SMC Networks 2671W User manual

38 Tesla
Irvine, CA 92618
Phone: [phone]
EZ Connect
TM
2.4 GHz
Wireless Ethernet Adapter
User Guide
From SMC’s EZ line of low-cost workgroup LAN solutions
October 2003
150000030200E R01 F1.0

Copyright
Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.
However, no responsibility is assumed by SMC for its use, nor for any infringements of patents
or other rights of third parties which may result from its use. No license is granted by
implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to
change specifications at any time without notice.
Copyright © 2003 by
SMC Networks, Inc.
38 Tesla
Irvine, CA 92618
All rights reserved.
Trademarks:
SMC is a registered trademark; and EZ Connect is a trademark of SMC Networks, Inc. Other
product and company names are trademarks or registered trademarks of their respective
holders.

i
C OMPLIANCES
FCC - Class B
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
FCC Caution: To assure continued compliance, (example - use only shielded
interface cables when connecting to computer or peripheral devices) any changes
or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement
FCC Radiation Exposure Statement: This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with a minimum distance of 20 centimeters (8 inches)
between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the interference-causing equipment standard
entitled “Digital Apparatus,” ICES-003 of the Department of Communications.

C OMPLIANCES
ii
Cet appareil numérique respecte les limites de bruits radioélectriques applicables
aux appareils numériques de Classe B prescrites dans la norme sur le matériel
brouilleur: “Appareils Numériques,” NMB-003 édictée par le ministère des
Communications.
EC Conformance Declaration - Class B
SMC contact for these products in Europe is:
SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8, 2o, 4a,
08970 - Sant Joan Despí,
Barcelona, Spain.
This information technology equipment complies with the requirements of the
R&TTE Directive 99/5/EC as well as the Council Directive 89/336/EEC on the
Approximation of the laws of the Member States relating to Electromagnetic
Compatibility and 73/23/EEC for electrical equipment used within certain voltage
limits and the Amendment Directive 93/68/EEC. For the evaluation of the
compliance with these Directives, the following standards were applied:
RFI
Emission: • Limit class B according to EN 55022:1998, IEC 60601-1-2 (EMC,
medical)
• Limit class B for harmonic current emission according to EN 61000-3-2/
1995
• Limitation of voltage fluctuation and flicker in low-voltage supply system
according to EN 61000-3-3/1995
Immunity: • Product family standard according to EN 55024:1998
• Electrostatic Discharge according to EN 61000-4-2:1995
(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)
• Radio-frequency electromagnetic field according to EN 61000-4-3:1996
(80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)
• Electrical fast transient/burst according to EN 61000-4-4:1995 (AC/DC
power supply: ±1 kV, Data/Signal lines: ±0.5 kV)
• Surge immunity test according to EN 61000-4-5:1995
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)
• Immunity to conducted disturbances, Induced by radio-frequency fields:
EN 61000-4-6:1996 (0.15 - 80 MHz with
1 kHz AM 80% Modulation: 3 V/m)
• Power frequency magnetic field immunity test according to
EN 61000-4-8:1993 (1 A/m at frequency 50 Hz)
• Voltage dips, short interruptions and voltage variations immunity test
according to EN 61000-4-11:1994 (>95% Reduction @10 ms, 30%
Reduction @500 ms, >95% Reduction @5000 ms)
LVD: • EN 60950 (A1/1992; A2/1993; A3/1993; A4/1995; A11/1997)
MDD: • IEC 60601-1

C OMPLIANCES
iii
Safety Compliance
Underwriters Laboratories Compliance Statement
Important! Before making connections, make sure you have the correct cord set.
Check it (read the label on the cable) against the following:
The unit automatically matches the connected input voltage. Therefore, no
additional adjustments are necessary when connecting it to any input voltage
within the range marked on the power adapter.
Operating Voltage Cord Set Specifications
120 Volts UL Listed/CSA Certified Cord Set
Minimum 18 AWG
Type SVT or SJT three conductor cord
Maximum length of 15 feet
Parallel blade, grounding type attachment plug
rated 15 A, 125 V
240 Volts (Europe only) Cord Set with H05VV-F cord having three
conductors with minimum diameter of 0.75 mm2
IEC-320 receptacle
Male plug rated 10 A, 250 V

