SMC Networks 802.11g User manual

ii
User Guide
Copyright
Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is
assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change
specifications at any time without notice.
Copyright © 2005 by
SMC Networks, Inc.
38 Tesla Irvine,
California 92618
Trademarks
SMC® is a registered trademark; and EZ-Stream, EZ Connect, Barricade and EZ Hub are trademarks of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their respective holders.
Rhapsody is a registered trademark of Listen.com, Inc.
Musicmatch is a registered trademark of Yahoo! Inc.
Microsoft, Windows, and Windows Media are trademarks or registered trademark of Microsoft Corp. in the United States and/
or other countries.
Warranty Limitations
The information provided herein may change with product qualification.
SMC Networks, Inc. assumes no responsibility for inaccuracies, errors, or omissions.
SMC Networks, Inc. assumes no responsibility for the use of this information, and all use of such information shall be entirely
at the user’s own risk. Specifications are subject to change without notice.
Please registerthis product and upgrade the product warrantyat SMC’s website: http://www.smc.com.

iii
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Table of Contents
About the SMCWAA-G EZ-Stream™ 802.11g Wireless Audio Adapter .....................1
Before You Start ....................................................................................................1
PC Requirements ...........................................................................................................1
Audio System Requirements ............................................................................................1
Network Requirements ...................................................................................................2
Contents of the Box .......................................................................................................3
Using the Remote Control ......................................................................................4
Understanding the Operating Modes and Screen Displays .....................................5
Operating Modes ............................................................................................................5
Browse Mode (Home Menu) ..........................................................................................5
Play Mode ..................................................................................................................5
Configuration Mode .....................................................................................................5
Screen Layouts ..............................................................................................................5
Select Screens (Home Menu) ........................................................................................5
Play Screens ...............................................................................................................6
Configuration Screens ..................................................................................................7
Edit Screens ...............................................................................................................8
Other Screens .............................................................................................................8
Installing the SMCWAA-G ......................................................................................8
Essential Information and System Setup ...........................................................................8
Connecting the SMCWAA-G to the Network .......................................................................9
Installing the Music Library Software ................................................................................9
Installing Musicmatch ..................................................................................................9
Installing Rhapsody ...................................................................................................10
Music Server Connection Problems ..............................................................................10
Configuring the SMCWAA-G ...........................................................................................10
Language Selection ...................................................................................................10
Using the Configuration Wizard (basic setup only) .........................................................11
Standby and Restart ....................................................................................................11
Using the SMCWAA-G ...........................................................................................11
Listening to Music ........................................................................................................12
Selecting and Playing Music ........................................................................................12
Setting up a Musicmatch Library on your PC .................................................................12
Listening to Internet Radio Stations ................................................................................12
Using Presets and Favorites ...........................................................................................13
Saving a Track to a Preset Number ..............................................................................13
Playing a Preset Item .................................................................................................13
Saving a Track to the Dynamic Playlist .........................................................................13
Selecting and Playing Favorites from the Dynamic Playlist ...............................................13
Replacing Favorites on the Dynamic Playlist ..................................................................13

iv
User Guide
Advanced Configuration Management ..................................................................14
Method 1: Using the Remote Control ...............................................................................14
Select Language ........................................................................................................14
Advanced Settings .....................................................................................................14
Configure Date/Time ..................................................................................................15
Select Profile .............................................................................................................15
Device Status ............................................................................................................15
Internet Radio ...........................................................................................................15
Configuration Wizard ..................................................................................................15
Network Information Needed by the Configuration Wizard ...............................................15
Configuration Wizard Menu .........................................................................................15
Changing Network Settings .........................................................................................16
Method 2: Using the SMCWAA-G PC Utility .......................................................................17
Installing the Utility ...................................................................................................17
Starting the SMCWAA-G PC Utility ................................................................................17
Managing Profiles Using the SMCWAA-G PC Utility ..........................................................17
Uploading New Software to the SMCWAA-G .....................................................................18
Performing a Hard Reset to Factory Settings ....................................................................19
Firewall Settings ..................................................................................................19
Troubleshooting ...................................................................................................20
Troubleshooting Chart ...................................................................................................20
Error Codes .................................................................................................................21
Menu Tree Diagrams ............................................................................................22
Top Level Menus ..........................................................................................................22
Configuration Mode Menus .........................................................................................23
Configuration Wizard Menus ..........................................................................................24
Wireless LAN Configuration Wizard ...............................................................................24
Wired Ethernet Configuration Wizard ............................................................................25
Music Track Menus .......................................................................................................26
Internet Radio Menus ...................................................................................................27
Technical Specifications .......................................................................................28
Standards Compliance .........................................................................................30
FCC - Class B ...............................................................................................................30
Caution Statement .......................................................................................................30
FCC Radiation Exposure Statement ..............................................................................30
Industry Canada – Class B ..........................................................................................31
EC Conformance Declaration ......................................................................................31
Safety Compliance .....................................................................................................31
Glossary of Terms ................................................................................................33

