body of water).
tSENSORS: ORP, pH, Temperature, flow and optional free chlorine.
tVOLTAGE: Requires 120VAC input voltage in North America and 240VAC input voltage in Europe.
tSECURITY: PoolWarden is designed with a lockable enclosure and provides up to four levels of password
security protection (Admin, Tech, Service and Guest) for both local onsite and remote offsite interaction with the
controller.
tCOMMUNICATION: PoolWarden can connect to the Internet for direct monitoring, setup, and data interface by
adding the PW-Plus communication module which adds WIFI and Ethernet.
tDATA: PoolWarden will record up to 8192 lines of data with the built in internal memory. There is no limit when
adding the PW-Plus communication device
tHEATERS: Auxiliary relays can control pool heaters with up to two set-points for each day to facilitate
energy management.
tPUMP CONTROL: Auxiliary relays can be setup as a simple timer for controlling the on/off state of
main pumps.
tOVERFEED PROTECTION: PoolWarden is designed with 2 types of overfeed protection. Standard overfeed
limits the amount of time a relay can turn on feed equipment in a 24-Hour period.
tPROPORTIONAL/SPAN CONTROL: Proportionally reduces the on-time as the measurement gets closer to the
set-point to prevent overshoot.
tE-MAIL ALERTS: The data server provides support for 4 email addresses and 4 phone numbers for texts.
tAUXILIARY RELAYS: Auxiliary relays can control additional / backup sanitizer or acid feed pumps.
tPRINTING: Bluetooth printing when adding the PW-Plus communication module.
tSOFTWARE UPDATING: PW-Plus supports immediate software updating over the Internet.
PoolWarden Overview

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 6
Maximum Electrical Specifications
ITEM DESCRIPTION LIMIT
Input Voltage Maximum input AC voltage 240 VAC, 50-60 Hz
Input Current Maximum input current 10 A
Relay Voltage Maximum relay voltage 240 VAC
Relay Current Maximum Relay Current 2.5 A
Fuse Rating F1 5A, 250V, 05x20
Fuse Rating F2 5A, 250V, 05x20
Fuse Rating F3 1A, 250V, 05x20
Standby Current Maximum operating current 0.1 A Max
pH Measurement of pH 4.22 to 9.98
ORP Oxidation Reduction Potential 0 to 999 mV
Free Chlorine - PPM
With optional TrueDPD sensor NSF Certified Range
0 to 6.0 PPM 10%
Free Chlorine - PPM Extended non-NSF Certified Range 6.0 to 9.5 PPM 20%
Certifications
4010758
Conforms to
UL STD 1563
Certified to CSA STD
C22.2 No. 218.1
NSF/ANSI 50 - Equipment
for Swimming Pools, Spas,
Hot Tubs and Other
Recreational Water Facilities
http://info.nsf.org/Certified/Pools/Listi
ngs.asp?Company=C0214550&Stan
dard=050&
Environmental Specifications
ITEM DESCRIPTION LIMIT
Elevation Not to be used above 2000 m
Temperature Minimum/Maximum Operating Temperature 30/110 °F
Temperature Water temperature measurement. 32 to 122 °F
IP Rating Suitable for Outdoor Use IPX3
Pollution Pollution Degree 2

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 7
ITEM DESCRIPTION
PW-SMTD PoolWarden controller with flow cell and sensors, pre-mounted white backboard
PW-DMTD Adds second pool flow cell and sensors - 2 pool control
PW+SMTD Add PW-Plus communication module to PW-SMTD
PW+DMTD Add PW-Plus communication module to PW-DMTD
PW-SFAC PW-SMTD with single pool TrueDPD free chlorine sensor
PW-DFAC PW-DMTD with 2 pool TrueDPD free chlorine sensor
PW+SFAC Adds PW-Plus communication to PW-SFAC
PW+DFAC Adds PW-Plus communication to PW-DFAC
Models and Options