C OMPLIANCES
iv
Wichtige Sicherheitshinweise (Germany)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie
keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes
Tuch zur Reinigung.
4. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht
zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen
oder Fallen könnte Beschädigungen hervorrufen.
7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor
Überhitzung schützt. Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt
werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann.
Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es
vom Stromnetz trennen. Somit wird im Falle einer Überspannung eine
Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten
in das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag
auslösen.
13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen
und von einer qualifizierten Servicestelle zu überprüfen:
a.Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d.Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert
oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
e.Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. Stellen Sie sicher, daß die Stromversorgung dieses Gerätes nach der EN
60950 geprüft ist. Ausgangswerte der Stromversorgung sollten die Werte von
AC 7,5-8 V, 50-60 Hz nicht über oder unterschreiten sowie den minimalen
Strom von 1 A nicht unterschreiten.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt
70 dB(A) oder weniger.

v
T ABLE OF C ONTENTS
EZ Connect™ 2.4 GHz Wireless Ethernet
Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Package Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hardware Description . . . . . . . . . . . . . . . . . . . . . . . 3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . 7
System Configuration . . . . . . . . . . . . . . . . . . . . . . . 8
EZ Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . 9
Using IPCONFIG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Utility Installation and Configuration . . . . . . . . . 11
Using the Configuration Utility . . . . . . . . . . . . . . . . . . . . . . 12
Utility Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IP Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Statistic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Wireless Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Configuring Your IP Address . . . . . . . . . . . . . . . . 25
Windows 98/Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

T ABLE OF C ONTENTS
vi
Web Management . . . . . . . . . . . . . . . . . . . . . . . . .33
Browser Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Disable Proxy Connection . . . . . . . . . . . . . . . . . . . . . . . 33
Internet Explorer (5.5 or above) in Microsoft Windows . 33
Internet Explorer in Macintosh . . . . . . . . . . . . . . . . . . . . 33
Navigating the Web Browser Interface . . . . . . . . . . . . . . . 34
Making Configuration Changes . . . . . . . . . . . . . . . . . . . 34
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
MAC Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Network Configuration and Planning . . . . . . . . .52
Network Topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Ad Hoc Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Infrastructure Wireless LAN . . . . . . . . . . . . . . . . . . . . . . 53
Infrastructure Wireless LAN for Roaming Wireless
PCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
A Wireless LAN with Internet Access . . . . . . . . . . . . . . . 55
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .56
SMC Networks 802.11b Wireless Product
Maximum Distance Table . . . . . . . . . . . . . . . . . . . . . . . . . 57
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

1
EZ C ONNECT
™
2.4 GH Z
W IRELESS E THERNET A DAPTER
Introduction
SMC’s EZ Connect 2.4 GHz Wireless Ethernet Adapter
(SMC2671W) can function as:
•an Ethernet adapter, providing a wireless connection via an
RJ-45 connection to devices such as Microsoft Xbox and
Ethernet ready embedded devices
•a standard IEEE 802.11b access point
•a wireless range extender, allowing you to effectively extend
the coverage of another SMC2671W that is configured to
operate in Access Point mode
This solution offers fast, reliable wireless connectivity with
considerable cost savings over wired LANs (eliminates long-term
maintenance overhead for cabling). Just install enough wireless
access points to cover your network area, plug wireless cards into
your notebooks or install wireless adapters into your desktops,
and start networking.
Use this device in conjunction with SMC’s EZ Connect Wireless
Cards to create an instant network that integrates seamlessly
with Ethernet LANs. Moreover, moving or expanding your network
is as easy as moving or installing additional access points – no
wires!

