SMART RTM-ATCA-F140 Series Quick start guide

RTM-ATCA-F140 Series
Installation and Use
P/N: 6806800M97L
September 2019

© 2019 SMART Embedded Computing™, Inc.
All Rights Reserved.
Trademarks
The stylized "S" and "SMART" is a registered trademark of SMART Modular Technologies, Inc. and “SMART Embedded
Computing” and the SMART Embedded Computing logo are trademarks of SMART Modular Technologies, Inc. All other names
and logos referred to are trade names, trademarks, or registered trademarks of their respective owners. These materials are
provided by SMART Embedded Computing as a service to its customers and may be used for informational purposes only.
Disclaimer*
SMART Embedded Computing (SMART EC) assumes no responsibility for errors or omissions in these materials. These
materials are provided "AS IS" without warranty of any kind, either expressed or implied, including but not limited to,
the implied warranties of merchantability, fitness for a particular purpose, or non-infringement. SMART EC further does
not warrant the accuracy or completeness of the information, text, graphics, links or other items contained within these
materials. SMART EC shall not be liable for any special, indirect, incidental, or consequential damages, including without
limitation, lost revenues or lost profits, which may result from the use of these materials. SMART EC may make changes to
these materials, or to the products described therein, at any time without notice. SMART EC makes no commitment to update
the information contained within these materials.
Electronic versions of this material may be read online, downloaded for personal use, or referenced in another document as a
URL to a SMART EC website. The text itself may not be published commercially in print or electronic form, edited, translated,
or otherwise altered without the permission of SMART EC.
It is possible that this publication may contain reference to or information about SMART EC products, programming, or services
that are not available in your country. Such references or information must not be construed to mean that SMART EC intends
to announce such SMART EC products, programming, or services in your country.
Limited and Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply
unless otherwise agreed to in writing by SMART Embedded Computing.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (b)(3) of the Rights in
Technical Data clause at DFARS 252.227-7013 (Nov. 1995) and of the Rights in Noncommercial Computer Software and
Documentation clause at DFARS 252.227-7014 (Jun. 1995).
SMART Embedded Computing, Inc.
2900 S. Diablo Way, Suite 190
Tempe, Arizona 85282
USA
*For full legal terms and conditions, visit www.smartembedded.com/ec/legal

Table of Contents
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 3
About this Manual ...............................................................11
Safety Notes....................................................................15
Notice de Sécurité...............................................................23
Sicherheitshinweise .............................................................31
1 Introduction.................................................................39
1.1 Overview ...............................................................39
1.2 Features ...............................................................39
1.3 Standard Compliances ....................................................40
1.4 Mechanical Data .........................................................41
1.5 Ordering and Support Information ...........................................42
2 Hardware Preparation and Installation ...........................................43
2.1 Overview ...............................................................43
2.2 Unpacking and Inspecting the RTM ..........................................43
2.3 Environmental and Power Requirements ......................................44
2.3.1 Environmental Requirements..........................................44
2.4 RTM Installation and Removal ..............................................46
2.4.1 Installing the RTM ................................................46
2.4.2 Removing the RTM .................................................48
3 Controls, LEDs, and Connectors ...............................................51
3.1 Overview ...............................................................51
3.2 Face Plate Connectors and LEDs ...........................................51
3.2.1 LEDs ............................................................52
4 Functional Description........................................................53
4.1 Block Diagram .........................................................53
4.2 Management Resources ...................................................53
4.2.1 FRU Serial EEPROM................................................54