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 8
Mounting PoolWarden
Turn off any heaters, pool or spa circulation systems, chemical feed pumps or any related shut-off valves
or equipment and relieve pressure from the filtration system. Find a suitable mounting location near a
120/240 VAC power source that meets the following criteria:
tFacilitates a combined (influent & effluent) maximum tubing run of 30’.
tDo not mount controller above electrical sources or electrical equipment.
tAt least 10’ away from any pool, spa or body of water and not accessible to the public.
tAway from corrosive materials including fumes and physical hazards.
tNot in direct sunlight or directly above or near any heat source.
tFor 240 VAC, ability to hard wire with GFCI (ground fault circuit interrupter) protection.
Securely mount controller, or the optional controller backboard, vertically on the wall using supplied
screws or appropriate fasteners for the wall construction. Product shall be positioned such that the power
supply cord plug, which is the disconnect device, can be easily accessible.
Flow Cell To Circulation Plumbing
There are many ways to connect the flow cell tubing to the circulation plumbing. Always make sure the
input source to the flow cell is well upstream from any chemical injection points. Successful flow cell
installation requires a pressure differential, or there will be no water flowing through the cell. The Flow
cell input should be filtered water and therefore after the filter. Never install the input to the flow cell
between the main circulation pump and filter as that will be very high pressure which may damage the
sensors and provide the most debris to the flow cell. PoolWarden is equipped with a strainer to filter out
any debris that does get past the filter. Periodically check and clean the strainer. Install the flow cell
return after the heater, there will be a pressure drop across that should be sufficient to provide flow
through the flow cell. If there is no heater, the next choice is the suction plug in the pumps strainer, make
sure to adjust the return valve on the flow cell to keep the pressure in the flow cell positive.
tFlow Cell Input: Drill & tap a connection point in the circulation system at a location just after the filter.
The best location is where there is a pipe fitting as that will provide the most threads. Install a tube
connector and run tubing to the input side of the flow cell.
tFlow Cell Output: Drill & tap a connection point in the circulation system at a location with reduced
pressure just after the heater. Install a tube connector and run tubing to the return side of the flow
cell.
CAUTION: Maximum pressure across the sensors should be 10 PSI (pressure gauge may be required).
Always expose the sensors to positive pressure. Prevent exposing the sensors to suction or a vacuum
by connecting the flow cell output tubing to the suction side of the pump as the vacuum may suck the
sensor gel from the sensors rendering the sensors inoperable in a very short period of time.
tIf not pre-mounted, find a suitable location to mount the acrylic flow cell within 3 feet of the controller.
Mount and assemble flow cell parts according to the following figures. If the TrueDPD is being
installed there will be a few additional fittings for the flow cell to connect to the TrueDPD inlet.
Remove pH (Blue) and ORP (Red) sensors from the boxes. Use Teflon tape on sensor threads and
all other flow cell parts to ensure water tight connection and fasten accordingly. REMOVE THE
SENSOR GUARDS FROM THE SENSORS!
tInstall the appropriate 1/2” or 3/8” hard vinyl input and output tubing from the pools circulation system
connection points to the “In” and “Out” connection points on the flow cell.
tOnce connected, turn circulating pump back on, test for leaks at all connection points, and make sure
all air evacuates form the tubing.
PPPoolWarden Installation

