SMART-AVI UUX-PLUS User manual

WUXGA Video amd USB
Keyboard & Mouse Splitter
and Extender over CAT5
EXTEND AND SPLIT WUXGA
VIDEO AND USB 1.1 KEYBOARD
AND MOUSE UP TO 500 FEET
OVER CAT5 CABLE
Quick Start Guide
VIDEO
Bandwidth 400MHz
Analog Signal Level 1 Volt
Input Interface 3 RCA RGB
Output Interface RJ45
Format YPbPr analog component video
AUDIO
Bandwidth 20 Hz
Signal Level 0dB
Impedance 10K ohms
Input Interface RCA Left and Right
OTHER
System Cable CAT5 UTP EIA 568A
Power 5V DC @ 1A
Dimensions 5.25”W x 1”H (3U) x 3.5”D
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
UX-PLUS
WHAT’S IN THE BOX
PART NO. Q-TY DESCRIPTION
UX-TXPLUS 1 WUXGA, USB 1.1, CAT5
Transmitter
UX-RXPLUS 1 WUXGA, USB 1.1, CAT5
Receiver
PS5VD2A-WMT 2 PS5VD2A Power Supply
Quick Start Guide 1

ABOUT UX-PLUS
The UX-PLUS is a cross-platform WUXGA and USB KVM
switch capable of sharing one computer between two
consoles, one local and one remote.
FEATURES
• Supports WUXGA video extension for resoluons
up to 1920 x 1200
• Local WUXGA output for a local display
• Plug and play, no soware required
• Fully compliant with USB 1.1 specicaons
for Keyboard and Mouse
• Built-in skew compensaon
• Uses a single CAT5 UTP cable up to 500 feet
• External power adapter for transmier and receiver
unit
• Fully transparent (does not use any emulaon)
APPLICATION
• Security
• PC Networking
• Conference Center Systems
• Point of Sale
• Camera Surveillance
• Video Phone
• Control Room Systems
• Recording Studio
• PC KVM Extension
• MAC Keyboard Mouse Extender
1. Turn off the computer and displays
2. Connect the VGA/USB cable from the computer into the VGA/USB connector on the UX-PLUS transmitter
3. Connect the local display to the VGA connector on the UX-PLUS transmitter.
4. Connect the local USB keyboard and mouse to the USB connectors on the UX-PLUS transmitter.
5. Connect the remote display to the VGA connector on the UX-PLUS receiver
6. Connect the remote USB keyboard and mouse to the USB connectors on the UX-PLUS receiver.
7. Connect the power cord to both the UX-PLUS transmitter and receiver.
8. Power on the computers and the display
UX-TXPLUS FRONT
UX-TXPLUS BACK UX-RXPLUS BACK
UX-RXPLUS FRONT
HARDWARE INSTALLATION
VGA/USB IN
VGA OUT
USB OUT
CAT5/6
500 ft
UX-PLUS-TX UX-PLUS-RX