4 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Table of Contents
4.2.2 Temperature Sensors ...............................................54
4.2.3 LEDs ............................................................54
4.2.4 I2C Address Map ...................................................55
4.3 1Gbps SFP Ports ........................................................56
4.3.1 Connectivity .......................................................56
4.3.2 Front Blade Port Mapping ............................................56
4.3.3 SFP Connection....................................................56
4.3.3.1 I2CBus...................................................57
4.3.3.2 SFP Status Signals .........................................57
4.3.3.3 SFP Control Signals .........................................57
4.4 10Gbps SFP+ Ports ......................................................57
4.4.1 Connectivity .......................................................58
4.4.2 Front Blade Port Mapping ............................................58
4.4.3 BCM8727 Configuration Flash.........................................58
4.4.4 Transmitter Control .................................................58
4.4.5 BCM8727 Status ...................................................59
4.4.6 SFP+ Connection...................................................59
4.4.6.1 I2CBus...................................................59
4.4.6.2 SFP+ Status Signals ........................................60
4.4.6.3 SFP Control Signals .........................................60
4.4.6.4 PHY Management Interfaces ..................................60
4.5 10Gbps Fabric Ports ......................................................60
4.5.1 Fabric Connectivity..................................................61
4.5.2 Fabric Front Blade Port Mapping .......................................61
4.5.3 BCM84754 Configuration Flash........................................61
4.5.4 Transmitter Control .................................................61
4.5.5 BCM84754 Status ..................................................62
4.5.6 Fabric SFP+ Connection .............................................62
4.5.6.1 SFP+ I2CBus..............................................62
4.5.6.2 SFP+ Status Signals ........................................62
4.5.6.3 SFP+ Control Signals ........................................62
4.5.7 PHY Management Interfaces..........................................63
4.6 40Gbps Fabric Ports ......................................................63
4.6.1 Fabric Connectivity..................................................63
4.6.2 Fabric Front Blade Port Mapping .......................................64
4.6.3 BCM84740 Configuration Flash........................................64
4.6.4 Transmitter Control .................................................64
4.6.5 BCM84740 Status ..................................................65

Table of Contents
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 5
4.6.6 Fabric QSFP+ Connection ............................................65
4.6.6.1 QSFP+ I2CBus ............................................66
4.6.6.2 QSFP+ Status Signals .......................................66
4.6.6.3 QSFP+ Control Signals ......................................66
4.6.7 PHY Management Interfaces..........................................66
4.7 GPS Connectors .........................................................67
4.8 FPGA .................................................................67
4.8.1 Front Blade Interface ................................................67
4.8.2 SFP/SFP+/QSFP+ Control and Status ..................................68
4.8.3 BCM8727 Control and Status .........................................68
4.8.4 BCM84754 Control and Status ........................................69
4.8.5 BCM84740 Control and Status ........................................69
4.8.6 Reset Handling.....................................................69
4.8.7 SPI Flash .........................................................69
4.8.8 FPGA Configuration.................................................70
4.9 Reset Scheme ..........................................................70
4.10 Power Management ......................................................70
4.10.1 Power Requirements ................................................71
A RTM-ATCA-F140-D Information.................................................73
A.1 RTM-ATCA-F140-D Overview ..............................................73
A.2 Mechanical .............................................................73
A.2.1 RTM Installation ...................................................75
A.3 Ordering and Support Information ...........................................77
B Related Documentation .......................................................79
B.1 SMART Embedded Computing Documentation .................................79

6 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Table of Contents

List of Figures
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 7
Figure 3-1 Face Plate .......................................................51
Figure 4-1 Block Diagram ....................................................53
Figure 4-2 1GB Base Channel Interconnect ...................................... 56
Figure 4-3 Fabric 10GB Interconnect ...........................................58
Figure 4-4 Fabric 10Gb Interconnect ...........................................61
Figure 4-5 Fabric 40Gb Interconnect ...........................................64
Figure A-1 Location of Zone 3 Attachment Block and Captive Screw ...................73
Figure A-2 Face Plate of the RTM-ATCA-F140-D ..................................74
Figure A-3 Upper and Lower Handles ........................................... 75
Figure A-4 Upper and Lower Handle Locking Mechanisms ..........................76
Figure A-5 Captive Screw from the RTM-ATCA-F140-D .............................77