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 9

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 10

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 11
tThere is a small magnet in the flow cell that is held in place with a piece of tape. Remove the tape and
make sure the magnet remains in the hole above the filter / strainer. If using a digital flow sensor the
magnet will not be needed.
IMPORTANT NOTE: There needs to be enough flow (0.5 gpm) through the flow cell to raise the flow
magnet inside the flow cell to make contact with the flow sensor. To test this, turn the “input” shut-off valve
to the off position and watch the flow magnet drop from the flow sensor. Next, turn the input shut-off valve
back on and watch the flow magnet rise to the flow
sensor. If the flow magnet rises abruptly and
pings/knocks the flow cell acrylic then the flow is
too high. To reduce flow, perform the same
exercise, but now open the shut-off valve slowly
and stop when you see the magnet “slowly” rise to
make connection with the flow sensor. Leave the
shut-off valve in that position.
Sensor Wire Connection
If not pre-mounted, route the pH (Blue Sensor
Wires), ORP (Red Sensor Wires), flow sensor and
temp sensor wires through the cable grips at the
bottom of controller and connect as labeled inside
the controller. Note: Black wires are always
negative (-) and the Clear or Red wires are
always positive (+).
REQUIRED Flow Sensor Connections:
Connect flow sensor wires for pool #1 to flow
tOptional Flow Sensor Connections: Flow switch
2 & 4 are auxiliary switches for Pool #1 and Pool
#2 respectively. For powered 3 wire digital flow
meters or water level indicators use the 18VDC
connection on the left of the main board, note
that it has a 1 amp fuse.
Supply 110/240 Vac Input Selection
The PoolWarden supports both 110 VAC and 240 VAC. For 110 VAC the power cord includes a GFCI on
the end of the cord that plugs in. For 240 VAC the cord should be removed and the PoolWarden should be
hardwired to a circuit breaker with a GFCI by a licensed electrician. The cord can be returned to
ControlOMatic for a credit.
tVAC Selector: The red switch in the center of the bottom circuit board must have the switch notch up
for 110 VAC, and down for 240 VAC. Incorrect selection will damage the PoolWarden.
tA good solid earth ground is required for PoolWarden to work properly. Without a solid ground
connection the sensors may drift.
tThe ORP and pH relay are directly connected to the input VAC. If you have the PoolWarden set for 240
VAC then the loads must also be 240 VAC.
For 240 VAC operation, the neutral line will be connected to the Red 240 VAC wire and the Line
connection will be to the Black 240 VAC wire. The Neutral connection for pH and ORP relays switches
the Neutral input VAC wire. The relays are double pole double throw and break both lines.

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 12
Load / Equipment Connection & Installation
ORP & pH RELAYS: The chemical feed relays for pH and ORP are internally connected to the input VAC
main input which is located on the right side connector on the circuit board through 10 AMP fuses F1 and
F2. No voltage is being supplied to the load / equipment when the relay is off, hence, voltage is being
supplied to the load / equipment when the relay is on. Any standard chemical feed pump or solenoid can
be hard wired directly into the appropriate ORP and pH connection terminals as shown below in
PICTURE 4 so long as their voltage matches the input VAC connected to the PoolWarden.
Note: Minimum wire gauge for output relays is 16 gauge.
tVACBLK: Connection to the VAC black (Line) wire
tVACWHT: For 110 VAC connect to the input white neutral wire. For 240 VAC connect to the red VAC
wire.
tPH / ORP WHT: For 110 connect to the white neutral wire on the load. For 240 connect to one of the
Line connections.
tPH / ORP BLK: For 110 connect to the black line wire on the load. For 240 connect to the other Line
connection.
tPH / ORP GND ( ): Connect to the green ground wire on the load.
DRY CONTACT RELAYS: A dry contact relay is not connected to any voltage and acts as a switch. To
supply power to a load / equipment (such as a chemical pump) through any of the auxiliary dry contact
relays, the voltage must be supplied using a jumper to the main input voltage. To facilitate this jump,
PoolWarden is equipped with terminals right next to the auxiliary dry contact relay terminals labeled
VACBLK, VACWHT and GROUND ( ). Please note that these VAC terminals are after the 10 AMP
fuses F1 and F2.
Relay Board Acronyms for the Auxiliary Dry Contact Relays:
tAUX#NO1: Normally Open aux relay, side 1 of the relay
tAUX#NO2: Normally Open aux relay, side 2 of the relay
tAUX#C1: Common connection to relay # side 1.
tAUX#C2: Common connection to relay # side 2.
tGROUND ( ): Connected to the GROUND connection on the input VAC terminal.