1
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
About the SMCWAA-G EZ-Stream™ 802.11g Wireless Audio Adapter
With the SMCWAA-G EZ-Stream™ 802.11g Wireless Audio Adapter (SMCWAA-G) you are able to break away from your
computer and enjoy digital music anywhere in your home. The SMCWAA-G plugs into an audio system and connects, using a
wireless or wired Ethernet link to a personal computer (PC), or directly to the Internet via an Access Point (AP) or wireless
router.
Using the SMCWAA-G’s remote control and LCD display,you can browse and play tracks stored on your PC, or listen to
Internet Radio stations or music tracks available online.
The SMCWAA-G is easy to set up on a wireless or wired Ethernet network. The Musicmatch Jukebox program, running on
any PC on the network, enables the SMCWAA-G to browse audio files on the PC and play them back over the audio system.
The SMCWAA-G is a complete package that allows you to enjoy the digital music experience within minutes, out-of the box.
Key Features
You can:
• Connect your SMCWAA-G to an audio system, then use its Remote Control to browse and play:
•thousands of Internet radio stations
•any audio tracks you have stored on any PC on your network
•thousands of music tracks available on the Internet, through services such as Rhapsody
• Store up to 10 of your favorite radio stations or albums/tracks on shortcut buttons
• Keep 20 more favorites in your own dynamic playlist
• Create your own Internet radio station database online
• Browse music tracks by Song, Album, Artist, Genre, Playlist or All Tracks
• Configure the SMCWAA-G for your home network, using the remote control and LCD display
• Maintain up to three different customized configurations.
• Use the SMCWAA-G PC Utility to install firmware upgrades.
Before You Start
The SMCWAA-G is designed to operate with your PC and a local area network(LAN) or wireless local area network (WLAN),
with a connection to the Internet. Please check the following before you start the installation:
PC Requirements
The minimum PC specification is:
• A Pentium Class processor 300MHz, with 128 MB RAM, 150 MB hard drive space
• A 4x CD-ROM drive
• Windows 98SE, ME, 2000 or XP
• Microsoft Internet Explorer 5.0 or later, Netscape Navigator, or other windows compatible Internet browser application
• SVGA or higher resolution monitor (minimum resolution 800 x 600).
Audio System Requirements
Any audio system (amplifier, VCR, DVD, etc.) with an auxiliary (AUX) input.

2
User Guide
Network Requirements
The SMCWAA-G can communicate with your home network using TCP-IP over either an IEEE802.11b/g wireless link or a
hard-wired Ethernet link. The network must provide:
• Internet access
(used to listen to Internet radio stations and online music tracks) and
• Communication between the SMCWAA-G and at least one PC, running a UPnP server application, such as Musicmatch
(used to play music from the PC’s hard disk).
If one PC provides both Musicmatch and Internet connectivity, it will be necessary to enable Internet Connection Sharing (see
Windows Help for instructions) or to install a local Proxy Server on the PC.
Two typical network configurations are shown below:
Notes:
1. In the wireless mode, the SMCWAA-G must communicate with an Access Point (AP) or wireless router in Infrastructure
Mode.
Please consult your AP/Router documentation for information on system setup.
2. The AP may also integrate Network Router and/or DSL/Cable Modem functions.
Wireless LAN Connection

3
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Contents of the Box
Check that the box contains all the following items:
• 1 SMCWAA-G wireless audio adapter
• 1 SMCWAA-G EZ-Stream™ 802.11g Wireless Audio Adapter Quick Install Guide
• 1 audio connector cable (twin RCA connectors at both ends)
• 1 Ethernet cable
• 1 power supply unit with integrated cable
• 1 infra-red remote control, plus two AAA batteries
• An installation CD, which you can use to install:
•the Musicmatch PC jukebox
•the Rhapsody online music service
•Acrobat Reader (needed to view the User Guide on-screen)
•the SMCWAA-G PC Utility and
•this User Guide, in PDF format.
Wired Ethernet Connection

