Smart Bridge 9500N-000 User manual

【Quick Install Guide : Smart Bridge 9500N-000 Quick Temperature Detector】
1 QIG-QTM 0.0.1-001 06-2020 / v1.0
➢Product Contents
The contents of the 9500N-000 quick temperature detector includes the
following objects:
-9500N-000 quick temperature detector x1 set
-USB power cord x 1 cable
-USB Power Supply 110/240V to 5V USB output x 1 set
-3M double-sided sticker x1
➢Prepare Before Use
1. Please take out the quick temperature detector and 3M double-sided
glue sticker then paste to the position you want. Plug in the USB
power cord and connect to the power supply.
2. After power-on, OLED-screen will display the booting- screen about
5 to 10 seconds. Enter to temperature measurement mode directly
after the display is off.
➢Settings
Three different mode for setting temperature、temperature unit and alarm
sound sequentially. Holding the button with different time for different
setting:
1. Alarm temperature adjustment: Hold the button then release it while OLED
displays 3~5 to enter the setting. (Default: 37.5℃)
2. Celsius/Fahrenheit adjustment: Hold the button then release it while OLED
displays 6~9 to enter the setting. (Default: Celsius)
3. Alarm sound adjustment: Hold the button then release it while OLED
displays 9~11 to enter the setting. (Default: Speaker On)
Setup:
1. Press the side-button until OLED displays “3” then release. Display such
as 37.0, press again to 37.1 and so on. When the system detects no
further pressing within 3 seconds, the current temperature the alarm
temperature threshold. (Figure 1)
2. Press the side-button until OLED displays “6” then release. Display such
as ℃ and press again for ℉. When the system detects no further
pressing within 3 seconds, use the current temperature unit. (Figure 2)
3. Press the side-button until OLED displays “9” then release. Display such
as “Speaker On” and press again for “Speaker Off”. When the system
detects no further pressing within 3 seconds, use the current alarm sound
setting. (Figure 3)
➢Measurement
1. The forehead is about 30-50 cm from the center of
the sensor.
2. Temperature measurements can be obtained 3 seconds later
(Figure 4)
3. Get your temperature correctly and you'll hear Bi sound
◼If the temperature is measured higher than setting
value, you will hear the “Bi Bi Bi” sound.
◼If the temperature is lower than setting value, you will
only hear a beep.
Remarks
1. The product of quick temperature detector cannot work under the
sunshine. For outdoor usage, it is recommended to set up a scaffold,
block ingenuity to the sun. When the sun shines directly, the hair quickly
absorbs the sun energy. Therefore the body temperature will pull up
and, do not measure the temperature at this time.
2. The ambient temperature need to be controlled between 15 to 35
degrees Celsius. Too low, or too high, measured body temperature has
been unable to refer. Please control the ambient temperature in order
to get the correct body temperature.
37.0
37.1
37.2
37.3
37.4
37.5
37.6
37.7
37.8
37.9
38.0
Figure1
Figure2
Figure3

【Quick Install Guide : Smart Bridge 9500N-000 Quick Temperature Detector】
2 QIG-QTM 0.0.1-001 06-2020 / v1.0
3. Into different environment: When a person enters the room from
outside, if the temperature gap between the two is too large, it needs to
be delayed by about 5 minutes, in the test temperature. For example,
outdoor is 35 degrees Celsius, directly into the room for 25 degrees
Celsius condition, Detect temperature immediately, the temperature will
be incorrect. For fast temperature detector, it is recommended to
power-on 5 minutes for warn up the system. Then, the detector could
be work in normal.
This product is mainly to detect the temperature of the forehead.
Other parts of the human body, the test will be incorrect. Chinese
website: http://www.smartbridge-info.com / English Website:
http://www.smartbridge-tech.com
