SMART-AVI SM-DVN Series User manual

Advanced 4/8 DVI-I Matrix KVM 1
1-800-284-2131
www.smartavi.com
USER MANUAL
Advanced 4/8-Port DVI-D matrix KVM
SM-DVN-44X 4-Port DVI-D KVM Matrix, 4 Users
SM-DVN-82X 8-Port DVI-D KVM Matrix, 2 Users
SM-DVN-84X 8-Port DVI-D KVM Matrix, 4 Users
SM-DVN matrix series

Advanced 4/8 DVI-I Matrix KVM 2
TECHNICAL SPECIFICATIONS_____________________________________________________________ 3
WHAT’S IN THE BOX?_____________________________________________________________________ 4
SM-DVN FRONT AND REAR_______________________________________________________________ 4
INSTALLATION____________________________________________________________________________ 5-8
LED’s BEHAVIOR__________________________________________________________________________ 11
SYSTEM OPERATION______________________________________________________________________12
TROUBLESHOOTING______________________________________________________________________ 12
TECHNICAL SUPPORT_____________________________________________________________________12
LIMITED WARRANTY STATEMENT________________________________________________________ 13
Table of contents

Advanced 4/8 DVI-I Matrix KVM 3
VIDEO
Format DVI-I Dual Link
Host Interface SM-DVN-44X (4) DVI-I 29-pin (female) / DVI-D
SM-DVN-82X / SM-DVN-84X (8) DVI-I 29-pin (female) / DVI-D
User Console
Interface
SM-DVN-82X (2) DVI-I 29-pin (female) / DVI-D
SM-DVN-44X / SM-DVN-84X (4) DVI-I 29-pin (female) / DVI-D
Max Resoluon 2560 x 1600 @ 60Hz; 3840x2160 @ 30Hz (w/HDMI-to-DVI adapter)
DDC 5 volts p-p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20 .
Output Cable Length Up to 20 .
AUDIO
Input (4) / (8) Connector Stereo 3.5mm Female
Output (2) / (4) Connector Stereo 3.5mm Female
CONTROL
Front Panel Push Buons with LED indicators
RS232 Via Serial @ 115200 bps
Hot Keys Via Keyboard
POWER
Power Requirements
SM-DVN-44X 12V DC, 2A (minimum) power adapter with center-pin posive polarity.
SM-DVN-82X /
SM-DVN-84X 12V DC, 3A (minimum) power adapter with center-pin posive polarity.
ENVIRONMENT
Operang Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
OTHER
Emulaon Keyboard, Mouse and Video
Control Front Panel Buons
Technical Specifications
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Type A to B SM-DVN-44X (4)
SM-DVN-82X / SM-DVN-84X (8)
User Console Interface (2) USB Type-A for keyboard and mouse connecon only

Advanced 4/8 DVI-I Matrix KVM 4
SM-DVN Unit 4/8-port DVI-D Matrix KVM
PS12VDC2A or
PS12VDC3A
12V DC, 2A (minimum) power adapter with center-pin posive polarity or
12V DC, 3A (minimum) power adapter with center-pin posive polarity.
User Manual
What’s in the box?
SM-DVN-84X rear
SM-DVN-84X front
SM-DVN-44X rear
SM-DVN-44X front

Advanced 4/8 DVI-I Matrix KVM 5
1. Ensure that power is turned o or disconnected from the unit and the computers.
2. Use a DVI cable to connect the DVI output port from each computer to the
corresponding DVI-D IN ports of the unit.
3. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the
respecve USB ports of the unit.
4. Oponally, connect a stereo audio cable (3.5mm to 3.5mm) to the audio output of each
computer to the AUDIO IN ports of the unit.
5. For each user, connect a monitor to each DVI-D OUT console port of the unit using
DVI cables.
6. For each user, connect a USB keyboard and mouse to the two USB console ports.
7. Oponally, for each user, connect stereo speakers to the AUDIO OUT ports of the unit.
8. Finally, power on the KVM by connecng a 12VDC power supply to the power
connector, and then turn on all the computers.
Note: You can connect up to 8 computers to the 8 port KVM and up to 4 computers to the 4 port
KVM.
installation
SM-DVN-44X Shown