4
User Guide
Using the Remote Control
The table below describes the functions of all the keys on the remote control in all three operating modes:-
The SMCWAA-G Remote Control
Key Select and Play Modes Configuration & Edit Modes
Standby on/off (short press). Restart SMCWAA-G (press and hold)
Information button (see Note 1): switch between Play and Select screens
Note 1) If pressed while editing, a screen appears asking if you want to Discard Changes.
‘No’ returns to Edit mode,‘Yes’ performs the normal function of the button.
Hotkeys for selecting stored favorites 0 - 9
Enter numbers and text:
Repeated presses of the ‘2’ key
will scroll through ‘2’,’a’, ‘b’, ‘c’,
‘A’, ‘B’ and ‘C’.
Store current station/track as a PRESET.
Press, then press required number key Inactive
Increase Volume Toggle upper/lower case
PLAYLIST: Open Select Menu for Dynamic Favorites list
Decrease Volume Toggle Insert/Replace modes
Scroll Up / Down (see Note 2) to highlight previous/next menu item
Press and hold for fast scroll
Note 2) These keys can be used to scroll through all characters in Edit mode, but the keypad is usually a quicker method.
Return to previous, higher level menu
Go to Home Menu
Select highlighted menu item
Add or remove current station/track to/from the Dynamic Playlist)
JUMP TO function - see page 6
Skip back through track, album or playlist Backspace(deletelastcharacter)
Play selected station/track, or Pause currently playing station/track
Skip forward through track (press and hold), or
skip tracks in album or playlist (press and release)
Switch off sound. Press again to switch sound on again
Stop Play
REPEAT track (press once)
Repeat all tracks in album or playlist (press twice)
Used to select an item (same function as )
1Open Configuration Menu
SHUFFLE-play current album/playlist
Note: Gray shading denotes key is inactive in Configuration Mode
+
-
and
OK

5
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Understanding the Operating Modes and Screen Displays
Your SMCWAA-G has three operating modes and four main LCD screen layouts, as follows:
Operating Modes
Browse Mode (Home Menu)
Browse Mode is the normal startup mode of the SMCWAA-G. Here, you can browse your locally stored tracks, as well as
tracks and radio stations on the Internet, and select what you want to hear.
Note: the SMCWAA-G will start in Configuration Mode (Configuration Wizard) if it has problems in connecting to the
network.
Play Mode
The Play Mode has its own screen display, but the SMCWAA-G can carry on playing while you work in Browse Mode or
Configuration Mode, to select your next track or to change system settings.
Configuration Mode
This mode must be used when you first install your SMCWAA-G, but you will only ever need it again if you want to change any
of the stored system settings.
Basic use of the Configuration Mode is described in Configuring the SMCWAA-G on page 10. For the full range of
configuration capabilities, see Configuration Mode Menus on page 23.
Screen Layouts
Select Screens (Home Menu)
The SMCWAA-G normally starts in Browse Mode, showing the Home Menu, which is a Select Screen. To return to the
Browse Mode at any time, simply press the HOME key ( ) once. A typical Home Menu may look like this:
At the top is the Screen Title. For the Home Menu, this is the Device Name, in this case SMCWAA-G. You can change this
name in the Configuration Mode.
Beneath the top line is a number of menu items. In the Home Menu, each item represents a different audio source. The Type
Icons on the right, in this case , represent folders, each containing further items. If there are more than three menu items,
you can scroll up or down to see the full list. The numbers in the center bottom of the display (2 / 5 in the example above)
show the number of the highlighted item and the total number of items in the current menu.
Note: Some item types, such as Musicmatch, Rhapsody and Windows Media Connect, may be available from more than
one PC on the network. To avoid confusion, the Network Name of the PC is included with the item name. In this example,
Musicmatch (MyPC) is a Musicmatch library stored the machine called MyPC.
Note: The computer name can be changed using the Windows Control Panel.
To select from any menu, press the key to highlight the item you want. The icon at the bottom right of the
screen means you can now press or to select the item.
Musicmatch (MyPC)
Dynamic Playlist
Internet Radio
SMCWAA-G
2/5
or
OK

6
User Guide
The name of the selected folder (in this case, Internet Radio) becomes the Screen Title of the next screen, which may look
like this:
This is almost the same as the Home Menu, but now the icon appears on the left, which means you can use the key to
go back to the previous (in this case, Home) menu screen.
From this screen, if you choose Genre, then choose Big Band from the next screen,all the available Big Band stations will be
listed and the Type Icon will change to the Radio Station/Playlist icon, , like this:
The new screen title is Big Band, there are now three stations to choose from and Radio Nostalgia is highlighted.
If you now press the (Play/Pause) button, Radio Nostalgia will start playing.
You can use the same method to browse albums and tracks in Musicmatch, Rhapsody or Windows Media Connect.
Notes:
1. The Type Icon for a single track is like this: .
2. If the Type Icon appears, this means you are not allowed to use this audio source, and you will need a password to
unlock it.
FINDING ITEMS IN LONG MENUS
For faster scrolling through a long menu, press-and-hold the key.
To search for items by initial letter, use the JUMP TO function. For example, to jump to the first item beginning with a ‘b’ (or
‘B’), press , , then . Part or whole words can be entered before pressing , to narrow the search.
Play Screens
While playing music, the screen shows the current date and time at the top, plus information about the music being played.
Note: The Date, Time, Time Zone and Date/Time display formats can all be set in the Configuration Mode)
When listening to an album track, the screen shows how long the track has been playing and its total length, both in minutes
and seconds (e.g. 02:17 / 03:45).
When listening to Internet Radio, only the connect time is displayed, in hours, minutes and seconds (e.g. 1:23:15).
My Favorites
Genres
Internet Radio
2/2
KCEA
Radio Nostalgia
Stay Tuned America
Big Band
2/3
or
22
,OK OK