EZ C ONNECT ™ 2.4 GH Z W IRELESS E THERNET A DAPTER
2
Package Checklist
The EZ Connect 2.4 GHz Wireless Ethernet Adapter package
includes:
•One EZ Connect 2.4 GHz Wireless Ethernet Adapter
(SMC2671W)
•One 5 VDC power adapter
•Installation CD containing this User Guide, EZ Installation
Wizard, and Utility program
•One RJ-45 cable
Please register this product and upgrade the product warranty on
SMC’s web site at http://www.smc.com
Inform your dealer if there are any incorrect, missing, or damaged
parts. If possible, retain the carton, including the original packing
materials. Use them again to repack the product in case there is a
need to return it.

3
H ARDWARE D ESCRIPTION
The Wireless Ethernet Adapter supports 1, 2, 5.5 and 11 Mbps
half-duplex connections to Ethernet networks. This device is fully
compliant with 2.4 GHz DSSS CSMA/CA wireless networking as
defined in IEEE 802.11b. It can be connected via an RJ-45
connection to devices such as Nintendo GameCube, Microsoft
Xbox, Sony PlayStation II, and Ethernet ready embedded
devices. It can also function as an IEEE 802.11b Access Point or
as a Range Extender (see “Introduction” on page 1).
Figure 1. Rear Panel
Note: If you use the RELOAD button at the bottom, the Wireless
Ethernet Adapter performs a power reset. If the button is
held depressed for over 5 seconds, all the LEDs will
illuminate and the factory settings will be restored.
Item Description
Power Inlet Connect the included power adapter to this inlet.
Warning: Using the wrong type of power adapter may damage
your adapter.
LAN Port Fast Ethernet port (RJ-45). Connect device (such as a PC, hub
or switch) on your local area network to this port.
MDI/MDIX
Switch Press down the switch to connect to a network device with a straight-through twisted-pair cable; otherwise, connect to the
network device with (MDI-X) station ports at both ends by suing
crossover cabling.
Power Connector
RJ-45 Port
MDI/MDIX Switch

H ARDWARE D ESCRIPTION
4
Applications
EZ Connect wireless products offer a fast, reliable, cost-effective
solution for wireless Ethernet client access to the network in
applications such as:
• Video Game Systems
Provides wireless Internet access for users of video game
systems such as Nintendo GameCube, Microsoft Xbox and
Sony PlayStation II
• Remote access to corporate network information
E-mail, file transfer, and terminal emulation
• Difficult-to-wire environments
Historical or old buildings, asbestos installations, and open
areas where wiring is difficult to employ
• Frequently changing environments
Retailers, manufacturers, and banks which frequently
rearrange the workplace or change locations
• Temporary LANs for special projects or peak periods
Trade shows, exhibitions, and construction sites that need a
temporary setup. Retailers, airline, and shipping companies
that need additional workstations for peak periods. Auditors
who require workgroups at customer sites
• Access to databases for mobile workers
Doctors, nurses, retailers, or white-collar workers who need
access to databases while being mobile in a hospital, retail
store, in an office, or on a campus
• SOHO users
SOHO (Small Office and Home Office) users who need easy
and quick installation of a small computer network

LED I NDICATORS
5
LED Indicators
The Wireless Ethernet Adapter includes three status LED
indicators, as described in the following figure and table.
Figure 2. Front Panel
LED Status Description
Wireless
Link TX/RX Flashing (Green) The device is transmitting or receiving data through wireless links.
Ethernet
Status LNK/ ACT On (Orange) The device has established a valid 10Mbps Ethernet link.
On (Green) The device has established a valid
100Mbps Ethernet link.
Flashing The device is transmitting or receiving
data on the Ethernet LAN
Power (PWR) On (Red) Power is being supplied.