Advanced 4/8 DVI-I Matrix KVM 6
Installation (continued)
SM-DVN-84X Shown

Advanced 4/8 DVI-I Matrix KVM 7
Installation (continued)
EDID Learn:
The KVM is designed to learn the connected monitor’s EDID upon power up. In the event of
connecng a new monitor to the KVM, a power recycle is required.
The KVM will indicate to the user that the EDID learn process is ongoing by ashing the LED next to
DVI OUT port 1. When the LEDs stop ashing, the EDID learn process is done.
The monitor must be connected to the video output connector located in the console space at the
back of the KVM during the EDID learn process.
If the read EDID from the connected monitor is idencal to the current stored EDID in the KVM then
the EDID learn funcon will be skipped unless the force learn EDID process is used. To force learn
the EDID, hold down the First and Last CAC buons of Front Panel for 3 seconds to force Learn

Advanced 4/8 DVI-I Matrix KVM 8
System operation
There are three ways to control the SM-DVN: Keyboard Hotkeys, RS-232 Serial Commands, and
Front Panel Buons. All modes of control will allow the user the set their desired conguraons.
front panel control
To switch to an input port for a given console, push the UP or DOWN buons as many mes as
needed to navigate to the desired channel. The channel number indicator will display to selected
channel for each console.
By default, the unit will start in View Mode, indicated by a red LED above the CAC buon on the
front panel. In View Mode, keyboard and mouse funconality are disabled. Control Mode enables full
keyboard and mouse funconality.
hotkey and rs232 serial control
The SM-DVN may also be controlled via RS-232 commands. To use these commands, you must use
HyperTerminal or an alternave terminal applicaon. The sengs for the connecon are as follows:
Baudrate 115200; Data Bits 8; Parity None; Stop Bits 1; Flow Control None.
Once you have connected to the SM-DVN via Serial, you will see the SM-DVN informaon when the
device starts up.
The following commands can be used for RS-232 with available keyboard hotkeys:
Command Descripon HotKey RS-232 Command
Switch all USB devices and
Main video
[CTRL][CTRL] c [port #]
[ENTER]
//c[user #] [port #]
[ENTER]
Switch Channel View Only [CTRL][CTRL] v [port #]
[ENTER]
//v[user #] [port #]
[ENTER]
Learn EDID [CTRL][CTRL] e [ENTER] //e[ENTER]
Trigger Hotplug [CTRL][CTRL] h [ENTER] //h[ENTER]
Reset Soware [CTRL][CTRL] r [ENTER] //r[ENTER]
View Current Hotkey N/A //hk [ENTER]

Advanced 4/8 DVI-I Matrix KVM 9
Custom hotkey triggers
Users are able to customize the keys that trigger Hotkeys. The default trigger for hot key funcon on
the Keyboard is Ctrl +Ctrl. The trigger funcon can be used to change to double Ctrl, Shi, or Scroll
Lock.
To view hotkey trigger seng:
Type on Keyboard: Alt + Alt + Alt + k + 0 + [Enter]
The LED Light on the user’s keyboard will Flash indicang which trigger is currently acve
Num Lock LED ash indicates CTRL
Caps Lock LED ash indicates Shi
Scroll Lock LED ash indicates Scroll Lock
To change the hotkey trigger seng:
Hotkey trigger twice + k + [1 | 2 | 3]
1 - Ctrl
2 - Shi
3 - Scroll Lock
Example: If the hotkey trigger is Shi and would like to change to Scroll Lock,
Type: Shi + Shi + k + 3

Advanced 4/8 DVI-I Matrix KVM 10
User Console Interface – Display LED:
Front Panel – Port Selecon LED’s:
EDID Learn - Front Panel LED’s:
All LED’s are turned on for 1 second. Then:
 Port 1 LED’s will ash unl the end of the process.
#Status Descripon
1O Monitor is not connected
2On Monitor is connected
3Flashing (back panel) EDID problem – Learn EDID to x the problem
#Status Descripon
1Red View Mode
2Green Control Mode
Led’s behavior

Advanced 4/8 DVI-I Matrix KVM 11
System operation
Front Panel Control
Below is a list of commands sent through buon presses on the front panel. Refer to diagram below
for the names of buons:
 Press CAC buon - Toggle between Control and View mode
 Press UP buon - Increment current channel, loop back to 1 aer ch. 8
 Press DOWN buon - Decrement current channel, loop back to 8 aer ch. 1
 Press and hold the CAC buon, then press the UP buon - enables CAC mode only when
user is already in control mode
 Press and hold the CAC buon, then press the DOWN buon - disables the display and
KM control for that user.
Close-up of the Front Panel controls for the matrix series.

