SMC Networks SMC-BT10 EZ Connect User manual

Wireless SMC-BT10
EZ ConnectTM Wireless Bluetooth USB Adapter
www.smc.com
The EZ Connect™ Wireless Bluetooth USB Adapter (SMC-
BT10) is another cutting edge wireless technology brought
to you by SMC. The SMC Wireless Bluetooth USB Adapter
allows your USB PC or notebook to work with all Bluetooth
devices.
Simply plug in your SMC-BT10 Wireless Bluetooth USB
Adapter into the USB port on your laptop or desktop.
Bluetooth technology allows you to communicate with
other Bluetooth devices to wirelessly share files, transfer
data, print, synchronize your PDA information, send and
receive email, browse the web, and use a mobile phone to
access the Internet. The SMC Wireless Bluetooth USB
Adapter supports Class 2 Bluetooth and has a operating
range of up to 30 feet.
Connect with up to seven other Bluetooth devices at the
same time, the SMC Wireless Bluetooth USB Adapter sup-
ports encryption and authentication to ensure secure data
transmission across the network. The EZ Connect™
Wireless Bluetooth USB Adapter includes an EZ Installation
Wizard that enables quick and easy setup. Simply put the
EZ Installation Wizard CD into your CD drive, and click on
the Install Driver/Utility Link. The wizard will perform the
installation automatically. Then plug in your SMC-BT10 into
the USB slot of your laptop or PC, and you will be ready to
enjoy the freedom of wireless Bluetooth networking. The
new product instantly creates a Personal Area Network
(PAN) connecting your PC or laptop to nearby Bluetooth-
enabled devices. The SMC Wireless Bluetooth USB Adapter
brings you a new level of experience in available, reliable,
and cost-effective wireless networking!
FEATURES
EZ Installation Wizard
Bluetooth v1.2 compliance
Class 2 Bluetooth Support
Sleek and compact
Connect up to 7 different Bluetooth-enabled devices
Encryption and authentication ensure safe, secure communications
Supports Windows 98SE, ME, 2000, XP and Mac OS 10.2.x and above
Setup is simple and easy with EZ Installation Wizard
Adds latest Bluetooth technology to your existing PC or notebook.
Works with all Bluetooth-enabled devices to wirelessly share files,
print, synchronize your PDA information, and use a mobile phone to
access the Internet
Allows for operating range at up to 30 feet
Compact, easy to carry form factor
Instantly create your Personal Area Network (PAN)
Encryption link and authentication protect your information and
ensure secure data transmissions
Works with major operating systems
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMC-BT10
STANDARDS
• Bluetooth™ specification v1.2
• USB v1.1, 2.0
INTERFACE
• USB (Type A)
RADIO
• Class 2 Bluetooth
LINK MODE
• ACL, eSCO (Extended Synchronous Connection-Oriented)
DATA RATES
• Asynchronous: 723.2kbps / 57.6kbps
• Synchronous: 433.9kbps / 433.9kbps
FREQUENCY BAND
• 2.4GHz
MODULATION
• GFSK (Gaussian Frequency Shift Keying)
SPECTRUM
• AFH (Adaptive Frequency Hopping)
ANTENNA TYPE
• Internal
RECEIVER SIGNAL RANGE
• Better than -76dBm @0.1%BER
RF OUTPUT POWER
• -6~+4dBm (Max +6 dBm)
OPERATION CURRENT
• < 80mA(max)
OPERATING DISTANCE
• Up to 30 feet
• Up to 9 m
SECURITY
• Pairing, Encryption, Authentication
COMPATIBLE OS
• Microsoft Windows 98 SE/2000//ME/XP,
Mac OS v10.2 and higher
BLUETOOTH SOFTWARE SUPPORT
• PAN, DUN, SPP, LAN, FTP, Synchronization,
OBEX, HCRP, HID, FAX, BIP, AV, HS
OPERATION TEMPERATURE
• -40 - 850C
STORAGE TEMPERATURE
• -40 - 1050C
REGULATORY COMPLIANCE
•FCC
• ETSI
• Industry Canada
DIMENSION
• 46 x 19 x 10 mm
• 1.8 x .75 x .40 in
WEIGHT
• 0.02 lbs
•9 g