7
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Here is a typical Play Screen display:
The icons to left and right of the display provide information about the network connection and the audio buffer level
respectively. The left-hand icon shows the signal strength as a vertical bar, when using a wireless LAN connection, or is just
the word LAN, if the SMCWAA-G is using wired ethernet. The buffer icon normally shows a full-height bar, indicating a full
buffer. The height of the bar may vary, but if it falls to zero, the connection will be lost, and you will have to connect again. This
should never happen with local sources (networked PCs), but some Internet Radio stations can be unreliable.
Notes:
1. Any station, album or track information that will not fit in the display width will scroll horizontally.
2. If scrolling stops, you can start it again by pressing the INFO key ( ) twice.
While the station is playing, the play icon ( ) is displayed, At any time, you can press the button to pause a track, or
mute a radio station. The pause icon (||) is then shown, until you press the button again or stop the track/station. To stop
a track, or disconnect a radio station, either press the stop key ( ) or select a new track/station.
You can adjust the playback volume with the increase ( ) and decrease ( ) keys. A horizontal bar display shows the
volume level as you are changing it, and returns a few seconds later to the Play Screen. You can switch the sound off, without
pausing a track or disconnecting a radio station, by pressing the Mute ( ) button. Press the Mute button again to switch the
sound on again.
Press the INFO key ( ) to return to last Select Screen, where you can prepare your next track or station, or press to
start again at the Home Menu. The current track/station will continue to play until the end, or until you select something else
(or change the active Profile). Press at any time to return to the Play Screen.
Note: For more features you can use while playing music, see Listening to Music on page 12.
Configuration Screens
When first powered up, and whenever you press the SYSTEM key ( ), the SMCWAA-G enters the Configuration Mode.
The top level Configuration Menu looks like this:
This mode uses Select screens in the same way as the Browse Mode. When an item is selected for reconfiguration, its
name becomes the title of the next menu screen and the icon appears on the left, to show that you can return to the
previous menu by pressing the key.
08-Jul-2005 15:02
Digitally Imported Mostly
Vivaldi – 4 Seasons
07:21
+-
Device Status
Internet Radio
Configuration Wizard
Configuration
2/7

8
User Guide
In Configuration Mode, Type Icons are only used after an item to show whether it is enabled ([*]) or disabled ([ ]). If you
select such an item (by pressing or ), you will be able to change its status and make any other settings required by the
new status. Sometimes you will have to select Yes or No from another menu screen, then return by pressing .
Edit Screens
The Edit Screen is used seen in the Configuration Mode.
The keypad on the remote control is used to enter text and numbers, and an icon under the text shows where the next
character will be inserted.
Editing is rather like sending a text message on a mobile phone. For example, repeated presses of the ‘2’ key, will scroll
through ‘2’, ‘a’, ‘b’, ‘c’, ‘A’, ‘B’ and ‘C’, so you will need to press three times to enter a ‘b’ (or six times for ‘B’). After a pause of
about 1 second, the icon moves right for you to enter the next character.
Special characters can be entered by repeated presses of the ‘0’ and ‘1’ keys, as follows:
The key moves the icon left, one character at a time, so you can go back and insert characters. If you make a mistake, use
the key to delete the character before the icon.
If you press when the icon is at the beginning of the line, this will cancel the edit, and return you to the previous screen.
When you have finished editing the line, press or , to accept the entry and move to the next screen.
This is a typical Edit Screen, where the Device Name is being edited.
Other Screens
Other screens may appear sometimes, to tell you what is happening. Some examples are actions that may take a few
seconds, such as saving settings, connecting to a radio station or restarting the device.
If an action is taking some time to complete, a rotating wheel icon ( ) will appear at the bottom of the screen.
Note: These displays are all temporary and are not interactive.
Installing the SMCWAA-G
Essential Information and System Setup
Check the following before you start installing the SMCWAA-G:
• If your wireless network uses encryption, you will need to know the WEP or WPA encryption key
• If you use a firewall, check it is correctly configured for the SMCWAA-G (see Firewall Settings on page 19)
0 * # _ (underscore) ~
1 . , ? ! - (hyphen) & <SPACE>
OK
0
1
OK
SMCWA
Change
Cancel OK

