Smartek ST-X500 User manual

STEAM PRESS
INSTRUCTION MANUAL
MODEL NO.ST-X500
Features of the Steam Press................................1
Safety Reminders.................................................2
Parts ldentification.............................................3-4
Steam Press Operation.....................................5-9
Cleaning the Steam Press..................................10
Suggestion for Success.......................................11
Use of the Pressing Cushion..............................12
Techniques for Pressing................................13-14
Troubleshooting.............................................15-16
CONTENTS

Steam press Instruction Manual Page1
Features of the Steam Press
Your Steam Press provides clean, professional results every time!
The pressing surface is seven times larger than most hand-held irons
Can reduce ironing time up to 50%
Mutiple dry and steam settings; burst setting removes stubborn wrinkles
Variable temperature control
Automatic shut-off safety feature while open or closed with audible alert
Automatic wake-up feature
Power indicator light
Over 100lbs. of even pressure makes for easy-to-use one hand operation
Protects delicate fabrics like silk
Non-stick ironing pad cover
Locking handle makes unit portable
Stores upright
Operate sitting down or standing up

Page2 Steam press Instruction Manual
SAFETY REMINDERS
WARNING - Read all of the instructions and then save them for future reference.
TO PROTECT against the risk of electric shock, DO NOT
immerse the appliance in water.
ALWAYS turn the switch to the OFF position before plugging in or
unplugging the unit.
DO NOT let the cord hang over the edge of counters.
DO NOT allow the cord to touch hot surfaces.
ALWAYS allow the appliance to cool completely for at least thirty
minutes before storing.
ALWAYS put the appliance in a secure place on a table or counter
when using.
DO NOT move the appliance without unplugging it first.
The appliance has very hot surfaces - DO NOT allow unsupervised
children to use the appliance.
ALWAYS disconnect the appliance from the outlet BEFORE
filling with or removing water. Be careful to avoid spilling water
on the appliance when filling.
USE DISTILLED WATER in the appliance. DO NOT use
perfume or products containing alcohol in the appliance.
ALWAYS disconnect the appliance when not in use.
DO NOT use the appliance if the cord gets damaged. Return the
appliance or have the cord repaired by a licensed electrician.
DO NOT operate the appliance if it has been dropped or damaged.
DO NOT disassemble the appliance. Incorrect reassembly can
cause a risk of electric shock. Send it to an authorized service
center for repair.
DO NOT operate another high wattage appliance on the same
circuit.
If an EXTENSION CORD is necessary, use a 13Ampere cord (for
110V/120V) appliances. Cords rated for less amperage may
overheat.
This appliance MUST BE grounded. DO NOT alter the plug or
attempt to defeat this feature.
Be careful. Burns can occur from touching HOT METALPARTS,
HOT WATER or STEAM.
a

Steam press Instruction Manual Page3
1. The Pressing Handle raises and lowers the Pressing Plate. By
lowering the Pressing Handle until it reaches the lowest point
possible you automatically obtain maximum pressure.
2. The Locking Knob will lock together the Pressing Plate and Ironing
Board. Use the Locking Knob to carry or Store the Steam Press.
3. The Steam Burst Button on the end of the handle grip produces a
burst of steam when pressed.
4. The Pressing plate is the temperature controlled surface that heats
and presses the fabric.
5. The Ironing Board is the padded surface that holds the fabric during
pressing.
6. The Power Indicator Light is illuminated when the unit is on.
7. The On/Off Switch can be pushed to turn the power on and off.
8. The Ready Light goes off when the Press has reached the selected
temperature.
9. The Steam Ready Light goes on when unit is ready to produce
bursts of steam.
10. The Temperature Control dial is used to set the desired
temperature for each fabric.
11. The Water Tank slides forward and is filled through holes in the
top. The Water Level can be seen through the front of the tank.
Slide the tank forward for a better view.
IDENTIFYING THE STEAM PRESS PARTS