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 13
tVACBLK: A convenient connection to the input VAC black line wire.
tVACWHT: A convenient connection to the input VAC white neutral wire.
tGROUND: A convenient connection to the green ground wire.
t
Supported Auxiliary Dry Contact Loads/Equipment:
tStandard Chemical Feed Pumps: Any Chemical Feed Pump can be connected to an Auxiliary Dry
Contact Relay as shown in PICTURE 4 on the previous page. This may be needed to set up a back up
sanitizer to the main sanitation control. A black wire 110 VAC jumper is needed to energize the dry
contact for 110 VAC operation and two jumpers for 240 VAC operation..
tChlorine Generators: A high power chlorine generator should not be powered using PoolWarden’s
internal power as it may exceed the input 2.5 AMP relay rating. Simply connect an auxiliary dry contact
to control the on/off status of the generator. When PoolWarden’s relay turns on, while the flow switch is
on, then the chlorine generator will turn on. When the relay is turned off it makes the chlorine generator
think there is no flow, and the chlorine generator will turn off.
tLoads / Equipment Using External 24 VAC (Erosion Feeders & Suction Side Cal Hypo): Solenoids are
used to control water flow through a chlorine erosion feeders and suction side cal hypo systems and
most use 24 VAC. Install a 24 VAC Transformer external to the PoolWarden and connect one of the
output leads to an AUX#C1 relay and connect the AUX DRY#NO1 to the solenoid as shown in
PICTURE 5. Connect the other 24 VAC Transformer wire to the remaining solenoid wire (C). If the 24
VAC Transformer has a an output ground wire then connect it to one of the Ground terminals on the
relay board.
tCirculation Pumps: Never connect a circulation pump directly to any of the relays inside PoolWarden.
Always use an external High-Power Relay that the Auxiliary Dry Contact Relay inside PoolWarden can
control. Please refer to the circulation pump’s manual for proper set-up and control of a variable speed
pump.
tExternal Alarms (Light or Sound): If a more noticeable alarm notification is needed beyond the red LED
on PoolWarden’s front panel, a relay can be set up to output the alarm status to an external buzzer or
light.

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 14
PoolWarden Plus - Option
When adding the PW-Plus module some steps are required to activate it. When included with the
PoolWarden it will already be activated.
tStep 1: Install the PW-Plus module, make sure the PoolWarden is off.
tStep 2: Connect the +5 power connector and the interface connector.
tStep 3: Turn the PoolWarden on.
tStep 4: Wait at lease 30 seconds before proceeding.
tStep 5: Press the down arrow from the readings screen, select enter password and enter 1927192766.
That will reconfigure the software for the PW-Plus.
tThe PW-Plus must be connected to the Internet for the time to update. Instructions are in the operation
manual.

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 15
The TrueDPD is an optional accessory that adds a free chlorine measurement. The measurement uses
the DPD method and is not affected by pH, cyanuric acid, saltwater chlorine generators or any other
variables that affect an ORP or amperiometric measurement. It interfaces with the controller using one of
the existing flow switch inputs.
Mounting: Locate a vertical section of wall space close enough to the controller so that the interface
cable can reach the controller. Attach to the wall with 4 screws. The TrueDPD must be located close to the
flow cell for the tube to reach.
When making a measurement, water will flow through the supply tube for about 20 seconds and for fresh
water to reach the sample chamber the supply tube must be as short as possible. Water from the
TrueDPD goes to the drain and does not continuously flow to keep the water fresh. With higher sample
times, the water in the tube will be less representative of the pool water as time goes on until the next
measurement.
Drain: Attach 1/2” tubing to the drain connection on the front of the measuring cell. The tube needs to be
routed through the cable grip near the front bottom center of the box. The tube end should be routed to a
waste drain that is lower than the TrueDPD and should have no obstructions. If there is no drain then a
bucket can be used but it will need to be emptied a couple times a week.
Water In: Attach a 1/4” “T” to the exit of the flow cell before the shut off valve. Attach the 1/4” NPT to barb
into the “T”. Route the inlet tube from the TrueDPD and attach to the barb. WARNING: If the pressure is
too high the tube may pop off of the barb fitting. The tube has a barb fitting on the flow cell and
inside the TrueDPD enclosure at the small pump. If inside the TrueDPD damage will occur to the
motors and circuitry.
nPool1 (PPM1) uses the lower pump on the left and Pool2 (PPM2) uses the pump on the right.
PoolWarden Interface: Connect the red interface wire to the Flow4 input on the PoolWarden display
board and the black wire to GND.
Power Supply: Plug the power supply into the power source. The power supply also supports 240 VAC.
If power source is 240 VAC then a suitable plug adapter may be needed. If there is no outlet, a short
extension cord can be used inside the controller enclosure allowing the 12V power supply to reside inside
the enclosure where it has additional protection.
TrueDPD Free Chlorine Sensor - Option