9
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
• If your AP has MAC filtering enabled, add the SMCWAA-G's MAC Address to the AP's Access Control List (ACL). This
unique 12-character identifier can be found on a label underneath the SMCWAA-G unit. It is also one of the items in the
Device Status display (see page 15). Please consult your AP documentation for help with this process.
Connecting the SMCWAA-G to the Network
• Insert the batteries into the remote control unit, observing the correct polarity
• Plug the power supply into a power outlet and the 9V DC power plug into the SMCWAA-G
• Connect the SMCWAA-G output to an audio system.
• If you wish to use a wired Ethernet link, connect an Ethernet cable to the SMCWAA-G.
Note: if you want to use a wireless link, you must not connect a wired ethernet cable to the SMCWAA-G
This photo shows the rear view of a SMCWAA-G,with (from left to right) two RCA audio connectors, a RJ45 wired Ethernet
socket, the reset point and the 9V DC power socket.
Installing the Music Library Software
With Music Library software, you can create a library of audio files on your PC, stored in MP3 or WMA formats. A UPnP
(Universal Plug and Play) Server allows your SMCWAA-G to browse through, and play, these files remotely from the PC,
using your Local Area Network (LAN).
Installing Musicmatch
Your SMCWAA-G comes with a CD that contains the Musicmatch Jukebox and UPnP Server programs.
Perform the following steps to install and set up Musicmatch:
1. Start the PC. Log in using an “Administrator” account, if using Windows 2000 or Windows XP. Otherwise you will not be
able to install any software
2. Insert the Installation CD and select the Install MUSICMATCH Jukebox option in the window that appears on your
desktop. If no window appears, browse the CD in Explorer and double-click on smc.exe.
3. When installation is complete, you will find a Musicmatch folder in your Program list under the Windows Start Menu and
the Musicmatch Jukebox icon ( ) on your desktop.
4. Start Musicmatch Jukebox,by double-clicking the icon or selecting Musicmatch Jukebox in the Start > All Programs >
Musicmatch folder.
5. Select Options, then Settings. Click on the CD Lookup/Connectivity tab and check the Enable Music Server and
Universal Plug and Play boxes, then click OK.
6. Musicmatch (My PC) should now appear as one of the items in the Home Menu.

10
User Guide
Notes:
1. Before you can use Musicmatch, you must put some files in the Library. See Setting up a Musicmatch Library on your PC
on page 12 or click Help in the Musicmatch Jukebox menu bar.
2. Your music library will be available using the SMCWAA-G, even when the Musicmatch Jukebox is not running.
Installing Rhapsody
Rhapsody is an online music service that gives you unlimited access to thousands of songs and albums, through the Internet
browser on your PC. Rhapsody brings together a large legal collection of digital music, selected Internet Radio stations,
flexible CD burning facilities, and detailed music information. To install Rhapsody:
1. Start the PC and log in as an “Administrator”, as above.
2. Ensure you have an active Internet connection, as files will be downloaded in the next step. It may also be necessary to
disable your firewall temporarily, to allow the download to take place.
3. Insert the Installation CD and select the Install Rhapsody option in the window that appears on your desktop. If no
window appears, browse the CD in Windows Explorer and double-click on smc.exe. Restart your PC, if requested.
4. When installation is complete, you will find a Rhapsody folder in your Program list under the Windows Start Menu and the
Rhapsody icon ( ) on your desktop.
5. Start Rhapsody,by double-clicking the icon or selecting Rhapsody in the Start > All Programs > Rhapsody folder.
6. Select Tools > Preferences, then highlight Rhapsody Server (UPnP) and check the Start UPnP Server once logged
in box. finally, click OK.
7. Rhapsody (MyPC) should now appear as one of the items in the Home Menu.
Note: Rhapsody is a premium subscription service.
Music Server Connection Problems
If any of the expected music server items is not displayed on the Home Menu, consult the section on Troubleshooting on
page 20 for possible causes and solutions.
Configuring the SMCWAA-G
For this procedure, you will need to use the Remote Control and the SMCWAA-G’s LCD display. Please read Using the
Remote Control on page 4 and Understanding the Operating Modes and Screen Displays on page 5 before proceeding.
Language Selection
1. When first connected, the SMCWAA-G will start in the Configuration Wizard.
2. Unless you prefer to work in French, Italian, German or Spanish, skip to step 4 below,
3. You can change the language (French, Italian, German or Spanish) using the menu item Select Language. Scroll up/
down to highlight your preferred language, then select it. All local screen messages will now be in the chosen language.
4. Scroll up/down to Configuration Wizard and select it. The Wizard starts with the message:
5. Press or to start the Wizard.
The Wizard Guides you
through the setup.
To begin press
Configuration Wizard
OK