Page4 Steam press Instruction Manual
12. The Ironing Board Cover is removable and washable for extended use.
13.The Pressing Cushion is a fabric covered pad used for pressing gathered or contoured
areas such as sleeves, darts, and yokes.
14. Aplastic water Spray Bottle is used for dampening fabric before pressing.
15. A Water Containeris used for filling the Water Tank.
16. Power light.
17. Temperature Ready Light.
18. Steam Ready Light.
Automatic features of the Steam Press include Auto Shut-Off and Auto Wake-up. These
multiple function safety features turn off electric power to the heater when the Pressing plate
has been left against the Ironing Board for more than 10 seconds OR if the Pressing plate is left
in the open (up) position without use after approximately 15 minutes. The heating ability of
the unit is restored when the Pressing plate is lowered or raised from its current position.
IMPORTANT NOTE: Auto Shut-Off does not mean power is totally cut off. Power is always
on, the Power Light remains on as well until the Power Switch is OFF.
To turn the power ON again, press the ON/OFF Switch to the OFF
position, then back to the ON position.
a
The followinginformation isprovided forservice bya qualifiedelectrician only:
Rated voltage:110V/120V; 60Hz;1300W
WARNING: This appliance must be grounded. Use onlythe propertype outlet when plugging in the appliance. Donot attempt to override
the ground wirefeature.

Steam press Instruction Manual Page5
STEAM PRESS OPERATION
STEP1 - PREPARATION FOR USE
Set the appliance on a sturdy work surface. Unlock the Locking Knob.
STEP 2- FILLING THE WATER TANK
BEFORE PLUGGING IN THE APPLIANCE, fill the water tank;
a. Always make sure the appliance is unplugged before filling the tank.
b.Fill the WaterTank with the Pressing Plate lifted to the raised (up) position. Slide the Water
Tank towards the front of the unit. It will not come completely out so do not force it to do so.
Using the Water Container, slowly pour the water into the Water Tank Fill Holes(C).
c. Be careful to avoid spilling water onto the Steam Press when filling.
d.Slide the WaterTank back into its recessed position.
STEP 3 - TURNING ON THE POWER
a. Always check to make sure the ON/OFF switch is OFF.
b. Make sure the Locking Knob is in the open position allowing free movement of the
Pressing Plate before plugging in the appliance.
c. Lift the Pressing plate to the fully raised (up) position.
d.Plug the appliance into an electric outlet.
e.Turn the ON/OFF switch to the ON position and the yellow Power Indicator light will shine.
The Power Indicator light is the left most light on the indicator row.

Page6 Steam press Instruction Manual
STEP 4 - SELECTING THE TEMPERATURE
a. Turn the Temperature Control Dial (A) until it points to the kind of fabric you wish to press.
b. Examine the garment label if unsure and look up the type on the chart (B) Below:
Nylon Silk Wool Cotton Linen
Acetate Polyester Triacetate
Rayon
IMPORTANT NOTE: If you can not determine the type of fabric, begin with the
lowest setting and increase the temperature as desired until
you obtain the proper results.
c. When the Ready Light (C) goes off, the Pressing Plate has reached the temperature
for the desired setting.
d. When changing the setting from a higher selection to a lower setting allow several
minutes for the Pressing Plate to cool sufficiently after making the change.
IMPORTANT NOTE: You may find it more efficient to arrange your fabrics from those requiring the lowest setting to those requiring the highest
setting and proceed accordingly. This will avoid any unnecessary delay or wait for the Pressing Plate to cool.

Steam press Instruction Manual Page7
STEP 5 - STEAM CONTROL
IMPORTANT NOTE: Steam is produced only when the Temperature Control Dial is set
to the higher temperatures.
The Temperature Control Dial must be set high enough to have sufficient heat to produce
steam. The center Temperature Ready Light goes off when the unit has reached the
desired temperature. The Steam Ready Indicator Light, the right most light on the
indicator row, will come on when the unit is ready to produce steam.
IMPORTANT NOTE: If this is the first time you are using the Steam Press or you have
been storing it for some time, lift the Pressing plate into the
raised position and press the Steam Burst Button several times
until the steam begins to flow.
IMPORTANT NOTE: The Steam Burst function can only be used when the Steam
Ready Light is on AND the steam press is in an opened position.
Do not use the Steam Burst function when the steam press is
closed, or you may damage the unit.