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 16
Item
Part Number Description
1 TrueDPD-DPD 18 gr DPD powder with 0.75ml measuring spoon -
2 TrueDPD-MAG Stirring motor magnet
3 TrueDPD-Tube-Pk Set of 3 replacement peristaltic tubes for the TrueDPD pumps
4 TrueDPD-KFS-HB1 Small peristaltic pump for the TrueDPD, 12 vdc
5 TrueDPD-Stir-MTR TrueDPD Stirring motor assembly, 12 vdc
6 TrueDPD-Tubing Silicon tubing, 1/4” OD x 1/8” ID
7 TrueDPD-Flow-Cell TrueDPD machined flow cell block
8
TrueDPD-Bottle-?oz
Reagent bottle, sizes are 4, 8 and 16 oz
9 TrueDPD-Injector Injector assembly, keeps DPD separate from the sample water
10
TrueDPD-Barbset-S
Set of the tube barb fittings for single pool version, with clamps.
11
TrueDPD-Barbset-D
Set of the tube barb fittings for two pool version, with clamps
12 TrueDPD-Kit-S 2’ Silicon tubing, tube barbs for single pool, injector and 2 pump tubes
13 TrueDPD-Kit-S 4’ Silicon tubing, tube barbs for two pool, injector and 3 pump tubes
TrueDPD Replacement Parts

PoolWarden Manual • www.poolwardentraining.com • 530-205-4520 • 17
PoolWarden Replacement Parts
Item
Part Number Type Description
1 ORP-COMP Sensor ORP Sensor, platinum band, red sensor body
1 ORP-COMG Sensor ORP Sensor, gold disk for salt water chlorinators
2 PH-COM1 Sensor PH Sensor, blue sensor body
3 PW-T10K-3ft Sensor Temperature sensor, 3 foot cable
4 PW-Flow3 Sensor Flow sensor detector, 3 foot cable
5 PW-FlowCell-MAG Sensor Flow sensor magnet
6 PW-Strainer Flow Cell Inlet water strainer with stainless steel screen
6
PW-Strainer-Screen
Flow Cell Stainless steel screen for inlet water strainer
7 1250-070-01 Flow Cell 1/4" FNPTxFNTP, SMC 2-Way Ball Valves
8 1250-080-01 Flow Cell 1/4" Ball Valve FNPT x MNPT, SMC
9 1250-100-01 Flow Cell 1/4" NPT, PP Threaded Nipple
10 2070-010-01 Flow Cell Machined PoolWarden flow cell acrylic block
11 PW-Plus Circuit Board Plus communication module
12 2370-020-07 Circuit Board PoolWarden motherboard
13 2370-130-06 Circuit Board PoolWarden sensor card dual pool
13 2370-050-06 Circuit Board PoolWarden sensor card single pool
14 2570-080-01 Cable Motherboard to relay board interconnect cable
15 2370-120-10 Circuit Board PoolWarden dual pool relay board (8 relays)
15 2370-040-10 Circuit Board PoolWarden single pool relay board (4 relays)
16 1020-080-01 Cable Cable grip, 1/2" NPT (.23-.47"), GRAY, bottom row
16 1020-070-01 Cable Cable grip, 3/8" NPT (.20-.39"), GRAY, top row
17 1350-010-01 Switch PoolWarden only, on / off switch - 20 amp