11
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Using the Configuration Wizard (basic setup only)
The Configuration Wizard will prompt you to edit the essential settings.
SETTING UP AWIRELESS CONNECTION
If the SMCWAA-G detects an active wired Ethernet connection, it will only operate in the Wired Ethernet mode (see below). If
you want to use a wireless link, make sure the Ethernet cable is not connected before you apply power to the SMCWAA-G.
The Wizard will then search for available wireless networks. If it does not find any networks, a message No Networks Found
is displayed. Start your wireless network and press , then or , to rescan for networks. When at least one network has
been found, the Configuration Wizard will ask you to enter the following details:.
1. Select Network
The SSIDs (Service Set IDentifiers) of all wireless networks found at startup will be displayed in the Select Screen,
together with options to Enter Network SSID and Rescan Network. For a basic setup, ignore these, and select the SSID
you want to use.
2. Enter Encryption Key
If the SSID name you select included the word [encrypted], the next screen will prompt you to enter the key for your
network. Otherwise you will go directly to the following prompt:
3. Network IP Settings
Choose Automatic (DHCP),unless you have a reason to assign a fixed IP address to your SMCWAA-G.
If so, see Changing Network Settings on page 16.
4. Enable Proxy Server
Choose No if your network does not use a proxy server. Otherwise, choose Yes, and enter details under Edit Proxy
Hostname and Edit Proxy Port.
5. Apply Settings?
When all settings have been made, the message Apply Settings? will be displayed. You can then save or discard all
changes, using the (save) or (discard) buttons.
For full instructions, see Advanced Configuration Management on page 14.
Standby and Restart
When you have finished using the SMCWAA-G, press the Standby button ( ). The display will become blank and the
device will remain in a standby state, consuming virtually no power, until you press again.
If you need to restart the device, for example, if the wireless link is lost, press and hold the Standby button until the display
Restart Device appears.
Using the SMCWAA-G
If you see the device name, which is factory-set to SMCWAA-G, displayed at the top of the screen, you are ready to listen to
Internet Radio and your PC-based music files. Note: you can change the device name, see Edit Device Name on page 14.
From the Home Menu, you can:
1. find music stored on a PC, or elsewhere on your local network;
2. find online music, using a streaming service, such as Rhapsody;
3. select Internet Radio Stations available through the vTuner service.
To enter the Home Menu, press on your remote control at any time.
Please refer back to Understanding the Operating Modes and Screen Displays on page 5, for instructions on using the
Remote Control to select albums, tracks and Radio Stations.
OK

12
User Guide
In the Home Menu, scroll up/down to find the source you want, then browse to the album, track or station that you want. If you
cannot find all your sources, see Troubleshooting on page 20.
Note: The menu trees for the user modes are on pages 22, 26 and 27.
Listening to Music
Selecting and Playing Music
If you select a music server item from the Home Menu, you can browse through Select Screens by various categories,
depending on the server you are using. Typical categories are:
Albums, All Tracks, Artists, Artists/Albums, Genres, Genres/Artists and Playlists.
Note: Rhapsody also offers a selection of Internet Radio Stations.
When you see the Play icon ( ) to the right of an item you can press to listen to it.
The basic key functions were described earlier under Play Screens on page 6, but you can also skip, REPEAT and SHUFFLE
tracks. This table shows all the features you can use in Play Mode:
Setting up a Musicmatch Library on your PC
Before you can use the SMCWAA-G to browse and play music files (in MP3 or WMA formats) from your PC, you need to add
them to your Musicmatch Jukebox Music Library.
Basic instructions for building a library are given below. Please read the Musicmatch Jukebox Help to learn about all the
available features, and how to use them.
1. Load music files on your PC and note the folder name(s) where they are stored
2. Start the Musicmatch program by clicking on the Musicmatch Jukebox desktop icon: .
3. If the Library is not already open click the My Library button.
4. Click the Add to Library button.
5. Locate the folder on your hard disk noted in step 1 and select the music files to be added to the Music Library. Click the
Add button to add the files to the Music Library, then click Exit.
Note: The Musicmatch server is always running, even after you have closed the Musicmatch application.
Listening to Internet Radio Stations
The SMCWAA-G comes with a pre-installed evaluation version of the vTuner Internet Radio service. Select Internet Radio
from the Home Menu, then select a station by browsing through the displayed categories.
Key Function Screen Icon
Play/Pause the highlighted item or
Stop playing the current item (none)
INFOrmation key: switch between Play and Select Screens (none)
Skip to the next track, or hold for 2+ seconds to fast forward the current track (none)
Skip to the previous track (if available) (none)
REPEAT the track currently playing. Press again to REPEAT ALL tracks and again to cancel repeating or
Play items in SHUFFLEd (random) order. Press again to play in normal order.
Note: Shuffle can be used with REPEAT ALL (above) to repeat-play a whole album in random order