Page8 Steam press Instruction Manual
STEP 6 - PRESSING
a. Lift the Pressing Handle (A). The Pressing Plate (B) moves to the up position.
b. Carefully arrange the garment to be pressed onto the Ironing Board (C) (the lower base of
the Steam Press).
c. Grasp the handle of the Pressing Plate(A) and lower it onto the Ironing Board (C),capturing
the garment between the two halves of the Steam Press. For light duty pressing, simply
lowering the handle and allowing the Pressing Plate to rest on the Ironing Board will be
sufficient. Return to the open position. For heavier duty pressing, continue to grasp the
handle and press downward until the Pressing Plate is pushed to its lowest position, then
open the press. If the Temperature Control is set high enough you may give the fabric a
burst of steam by pressing the Steam Burst Button (D) to remove stubborn wrinkles. While
the Pressing Plate is in the open or up position, simply press down on the Steam Burst
Button (D) and release it. The fabric will be given a burst of steam.
d. After a few seconds, lift the handle and raise the Pressing Plate back to the raised position.
IMPORTANT NOTE: If you forget to raise the Pressing Plate or become distracted, the
machine will give a warning beep and automatically shut-off after
approximately 10 seconds. The steam press will also shut-off after
15 minutes of no activity with the press in the open position. Auto
Shut-Off does NOT disconnect the power. Power is always on and
the power light remains on as well until the power switch is turned
OFF. The shut-off feature is a temporary aid until you can give full
attention to the unit again.

Steam press Instruction Manual Page9
STEP 7 - FINISHING PRESSING/STORING THE UNIT
a. Turn the ON/OFF switch to the OFF position. The yellow Power Indicator Light will go out.
Disconnect the plug from the outlet.
b. Wait for the Steam Press to cool completely.
c. Water left in the reservoir will not drip out if the machine is stored in an upright position. However,
it is recommended that if the machine will be stored for some time, that all the water in the unit be
drained by pressing the Steam Burst Button until all of the Water is pumped out.
d. Lower the Pressing Plate onto the Ironing Board pushing the handle to its lowest position.
e. Turn the Locking Knob (E) to the locked position. This should prevent the Steam Press from
opening while being moved or stored.
f. Loosely wrap the electric cord and place it in the opening at the front of the base (F) of the
Ironing Board. You are now ready to store the unit.
E

Page10 Steam press Instruction Manual
STEP 8 - CLEANING (As required)
a. Cleaning the Pressing Plate: Place the Pressing Cushion in the center of the Ironing
Board. Place a clean towel over the Pressing Cushion and the Ironing Board. Set the
Steam Control and Temperature Control to their maximum setting. When the Ready
Light comes on, gently lower the Pressing Plate onto the Pressing Cushion. With
water in the reservoir tank, press the Steam Burst Control 6 to7 times. Be careful to
avoid touching the hot metal surfaces or leaving your hand in the bursts of steam.
b. Once the Pressing Plate has cooled down you can clean the surface with a damp cloth.
DO NOT use any abrasives on the Pressing Plate.
c. The Ironing Board Cover is removable for normal washing. You can rinse the Ironing
Board Cover with mild detergent and warm water.

Steam press Instruction Manual Page11
SUGGESTIONS FOR SUCCESS --
USING PRESS CLOTH:
a. Placing a press cloth ( a piece of clean fabric) between the fabric and the Pressing Plate may be desirable, especially for more delicate fabrics.
OLDER STYLE BUTTONS AND ZIPPERS:
b. While most modern buttons and zippers require no special attention, some older types may be heat sensitive. Take care with items that could
melt. Lower the heat or steam settings, place the items FACE DOWN on the ironing board, and cover the fabric with a press cloth BEFORE
pressing. This will help protect delicate accessories and fasteners.
SPRAYBOTTLE METHOD:
c. Using a Spray Bottle, lightly spray the garment before placing it on the Ironing Board. This helps to distribute an even, fine mist over the fabric,
preparing it to be pressed, and removing all wrinkles.
DAMP CLOTH METHOD:
d. For the most stubborn or heavy gauge fabrics, place a damp cloth over the area to be pressed. Press the garment normally for a few seconds, then
raise the Pressing Plate and allow the steam to escape. Repeat the procedure until the fabric is dry.

Page12 Steam press Instruction Manual
USE OF THE PRESSING CUSHION --
Some garments have been constructed with details, such as darts, curved seams and shoulder pads, which are not intended to be pressed flat a
Pressing Cushion is supplied with your Steam Press for use with these areas.
a. Use the cushion whenever pressing areas where no creases are desired or to shape tailored garments.
b. Place the area to be pressed onto the Ironing Board.
c. Place the Pressing Cushion under the dart, seam. Etc.
d. Making sure the area to be pressed is raised, lower the Pressing Plate, The raised area is the only area the plate should contact.
IMPORTANT NOTE: DO NOT attempt to lower the Pressing Plate to its lowest position or lock the Pressing Plate against the Ironing Board
with the Pressing Cushion in place. You MAYDAMAGE the Steam Press by doing so.
e. Raise the Pressing Plate after a few seconds.