8 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Table of Contents

List of Tables
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 9
Table 1-1 Standard Compliance .................................................40
Table 1-2 RTM-ATCA-F140 Mechanical Data .......................................41
Table 2-1 Environmental Requirements ...........................................45
Table 4-1 Temperature Sensor Thresholds .........................................54
Table 4-2 PCF 8574 Port Usage .................................................55
Table 4-3 I2C Bus Address Map .................................................55
Table 4-4 Front Blade Port Mapping ..............................................56
Table 4-5 SFP Connector Pin Assignment .........................................57
Table 4-6 SFP+ Connector Pin Assignment ........................................59
Table 4-7 BCM8727 PHY Addressing .............................................60
Table 4-8 BCM84754 PHY Addressing ............................................63
Table 4-9 QSFP+ Connector Pin Assignment .......................................65
Table 4-10 BCM84740 PHY Addressing ............................................66
Table 4-11 FPGA Configuration Controls ...........................................70
Table 4-12 Power Requirements ..................................................71
Table B-1 SMART EC Publications ...............................................79

List of Tables
10 RTM-ATCA-F140 Series Installation and Use (6806800M97L)

RTM-ATCA-F140 Series Installation and Use (6806800M97L) 11
About this Manual
Overview of Contents
This manual is divided into the following chapters and appendices.
Safety Notes on page 15 summarizes the safety instructions in the manual.
Notice de Sécurité on page 23 is a European French translation of the Safety Notes section.
Sicherheitshinweise on page 31 is a German translation of the Safety Notes section.
Chapter 1, Introduction on page 39 describes the main features of the RTM-ATCA-F140.
Chapter 2, Hardware Preparation and Installation on page 43 describes the installation
prerequisites and the installation itself.
Chapter 3, Controls, LEDs, and Connectors on page 51 describes external interfaces such
as connectors and LEDs.
Chapter 4, Functional Description on page 53 contains a block diagram of the rear transition
module (RTM) and provides information on the IPMI functionality of the RTM.
Appendix A, RTM-ATCA-F140-D Information on page 73 contains information specific to
the RTM-ATCA-F140-D.
Appendix B, Related Documentation on page 79 lists SMART Embedded Computing user
manuals that are related to the RTM and the ATCA-F140.
Abbreviations
This document uses the following abbreviations:
Abbreviation Definition
AMC Advanced Mezzanine Card
ATCA Advanced Telecom Computing Architecture
BIX Base Interface Switch
EEPROM Electrically Erasable Programmable Read-Only Memory
FET Field-effect Transistor
FPGA Field-programmable Gate Array
FRU Field Replaceable Unit
FIX Fabric Interface Switch
IPMC Intelligent Platform Management Controller
LED Light-emitting Diode

12 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
About this Manua
l
REVIEW DRAFT 1
About this Manual
Conventions
The following table describes the conventions used throughout this manual.
MDC Management Data Clock
MDIO Management Data Input/Output
MMC Module Management Controller
PHY Physical Layer
PICMG PCI Industrial Computer Manufacturers Group
PCI Peripheral Component Interconnect
QSFP+ Quad Small Form-factor Pluggable Plus
RTM Rear Transition Module
SFP Small Form-factor Pluggable
SFP+ Small Form-factor Pluggable Plus
SPI Serial Peripheral Interface
TOD Time of Day
UART Universal Asynchronous Receiver/Transmitter
Abbreviation Definition
Notation Description
0x00000000 Typical notation for hexadecimal numbers (digits are 0 through F), for example used
for addresses and offsets
0b0000 Same for binary numbers (digits are 0 and 1)
bold Used to emphasize a word
Screen Used for on-screen output and code related elements or commands in body text
Courier +
Bold Used to characterize user input and to separate it from system output
Reference Used for references and for table and figure descriptions
File > Exit Notation for selecting a submenu
<text> Notation for variables and keys
[text] Notation for software buttons to click on the screen and parameter description
... Repeated item for example node 1, node 2, ..., node 12