13
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
The available categories will depend on the level of service you have installed, but will include items like: My Favorites,
Genres, Countries, New Stations, Popular Stations and Help.
To store station names in My Favorites, log on to the website shown in the first item of the Help Menu, and register the
SMCWAA-G, using the ID number in the second item - which is also the MAC Address of the SMCWAA-G. You will need to
register by entering your email address and a password of at least 6 characters. Then you can start to build up a set of My
Favorites, sorted into user-defined Groups. This list can be automatically downloaded to your SMCWAA-G every day, or you
can update it manually at any time (see Internet Radio on page 15).
More information about vTuner is available by following the other two items in the Help Menu.
When you see the Playlist/Radio icon (e.g. Radio XYZ ), you can highlight the item and press the Play/Pause button
( ) to connect to the station. During the connection process, a rotating wheel icon will appear in the center bottom of the
display. If the station is unavailable, the message Station down will appear after a while. Try again later!
Press to temporarily mute the station, and again to resume listening. Press to disconnect. As above, can be
used to switch between Station/track information and an Internet Radio Station Select Screen.
Using Presets and Favorites
There are two features of the SMCWAA-G that allow you to find your favorite Internet Radio stations, albums, artist lists,
playlists or tracks (all are just called ‘tracks’, below) quickly:
1. You can save up to 10 tracks as Presets, for instant access by pressing one of the number keys to .
2. You can also save up to 20 additional tracks in a Dynamic Playlist.
Saving a Track to a Preset Number
Select a track in the normal way, and check that it is active by playing it. Now press the PRESET button ( ), followed the
number key you want to use to play the track (e.g. ). The message ‘Preset stored at 2’ will appear briefly. To change a
preset, simply preset a different track to the same key.
Playing a Preset Item
At any time, simply press the relevant number button and the preset track will play.
Saving a Track to the Dynamic Playlist
To save a track in the Dynamic Playlist, first start the track, then press the (UN)MARK button ( ). A message ‘Favorite
added’ appears briefly on the screen, or ‘Item already exists’,if you try to save the same track twice.
Note: If you try to store more than 20 items in the Dynamic Playlist, a ‘List Full’ message appears on the screen, and you
must then remove at least one item before adding any more.
Selecting and Playing Favorites from the Dynamic Playlist
At any time, simply press the Playlist button ( ) to display the playlist of up to 20 s. Then Scroll up/down to highlight the
track you want to hear, and press the button to play it.
Replacing Favorites on the Dynamic Playlist
To remove a track from the playlist, first start it playing, then press the (UN)MARK button ( ). A message Favorite
removed will appear briefly on the screen. You can then play a new track and store it by pressing
0 9
2

14
User Guide
Advanced Configuration Management
There are two ways to change the setup of the SMCWAA-G. You can use the Remote Control and the LCD display or you can
use the SMCWAA-G PC Utility running on any PC that can communicate with the SMCWAA-G.
Note: The menu tree structures for the Remote Control method are shown on pages 23 and 24.
With just five exceptions, all configuration settings can be changed by either method. The exceptions are:
1. Selecting a Language (Remote Control only)
2. Setting Date & Time information and formats (Remote Control only)
3. Changing Internet Radio list settings (Remote Control only) and
4. Uploading new firmware (SMCWAA-G PC Utility only).
5. Changing the name of a Profile (SMCWAA-G PC Utility only).
Note: The SMCWAA-G PC Utility cannot be used until the SMCWAA-G has been set up, using the Remote Control, as
described in Configuring the SMCWAA-G on page 10.
Simple tasks, not requiring much editing of text or numbers, can easily be done with the remote control, but the SMCWAA-G
PC Utility is better for editing text and numbers, as it uses the PC’s keyboard and screen.
Method 1: Using the Remote Control
To enter Configuration Mode, press the SYSTEM key ( ) on the remote control to display the Configuration Menu, which
contains some or all of the following items, depending on settings:
Select Language
Scroll up/down to the Select Language item, and select it. Scroll up/down to highlight your language, then select it. All future
screen messages will then be displayed in that language. Note: The display language cannot be set by the SMCWAA-G PC
Utility.
Advanced Settings
This menu contains three items:
PROFILE MANAGEMENT
If this item is followed by an asterisk in brackets, [*], Profile Management is enabled. If there is a blank space between the
brackets, [ ], it is disabled.
To change, select the Profile Management menu , select Enabled or Disabled as required, then return to the Advanced
Settings menu by pressing .
KEY MANAGEMENT
This operates in the same way as Profile Management, and must be enabled if more than one Encryption Key is needed.
Note: Key Management is always available when using the SMCWAA-G PC Utility.
EDIT DEVICE NAME
The default name is SMCWAA-G. If Profile Management is enabled, you can enter your own names for any of the three
available profiles, initially called Profile1, Profile 2 & Profile 3. Select Edit Device Name, then select Change from the next
menu. Edit the name, press , then return to the Advanced Settings menu (i.e. press ).
Note: The device name can also be changed using the SMCWAA-G PC Utility (see Editing a Network Profile on page 18).
OK