Steam press Instruction Manual Page13
TECHNIQUES FOR PRESSING --
LARGE PIECES OF FABRIC:
To press large pieces of fabric, place the entire piece in the storage area behind the Ironing Board. The area you want to press first is on the top of
the pile.
Pull the fabric towards you, over the Ironing Board and lower the Pressing Plate, pressing each section as you move the fabric forward. Allowing
the fabric to drape in this manner will preserve the pressing and give you a complete job free of wrinkles.
SHIRTS and BLOUSES:
a. Place the shoulder yoke on the Ironing Board first, face down and press.
b. Place the sleeves on the Ironing Board next, with the fold parallel to the long seam and press.
c. Place the cuffs on the end of the Ironing Board and press.
d. Place the body of the shirt into the storage area between the Pressing Plate and Ironing Board, away from you. Press the side front of the shirt
including the placket, or pocked.
e. Pull the shirt towards you and continue to press each area until complete.
f. Place the shoulder yoke flat on the Ironing Board. Press to remove the crease.
g. Place the collar right side up on the Ironing Board and press.

Page14 Steam press Instruction Manual
PANTS:
a. Place the pressing Cushion under the waistband and press.
b. Reposition the waistband and continue around the pants until the entire waistband is pressed.
c. To press the inseam, place the Pressing Cushion under the area to be pressed. Press the entire inseam and repeat for the other leg.
d. Press the front and back pleats using the same method. Fold one leg along the creased line. Place it on the Ironing Board so that the seams will
not be pressed. Press the crease.
PLEATED SKIRTS:
a. Place the Pressing Cushion under the waistband and press.
b. Reposition the waistband and continue around the skirt until the entire waistband is pressed.
c. Place the pleated area on the Ironing Board. Fold the pleats carefully and press.
d. Continue with each pleated area until the garment is completed.
OTHER ITEMS:
a. EMBROIDERY should be placed FACE DOWN on the Ironing Board to reduce wear and prevent damage to delicate work.
b. CURTAINS may be pressed running them from one end of the Ironing Board to the other and pressing in sections until complete.
c. DRESSES with special needs should refer to the above sections on pleats, shirts (bodices), etc., for proper use of the Pressing Cushion.
IMPORTANT NOTE: Many types of clothing are intricate and unique to their owner. You may have to experiment with the best way to press
challenging garments. remember, if you put in a crease you did not intend, you can remove it just as simply with one of the
methods contained in these instructions.

Steam press Instruction Manual Page15
TROUBLE SHOOTING THE STEAM PRESS
Belowisachart detailingthemostcommonproblems,theircauses andsolutions.BeforeshippinganyappliancetoaservicecenterPleasechecktomake
surethatthesolutionisnotlistedhere:
PROBLEM CAUSE SOLUTION
Steam Press Cannot Be Opened Using
PressingHandle. Locking Knob is in Locked Position. Turn the Locking Knob to the Unlocked
Position.
Steam Press Becomes Warm but DOES
NOTRemoveWrinkles. Temperature Setting is not high enough for
thefabricattempted. Gradually increase the temperature until
obtainingthedesiredresults.
Press DOES NOT get warm. Temperaturehasnotbeenselected.
Pressisnotpluggedintoanoutlet.
Automatic Shut-Off has engaged. The
Pressing Plate has been lowered for more
than15secondswithoutbeingraised.
Automatic Shut-Off has engaged. The
Pressing Plate has been raised for more than
15minuteswithoutuse.
Turn the Temperature Control Dial to an
appropriatesetting.
Plugtheappliancein.
PushtheON/OFF switchtotheOFFposition
and back to ON. Raise the Pressing Plate
duringthewarm-upperiod.
PushtheON/OFF switchtotheOFFposition
and back to ON. Raise or lower the Pressing
Platetorestarttheheater.

Page16 Steam press Instruction Manual
The Pressing Handle will not move into the
Automatic Maximum pressure position. Item on the Ironing Board is too thick to use thispressure. Use lighter pressure on thicker items. Use
addedsteamforwrinkles.
Water drips from the Pressing Plate. Temperature Control Dial has not been set
properly.
SteamButtonhasbeenpressedtoolong.
Turn the Temperature Control Dial clock-
wisetoahighertemperature.
Don't press the Steam Button more than 5
secondscontinuously.
PROBLEM CAUSE SOLUTION
No Steam. Fill the water tank.
Turn the Temperature Control Dial clock-
wise to a higher temperature. Wait for the
Steam Ready light to come on.
Water Level is too low.
Controls have not been properly set.