H ARDWARE D ESCRIPTION
6
System Requirements
Before you install the Wireless Ethernet Adapter, be sure you
have met the following requirements:
•An AC power outlet (100~240 V, 50~60 Hz)
•An available RJ-45 (UTP) port on an Ethernet hub or switch
•802.11b compliant wireless Ethernet adapters with TCP/IP
protocols installed
•TCP/IP network protocol installed on each PC that needs to
access the Internet.
•A web browser, such as Microsoft Internet Explorer 5.5 or
above installed on one PC at your site for configuring the
Wireless Ethernet Adapter.

7
H ARDWARE I NSTALLATION
1. Select the Site – Choose a location for your Wireless Ethernet
Adapter. Usually, the best location is at the center of your
wireless coverage area, if possible within line-of-sight of all
wireless devices.
2. Place the Wireless Ethernet Adapter in a position that gives it
maximum coverage. Normally, the higher you place the
antenna, the better the performance.
3. Position the antennas in the desired positions. For more
effective coverage, position the antennas along different axes.
For example, try positioning the antennas around 45 to 90
degress apart. (The antennas emit signals along the
toroidal plane – and thus provide more effective
coverage when positioned along different axes.)
4. If used in Ethernet Adapter mode, connect the Ethernet cable
to the RJ-45 socket of the device will communicate wirelessly
with an access point.
5. If used in Acces Point, connect the Ethernet cable – The
SMC2671W can be wired to an Ethernet network through an
Ethernet device such as a hub or a switch using category 3, 4,
or 5 UTP Ethernet cable and an RJ-45 connector. (See
“Hardware Description” on page 3 for MDI/MDI-X cabling.)
6. Connect the power cable – Connect the power adapter cable
to the 5 VDC power socket on the rear panel.
Warning: Use only the power adapter supplied with the
SMC2671W.

8
S YSTEM C ONFIGURATION
The SMC2671W is a Plug-and-Play device. This means that, in
most cases, you will not need to configure it.
The SMC2671W Wireless Ethernet Adapter includes an SNMP
agent that is accessible through an SNMP manager application
(Refer to “Using the Configuration Utility” on page 12.) The latest
version may be downloaded from the SMC web site specified on
the back cover of this manual.
The SMC2671W can be configured by a web browser, which is
Internet Explorer 5.5 or above. Using the web management
interface, you can configure the Wireless Ethernet Adapter and
view statistics to monitor network activity.
Before you attempt to log into the SMC2671W’s web-based
administration, please verify the following.
1. Your browser is configured properly (see below).
2. Disable any firewall or security software that may be running.
3. Confirm that you have a good link LED where your computer
is plugged into the Wireless Ethernet Adapter. If you don’t
have a link light – then try another cable to get a good link.
4. To access the Internet through the Wireless Ethernet Adapter,
you must configure the network settings of the computers on
your LAN to use the same IP subnet as the Wireless Ethernet
Adapter. The default network settings for the Wireless
Ethernet Adapter are:
Gateway IP Address: 192.168.2.1
Subnet Mask: 255.255.255.0
SMC2671W IP Address: 192.168.2.25

9
EZ I NSTALLATION W IZARD
To configure your SMC2671W, first verify that your computer has
an IP address in the same address scheme as the SMC2671W. If
you are not familiar with this procedure, see the “Using
IPCONFIG” section below.
Note: The default IP address of the SMC2671W is 192.168.2.25.
1. Insert the SMC EZ Installation Wizard & Documentation CD
into your CD-ROM drive.
2. The EZ Installation Wizard will appear. Click “Configuration
Utility” to begin the utility installation and setup process.

EZ I NSTALLATION W IZARD
10
Using IPCONFIG
1. Click the “Start” button, click “Run” and type “command.”
2. Press “OK” and a black command prompt will appear.
3. Type “ipconfig” and press enter.
4. Verify that your IP Address is 192.168.2.xxx. If so, you can
now use the SMC EZ Installation Wizard to configure your
SMC2671W. If your IP Address is completely different, please
go to the “Configuring Your IP Address” on page 25.