15
SMCWAA-G EZ-Stream™ 802.11g
Wireless Audio Adapter
Configure Date/Time
The date and time formats can be set by selecting this menu . First the Select Time Zone menu offers a choice of 32 standard
zones, then Daylight Saving can be enabled or disabled and, finally, the Select Time Format menu offers 5 display formats
for the date and time, which are obtained automatically from the Internet.
Select Profile
If Profile Management is enabled, the Select Profile item will be seen. It can be used to change the active Profile. The
active profile is identified by an asterisk ( [*] ). To change profile, simply highlight the new profile and select it.The SMCWAA-
G will then display the message Restart Device while the new Profile is being activated.
Device Status
Select this useful item to scroll up/down through a list of all settings in the active Profile. This is pure information – nothing
can be changed while scrolling through this .
Internet Radio
Using an Internet login account, you can set up personalized radio favorite lists with your web browser and either have them
downloaded daily to your SMCWAA-G automatically, or download manually, whenever you want.
The three items in this menu allows you to:
1. Show the Radio List Version currently installed on the SMCWAA-G,
2. Enable/Disable Automatic Update (using the [*] and [ ] icons) and
3. Start a Manual Update immediately
Note: The Internet Radio options cannot be set using the SMCWAA-G PC Utility.
Configuration Wizard
The SMCWAA-G Configuration Wizard guides you through the process of configuring network profiles. It is used when you
want to use the remote control to:
• Install the SMCWAA-G for the first time (see Configuring the SMCWAA-G on page 10)
• Make changes to your network profile settings or
• Explore the more advanced options offered by the SMCWAA-G.
Network Information Needed by the Configuration Wizard
The Configuration Wizard guides you through the setup process, prompting you to select or edit all the settings for any of
the available SMCWAA-G Profiles.
Notes:
1. The SMCWAA-G determines some settings automatically during its search for available networks. Therefore it may not
need to prompt you for all of settings during the process described below.
2. You can leave the Configuration Wizard at any time by pressing again. You will then be asked to confirm that you
want to exit the Wizard and discard all changes.
Configuration Wizard Menu
STARTING THE CONFIGURATION WIZARD
The Configuration Wizard will start automatically the first time you power up your SMCWAA-G.
To start the Configuration Wizard at a later time:
1. Press to display the Configuration menu.

16
User Guide
2. Scroll up/down until Configuration Wizard is highlighted, and select it. When the introductory message appears (see
page 10), press to go to the next screen and begin the setup process.
Notes:
1. This process requires you to know some technical details of how your network is set up. If you are unsure of any of the
settings, consult the person who set up your network, or refer to the appropriate network documentation.
2. Please refer back to Edit Screens on page 8 for instructions on entering and changing text and numbers, using the
Remote Control.
Changing Network Settings
SELECTING APROFILE
If Profile Management is enabled, you will be prompted to Load Profile. Select one of the three Profiles for editing. Their
default names are Profile 1, Profile 2 and Profile 3, but they can be renamed, using the SMCWAA-G PC Utility. If Profile
Management is disabled, the Wizard will start at the next item.
SELECTING AWIRELESS NETWORK
At the Select Network menu, follow these steps to select the SSID for the wireless network profile you are editing:
1. If more than one wireless network is available, scroll up/down and select the SSID you want to use.
1. If the SSID is followed by ‘(encrypted)’, you will be asked to accept ( ) or change the WEP or WPA encryption key. For
security reasons, the current key will be shown as a row of asterisks, ***************.
2. If you want to set up a network that is not currently active, select Edit Network SSID and enter a new SSID, which must
contain between 2 and 32 alphanumeric, case-sensitive characters.
3. Press when you have finished setting the SSID.
SELECTING ANETWORK TYPE
If you have used Edit Network SSID, the Select Network Type menu will appear. Always select Infrastructure, as you
should be using your SMCWAA-G with a wireless Access Point (AP) or a wireless router. The Ad-hoc mode is not currently
supported.
SELECTING ENCRYPTION SETTINGS
If you see the Select Encryption menu, select:
•No if encryption is not used on the wireless network or
•WEP or WPA,if encryption is used.
If you select WEP or WPA, and Key Management is disabled, you will be prompted to Enter Key1.
If Key Management is enabled, you will see the Select Key Index menu and you must select one of the four possible keys
for editing. If a key already exists in the current profile, a row of asterisks (*******) will be displayed in place of the key value.
As you enter the key, the Key Type and Key Length will be displayed in the top of the screen, based on what you have
entered: i.e. ASCII or Hex, 64 bit or 128 bit. Press OK, then select Exit Key Editing and select the required key if you see
the Select Key menu.
SELECTING NETWORK IP SETTINGS
At the Network IP Settings menu, choose Automatic (DHCP) if your network uses DHCP or Static IP Address, if you want
to assign a fixed IP address for your SMCWAA-G.
If you choose Static IP Address, you will be prompted to edit/confirm the IP Address of the SMCWAA-G, the Subnet Mask,
the Gateway, the DNS Server Preferred and (optionally) the DNS Server Alternate.
OK
OK