Advanced 4/8 DVI-I Matrix KVM 12
Troubleshooting
No Power
 Make sure that the power adapter is securely connected to the power connector of the
unit.
 Check the output voltage of the power supply and make sure that the voltage value is
around 12VDC.
 Replace the power supply.
No Video
 Check if all the video cables are connected properly.
 Connect the computer directly to the monitor to verify that your monitor and computer
are funconing properly.
 Restart the computers
Keyboard is not working
 Check if the keyboard is properly connected to the unit.
 Check if the USB cables connecng the unit and the computers are properly connected.
 Try connecng the USB on the computer to a dierent port.
 Make sure that the keyboard works when directly connected to the computer.
 Replace the keyboard.
Mouse is not working
 Check if the mouse is properly connected to the unit.
 Try connecng the USB on the computer to a dierent port.
 Make sure that the mouse works when directly connected to the computer.
 Replace the mouse.
No Audio
 Check if all the audio cables are connected properly.
 Connect the speakers directly to the computer to verify that the speakers and the comput-
er audio are funconing properly.
 Check the audio sengs of the computer and verify that the audio output is through the
speakers.
Technical support
For product inquiries, warranty questions, or technical questions, please contact [email protected].

Advanced 4/8 DVI-I Matrix KVM 13
Limited warranty statement
A. Extent of limited warranty
SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specied above will be
free from defects in materials and workmanship for the duraon of 1 year, which duraon begins on
the date of purchase by the customer. Customer is responsible for maintaining proof of date of
purchase.
SmartAVI limited warranty covers only those defects which arise as a result of normal use of the
product, and do not apply to any:
a. Improper or inadequate maintenance or modicaons
b. Operaons outside product specicaons
c. Mechanical abuse and exposure to severe condions
If SmartAVI receives, during applicable warranty period, a noce of defect, SmartAVI will at its
discreon replace or repair defecve product. If SmartAVI is unable to replace or repair defecve
product covered by the SmartAVI warranty within reasonable period of me, SmartAVI shall refund
the cost of the product.
SmartAVI shall have no obligaon to repair, replace or refund unit unl customer returns defecve
product to SmartAVI.
Any replacement product could be new or like new, provided that it has funconality at least equal to
that of the product being replaced.
SmartAVI limited warranty is valid in any country where the covered product is distributed by
SmartAVI.
B. Limitaons of warranty
To the extant allowed by local law, neither SmartAVI nor its third party suppliers make any other
warranty or condion of any kind whether expressed or implied with respect to the SmartAVI
product, and specically disclaim implied warranes or condions of merchantability, sasfactory
quality, and tness for a parcular purpose.
C. Limitaons of liability
To the extent allowed by local law the remedies provided in this warranty statement are the
customers sole and exclusive remedies.
To the extant allowed by local law, except for the obligaons specically set forth in this warranty
statement, in no event will SmartAVI or its third party suppliers be liable for direct, indirect, special,
incidental, or consequenal damages whether based on contract, tort or any other legal theory and
whether advised of the possibility of such damages.
D. Local law
To the extent that this warranty statement is inconsistent with local law, this warranty
statement shall be considered modied to be consistent with such law.

Advanced 4/8 DVI-I Matrix KVM 14
NOTICE
The informaon contained in this document is subject to change without noce. SmartAVI
makes no warranty of any kind with regard to this material, including but not limited to,
implied warranes of merchantability and tness for parcular purpose. SmartAVI will not be
liable for errors contained herein or for incidental or consequenal damages in connecon
with the furnishing, performance or use of this material. No part of this document may be
photocopied, reproduced, or translated into another language without prior wrien consent
from SmartAVI, Inc.
20180109
Tel: (800) AVI-2131 • [phone]
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
www.smartavi.com