About this Manual
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 13
.
.
.
Omission of information from example/command that is not necessary at the time
being
.. Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in
registers)
| Logical OR
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injury
Indicates a property damage message
Indicates a hot surface that could result in moderate or serious injury
Indicates an electrical situation that could result in moderate injury or death
Indicates that when working in an ESD environment care should be taken to use
proper ESD practices
No danger encountered. Pay attention to important information
Notation Description

14 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
About this Manua
l
REVIEW DRAFT 1
About this Manual
Summary of Changes
This manual has been revised and replaces all prior editions.
Part Number Publication Date Description
6806800M97L September 2019
Re-branded to SMART Embedded Computing. Applied
new template to document and made light edits. Updated
Overview information to include RTM-ATCA-F140-D.
Updated Ordering and Support Information. Added
Appendix for RTM-ATCA-F140-D. Updated Related
Documentation to include data sheets. Updated safety
notes and German translations. Added RoHS information
in Standard Compliances table.
6806800M97K March 2017 Updated Chapter 4, SFP+ Connection and Copyright page
6806800M97J May 2016 Removed Declaration of Conformity
6806800M97H September 2015 Added Hint table on page 19. Updated Safety Notes
Summary, and Sicherheitshinweise.
6806800M97G September 2014
Replaced Figure 3-1 with ELMA handle variant figure.
Updated the section RTM Installation and Removal as per
ELMA handle usage.
6806800M97F July 2014 Updated Chapter 4, Functional Description.
6806800M97E April 2014 Rebranded to Artesyn.
6806800M97D May 2013 Corrected part number from 6806800M97C to
6806800M97B in the row 2 of this table.
6806800M97C December 2012 Updated Standard Compliances
6806800M97B April 2012 GA Release
6806800M97A August 2011 Initial Version

RTM-ATCA-F140 Series Installation and Use (6806800M97L) 15
Safety Notes
This section provides warnings that precede potentially dangerous procedures throughout
this manual. Instructions contained in the warnings must be followed during all phases of
operation, service, and repair of this equipment. You should also employ all other safety
precautions necessary for the operation of the equipment in your operating environment.
Failure to comply with these precautions or with specific warnings elsewhere in this manual
could result in personal injury or damage to the equipment.
SMART Embedded Computing intends to provide all necessary information to install and
handle the product in this manual. Because of the complexity of this product and its various
uses, we do not guarantee that the given information is complete. If you need additional
information, ask your SMART EC representative.
The product has been designed to meet the standard industrial safety requirements. It must
not be used in safety critical components, life supporting devices, or on aircraft.
Only personnel trained by SMART EC or persons qualified in electronics or electrical
engineering are authorized to install, remove, or maintain the product. The information
given in this manual is meant to complete the knowledge of a specialist and must not be
used as replacement for qualified personnel.
Keep away from live circuits inside the equipment. Operating personnel must not remove
equipment covers. Only factory authorized service personnel or other qualified service
personnel may remove equipment covers for internal subassembly or component
replacement or any internal adjustment.
Do not install substitute parts or perform any unauthorized modification of the equipment or
the warranty may be voided. Contact your local SMART EC representative for service and
repair to make sure that all safety features are maintained.
EMC
The product has been tested in a standard SMART EC system and found to comply with
the limits for a Class A digital device in this system, pursuant to part 15 of the FCC Rules,
EN 55022 Class A respectively.
These limits are designed to provide reasonable protection against harmful interference
when the product is operated in a commercial, business or industrial environment.
The product conducts, radiates and uses radio frequency energy and, if not installed
properly and used in accordance with this user documentation, may cause harmful
interference to radio communications.
Operating the product in a residential area is likely to cause harmful interference. If this
occurs, the user will be required to correct the interference at the user's expense.

16 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Safety Notes
Safety Notes
Changes or modifications not expressly approved by SMART EC could void the user's
regulatory compliance. Board products are tested in a representative system to show
compliance with the above mentioned requirements. A proper installation in a compliant
system will maintain the required performance.
Use only shielded cables when connecting peripherals to help assure that appropriate radio
frequency emissions compliance is maintained. For proper EMC shielding, only operate the
system with face plates installed and all vacant slots covered or populated with filler cards.
This is a Class A product based on the standard of the Voluntary Control Council for
Interference (VCCI) by Information Technology Interference. If this equipment is used in a
domestic environment, radio disturbance may arise. When such trouble occurs, the user
may be required to take corrective actions.
Grounding
If the product is not properly grounded, it may be damaged by electrostatic discharge.
The system contains EMI gaskets at the shelf and module level. Make sure that each of the
system's parts contact the EMI gasket.
The shelf is also fitted with an ESD jack/snap for use with conductive wrist straps. Make
sure the operator uses proper ESD protection.
Rear Transition Modules
Damage of the RTM
Incorrect installation of the RTM can cause damage to the RTM.
Use handles when installing/removing the RTM to avoid damage/deformation to the face
plate and/or PCB.
Bent pins or loose components can cause damage to the RTM, the backplane, or other
system components. Carefully inspect the RTM and the backplane for both pin and
component integrity before installation.
SMART EC and our suppliers take significant steps to ensure there are no bent pins on the
backplane or connector damage to the blades/RTMs prior to leaving the factory. Bent pins
caused by improper installation or by inserting blades with damaged connectors could void
the SMART EC warranty for the backplane or blades.
Installation
Personal Injury
This product operates with dangerous voltages that can cause injury or death. Use extreme
caution when handling, testing, and adjusting this equipment and its components.

Safety Notes
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 17
Damage of Circuits
Electrostatic discharge and incorrect product installation and removal can damage circuits
or shorten their life.
Before touching the product, make sure that you are working in an ESD-safe environment.
Hold the product by its edges and do not touch any components or circuits.
Data Loss
Wait until the blue LED is permanently illuminated before removing the blade.
Removing the blade with the blue LED still blinking causes data loss.
Restricted Access Area
This product is only to be installed in a restricted access area.
Damage of Blade and Additional Devices and Modules
Before installing or removing an additional device or module, read the respective
documentation.
Incorrect installation of additional devices or modules may damage the blade or the
additional devices or modules.
Blade Damage
Use handles when installing/removing the blade to avoid damage/deformation to the face
plate and/or PCB.
Damage to Blade/Backplane or System Components
Bent pins or loose components can cause damage to the blade, the backplane, or other
system components. Carefully inspect the blade and the backplane for both pin and
component integrity before installation.
SMART EC and our suppliers take significant steps to make sure that there are no bent pins
on the backplane or connector damage to the blades prior to leaving the factory. Bent pins
caused by improper installation or by inserting boards with damaged connectors could void
the SMART EC warranty for the backplane or blades.

18 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Safety Notes
Safety Notes
System Damage
WARNING: The intra-building port (s) of the equipment or subassembly is suitable for
connection to intra-building or unexposed wiring or cabling only. The intra-building port (s)
of the equipment or subassembly MUST NOT be metallically connected to interfaces that
connect to the outside plant (OSP) or its wiring. These interfaces are designed for use as
intra-building interfaces only (Type 2 or Type 4 ports as described in GR-1089) and require
isolation from the exposed OSP cabling. The addition of primary protectors is not sufficient
protection in order to connect these interfaces metallically to OSP wiring.
The intra-building port(s) of the equipment or subassembly must use shielded intra-building
cabling/wiring that is grounded at both ends.
Operation
Make sure that the display devices that are permanently connected to the VGA interface
provide a fire enclosure according to the IEC/EN/UL/CSA 60950-1 requirements.
All other devices that are only connected to the VGA interface for service purposes need
supervision during operation and must be disconnected after maintenance.
Product Damage - Product Surface
High humidity and condensation on the product surface causes short circuits.
Do not operate the product outside the specified environmental limits. Make sure the
product is completely dry and there is no moisture on any surface before applying power.
Overheating and Product Damage
When operating the product, make sure that forced air cooling is available in the shelf or
enclosure.
Operating the product without forced air cooling may lead to overheating and product
damage.
When operating the product in areas of electromagnetic radiation, secure the product in the
system using the front panel screws. Make sure the product is fully shielded by the
enclosure.
Data Corruption
If power to the unit is removed while a firmware update is in progress to the product's flash
memory, the changes will not be saved or the flash memory may be corrupted. In such
case, the product is likely to remain in a non-operable state and will require reconditioning
by qualified repair services.

Safety Notes
RTM-ATCA-F140 Series Installation and Use (6806800M97L) 19
Injuries or Short Circuits - Blade or Power Supply
In case the OR-ing diodes of the blade fail, the blade may trigger a short circuit between
input line A and input line B so that input line A remains powered even if it is disconnected
from the power supply circuit (and vice versa).
To avoid damage or injuries, always check that there is no voltage on the line that has been
disconnected before continuing your work.
The EMI radiation compliancy of the product has been qualified in a reference system.
Please note that the integrator needs to verify the EMI radiation compliancy of other
configurations/settings.
Product Damage
High humidity and condensation on the product surface causes short circuits.
Do not operate the product outside the specified environmental limits. Make sure the
product is completely dry and there is no moisture on any surface before applying power.
Switch Settings
Product Malfunction
Do not change settings of switches marked Reserved. Switches marked Reserved might
carry production-related functions and can cause the product to malfunction if setting is
changed.
Check and change the setting of any switch not marked Reserved before installing the
product.
Product Damage
Check and change switch settings before you install the product.
Setting/resetting the switches during operation can cause product damage.
Use minimal force when pressing the reset switch. Too much force may damage the reset
switch.
RJ-45 Connectors
System Damage
RJ-45 connectors on the front panel are either twisted-pair Ethernet (TPE) or E1/T1/J1
network interfaces. Connecting an E1/T1/J1 line to an Ethernet connector may damage
your system.

20 RTM-ATCA-F140 Series Installation and Use (6806800M97L)
Safety Notes
Safety Notes
Make sure that TPE connectors near your working area are clearly marked as
network connectors.
Verify that the length of an Ethernet cable connected to a RJ-45 TPE connector
does not exceed 100 meters or approximately 328 feet.
Make sure the TPE connector of the system is connected only to Safety Extra Low
Voltage (SELV) circuits.
If in doubt, ask your system administrator.
For more information, see the documentation of the respective product.
SFP/SFP+ Modules
Personal Injury and Damage of the RTM and SFP/SFP+ Modules
Installing and using SFP/SFP+ modules that are not fully certified and do not meet all
relevant safety standards may damage the RTM and the SFP/SFP+ modules and may lead
to personal injury.
Only use and install SFP/SFP+ modules that are fully certified and meet all relevant safety
standards.
Personal Injury
Optical SFP/SFP+ modules may be classified as laser products. When installing and using
any of these SFP/SFP+ modules the regulations which correspond to the respective laser
class apply to the whole RTM. Not complying to these regulations may lead to personal
injury.
When installing and using optical SFP/SFP+ modules which are classified as laser
products, make sure to comply to the respective regulations.
Eye Damage
Optical SFP/SFP+ modules may emit laser radiation when no cable is connected. This
laser radiation is harmful to your eyes. Do not look into the optical lens at any time.
SFP/SFP+ Module Damage
The optical port plug protects the optical fibers against dirt and damage. Dirt and damage
can render the SFP/SFP+ module inoperable.
Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+
module. When no cable is connected cover the port with an optical port plug.
